rada A-TC04 NoirCam User manual

A-TC04
NoirCam
USER MANUAL
Adena Limited 2023
www.a-dena.com

This manual provides information relevant to the installation of the A-TC04 NoirCam,
as well as its functions and control methods in details. Please read this manual careful-
ly before installing and using the camera.
Precautions
This product can only be used in the specified conditions in order to avoid any damage
to the camera:
To avoid causing damage to the camera, please observe the following key precautions:
1) Do not expose the camera and its components/accessories to rain or moisture.
2) Due to the risk of electric shock, do not open the camera’s casing. Installation and
maintenance of the device should only be carried out by qualified technicians.
3) Do not use the product beyond the temperature, humidity or power supply specifica-
tions stated in this user manual.
4) Please use a soft, dry cloth to clean the camera. If the camera is very dirty, clean it
with a diluted neutral detergent; Using any type of solvents may damage the surface of
the camera, thus you should not use them.
Electrical Safety
Installation and use of this product must strictly comply with the local electrical safety
standards.
Transportation
Avoid any stress, vibration, or moisture during transportation, storage, installation and
operation of the camera.
1

Installation
1) Do not rotate the camera head violently. Doing otherwise may cause mechanical
failure.
2) This camera is designed to be placed on a stable, horizontal surface. Do not install the
camera at
3) This product should be placed on a stable desktop or other horizontal surface. Do not
install the product at an angle, otherwise your camera’s image will be inclined;
4) Ensure there are no obstacles within the camera holder’s rotation range.
5) Do not power on before completing the camera’s installation.
Do Not Dismantle Camera
ADENA Limited is not responsible for any unauthorized modification or changes in the
camera’s behavior produced by dismantling of the product. Unauthorized dismantling of
the product will nullify your camera’s warranty.
Magnetic Interference
Electromagnetic fields at specific frequencies may affect the video image produced by
the camera. This is a Class A product; it may cause radio interference in domestic envi-
ronment. If used in such environment, please take this into account and apply appropriate
measures.
2

Table of Contents
1. Quick Installation Guide
1.1 Interface
1.2 Power-on Self-Test
2. Product Overview
2.1 Dimensions
2.1.1 Accessories
2.2 RS-232
2.2.1 RS-232 Jack
2.2.2 RS-232 Mini-DIN 8-pin Terminal Definition
2.2.3 RS-232(DB9) Port Definition
2.2.4 VISCA Networking Method
2.3 Rotary Dial
2.4 Product Features
2.5 Technical Specification
3. Remote Control Functions
IR Remote Control Keys and Commands
3.1 IR Remote Control Key Combinations
3.2 OSD Menu
4. Web interface and settings
4.1 Accessing the Web Interface
4.2 Web Interface Introduction
4.3 Configuration – Streaming
4.4 Configuration – Firmware Update
4.5 Monocular Tracking - Tracking Settings
5. Serial Port Communication Port
5.1 VISCA
5.1.1 VISCA Protocol List
5.1.2 Camera Control Command
5.1.3 Inquiry Command
...................................................................................................................
....................................................................................................................
.............................................................................................................
.............
............................................................................................................................
............................................................................................................
...................................................................................................................................
............................................................................................................
.......................................................
.................................................................................
...................................................................................
..................................................................................................................
..............................................................................................................................
................................................................................
...............................................................................
...............................................................................................................................
..............................................................................................................
..............................................................................................
..................................................................................................
..................................................................................................
......................................................................................
...........................................................................
......................................................................................................
...............................................................................................
...................................................................................
...............................................................................................................................
5
5
5
6
6
6
7
7
7
8
8
9
9
11
15
15
16
17
18
18
18
19
21
22
24
24
24
25
33
......................................................................................................
...............................................................................................................
......................................................................................................................................
...................................................................................................
3

Table of Contents
1. Quick Installation Guide
1.1 Interface
1.2 Power-on Self-Test
2. Product Overview
2.1 Dimensions
2.1.1 Accessories
2.2 RS-232
2.2.1 RS-232 Jack
2.2.2 RS-232 Mini-DIN 8-pin Terminal Definition
2.2.3 RS-232(DB9) Port Definition
2.2.4 VISCA Networking Method
2.3 Rotary Dial
2.4 Product Features
2.5 Technical Specification
3. Remote Control Functions
IR Remote Control Keys and Commands
3.1 IR Remote Control Key Combinations
3.2 OSD Menu
4. Web interface and settings
4.1 Accessing the Web Interface
4.2 Web Interface Introduction
4.3 Configuration – Streaming
4.4 Configuration – Firmware Update
4.5 Monocular Tracking - Tracking Settings
5. Serial Port Communication Port
5.1 VISCA
5.1.1 VISCA Protocol List
5.1.2 Camera Control Command
5.1.3 Inquiry Command
5.2 Pelco-D Protocol Command List
5.3 Pelco-P Protocol Command List
6. Maintenance and Troubleshooting
6.1 Camera Maintenance
6.2 Important Notice
6.3 Troubleshooting
.................................................................................................
..........................................................................................................
..................................................................................................................
...................................................................................... 37
39
40
40
40
41
...................................................................................................................
.......................................................................................
4

1. Quick Installation Guide
1.1 Interface
11. RS-232 Input
12.
RS-232 Output
6. USB Type-A 2.0 Output
3. Fixing Hole
10. RJ-45 Port (Network, PoE+)
7. 3G-SDI Output
5. HDMI Output
4. Tripod Screw Hole
Interface Introduction
1.2 Power-on Self-Test
1) After powering on and running a self-check, the camera will automatically
return to the preset 0 if it is configured.
2) The default address for the IR remote control is №1.
If the camera is returned to factory default settings, the remote control’s default
address will also reset to №1.
15. Power Switch Button
1. IR Sensor for the Remote Control
2. Lens
13. RS-422 (Compatible with RS-485)
Interface
14. DC12V Power Input Jack
8. 3.5mm Line Input
9. Rotary DIP Switch
5

2. Product Overview
2.1 Dimensions
2.1.1 Accessories
When you unpack the product, check that all the supplied accesso-
ries are included:
Supplied
Power adapter
USB2.0 Cable
RS-232 Cable
Camera Setup Guide Leaflet
IR Remote Control
6

2.2 RS-232
2.2.1 RS-232 Jack
2.2.2 RS-232 Mini-DIN 8-pin Terminal Definition
Connection method of the camera to a PC or a
controller.
Camera WindowsDB-9
1.DTR 1.DCD
2.DSR 2.RXD
3.TXD 3.TXD
4.GND 4.DTR
5.RXD 5.GND
6.GND 6.DSR
7.IR OUT 7.RTS
8.NC 8.CTS
9.RI
1
2
3
4
5
6
7
8
Port
DTR
DSR
TXD
GND
RXD
GND
IR OUT
NC
Definition
Data Terminal Ready
Data Set Ready
Transmit Data
System Ground
Receive Data
System Ground
IR Commander Signal
No Connection
NO.
7

Definitions
2.2.3 RS232(DB9) Port Definition
2.2.4 VISCA Networking Method
NO.
1
2
3
4
5
6
7
8
9
Port
DTR
DSR
TXD
GND
RXD
GND
IR OUT
NC
RI
Definition
Data Terminal Ready
Data Set Ready
Transmit Data
System Ground
Receive Data
System Ground
IR Commander Signal IR
No Connection
Ring Indicator
Networking Method
Device 1 Device2
1.DTR 1.DTR
2.DSR 2.DSR
3.TXD 3.TXD
4.GND 4.GND
5.RXD 5.RXD
6.GND 6.GND
7.IR OUT 7.OPEN
8. NC 8.OPEN
8

The product has RS232 input and output interfaces and can be cascaded in the
manner described above.
2.3 Rotary Dial
Caution
After switching the mode and dialing the code, you need to restart the
camera for changes to take effect.
2.4 Product Features
A-TC04 NoirCam is a standalone AI Auto-Tracking Network Camera that works
out of the box. It does not require applications to work and provides a clear,
high-quality UHD image via USB, HDMI, NDI|HX and network outputs, as well as
FHD via 3G-SDI. Advanced tracking algorithm ensures that the camera stays
focused on its target even if there are other potential targets walking in front of
it. It supports two distinct tracking modes, making it suitable for installations in
lecture halls, conferencing halls, auditoriums, and other facilities.
A-TC04 NoirCam is able to stream to RTMP platforms and has an audio input for
you to connect a microphone. Therefore, it can be used not only with specialized
hardware encoders/mixers/switchers, but also independently.
Dial Video Format
0 4KP60
1 4KP50
2 4KP30
3 4KP25
4 1080P60
5 1080P50
6 1080I60
7 1080I50
Dial Video Format
8 1080P30
9 1080P25
A 720P60
B 720P50
C Menu can be switched
D Menu can be switched
E Menu can be switched
F Menu can be switched
!
9

A-TC04 NoirCam comes with a preinstalled NDI|HX license, allowing users to
fully incorporate the camera into various production scenarios. It can be used
with smartphones, tablets, computers, professional AV hardware, and other
devices via NDI|HX protocol.
Other features include:
• 4K UHD Resolution: 1/1.8” Sony CMOS sensor. Up to 4K resolution with
frame rate up to 60 fps.
• Optical Zoom Lens: 25X optical zoom with a 59.2° angle lens.
• Leading Autofocus Technology: Fast, accurate and stable auto-focusing
technology.
• Low Noise and High SNR: High SNR image is achieved with low noise CMOS.
Advanced 3D noise reduction technology further reduces the noise while ensur-
ing high image clarity.
• Multiple output interfaces: HDMI, 3G-SDI, USB 2.0, RJ-45 (with NDI|HX and
PoE+). The camera simultaneously outputs audio and video signals.
• Multiple Audio/Video Compression Standards: The camera’s network inter-
face supports H.264/H.265 video compression formats; USB 2.0 supports
MJPEG, H.264, YUY2, NV12, H.265; The camera supports AAC audio compres-
sion format.
• Dual Stream Output: USB supports the main stream and a sub stream simul-
taneously.
• Built-in Gravity Sensor: Supports PTZ auto-flip function and easy installa-
tion.
• Multiple Network Protocols: Supports ONVIF Profile S, NDI|HX and NDI|HX3,
RTSP, RTMP, VISCA-over-IP, RTMPS, SRT protocols; Supports RTMP push mode,
easily connects to streaming servers (e.g. Wowza, YouTube); Supports RTP
multicast mode.
• Control Interfaces: The camera has an RS-422 port which is compatible with
RS-485, as well as RS-232 IN and RS232 OUT. RS-232 interface supports cascad-
ing.
• Multiple Control Protocols: Supports VISCA, PELCO-D, PELCO-P protocols;
Supports automatic identification protocols.
10

• AI Human Detection: Built-in high-speed processor and advanced image
processing and analysis algorithms. Users can choose real-time tracking or zone
tracking according to the environment.
• Multiple Applications: A-TC04 NoirCam is an excellent choice for Lecture
Capture and automatic tracking of the lecturers and presenters, for tracking of
the VIPs in corporate and governmental applications, for Video Conferencing,
Telemedicine, Unified Communications, Live Production and other usage scenar-
ios. The camera can be used together with other professional AV record-
ing/streaming/mixing/switching solutions, such as AREC Media Stations, or
independently.
2.5 Technical Specification
Camera Parameters
OPtical Zoom
Focal Length
Field of View
Iris Value
Image Sensor
Effective Pixels
Video Format
25X
f=7.1 mm~171.95 mm ±5%
Horizontal:
3.2° (N)~59.2° (W)
Vertical:
1.4° (N)~34.6° (W)
F1.61~F5.19±5%
1/1.8 inch SONY CMOS sensor
8.29 Megapixels (16:9)
HDMI:
3840*2160P60/50/25/59.94/29.97;
1080P60/50/30/25/59.94/29.97;
1080I60/50/59.94;720P60/50/59.94;
SDI:
1080P60/50/30/25/59.94/29.97;
1080I60/50/59.94; 720P60/50/59.94;
11

USB2.0:
MJPEG:
3840*2160/1920*1080/1280*720/1024*768/1024*576/800*600/
720*576/720*480/704*576/640*480/640*360/352*288/320*240
P30;
H264:
3840*2160/1920*1080/1280*720/1024*768/1024*576/800*600/
720*576/720*480/704*576/640*480/640*360/352*288/320*240
P30;
H265:
1920*1080/1280*720/1024*768/1024*576/800*600/720*576/72
0*480/704*576/640*480/640*360/352*288/320*240P30;
YUY2: 800*448/720*480P25/640*360/432*240P30
NV12: 800*448P25/640*480/640*360/432*240P30
0.05Lux (F1.8, AGC ON)
3D DNR
Auto/Manual/One Push/Specified Temperature
Auto/Manual/One Push
Auto/Manual/Shutter Priority/Aperture Priority/Brightness Priority
F1.8 ~ F11, CLOSE
1/25~1/10000
ON/OFF
OFF/Dynamic Level Adjustment
Brightness, Colour, Saturation, Contrast, Sharpness, B/W Mode,
Gamma Curve
≥50dB
AI Tracking
Effective tracking at distances up to 20 metres
Minimum Illumination
DNR
White Balance
Focus
Exposure Mode
Aperture
Shutter Speed
BLC
WDR
Video Adjustment
SNR
Tracking Function
Tracking Type
Tracking Distance
12

Tracking Modes
Interfaces
Video Compression
Format
Audio Input
Audio Output
Audio Compression
Format
RJ-45 Port
Network Protocols
Control Ports
Serial Port Communi-
cation Protocols
USB Communication
Protocol
Power Supply
Power Adapter
Input Voltage
Input Current
Consumption
Presenter (camera follows the first target it spots)
Zone Tracking (4 tracking zones can be set up, which can be set
within -110°∼+110° in horizontal and -27°∼+27° in vertical. Camera
uses zone PTZ presets to track targets)
HDMI, 3G-SDI, RJ-45 (Supports PoE+), USB Type-A 2.0, 3.5mm Line
IN, RS-232 IN, RS-232 OUT, RS-422 (Compatible with RS-485), Rotary
DIP Switch, DC12V Power Supply Jack, Power Switch Button.
Network: H.264, H.265
USB 2.0: MJPEG, H.264, H.265, YUY2, NV12
Double Track 3.5mm Linear Input
HDMI, Network, USB 2.0, 3G-SDI
AAC
10M/100M/1000M adaptive Ethernet port, support PoE+ (802.3at)
power supply, supports audio and video output
RTSP, RTMP, ONVIF Profile S, SRT, NDI|HX and NDI|HX3
Supports VISCA-over-IP, NDI, and ONVIF Profile S network control
protocols.
RS-232 IN, RS-232 OUT, RS-422 (compatible with RS-485)
VISCA/Pelco-D/Pelco-P
Supported baud rate: 115200/38400/9600/4800/2400
UVC (Video Communication Protocol), UAC (Audio Communication
Protocol)
HEC3800 Outlet (DC12V)
AC110V-AC220V to DC12V/2.5A
DC12V±10%
<1A
<12W
Camera Interface Description
13

Pan Move
Tilt Move
Pan Speed
Tilt Speed
Preset Speed
Preset Quantity
Storage Temperature
Storage Humidity
Working Temperature
Working Humidity
Dimensions
Weight
Intended Environment
Supplied Accessories
Suggested
Accessories
-110° ~ +110°
-27° ~ +27°
0.1°/s ~ 100°/s
0.1°/s ~ 70°/s
Pan: 78.8°/s, Tilt: 31.7°/s
Up to 255 presets (10 can be configured and used via remote
control)
-10°C ~ +60°C
20% ~ 95%
-10°C ~ +50°C
20% ~ 80%
220mm (L) × 144mm (W) × 159mm (H)
1.7kg
Indoors
Power Supply Unit, RS-232 Control Cable, USB Type-A 2.0 Cable,
Remote Control, Camera Setup Guide
A-B01 Camera Bracket
(https://www.a-dena.com/product-page/a-b01)
RADA Duo Wireless Microphones
(https://www.a-dena.com/product-page/rada-duo)
PTZ Parameters
Other Parameters
14

3. Remote Control Functions
IR Remote Control Keys and Commands
6. Zoom Control Keys
Zoom＋: Zooms in the lens, making the image appear closer.
Zoom－: Zooms out the lens, making the image appear farther.
7. “SET PRESET” and “CLEAR PRESET” Keys:
SET PRESET: Press this button and then a 0-9 number key to save the current
pan/tilt/zoom settings as that preset number position.
CLEAR PRESET: Press this button and then a 0-9 number key to clear that preset
number position.
1. Standby Key
Press and hold for 3 seconds to send the camera into standby mode.
Press and hold for 3 seconds again to boot up the camera. It will
perform the self-test and return to the “HOME” position or to Preset 0
if it is configured).
2. Camera Address Selection
Change the remote’s IR number to control the camera with the same
IR number. Please note that NoirCam is set to “1” by default.
3. Number Keys
Press to move the camera to presets 0-9. You will need to save them
first by following the procedure described under the point 7. “SET
PRESET” and “CLEAR PRESET” keys.
4. Asterisk (*) and Hash (#) Keys
These keys are used in some of the commands described bellow.
5. Focus Control Keys
AUTO: Enables autofocus on the camera.
MANUAL: Changes the focus mode to manual, allowing you to
change it with the plus (+) and minus (-) buttons.
1
2
3
4
5 6
7
8
910
15

Key: Moves the camera up; also used for navigation in the camera’s OSD menu.
Key: Moves the camera down; also used for navigation in the camera’s OSD menu.
Key: Moves the camera left; also used for navigation in the camera’s OSD menu.
Key: Moves the camera down; also used for navigation in the camera’s OSD menu.
“HOME” Key: Return to the middle position or enter the next level in the camera’s OSD
menu.
9. BLC ON/OFF Control Key
Back Light ON / OFF: Turn on or off the back light.
10. MENU Key
Enter/exit the OSD menu or return to the previous menu.
3.1 IR Remote Control Key Combinations
1. Setting the camera’s IR address number
【*】+【＃】+【F1】: Change the camera’s IR address to №1
【*】+【＃】+【F2】: Change the camera’s IR address to №2
【*】+【＃】+【F3】: Change the camera’s IR address to №3
【*】+【＃】+【F4】: Change the camera’s IR address to №4
2. Key Combination Functions
1) 【#】+【#】+【#】: Clear all presets
3) 【*】+【#】+【9】: Flip switch
5) 【*】+【#】+【3】: Menu set to
Chinese
7) 【*】+【#】+ Manual: Restore the
default user name, password, and IP
address
9)【#】+【#】+【1】: Switch the video
format to 4KP50
2) 【*】+【#】+【6】: Restore factory
defaults
4) 【*】+【#】+ Auto: Enter into the
aging mode
6) 【*】+【#】+【4】: Menu set to
English
8) 【#】+【#】+【0】: Switch the video
format to 4KP60
10)【#】+【#】+【2】: Switch the
video format to 4KP30
8. Arrow/HOME Control Keys
16

11)【#】+【#】+【3】: Switch the
video format to 4KP25
13)【#】+【#】+【5】: Switch the
video format to 1080P50
15)【#】+【#】+【7】: Switch the
video format to 1080I50
17)【#】+【#】+【9】: Switch the
video format to 1080P25
12)【#】+【#】+【4】: Switch the
video format to 1080P60
14)【#】+【#】+【6】: Switch the
video format to 1080I60
16)【#】+【#】+【8】: Switch the
video format to 1080P30
【F1】：Turn off AI Human Detection
【F2】：Turn on AI Human Detection
【F3】：Toggle between real time
tracking mode and zone tracking mode
【F4】：Change tracking target in real
time tracking mode
3.2 OSD Menu
To enter the OSD menu, press “MENU” on the remote. Use the arrow keys to
navigate this menu/change values. Press “HOME” to enter the next menu.
Use arrows “Up” and “Down” to navigate the menu, press “Home” to enter a
submenu, and use arrows “Left” and “Right” to adjust values. Press “Menu” to
return.
17

4. Web interface and settings
4.1 Accessing the Web Interface
To connect the A-TC04 NoirCam to network, connect an Ethernet cable to its
RJ-45 port and plug it into a switch or router. The camera comes with a static
default IP address 192.168.5.163.
Use an Ethernet cable to connect the camera to network. NoirCams come with a
static default IP address 192.168.5.163. To change the camera’s IP address,
connect to the camera using a computer and set the computer to be in the same
network as the camera. If you know how to do this, continue to “4.2 Web Inter-
face Introduction”.
If you do not know, then please first make sure that the computer is in the same
network segment as the camera. Thus, computer must also have an IP address
192.168.5.xxx. If you are using Windows, open Settings -> Advanced network
settings -> Change adapter options. In the menu that opens, double-click on your
Ethernet adapter, click on Properties -> Internet Protocol Version 4 and click on
Properties. Select “Use the following IP address” and type in an IP address that
matches the camera’s network segment, for example 192.168.5.160. Click on
the empty field in “Subnet mask” and let it auto-fill to 255.255.255.0. Then press
“OK” to save your settings. You should now be able to access the camera by
typing its IP address 192.168.5.163 in a browser.
This process is demonstrated on the ADENA Limited YouTube channel in video
“26. How to Change the IP Address of your AREC Device”.
4.2 Web Interface Introduction
After you land on the camera’s web page, use the default username and pass-
word “admin” to access it.
There are three pages on the web interface of A-TC04:
• Preview
• Monocular tracking
• Configuration
After logging in, you will see the camera’s preview. You can control its PTZ from
this page, change focus modes, save and go to presets, and control other
options, including audio and streaming.
18

Tracking settings can be adjusted on the “Monocular tracking” page and are
described in “4.5 Tracking Settings.”
Camera’s streaming, image, and other settings can be changed in the “Configura-
tion” page. This page is described in headings 4.3 and 4.4.
4.3 Configuration – Streaming
1) Configuring the camera’s video encoding
NoirCam’s streaming settings can be changed in the “Configuration” page. Click
on it, then proceed to -> Video Configure-> Video Encode
You can change the parameters to better suit the camera’s network environment.
To access the camera via RTSP (or to use it via RTSP), use the following link
structure:
rtsp://IP address of the camera/stream name (by default it is live/av0 for the
main stream and live/av1 for the sub stream. These can be changed in the
“Stream Name” fields).
19
