Radiant RK 18 User manual

User instruction
CE 0694 RK 18_25 OV - RAD - ING - MAN.UT - 1104A - DIGITECH 2 - REGNO UNITO - EXTRAHEAT - CBD
Technical specification by RADIANT BRUCIATORI S.p.A. Montelabbate (PU) ITALY ENGLISH
User Manual
for model
RK 18
OV
RK 25 OV
Premix condensing boiler

USER INSTRUCTIONS
1
BOILER OPERATING INSTRUCTIONS
Make sure that the authorised technician who tested the boiler has stamped the guarantee booklet.
The installation, first start-up, regulation and maintenance operations must be carried out exclusively by qualified
personnel (e.g. Radiant authorised Service Centres). Incorrect installation can cause damage to property and
injury to persons or animals, for which the manufacturer will not be held responsible.
During the installation, the technician must carry out the following checks:
■The data on the data plate must correspond to that of the mains supply networks (gas, electricity, water).
■The boiler must be regulated according to its designed use and performance.
■The flue gas exhaust and combustion air intake system must be correctly installed and operational.
■The exhaust gas discharge and ventilation systems must comply with the requirements of national and local
standards regardless of whether the boiler is installed indoors, outdoors or in its own cabinet (see section
“Reference standards”.
General warnings
 If there is any doubt as to whether the appliance has been tested by an authorised technician, do not attempt
to start it. All maintenance and gas conversion operations MUST BE CARRIED OUT BY PROFESSIONALLY
QUALIFIED PERSONNEL, registered in accordance with current legislation.
 Make sure that the requirements relating to the air intake and ventilation of the room in which the
boiler is to be installed have been complied with.
 The boilers can be installed outdoors in a partially protected location, in accordance with current
standards and where the minimum external temperature does not fall below –10°C. The manufacturer
will not be held responsible for installation in locations where the temperature falls to below –10°C.
 The boiler is fitted with an antifreeze system. If the boiler is installed in a location where there is a risk of
freezing, the anti-freeze system will only come into operation if the power is on and the gas supply valve is
open (the frost protection is active even with the ON/OFF switch in OFF position). The manufacturer will not
be held responsible for damage to the boiler caused by non-compliance with this instruction.
 Should any part of the boiler freeze-up, do not attempt to light it under any circumstances, but instead call the
Service Centre immediately.
 The Benchmark Book is an integral part of an installation. The Benchmark handbook should be filled-in each
time a boiler is installed. In addition to checking the combustion, all ordinary and extraordinary maintenance
operations must be reported in the booklet together with the name of the person carrying out the maintenance
and, where applicable, his company.
 The appliance’s combustion system must be checked every two years. This check includes testing the
efficiency of the boiler and must be carried out by authorised personnel possessing the qualifications as
required by current law.
 Do not obstruct the ventilation openings in rooms where there are gas-burning appliances installed (boiler,
cooker, etc.).
If you smell gas …
 DO NOT ACTIVATE ANY ELECTRIC SWITCHES, TELEPHONES OR ANY OTHER DEVICE THAT MAY
GENERATE ELECTRICAL DISCHARGES OR SPARKS.
 OPEN DOORS AND WINDOWS IMMEDIATELY TO CREATE A CURRENT OF AIR THAT WILL RAPIDLY
CLEAR THE ROOM.
 CLOSE ALL GAS TAPS AND VALVES.
 CALL FOR PROFESSIONALLY QUALIFIED PERSONNEL.

USER INSTRUCTIONS
2
Boiler controls - Control panel
LEGEND
1. ON/OFF BUTTON
2. HEATING TEMPERATURE CONTROL KNOB
3. NOT OPERATIVE KNOB.
4. OUTSIDE TEMPERATURE DISPLAY (ONLY WITH OPTIONAL OUTDOOR SENSOR).
5. SERVICE BUTTON.
6. WINTER MODE SELECTION BUTTON.
7. TERMINAL BOARD FOR EXTERNAL WIRING.
8. TEMPERATURE, ERROR CODE AND OPERATING STATUS DISPLAY .
9. TIME CLOCK (optional)
7654321
89
Fig. 1

USER INSTRUCTIONS
3
Starting - up the boiler
•Open the gas Isolation valve located under the
boiler.
•Switch on the boiler by placing the ON/OFF
switch (1)in the ON position (see “Control
panel”).
•The boiler will light automatically (with the
WINTER mode selected and room thermostat
connected).
■“WINTER” mode
To switch boiler operation to “WINTER” mode,
press button 5(see fig. 1). The boiler will only work
for the central heating system. The “WINTER” mode
setting of the boiler is signalled by the symbol lit
continuously on the control panel.
The automatic ignition system will light the burner
every time there is a demand for room heating. In
this case, the symbol on the control panel will flash.
■Regulating the heating temperature
The heating temperature is regulated by knob 2 (see fig.1).
•Rotating the knob anticlockwise reduces the temperature.
•Rotating the knob clockwise increases the temperature.
•The range of temperature settings for the central heating runs from a minimum of 30°C to a maximum of 80°C,
or, in the case of low temperature operation, from a minimum of 25°C to a maximum of 59°C.
7654321
89
Fig. 1

USER INSTRUCTIONS
4
Diagnostics – Error codes:
This paragraph contains a list of error codes that the boiler may generate on the display 7 (see “Control panel”)
together with the relative indications and the operations that the user can carry out to reset the boiler.
If the problem re-occurs after the following actions have been taken, call an authorised Service
Centre.
_E01
E01E01
E01_ Ionisation block
Code E01 lit continuously on the display.
Check that the gas valve on the boiler and gas meter are open and that there is gas in the mains supply (or in
the tank).
Switch off then switch on the appliance using switch 1(see “Control panel”) on the control panel.
When the error code on the display disappears, the boiler will restart.
If the problem persists, Call the Service Centre.
_E02
E02E02
E02_ Safety Thermostat tripped
Code E02 lit continuously on the display. Call the Service Centre.
_E03
E03E03
E03_ Flue Gas Thermostat tripped
Code E03 lit continuously on the display. Call the Service Centre.
_h2o
h2oh2o
h2o_Low Water Pressure Alarm
Code H2O lit continuously on the display.
Fill the system until the pressure gauge reches 1.0 bar.
The boiler will restart automatically.
If the problem persists, Call the Service Centre.
_E05
E05E05
E05_ Heating Sensor malfunction
Code E05 lit continuously on the display. Call the Service Centre.
_E16
E16E16
E16_ Electric Fan Malfunction
Code E16 lit continuously on the display. Call the Service Centre.
_E22
E22E22
E22_ Parameter programming request
Code E22 lit continuously on the display. Call the Service Centre.
_E35
E35E35
E35_ Flame Detection Malfunction
Code E35 lit continuously on the display. Call the Service Centre.
N.B. If the boiler is to be left unused for a long period of time, the user must do one of the following:
Make the boiler safe by disconnecting all the power supplies (electricity and gas), and draining the heating
system and the condensate trap.
Leave the boiler in standby, leaving the electricity and gas supplies connected and, consequently the anti-freeze
function.
