Radio Shack 32-3001 User manual

Cat. No. 32-3001
OWNER’S MANUAL
Please read before using this equipment.
SM-1000
Audio Mixer with Echo (Rack Mount Type)
32-3001.fm Page 1 Tuesday, August 10, 1999 8:02 AM

2
FEATURES
© 1995 Tandy Corporation.
All Rights Reserved.
Radio Shack is a registered trademark used by Tandy Corporation.
Your Radio Shack SSM-1000 Audio
Mixer with Echo is a sophisticated
control center for recording from multi-
ple playback sources such as a CD
player, tuner, turntable, or VCR, or
from live performances. A seven band
equalizer and an echo effect are incor-
porated into the mixer so you can tai-
lor the sound to compensate for
environmental conditions or for per-
sonal preference. The mixer’s many
features give you almost limitless
sound combinations.
Its features include:
7-Band Frequenc
y
Equalizer — al-
lows you to tailor the sound output to
your preference.
Two Pairs of Stereo PHONO Inputs
— for using turntables with either
magnetic or ceramic cartridges.
Stereo Line Inputs — let you connect
most high level audio sources, such
as a tape deck, amplifier, tuner, or
VCR.
Low-Noise Tape Out Jack — for
high-quality tape recording.
Slide Controls — for fingertip control
of sound mixing and fading adjust-
ments.
Monitor Controls — let you hear and
check line inputs using headphones
before mixing.
Normal/Standb
y
/Talkover Switch —
lets you control when you talk with
music, talk over music, or talk without
interrupting the music or being heard
through the mixer, to give you a “DJ’s”
control.
Phono 1/Phono 2 Fader Control —
allows you to quickly and smoothly
switch between playing PHONO 1 and
PHONO 2.
Monitorin
g
Controls — lets you lis-
ten to the outputs of MIC, PHONO 1,
PHONO 2, LINE 1, LINE 2, or MAS-
TER through headphones.
To obtain best performance of your
audio SSM-2200 Mixer, please read
this manual carefully before you con-
nect it to other audio components.
For your important records, we recom-
mend you record this unit’s serial
number in the space provided. You’ll
find the serial number on the bottom of
the unit.
Serial Number:
32-3001.fm Page 2 Tuesday, August 10, 1999 8:02 AM

3
CONTENTS
Preparation.............................................................................................................4
Connecting the Outputs ....................................................................................4
Connecting Inputs and Presetting Levels .........................................................4
Pre-Adjusting the Monitor Levels......................................................................5
Listening Safely..........................................................................................6
Operation................................................................................................................7
Basic Operation ................................................................................................7
Using The “DJ’s” Microphone............................................................................8
Normal........................................................................................................8
Talkover ......................................................................................................8
Standby ......................................................................................................8
Using Echo........................................................................................................8
Using the 7-Band Frequency Equalizer ............................................................9
Troubleshootin
g
..................................................................................................10
Care and Maintenance ........................................................................................ 11
Specifications......................................................................................................12
Warnin
g
: To prevent fire or shock hazard, do not expose this mixer to rain or mois-
ture.
This symbol is intended to alert you to the presence of uninsulated dan-
gerous voltage within the mixer’s enclosure that might be of sufficient
magnitude to constitute a risk of electric shock. Do not open the mixer’s
case.
This symbol is intended to inform you that important operating and main-
tenance instructions are included in the literature accompanying this mix-
er.
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER OR BACK. NO USER-SERVICE-
ABLE PARTS INSIDE. REFER SERVIC-
ING TO QUALIFIED PERSONNEL.
CAUTION !
!
32-3001.fm Page 3 Tuesday, August 10, 1999 8:02 AM

4
PREPARATION
CONNECTING THE
OUTPUTS
Connect your amplifier and a cassette
recorder to the audio output jacks on
the back of the mixer.
1. Connect the amplifier’s left and
right input jacks to the mixer’s
MAIN OUT output jacks to play the
mixer’s sound.
2. Connect the tape recorder’s left
and right input jacks to the mixer’s
TAPE OUT output jacks to record
the mixer’s sound.
CONNECTING INPUTS
AND PRESETTING
LEVELS
Connect your audio sources (AM/FM
tuners, CD players, cassette decks, or
phonograph players) to the audio in-
put jacks on the back of the mixer.
1. Connect the AC power cord to a
standard AC outlet.
2. Before turning on the power:
•Set
MIC, PHONO 1, PHONO 2,
LINE 1, and LINE 2 to 0.
•Set NORMAL/STANDBY/TALK-
OVER to STANDBY.
•Set
MONITOR LEVEL fully coun-
terclockwise to minimum.
•Set
EQUALIZER BYPASS/ON to
BYPASS.
3. Set POWER OFF/ON to ON to turn
on the mixer’s power. The VU
meters and the power indicator
lights.
4. Connect a high-quality micro-
phone with a 1/4-inch plug to the
MIC terminal.
Note: This is the remote (guest)
microphone.
5. Set MIC main volume control to 5.
(illus - show the
left and ri
g
ht out-
put jacks.)
(illus - show the
left and ri
g
ht input
jacks.)
(illus)
32-3001.fm Page 4 Tuesday, August 10, 1999 8:02 AM

5
Note: You can set the control to
any other position (except 0).
However, to get an accurate pre-
set, all the volume controls must
set to the exact same position.
5. While you use the microphone,
insert a flat bladed screwdriver
into the slot above the corre-
sponding volume control and
adjust it until you obtain a reading
of 0on the OUTPUT LEVEL VU
meters.
6. Temporarily set the MIC main vol-
ume control to 0.
7. Repeat Steps 4 through 7 to con-
nect and adjust the preset levels
of all your other audio input
sources.
Notes:
• Do not connect the high-level out-
puts of an audio source to the low-
level PHONO CERAMIC 2
(ceramic) jacks.
• Except for the PHONO ceramic
inputs, you can connect any high-
level audio source (tuner, cassette
tape deck, CD player, magnetic-
cartridge turntable, or VCR) to any
set of input jacks.
• Connect the ground wires (usually
black or green) from your mag-
netic cartridge turntable to the
GND screw terminal on the back of
the mixer.
PRE-ADJUSTING THE
MONITOR LEVELS
To listen in privacy or monitor the au-
dio source inputs so you can locate an
exact passage or section before mix-
ing it into the MAIN OUTPUT, insert a
pair of stereo headphones (not sup-
plied) equipped with a 1/4-inch plug
into the PHONES jack on the lower left
front corner of the mixer. Your local
Radio Shack store sells a wide selec-
tion of headphones.
1. Set the volume control of the input
sources to be monitored to their
minimum settings.
(illus)
(illus)
(illus)
32-3001.fm Page 5 Tuesday, August 10, 1999 8:02 AM

6
2. Set MONITOR to MIC to select the
remote microphone.
Note: The DJ’s microphone input
cannot be monitored.
3. Set MONITOR LEVEL to approxi-
mately halfway between mini-
mum and maximum.
4. Adjust the volume control of the
input source you selected until
you hear the signal in the head-
phones at the desired level.
Caution: Be careful not to acci-
dentally slide up the main volume
control of the monitored source
before you are ready to put it “on
the air.”
5. Repeat Steps 1 through 4 to
select and preadjust the monitor
volume level of the rest of the
audio input sources (PHONO 1,
PHONO 2, LINE 1, or LINE 2) you
want to monitor.
To monitor an audio input source, sim-
ply select the desired MONITOR switch
and use MONITOR LEVEL to adjust the
volume as desired.
Listening Safely
Do not listen at extremely high volume
levels. Extended, high-volume listen-
ing can lead to permanent hearing
loss.
Follow these guidelines to protect your
hearing, especially when you use
headphones.
• Always start by setting the volume
to the lowest level possible before
you begin listening. Put the ear-
phone or headsets on, then grad-
ually increase the volume as
necessary.
• Once you set the volume, do not
increase it. Over a period of time,
your ears adapt to the volume
level, so a volume level that does
not cause discomfort might still
damage your hearing.
Caution: As you begin to mix, be
careful not to get into the habit of al-
ways increasing volume levels to
achieve the proper balance. You can
bring high levels down just as easily
as bring low levels up. Try to keep the
independent level controls in the mid-
dle position (3to 8), and adjust the
overall volume with the MASTER vol-
ume control as well as the volume
control of your input audio equipment.
Listening at excessive volume levels
will soon give you ‘’tired ears’’ and you
won’t be as pleased with your finished
product later.
(illus)
(illus)
32-3001.fm Page 6 Tuesday, August 10, 1999 8:02 AM

7
OPERATION
BASIC OPERATION
You can mix up to 6 inputs at the
same time and use the built-in equal-
izer and echo generator to tailor the
sound as desired.
1. Set MASTER to approximately 5.
2. Set the switch above each volume
control to select the input you
want to activate. (For example, set
MIC HI/LOW to HI when you use a
high impedance microphone, or
LOW when you use a low imped-
ance microphone.
3. Adjust the corresponding volume
level control to obtain a reading of
0on the OUTPUT LEVEL VU
meters.
Note: The OUTPUT LEVEL VU
meter indicates the output signal
levels of the left and right chan-
nels.
4. Adjust MONITOR LEVEL clock-
wise to increase the main (DJ)
microphone’s volume; rotate it
counterclockwise to decrease the
volume.
5. Set ECHO BYPASS/ON to ON to
produce an ECHO effect and to
BYPASS to eliminate the ECHO
effect. (See “Using Echo.”)
6. Push in EQUALIZER BYPASS/ON
to
ON to operate the right and left
7-channel frequency equalizer
controls. (See “Using the 7-Band
Frequency Equalizer.”)
7. When two turntables (or other
audio components connected to
the
PHONO 1 and PHONO 2 inputs)
are playing at the same time, slide
FADER (PHONO 1/PHONO 2):
• Left, to fade in the volume of
PHONO 1 and fade out the vol-
ume of PHONO 2.
• Right, to fade in the volume of
PHONO 2 and fade out the vol-
ume of PHONO 1.
Note: This lets you quickly and
smoothly change from playing
PHONO 1 to playing PHONO 2 (or
vice versa).
8. Set the MASTER volume to the
desired volume.
9. Set POWER OFF/ON to OFF to turn
off the mixer’s power. The VU
meters lights go off.
(illus)
32-3001.fm Page 7 Tuesday, August 10, 1999 8:02 AM

8
USING THE “DJ’S”
MICROPHONE
Normal
For equal blending of voice and mu-
sic, set NORMAL/STANDBY/TALKOVER
to NORMAL. In the NORMAL mode, the
“DJ” MIC input is mixed to blend equal-
ly with all the main volume inputs
(MIC, PHONO 1, PHONO 2, LINE 1, and
LINE 2). You can adjust LEVEL to in-
crease or decrease the microphone
level without affecting the main vol-
ume inputs.
Talkover
Start with a microphone level that
gives a VU reading of 5to 3.
To talk over music, set NORMAL/
STANDBY/TALKOVER to TALKOVER.
The mixer automatically reduces all
the main volume inputs (MIC, PHONO
1, PHONO 2, LINE 1, and LINE 2) just
enough for you to hear yourself in the
headphones or speakers (over the
music).
When you finish speaking, set NOR-
MAL/STANDBY/TALKOVER to STAND-
BY. The mixer automatically returns all
the main volume inputs to their origi-
nal levels.
Standby
To disable the MIC INPUT microphone,
set NORMAL/STANDBY/TALKOVER to
STANDBY.
Note: Set MIC LEVEL to minimum (full
counterclockwise) when the micro-
phone is not in use.
USING ECHO
The echo mode is applied to the
sound after all the inputs are mixed.
Set ECHO BYPASS/ON to ON to turn on
the echo mode and activate the DE-
LAY and REPEAT functions. Set ECHO
BYPASS/ON to BYPASS to turn off the
echo mode.
The DELAY control lets you induce a
measured time delay to simulate an
echo. Set DELAY to full counterclock-
wise for a minimum (0) time delay and
to full clockwise for a maximum time
delay.
The REPEAT control lets you control
the length of time a tone is repeated
(reverberation). Set REPEAT to 10 for
the longest time and to 0 for the short-
est time.
(illus)
32-3001.fm Page 8 Tuesday, August 10, 1999 8:02 AM

9
USING THE 7-BAND
FREQUENCY
EQUALIZER
With the seven sliding frequency con-
trols, you can tailor the sound pro-
cessed through the mixer to fit the
acoustic surroundings and your per-
sonal taste.
Each control varies by ±12 dB the lev-
el of a narrow band of frequencies
centered around the frequency noted
between the controls (60 Hz, 150 Hz,
400 Hz, 1 kHz, 2.4 kHz, 6 kHz, and 15
kHz).
Set the EQUALIZER BYPASS/ON
switch to ON to turn on the frequency
equalizer. Then slide the control up to
boost the indicated frequency range or
down to reduce it.
Notes:
• If you set the control to the center
position, the frequency range is
unaltered.
• In order to provide smooth fre-
quency control, the effect of these
controls must overlap slightly.
Thus, the 1 kHz control has a
slight effect on the range of fre-
quencies covered by the 400 Hz
and the 2.4k Hz controls.
Frequency Purpose
60 Hz Adjusts the frequencies in the low bass range (low organ notes
and bass drums). Reduces rumble or other low-frequency noise
150 Hz Adjusts the frequencies in the low to middle bass range (low
organ notes, bass drums, timpani and some low-bass)
400 Hz Adjusts frequencies in the middle-bass range (timpani and
some low-bass instruments)
1 kHz Adjusts the range of frequencies in the middle frequency range
where the ear is most sensitive (vocals).
2.4 kHz Adjusts the range of frequencies in the upper middle frequency
range that include vocals and some upper-midrange instru-
ments (clarinet and saxophone)
6 kHz Adjusts the range of frequencies in the lower high frequency
range that include some vocals and upper-midrange instru-
ments (clarinet and saxophone).
15 kHz Adjusts high-frequency sounds (cymbals, flutes, and violins).
32-3001.fm Page 9 Tuesday, August 10, 1999 8:02 AM

10
TROUBLESHOOTING
Your SSM-1000 Mixer should require very little maintenance. If you do have prob-
lems, refer to the troubleshooting chart below for possible solutions.
Caution: Only a qualified service technician should perform repairs on this SSM-
1000 Mixer!
Problem Solution
Nothing works
Check the AC power connection.
Make sure the AC outlet is ‘’live’’.
Check the power connections to the rest of the system
(amplifier/receiver, etc.)
No signal from an
audio input source.
Check the control setting.
Check the connections between the mixer and the input
source.
Hum from PHONO Connect the turntable’s ground wire (usually black or
green) to one of the GND screws on the back of the
mixer.
Hum from other
inputs Make sure there are no low level inputs connected to the LINE 1 and 2 jacks.
Feedback “squeals” Move the microphone farther away from the output
speakers or use a directional microphone.
32-3001.fm Page 10 Tuesday, August 10, 1999 8:02 AM

11
CARE AND MAINTENANCE
Your Radio Shack Audio SSM-1000 Mixer with Echo is an example of superior de-
sign and craftsmanship. The following suggestions will help you care for your SSM-
1000 Mixer so you can enjoy it for years.
Keep the mixer dry. If it gets wet, wipe it dry immediately. Liquids
might contain minerals that can corrode the electronic circuits.
Use and store the mixer only in normal temperature environments.
Temperature extremes can shorten the life of electronic devices and
distort or melt plastic parts.
Keep the mixer away from dust and dirt, which can cause premature
wear of parts.
Handle the mixer gently and carefully. Dropping it can damage circuit
boards and cases and can cause the mixer to work improperly.
Wipe the mixer with a damp cloth occasionally to keep it looking new.
Do not use harsh chemicals, cleaning solvents, or strong detergents
to clean the mixer.
Modifying or tampering with the mixer’s internal components can cause a malfunc-
tion and might invalidate your mixer’s warranty (and void your FCC authorization to
operate it). If your mixer is not performing as it should, take it to your local Radio
Shack store for assistance.
CLEANER
32-3001.fm Page 11 Tuesday, August 10, 1999 8:02 AM

12
SPECIFICATIONS
Input Impedance
Microphone..................................................................................600 ohm (Low)
10k ohm (High)
Phono Magnetic 1 and 2........................................................................50k ohm
Phono Ceramic 1 and 2.......................................................................100k ohm
Line 1 and 2 .........................................................................................100k ohm
Output Level (Tape Out/Main Out)..................................................................2V
Sensitivity (Master volume at 10 (Max) position)
Microphone....................................................................................0.5 mV (Low)
2.5 mV (High)
Phono Magnetic 1 and 2.............................................................................3 mV
Phono Ceramic 1 and 2 .................................................................................. 2V
Line 1 and 2 (±3 dB Range)............................................................... 20–20 kHz
Signal-to-Noise (S/N) Ratio
Microphone................................................................................................55 dB
Phono Magnetic 1 and 2............................................................................ 65 dB
Line 1 and 2 ...............................................................................................70 dB
(T.H.D. at rated output (From 20 Hz to 20 kHz at Maximum Master Volume)
0.05 %)
Channel Separation at 1 kHz...........................................................................60 dB
Maximum Input Level
Microphone.................................................................................................7 mV
Phono Magnetic 1 and 2........................................................................... 20 mV
Phono Ceramic 1 and 2.............................................................more than 1.2 V
Line 1 and 2 (at Maximum Master Volume)..................................more than 1 V
Control Frequency Accuracy..................................................................+/- 10 %
(at 60 Hz, 150 Hz, 400 Hz, 1k Hz, 2.4k Hz, 6k Hz, 15k Hz)
Control Range at Rated Output ............................................................+/- 12 dB
32-3001.fm Page 12 Tuesday, August 10, 1999 8:02 AM

13
NOTES
32-3001.fm Page 13 Tuesday, August 10, 1999 8:02 AM

14
32-3001.fm Page 14 Tuesday, August 10, 1999 8:02 AM

15
32-3001.fm Page 15 Tuesday, August 10, 1999 8:02 AM

RADIO SHACK
A Division of Tandy Corporation
Fort Worth, Texas 76102
#A5 Printed in (Site)
RADIO SHACK LIMITED WARRANTY
This product is warranted against defects for 1 year from date of purchase from Radio
Shack company-owned stores and authorized Radio Shack franchisees and dealers.
Within this period, we will repair it without charge for parts and labor. Simply bring your
Radio Shack sales slip as proof of purchase date to any Radio Shack store. Warranty
does not cover transportation costs. Nor does it cover a product subjected to misuse or
accidental damage.
EXCEPT AS PROVIDED HEREIN, RADIO SHACK MAKES NO EXPRESS WARRAN-
TIES AND ANY IMPLIED WARRANTIES ARE LIMITED IN DURATION TO THE DURA-
TION OF THE WRITTEN LIMITED WARRANTIES CONTAINED HEREIN. Some states
do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limi-
tation(s) or exclusion(s) may not apply to the purchaser.
This warranty gives you specific legal rights and you may also have other rights which vary from
state to state.
We Service What We Sell
9/94
32-3001.fm Page 16 Tuesday, August 10, 1999 8:02 AM
