rada OnyxCam A-TC02 User manual

A-TC02
OnyxCam
USER MANUAL
Adena Limited 2022
www.a-dena.com

This manual provides information relevant to the installation of the A-TC02 OnyxCam,
as well as its functions and control methods in details. Please read this manual careful-
ly before installing and using the camera.
Precautions
To avoid damage to the camera, please only use this product in the specified conditions
and observe the following precautions:
1) Do not expose the camera and its components/accessories to rain or moisture.
2) Due to the risk of electric shock, do not open the camera’s casing. Installation and
maintenance of the device should only be carried out by qualified technicians.
3) Do not use the product beyond the temperature, humidity or power supply specifica-
tions stated in this user manual.
4) Please use a soft, dry cloth to clean the camera. If the camera is very dirty, clean it
with a diluted neutral detergent; Using any type of solvents may damage the surface of
the camera, thus you should not use them.
Electrical Safety
Installation and use of this product must strictly comply with the local electrical safety
standards.
Transportation
Avoid any stress, vibration, or moisture during transportation, storage, installation and
operation of the camera.
1

Installation
1) Do not rotate the camera head violently. Doing otherwise may cause mechanical
failure.
2) This camera is designed to be placed on a stable, horizontal surface. Do not install the
camera at
3) This product should be placed on a stable desktop or other horizontal surface. Do not
install the product at an angle, otherwise your camera’s image will be inclined;
4) Ensure there are no obstacles within the camera holder’s rotation range.
5) Do not power on before completing the camera’s installation.
Do Not Dismantle Camera
ADENA Limited is not responsible for any unauthorized modification or changes in the
camera’s behavior produced by dismantling of the product. Unauthorized dismantling of
the product will nullify your camera’s warranty.
Magnetic Interference
Electromagnetic fields at specific frequencies may affect the video image produced by
the camera. This is a Class A product; it may cause radio interference in domestic envi-
ronment. If used in such environment, please take this into account and apply appropriate
measures.
2

Table of Contents
1. Quick Installation Guide 5
1.1 Interface 5
1.2 Connection Diagram 6
1.3 Mounting Brackets 7
1.3.1 Wall Mount 7
1.3.2 Ceiling Mount 8
2. Product Overview 10
2.1 Dimensions 10
2.2 Accessories 10
2.3 RS-232 11
2.4 Rotary Dial 13
2.5 Product Features 13
2.6 Technical Specification 15
3. Remote Control Functions 19
3.1 IR Remote Control Keys and Commands 19
3.2 IR Remote Control Key Combinations 20
3.3 OSD Menu 21
4. Web interface and settings 22
4.1 Accessing the Web Interface 22
4.2 Web Interface Introduction 22
4.3 Configuration – Streaming 23
4.4 Configuration – Firmware Update 25
4.5 Monocular Tracking - Tracking Settings 26
5. Serial Port Communication Port 27
5.1 VISCA 27
5.1.1 VISCA Protocol List 27
5.1.2 Camera Control Command 28
5.1.3 Inquiry Command 39
................................................................................................
....................................................................................................................
.............................................................................................................
................................................................................................................
...................
.............
.........................................................................................................................
.....................................................................................................................
...............................................................................................................................
............................................................................................................................
...........................................................................................................................
....................................................................................................................................
.............................................................................................................................
..................................................................................................................
........................................................................................................
................................................................................................................
..........................................................................
...............................................................................
........................................................................................................................... ...
...............................................................................................................
..............................................................................................
.................................................................................................
..................................................................................................
......................................................................................
...........................................................................
.....................................................................................................
.....................................................................................................................................
...................................................................................................
........................................................................................
.......................................................................................................
3

5.2 Pelco-D Protocol Command List 44
5.3 Pelco-P Protocol Command List 45
6. Maintenance and Troubleshooting 46
6.1 Camera Maintenance 46
6.2 Important Notice 46
6.3 Troubleshooting 46
...............................................................................
................................................................................
.........................................................................................
..................................................................................................
..........................................................................................................
............................................................................................................
4

1. Quick Installation Guide
1.1 Interface
1.
Camera Lens
2. Camera Base
11. Rotary Dial Switch
12.
RS232 Input Interface (Input)
4.
Infrared Receiver
13. RS232 Output Interface (Output)
14. RS422 Compatible with RS485
Interface
6. Screw Hole for Tripod
15. LAN Port
16. Power Input Socket (DC12V)
8.
HDMI
9. USB3.0
3. Remote Control Receiving Indicator
10. Audio Input Interface (LINE-IN)
7. 3G-SDI Output Interface
5. Tripod Screw Hole
Interface Introduction
17. Power Switch Button
When using the camera, please put the plastic pad on the bottom-center of the device
5

1.2 Quick Installation Guide
1) After powering on and running a self-check, the camera will automatically
return to the preset 0 if it is configured.
2) The default address for the IR remote control is №1.
If the camera is returned to factory default settings, the remote control’s default
address will also reset to №1.
6

1.3 Mounting Brackets
Caution
Ceiling or wall mounting brackets can only be mounted on template and
concrete walls. For safety reasons, plasterboard walls are not recommended.
1.3.1 Wall Mount
7

1.3.2 Ceiling Mount
8

9

2. Product Overview
2.1 Dimensions
2.2 Accessories
When you unpack the product, check that all the supplied accesso-
ries are included:
Supplied
Power adapter
USB3.0 Cable
RS-232 Cable
Quick Installation Guide leaflet
Plastic pad
IR Remote Control
10

2.3 RS-232
1) RS-232 Jack
2)RS-232 Mini-DIN 8-pin Terminal Definition
Connection method of the camera to a PC or a
controller.
Camera WindowsDB-9
1.DTR 1.DCD
2.DSR 2.RXD
3.TXD 3.TXD
4.GND 4.DTR
5.RXD 5.GND
6.GND 6.DSR
7.IR OUT 7.RTS
8.NC 8.CTS
9.RI
1
2
3
4
5
6
7
8
Port
DTR
DSR
TXD
GND
RXD
GND
IR OUT
NC
Definition
Data Terminal Ready
Data Set Ready
Transmit Data
Signal Ground
Receive Data
Signal Ground
IR Commander Signal
No Connection
NO.
11

Definitions
3)RS232(DB9) Port Definition
4)VISCA Networking Method
NO.
1
2
3
4
5
6
7
8
9
Port
DCD
RXD
TXD
DTR
GND
DSR
RTS
CTS
RI
Definition
Data Carrier Detect
Receive Data
Transmit Data
Data Terminal Ready
System Ground
Data Set Ready
Request to Send
Clear to Send
Ring Indicator
Networking Method
Device 1 Device2
1.DTR 1.DTR
2.DSR 2.DSR
3.TXD 3.TXD
4.GND 4.GND
5.RXD 5.RXD
6.GND 6.GND
7.IR OUT 7.OPEN
8. NC 8.OPEN
12

The product has RS232 input and output interfaces and can be cascaded in the
manner described above.
2.4 Rotary Dial
Caution
Ceiling or wall mounting brackets can only be mounted on template and
concrete walls. For safety reasons, plasterboard walls are not recommended.
2.5 Product Features
A-TC02 OnyxCam is a standalone AI Auto-Tracking Network Camera that works
out of the box. It does not require applications to work and provides a clear,
high-quality Full HD image via USB, HDMI, SDI, NDI-HX and network outputs.
Advanced tracking algorithm ensures that the camera stays focused on its
target even if there are other potential targets walking in front of it.
A-TC02 OnyxCam is able to stream to RTMP platforms and has an audio input
for you to connect a microphone. Therefore, it can be used not only with special-
ized hardware encoders/mixers/switchers, but also independently.
Dial Video Format
0 1080P60
1 1080P50
2 1080P30
3 1080P30
4 720P60
5 720P50
6 1080P59.94
7 1080P29.97
Dial Video Format
8 720P59.94
9 -----
A -----
B -----
C -----
D -----
E -----
F -----
13

A-TC02 OnyxCam comes with a preinstalled NDI-HX license, allowing users to
fully incorporate the camera into various production scenarios. It can be used
with smartphones, tablets, computers, professional AV hardware, and other
devices via NDI-HX protocol.
Other features include:
Full HD Resolution: 1/2.8” high-quality CMOS sensor. Up to 1920x1080
resolution with frame rate up to 60 fps.
Optical Zoom Lens: 20X optical zoom lens.
Leading Autofocus Technology: Fast, accurate and stable auto-focusing
technology.
Low Noise and High SNR: High SNR image is achieved with low noise
CMOS. Advanced 2D/3D noise reduction technology further reduces the noise
while ensuring high image clarity.
Multiple video output interfaces: HDMI, 3G-SDI, USB3.0, LAN.
Combined audio/video output: Simultaneously output audio and video
signal via HDMI, SDI and LAN interfaces. LAN interface supports POE, USB 3.0
supports dual code stream, SDI supports transmission up to 100m under
1080P60 format.
Multiple Audio/Video Compression Standards: The camera supports
H.264/H.265 video compression formats; AAC, MP3 and G.711A audio compres-
sion formats, and 8000,16000,32000,44100,48000 Hz audio sampling rate.
Dual Coding Stream on USB3.0: Supports the main stream and a sub
–stream, as well as simultaneous output; supports YUY2, MJPEG, H.264, NV12,
H.265 video coding formats.
Built-in Gravity Sensor: Supports PTZ auto-flip function and easy installa-
tion.
Multiple Network Protocols: Supports ONVIF, NDI-HX, GB/T28181, RTSP,
RTMP, VISCA OVER IP, RTMPS, SRT protocols; Supports RTMP push mode, easily
connects to streaming servers (e.g. Wowza, FMS); Supports RTP multicast
mode; Control Interfaces: RS422 is compatible with RS485, RS232-IN,
RS232-OUT. RS232 interface supports cascading.
Multiple Control Protocols: Supports VISCA, PELCO-D, PELCO-P protocols;
Supports automatic identification protocols.
14

Quiet Pan/Tilt Movement: Thanks to the highly accurate stepping motor,
camera pans/tilts extremely quietly and smoothly.
AI Human Detection: Built-in high-speed processor and advanced image
processing and analysis algorithms. Users can choose real-time tracking or
regional tracking according to the environment.
Multiple Applications: A-TC02 OnyxCam is an excellent choice for Lecture
Capture and automatic tracking of the lecturers and presenters, for tracking of
the VIPs in corporate and governmental applications, for Video Conferencing,
Telemedicine, Unified Communications, Live Production and other usage scenar-
ios. The camera can be used together with other professional AV record-
ing/streaming/mixing/switching solutions, such as AREC Media Capture
System, or independently.
2.6 Technical Specification
Camera Parameter
Parameter/Model
Focus
FOV
Aperture Value
Digital Zoom
Effective Pixels
Video Format
20X
5.2 -- 98mm
3.2° (N)
56°(W)
F1.5 -- F3.0
15X
2.07, 1/2.8-inch high-quality CMOS sensor
HDMI/SDI: 1080P60, 1080P50, 1080P30, 1080P25,
720P60, 720P50,
1080P59.94, 1080P29.97, 720P59.94;
USB3.0: main stream: YUY2/NV12:
1920×1080/1280×720/1024×576/800×600/800×448/640
×360/640×480/480×270/320×180@30/25/20/15/10/5fp
s;
MJPG/H264:
1920×1080/1600×896/1280×720/1024×576/960×540/80
0×600/800×448/720×576/720×480/640×360/640×480/4
80×270/352×288/320×240@30/25/20/15/10/5fps;
15

Video Format
Minimum
illumination
DNR
AWB
Focus mode
Exposure mode
Iris value
Shutter Speed
BLC
Dynamic range
Image adjustment
SNR
AI Function & Performance
Real-Time Tracking
Regional Tracking
Interface
Product Interface
Sub-stream:YUY2/NV12:
1920×1080/1280×720/1024×576/800×600/800×448/640×360/64
0×480/480×270/320×
180@30/25/20/15/10/5fps;
MJPG/H264:
1920×1080/1600×896/1280×720/1024×576/960×540/800×600/8
00×448/720×576/720
×480/640×360/640×480/480×270/352×288/320×240@30/25/20/
15/10/5fps;
0.5Lux (F1.8, AGC ON)
2D﹠3D
Automatic, manual, one-push white balance, specified color tem-
peratures
Automatic, manual, one-push focus
Auto, manual, shutter priority, aperture priority, brightness priority
F1.8 -- F11, CLOSE
1/25 -- 1/10000
On/off
Off, 1 -- 8
Brightness, chroma, saturation, contrast, sharpness, black and
white mode, gamma curve
≥50dB
Effective tracking range up to 15 meters
Maximum 4 Tracking Regions. The camera can set the regions
within horizontal -170°∼+170° and vertical -30°∼+90°
HDMI, RJ-45 (PoE), USB3.0 (B Type, compatible with USB2.0)
3G-SDI, RS-232 IN/OUT, RS-422 (compatible with RS-485), Rotary
Switch, DC 12V Power
16

Video Encoding Format
Audio input interface
Audio output interface
Audio compression
Network interface
Network protocol
Control Interface
Serial communication
protocol
USB
communication protocol
Power interface
Power adapter
Input voltage
Input currency
Consumption
Network Interface:Supports main stream and sub-stream H.265,
H.264
USB3.0 Interface:main stream supports YUY2, MJPG, H264, NV12
Dual channel 3.5mm linear input
HDMI, SDI, LAN, USB3.0
AAC, MP3, G.711A
10M/100M adaptive Ethernet port, supports POE power supply, sup-
ports audio and video outputs
RTSP, RTMP, ONVIF, NDI-HX, GB/T28181, VISCA OVER IP, RTMPS, SRT
Supports remote upgrade, remote restart, remote reset
RS-232-IN, RS-232-OUT, RS-422 compatible with RS-485
VISCA/Pelco-D/Pelco-P; supports baud rates
115200/38400/9600/4800/2400
UVC (video communication protocol), UAC (audio communication
protocol)
HEC3800 Power socket (DC12V)
Input AC100V-AC240V; output DC12V/2.0A
12V±10%
<1A
<12W
PTZ
Pan rotation
Tilt rotation
Pan speed
Tilt speed
Preset speed
-170° -- +170°
-30° -- +90°
0.1°/s -- 100°/s
0.1°/s -- 45°/s
Pan:100°/s,Tilt:45°/s
17

Preset quantity
Other Parameters
Storage temperature
Storage humidity
Working temperature
Working humidity
Dimension
Weight
Environment
Maximum 255 preset positions can be set (10 via the remote
control)
-10℃-- +70℃
20% -- 95%
-10℃-- +50℃
20% -- 80%
181mm×115mm×149mm
1.15kg
Designed for indoor use
Accessories
Package contents Power adapter, RS232 control line, USB3.0 connection line,
remote control (no batteries included), quick installation guide
leaflet
18

3. Remote Control Functions
3.1 IR Remote Control Keys and Commands
6. Zoom Control Keys
Zoom+: Zooms in the lens, making the image appear closer.
Zoom-: Zooms out the lens, making the image appear farther.
7. “SET PRESET” and “CLEAR PRESET” Keys:
SET PRESET: Press this button and then a 0-9 number key to save the current
pan/tilt/zoom settings as that preset number position.
CLEAR PRESET: Press this button and then a 0-9 number key to clear that preset
number position.
1. Standby Key
Press and hold for 3 seconds to send the camera into standby mode.
Press and hold for 3 seconds again to boot up the camera. It will
perform the self-test and return to the “HOME” position or to Preset 0
if it is configured)
2. Camera Address Selection
Change the remote’s IR number to control the camera with the same
IR number. Please note that OnyxCam is set to “1” by default.
3. Number Keys
Press to move the camera to presets 0-9. You will need to save them
first by following the procedure described under the point 7. “SET
PRESET” and “CLEAR PRESET” keys.
4. Asterisk (*) and Hash (#) Keys
These keys are used in some commands described bellow
5. Focus Control Keys
AUTO: Enables autofocus on the camera
MANUAL: Changes the focus mode to manual, allowing you to
change it with the plus (+) and minus (-) buttons.
19
Table of contents
