Raddy RD23 Mounting instructions

60×110mm

RD23
USE MANUAL

RD23
Overview
Operation Instruction
FM Radio
DAB/DAB+ Radio
System Setting
Charging Method
Precautions
Technical Parameters
Packing Accessories
Frequently Asked Questions
1
2
4
5
6
6
7
8
8
9
Contents
Inhalt
Überblick
Beschreibung der Bedienelemente
FM Radio
DAB/DAB+ Radio
Systemeinstellungen
Ladung der internen Batterie (Akku)
Sicherheitshinweise
Technische Daten
Packungsinhalt
Problembehandlung
11
12
14
15
16
17
18
19
19
19

RD23
Aperçu
Détail du fonctionnement de chaque bouton
Radio FM
Radio DAB/DAB+
Paramètres système
Méthode de chargement de la batterie
Précautions d’usage
Paramètres techniques
Accessoires
Solutions aux problèmes fréquents
Table des matières
Sommario
Panoramica
Istruzioni di utilizzo per ogni pulsante
Radio FM
Radio DAB/DAB+
Impostazioni di sistema
Metodo di ricarica della batteria
Precauzioni
Specifiche tecniche
Accessori inclusi nella confezione
Possibili soluzioni a problemi comuni
34
35
38
39
40
41
42
43
43
43
22
23
25
26
27
28
29
30
30
30

Overview
1
RD23
①Power switch ON/OFF
②Earphone output jack
③USB port
④TF card slot
⑤Volume knob
⑥DC 5V charging jack
⑦Charging indicator
⑧Previous MP3/station,
rewind
⑨Play/Pause/Confirm
⑩Next MP3/station,
fast-forward
⑪Select/Store stations
⑫DAB station information
⑬Lock button
⑭Music repeat
⑮Auto scan button
⑯Mode switch among
FM/DAB/USB/TF
⑰DAB system menu
⑱0-6 number buttons
⑦
⑤
⑨
⑧
① ③ ④②
⑥
⑪
⑫
⑬
⑭
⑩
⑮
⑯
⑰
⑱

2
Operation Instruction
RD23
(1) ON/OFF: Power switch, turn on or turn off this radio;
(2) :Earphone output jack. Plug in earphone, then
the audio will transfer to the earphone, the speaker will
be mute;
(3) USB: Plug in USB flash drive with MP3 files inside
and then the MP3 files can be played;
(4) TF: Plug in TF card with MP3 files inside and then
the MP3 files can be played (may not play other format
audio files except MP3 format); Please insert the TF
card in right direction. If not, may damage the TF card
or the TF card slot of this product;
(5) :Volume knob, volume up to the big side,
volume down to the small side;
(6) DC5V IN: DC5V charging jack, please kindly use
the standard mobile phone charger to charge this
radio;
(7) LED: Charging indicator. When charging, it is in red
color; when fully charged, it will turn green color;
(8) :In USB/TF mode, short press for previous MP3
file while hold press to rewind; In FM mode, short press
for previous station with less 0.1MHz, hold press to
scan previous valid station; In DAB mode, short press
to scan previous DAB station and will play the station 2
seconds after scan out. Use with “P” button or “MENU”
button to choose previous choice;
(9) OK: In USB/TF mode, short press to play or pause;
In FM/DAB mode, short press to turn speaker mute;
Short press to confirm after press “P” or “MENU”
button;

3
RD23
(10) :In USB/TF mode, short press for next MP3 file
while hold press to fast-forward; In FM mode, short
press for next station with more 0.1MHz, hold press to
scan next valid station; In DAB mode, short press to
scan next DAB station and will play the station 2 seconds
after scan out. Use with “P” button or “MENU” button to
choose next choice;
(11) P: Short press “P” button to recall preset stations,
hold press “P” button to store stations; In FM/DAB
mode (If have stored some stations), short press “P”
button to enter recalling preset station mode, and then
short press “ ” or “ ” button to check each preset
station, and short press “OK” button to play your
desired preset station; Hold press “P” button to enter
store station mode, and then short press “ ” or “ ”
button to check each preset station number, and short
press “OK” button to store current playing station to
current preset station number;
(12) INFO: Short press to check DAB station information,
each short press to show current playing station dynamic
text, signal strength, station frequency, bit rate, audio
format, time and date;
(13) :Lock button, short press this button, all other
buttons will be locked and can not work until short
press this button to unlock it again;
(14) :First short press for ONE, repeating the current
one MP3 file; Next short press for ALL, repeating all the
MP3 files;
(15) SCAN: In FM/DAB mode, hold press for over 1.5
seconds to automatically scan and memory stations;
(16) MODE: Short press to switch mode among FM/

4
RD23
DAB/Bluetooth/USB/TF; Hold press to turn to time
clock to display time and date;
(17) MENU: System setting button;
(18) 1-6: Press the number button to play the stored
stations/music directly.
Because different places use different frequencies,
when use this radio first time. You need to scan local
FM radio stations as follows:
Turn on this radio and short press “MODE” button to
change to FM mode. Pull out the radio antenna, then
hold press the button “SCAN” for over 1.5 seconds.
The numbers on the display screen will jump up quickly
from 87.5MHz and stop at 108MHz, which means the
FM radio is scanning stations automatically. When it
finishes the scanning, it will automatically turn back to
play the first station. If scan out few or no FM stations,
you can scan it again.
When finishes scanning, it will automatically store the
stations, and you can select your desired station to
play with following 3 methods:
(1) Short press “P” button to enter recalling preset
station mode, and then short press “ ” or “ ” button
to check each preset station, and short press “OK”
button to play your desired preset station;
(2) Short press 1-6 number buttons to directly select
station to play. When you find your interested station,
you can hold press 1-6 number buttons to store this
station to this number, then next time, you can short
FM Radio

5
RD23
press this number button to select this station to play
directly;
(3) When the stations are less, you can short press
“ ” or “ ” button for previous or next station with less
or more 0.1MHz, or hold press “ ” or “ ” button to
scan previous or next valid station.
DAB/DAB+ is digital audio broadcasting, can play
more than one station at same frequency. It have 4
methods to scan stations:
(1) When first time to use this radio, it will automatically
scan stations and update time and date in DAB mode;
(If can not scan out DAB stations, will default to display
time and date);
(2) Completely pull out the radio antenna, then hold
press the button “SCAN” for over 1.5 seconds to
automatically scan DAB radio;
(3) Short press “MENU” button, select “Full scan”
column, short press “OK” button, then DAB radio will
automatically scan stations;
(4) Short press “MENU” button, select “Manuel tune”
column, short press “OK” button to choose one
frequency, short press “OK” button again, then DAB
radio will automatically scan stations;
When finish scanning, you can short press “ ” or
“ ” button for previous or next station; Or you can
hold press 1-6 number buttons to store your
interested stations to 0-6 numbers, then next time,
you can short press this number button to select this
station to play directly.
DAB/DAB+ Radio

6
RD23
One short press “MENU” button to set system of this
radio, one more short press “MENU” button or without
any operation within 30 seconds, then will exit the
setting interface.
TA: In DAB mode, short press “MENU” button, and
short press “ ” or “ ” button to select “TA” column,
and short press “OK” button to confirm to choose
whether to play traffic stations or not;
Short press “MENU” button to enter system setting
interface, and short press “OK” button to enter submenu:
(1) Time: Short press “ ” or “ ” button to choose,
and short press “OK” button to confirm to set time and
date;
(2) Language: Short press “ ” or “ ” button to
choose, and short press “OK” button to confirm to set
language, default language is English;
(3) Factory setting: Short press “ ” or “ ” button to
choose, short press “OK” button to confirm to reset,
then all setting information will be reset to original
factory status;
(4) SW version: Short press “OK” button to check
DAB software version.
System Setting
Charging Method
When the battery power symbol on the top right corner
of display screen flashing, it indicates that the battery
voltage is not enough and you need to charge the
battery as follows:
