Radial Engineering Twin-Iso User manual

9
9
TWIN-ISO SPECIFICATIONS
Frequency response 10Hz to 50kHz +/- 1dB
Max output level +21dBu (20Hz, 1% THD)
Phase distortion 0.3° at 20Hz
Total harmonic distortion 0.001% THD @1k, +4dBu (0.035% at 20Hz)
Common-mode rejection 94dB @ 60Hz (83dB @ 3kHz)
Inputs Balanced, line-level, pin-2 hot
Outputs Balanced, line-level, pin-2 hot
Power requirement None, completely passive
Size 3.25” x 5” x 1.875”
Weight 2 lbs.
8
INPUT PANEL
1. Ground lift (inputs) Lifts
the ground pin-1 on both
XLR input connectors.
2. Input-1 & 2 For low
impedance, balanced line-
level signals.
3. Bookend design 14
gauge steel outer shell
creates protective zone
around connectors and
switches.
OUTPUT PANEL
4. Output-1 & 2 line-level
transformer-isolated
outputs.
5. Polarity reverse 180°-
Polarity reverse switch for
outputs-1 & 2.
6. Full-bottom no-slip pad
This provides electrical
isolation and plenty of
"stay-put" friction to keep
the Twin-ISO in one place.
CONSTRUCTION
7. Ultra rigid steel I-beam
enclosure eliminates
stress that could torque
the PC board and cause
solder joint failure.
8. Jensen transformers
offer outstanding audio
performance.
9. Military-grade double-
sided PCB with plated
through-holes is bolted to
welded steel standoffs.
10. Sturdy high-cycle PCB
mounted switches are
rated for long life.
www.radialeng.com
Radial Engineering Ltd.
1588 Kebet Way, Port Coquitlam BC V3C 5M5
Tel: [phone] Fax: [phone]
email: [email protected]
Twin-Iso™
True to the Music
Radial Twin-Iso user guide - Part #: R870 1025 00 / 06-2017
Appearances and specifi cations subject to change without notice.
Copyright © 2017, all rights reserved.
1
7
2 3
Twin-Iso™User Guide
Radial Engineering Ltd. Twin-Iso™User Guide Radial Engineering Ltd.
RADIAL LIMITED THREE YEAR
TRANSFERABLE WARRANTY
RADIAL ENGINEERING LTD. (“Radial”) warrants this product to be free from
defects in material and workmanship and will remedy any such defects free
of charge according to the terms of this warranty. Radial will repair or replace
(at its option) any defective component(s) of this product (excluding fi nish and
wear and tear on components under normal use) for a period of three (3) years
from the original date of purchase. In the event that a particular product is no
longer available, Radial reserves the right to replace the product with a similar
product of equal or greater value. To make a request or claim under this limited
warranty, the product must be returned prepaid in the original shipping container
(or equivalent) to Radial or to an authorized Radial repair center and you must
assume the risk of loss or damage. A copy of the original invoice showing date
of purchase and the dealer name must accompany any request for work to be
performed under this limited and transferable warranty. This limited warranty shall
not apply if the product has been damaged due to abuse, misuse,misapplication,
accident or as a result of service or modifi cation by any other than an authorized
Radial repair center.
THERE ARE NO EXPRESSED WARRANTIES OTHER THAN THOSE ON THE
FACE HEREOF AND DESCRIBED ABOVE. NO WARRANTIES WHETHER
EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO, ANY IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE SHALL EXTEND BEYOND THE RESPECTIVE WARRANTY
PERIOD DESCRIBED ABOVE OF THREE YEARS. RADIAL SHALL NOT
BE RESPONSIBLE OR LIABLE FOR ANY SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES OR LOSS ARISING FROM THE USE OF THIS
PRODUCT. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND
YOU MAY ALSO HAVE OTHER RIGHTS, WHICH MAY VARY DEPENDING ON
WHERE YOU LIVE AND WHERE THE PRODUCT WAS PURCHASED.
User Guide
True to the Music ®
®
10
4
5
6

J-RAK
The optional J-RAK is a high density rackshelf for Radial DI’s and splitters.
It’s a 2RU rack chassis that allows up to 8 Radial devices in one neat high density
19” package. The DI’s can be mounted with either the input side or output side
facing the front. Ideal for studio or touring. Constructed of 14 gauge steel with
a baked enamel fi nish.
J-CLAMP
The optional J-CLAMP can mount a single Radial
device to virtually any surface. Perfect for hiding away
inside racks, on podiums or under tables. Constructed
of 14-gauge steel with a baked enamel fi nish.
TWIN-ISO BLOCK DIAGRAM
LEFT IN LEFT OUT
RIGHT IN RIGHT OUT
POLARITY
GND LIFT
POLARITY
WELCOME
Congratulations on your purchase of the Radial Twin-Iso stereo (dual mono)
line-level isolator. The Twin-Iso is a handy device that will allow you to isolate
audio equipment and eliminate troublesome noise caused by ground loops.
The Radial Twin-Iso employs two high-performance Jensen isolation
transformers to ensure the best signal transfer is enjoyed without artifacts or
distortion. This makes the Twin-Iso a perfect choice where multiple consoles
need to be sub-mixed, when isolating amplifi er distribution racks and for
connecting remote speaker towers. The Twin-Iso can also eliminate ground
loop problems where equipment must be connected to alternate power
sources such as generators.
As with all Radial products, the Twin-Iso is made with 14 gauge steel and
features an internal welded I-beam frame for maximum rigidity. Switches
and jacks are protected by our unique bookend construction, making the
Twin-Iso virtually impossible to damage even in the most abusive touring
environments.
We have purposely written this manual to be short, as most users will likely
be familiar with the Twin-Iso’s applications. We do suggest that you take a
moment to read through this document to familiarize yourself with the features
that have been built in. For more detailed information, please visit the Radial
website. This is also where we post questions and answers that come from
users after the product is released. If you do not fi nd an answer, we invite you
to send us an email at [email protected] and we will do our best to answer
your query in a prompt and professional manner.
The Radial Twin-Iso is a wonderful device that will surely provide you with
years of problem-solving connectivity. Enjoy!
INTRODUCTION
The Radial Twin-Iso has been designed to provide electrical isolation
between two line-level devices such as between two mixing consoles, remote
speakers, crossovers and amplifi er racks. Use the Twin-Iso anywhere source
and destination devices may cause system noise because of different ground
potentials (often referred to as ground loops).
So-called ground loops are caused by differing voltage references from various
pieces of equipment that, when connected together, can introduce a 60 cycle
hum in the sound system. Although there are various solutions that can be
engineered to eliminate noise, the simplest and most effective is to isolate the
source and destination with an audio transformer.
The Radial Twin-Iso employs two high-quality Jensen transformers to do the
task. Jensen is renowned for their quality and the ability of their transformers
to handle high signal levels without saturation and transfer the signal without
introducing phase distortion or group delay. Although the cost is higher, a good
quality transformer will assure the signal remains true to the source, resulting
in better sound.
When you fi rst pick up the Radial Twin-Iso, you will immediately notice the
weight. This ‘hefty’ device employs a welded steel I-beam internal construction
to assure the internal PCB will not torque, preventing part failure. Besides
the heavy-duty enclosure, the extra-large transformers add to the Twin-Iso’s
robustness. As a rule, the larger the transformer, the more signal handling
capacity it will have and the Jensen transformers can drive loads of 600 ohms
up to +21dBu at 20Hz.
The Radial Twin-Iso is equipped with two XLR inputs and two XLR outputs.
Each channel is 100% isolated from the other to eliminate cross-talk or
interaction, thus allowing two completely different audio sources to use
the Twin-Iso at the same time. Although the Twin-Iso is designed for +4dB
professional line-level signals, the transformers will actually handle over 20dB
without choking.
Each of the Twin-Iso’s outputs feature a 180° polarity reverse switch to ensure
both consoles are ‘in phase’ and pushing the speakers in the same direction.
This allows the Twin-Iso to feed a sub-group or auxiliary input of a console
where polarity reversals are generally not provided. Finally, the Twin-Iso is
equipped with a ground lift switch to further reduce system noise should it be
present.
USING THE TWIN-ISO
As with all Radial products, using the Twin-Iso is simple and straight forward.
Make sure the sound system is turned off and all levels are set to zero before
making audio connections. This will avoid any pops in the sound system that
could cause damage to speakers.
The Twin-Iso is completely passive and does not require a power supply of
any kind. Connect the source device to the Twin-Iso inputs. Connect the Twin-
Iso outputs to the destination device. Turn the system up slowly and listen for
noise. In the unlikely event you should encounter noise, simply depress the
ground lift switch. That’s all there is to it.
Twin-Iso™User Guide Twin-Iso™User Guide Twin-Iso™User Guide
Radial Engineering Ltd.
Radial Engineering Ltd.Radial Engineering Ltd.
AUX CONSOLE master outputs
connect to Twin-Iso inputs.
MAIN CONSOLE Twin-Iso
outputs feed main console.
