Motorola P100 Series User manual

P100 Series
Quick Reference Guide
6878276A01-B EMEA QRG.book Page 1 Thursday, September 23, 2010 6:31 PM

6878276A01-B EMEA QRG.book Page 2 Thursday, September 23, 2010 6:31 PM

1English
m
P100 Portable Radios Series
Quick Reference Guide
Important Safety Information
Product Safety and
RF Exposure Compliance
ATTENTION!
This radio is restricted to occupational use
only to satisfy FCC/ICNIRP RF energy
exposure requirements. Before using this
product, read the RF energy awareness
information and operating instructions in the
Product Safety and RF Exposure booklet
enclosed with your radio (Motorola Publication
part number 6864117B25) to ensure
compliance with RF energy exposure limits.
For a list of Motorola-approved antennas and
other accessories, visit the following Web site:
http://www.motorola.com/governmentandenterprise
Radio Controls
Before using this product,
read the operating
instructions for safe usage
contained in the Product
Safety and RF Exposure
booklet enclosed with your
radio.
!
Caution
1
2
3
4
5
On/Off/Volume Control Knob
LED Indicator
Speaker
Microphone
Liquid Crystal Display (LCD)
Push-to-Talk (PTT) Button
Side Programmable Buttons
Accessory Connector
Programming Port
Left/Right Buttons
Front Programmable Buttons
Alphanumeric Keypad (Full
Keypad Model Only)
1
2
3
4
5
6
7
8
9
10
11
12
6
7
8
12
9
10
11
P180/P185 Full Keypad Radio
6878276A01-B EMEA QRG.book Page 1 Thursday, September 23, 2010 6:31 PM

2
English
Liquid Crystal Display
Keypad
Front Left/Right Buttons
Front Programmable Buttons
A
B
1
2
3
4
5
8
9
6
7
10
11
On/Off/Volume Control Knob
LED Indicator
Speaker
Microphone
Liquid Crystal Display (LCD)
Push-to-Talk (PTT) Button
Side Programmable Buttons
Accessory Connector
Programming Port
Left/Right Buttons
Front Programmable Buttons
1
2
3
4
5
6
7
8
9
10
11
Left Navigation
Indicator for Text
Scrolling
Decimal Points
for Frequency
Data
Right Navigator
Indicator for Text
Scrolling
A
B
P160/P165 Limited Keypad Radio
6878276A01-B EMEA QRG.book Page 2 Thursday, September 23, 2010 6:31 PM

3English
Programmable Buttons
1
2
4
5
8
9
Channel Selector Knob
On/Off and Volume Knob
LED Indicator
Speaker
Microphone
Push-to-Talk (PTT) Button
Side Programmable Buttons
Accessory Connector
Programming Port
1
2
3
4
5
6
7
8
9
Button Function
Backlight Toggles backlight
display between ON
and OFF.
Call Alert Initiates Call Alert.
Channel
Alias
Toggles display
between Channel
Number and
Channel Alias.
Channel
Scan
Starts or stops
Channel Scan.
Monitor Monitors channel for
any activity as long
as the button is
pressed.
Selective
Call
Initiates Selective
Call.
Power
Level
Selects required
power level: High or
Low.
P140/P145 Non Keypad Radio
3
6
7
6878276A01-B EMEA QRG.book Page 3 Thursday, September 23, 2010 6:31 PM

4
English
Keypad
Lock
Locks or unlocks all
buttons except PTT,
Side Programmable
Button 1, Side
Programmable
Button 2 and ON/
OFF/Volume Knob.
Applicable for Long
Press only.
Nuisance
Channel
Delete
Removes unwanted
channel(s)
temporarily from
scan list during Scan.
Applicable for Long
Press only.
Phone
Mode
Enables or disables
Phone feature for the
selected channel.
TPL/DPL
Enable
Enables or disables
radio from requiring
matching TPL/DPL
to unsquelch.
Prime
Channel
Enables quick move
to the selected Prime
Channel.
Button Function
PTT ID
Enable
Enables or disables
PTT ID sent on PTT
press.
Reverse
Burst
Selects the Reverse
Burst Type: None,
180 or 240.
Scrambling
Code
Select
Toggles between the
two scrambling
codes available.
Scrambling
Enable/
Disable
Enables or disables
Voice Inversion
Scrambling feature
for the selected
channel. Applicable
for Long Press only.
Squelch
Level
Selects desired
squelch level:
Normal or Tight.
Unassigned No function is
programmed to this
button.
VOX Enables or disables
VOX feature for the
selected channel.
Button Function
Sticky
Monitor
Toggles the
permanent monitor
function until button
is pressed again.
Applicable for Long
Press only.
Talkaround/
Repeater
Mode
Enables toggle
between repeater
and talkaround mode
operations.
Volume Set Controls audio level.
Button emits
continuous tone to
indicate current
volume level. To
change volume level,
turn volume knob to
desired level while
pressing
programmable
button. Applicable for
Long Press only.
Button Function
6878276A01-B EMEA QRG.book Page 4 Thursday, September 23, 2010 6:31 PM

5English
LCD Icons Display
LCD
Indicator Description Function
Signal
Strength
More bars
indicate a
stronger
signal.
Talkaround Radio not
transmitting
through
repeater.
Power
Level
“L”
indicates
that radio is
transmitting
in low
power; “H”
indicates
that radio is
transmitting
in high
power.
Monitor Radio is
monitoring
a selected
channel.
Voice
Inversion
Scrambling
Illuminates
when
Scrambling
Mode is
ON.
Phone
Mode
Illuminates
when
Phone
Mode is
selected.
Prog. Mode Illuminates
when Prog.
Mode is
ON.
Keypad
Lock
Illuminates
when
keypad is
locked.
LCD
Indicator Description Function
Battery
Level
Shows
remaining
charge in
battery by
number of
bars
(0 – 3).
Blinks
when the
battery is
low.
Scan Blinks
without dot
when
normal
Scan is
activated.
Illuminates
without dot
when there
is some
activity on
a non-
priority
channel.
LCD
Indicator Description Function
6878276A01-B EMEA QRG.book Page 5 Thursday, September 23, 2010 6:31 PM

6
English
LED Colors
Scan
(con’td)
Illuminates
with dot
blinking to
indicate
that there is
some
activity on
the Priority
Channel.
LED Color Indication
Green
Illuminated
Radio is transmitting
in normal mode or
Scrambling Mode.
Green
Normal
Blinking
Radio is receiving in
normal mode.
Channel is busy.
Radio passed self-
test during powering
up.
LCD
Indicator Description Function
Amber
Illuminated
Monitor or
Permanent Sticky
Monitor activated.
Selective Call
received.
Amber
Normal
Blinking
Radio is in active
Scan Mode.
Radio is receiving in
Scrambling Mode.
Amber Fast
Blinking
Call Alert received.
Red Normal
Blinking
Radio is transmitting
in normal mode or
Scrambling Mode
while battery is low.
Red Fast
Blinking
Radio failed self-test
during powering up.
LED Color Indication Computer Software Copyright
The products described in this
manual may include copyrighted
computer programmes stored in
semiconductor memories or other
media. Laws in the United States of
America and other countries
preserve for Motorola Europe and
Motorola Inc. certain exclusive rights
for copyrighted computer
programmes, including the right to
copy or reproduce in any form the
copyrighted computer programme.
Accordingly, any copyrighted
computer programmes contained in
the products described in this manual
may not be copied or reproduced in
any manner without the express
written permission of the holders of
the rights. Furthermore, the purchase
of these products shall not be
deemed to grant either directly or by
implication, estoppel, or otherwise,
any license under the copyrights,
patents, or patent applications of the
holder of the rights, except for the
normal non-exclusive royalty free
license to use that arises by
operation of the law in the sale of the
product.
6878276A01-B EMEA QRG.book Page 6 Thursday, September 23, 2010 6:31 PM

1Deutsch
m
P140/P145/P160/P165/P180/
P185 Handfunkgeräteserie
Kurzübersicht
Wichtige
Sicherheitshinweise
Produktsicherheit und
Einhaltung der
Strahlenschutzbedingungen
ACHTUNG!
Zur Erfüllung der FCC/ICNIRP-HF-
Strahlenschutzbedingungen ist dieses
Funkgerät ausschließlich für den beruflichen
Einsatz bestimmt. Lesen Sie vor Verwendung
dieses Produkts die mit Ihrem Funkgerät gelieferte
Beilage über Produktsicherheit und
Funkfrequenzstrahlung (Motorola-Druckschrift-Nr.
6864117B25), die nützliche Informationen zur
Einhaltung der Strahlenschutzbedingungen enthält.
Eine Liste der von Motorola genehmigten Antennen
und Zubehörteile finden Sie auf folgender Website:
http://www.motorola.com/governmentandenterprise
Bedienelemente des
Funkgeräts
Bitte lesen Sie vor
Inbetriebnahme dieses
Produkts die mit Ihrem
Funkgerät gelieferte
Beilage über
Produktsicherheit und
Funkfrequenzstrahlung
zum sicheren Betrieb des
Funkgeräts.
!
C a u t i o n
W
arn
hi
nwe
i
s
1
2
3
4
5
P180/P185 Funkgerät ohne
Tastatur
Ein/Aus/Lautstärkeregler
LED-Anzeige
Lautsprecher
Mikrofon
Flüssigkristallanzeige (LCD)
Sendetaste (PTT)
Programmierbare
Seitentasten
Zubehöranschluss
Programmieranschluss
Links-/Rechtstasten
Programmierbare Tasten
vorne
Alphanumerische Tastatur
(nur bei Modellen mit
Volltastatur)
1
2
3
4
5
6
7
8
9
10
11
12
6
7
8
12
10
11
9
6878276A01-A EMEA QRG_DE.fm Page 1 Tuesday, December 7, 2010 10:50 AM

2
Deutsch
Flüssigkristallanzeige
(LCD)
Tastatur
Vorderseitige
Links-/Rechtstasten
Vorderseitige
programmierbare Tasten
Dezimal-
stellen für
Frequenz-
daten
Links-
seitiger
Navigations-
pfeil für Text-
Scrolling
Rechts-
seitiger
Navigations-
pfeil für
Text-Scrolling
A
B
A
B
1
2
3
4
5
8
9
6
7
10
11
Ein/Aus/Lautstärkeregler
LED-Anzeige
Lautsprecher
Mikrofon
Flüssigkristallanzeige (LCD)
Sendetaste (PTT)
Programmierbare
Seitentasten
Zubehöranschluss
Programmieranschluss
Links-/Rechtstasten
Programmierbare Tasten
vorne
1
2
3
4
5
6
7
8
9
10
11
P160/P165 Funkgerät mit
Teiltastatur
6878276A01-A EMEA QRG_DE.fm Page 2 Tuesday, December 7, 2010 10:50 AM
