Radio Shack 10 Watt Guitar Amplifier User manual

1
CONTENTS
Connecting a Sound Source ................................................................................................ 2
Connecting Headphones ...................................................................................................... 2
Listening Safely ............................................................................................................ 2
Connecting to Power ............................................................................................................ 2
Turning Power On/Off .......................................................................................................... 2
Adjusting the Sound ............................................................................................................. 2
Using the amplifier As a Portable Public Address (PA) System ........................................... 3
Care ..................................................................................................................................... 3
Specifications ....................................................................................................................... 3

OWNER’S MANUAL — Please read before using this equipment.
©2000 RadioShack Corporation. All Rights Reserved.
RadioShack and RadioShack.com are trademarks
used by RadioShack Corporation.
10 Watt Guitar Amplifier
Your RadioShack 10 Watt Guitar Amplifier
can be used with sound sources such as an
electric guitar, keyboard, or microphone. The
amplifier is compact and portable, and you
can set it on almost any flat surface while
you practice or entertain. It provides 10 watts
RMS (Root Mean Square) for optimum
sound quality, and has these features:
Full-Range 8-Inch Speaker — for excellent
sound reproduction.
Rotary Volume, Base, Midrange, and Tre-
ble Controls — let you easily control the
sound.
1/4-Inch Input Jack — provides easy con-
nection to an instrument, or to a microphone
for use as a portable PA.
Headphone Jack — lets you connect head-
phones for private listening.
Distortion Control — lets you select a clear
sound or add the desired amount of distor-
tion to match your musical style.
Carry Handle — makes the amplifier easy to
carry. Cautions:
• To prevent electrical shock, any AC-
powered equipment that you connect to
the amplifier should be connected to a
3-prong (grounded) AC outlet.
• To avoid damaging the amplifier’s
speaker, connect the sound source to
the amplifier before you connect the
amplifier to power.
WARNING: To reduce the risk of fire or
shock hazard, do not expose this product to
rain or moisture.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER OR BACK. NO USER-SERVICE-
ABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED PERSONNEL.
This symbol is intended to alert
you to the presence of uninsulated
dangerous voltage within the prod-
uct’s enclosure that might be of
sufficient magnitude to constitute a
risk of electric shock. Do not open
the product’s case.
This symbol is intended to inform
you that important operating and
maintenance instructions are
included in the literature accompa-
nying this product.
!
!

2
CONNECTING A SOUND
SOURCE
Use a phono cable with a 1/4-inch (6.35 mm)
plug (such as RadioShack Cat. No. 42-2473
or 42-978, not supplied) to connect an electric
guitar, keyboard, or microphone to the INPUT
jack on the amplifier.
Caution: Be sure to turn VOLUME to 0before
you connect or disconnect a guitar’s cable to
the amplifier.
Note: For a smaller keyboard, you might need
a 1/8-inch to 1/4-inch plug adapter (Cat. No.
274-367).
CONNECTING HEADPHONES
To listen privately or to monitor the sound
source, connect low-impedance headphones
(not supplied) with a 1/4-inch (6.35 mm) plug to
the PHONES jack on the amplifier. Your local
RadioShack store sells a wide selection of
headphones.
Listening Safely
• To protect your hearing, follow these
guidelines when you use headphones.
• Set the volume to the lowest setting
before you begin listening. After you
begin listening, adjust the volume to a
comfortable level.
• Do not listen at extremely high volume
levels. Extended high-volume listening
can lead to permanent hearing loss.
• Once you set the volume, do not increase
it. Over time, your ears adapt to the
volume level, so a volume level that does
not cause discomfort might still damage
your hearing.
CONNECTING TO POWER
Make sure VOLUME is set to 0, then connect
the AC power cord to a standard AC outlet.
TURNING POWER ON/OFF
1. Turn VOLUME to 0.
2. Press POWER up to turn on the amplifier.
The power indicator lights.
3. Press POWER down to turn off the ampli-
fier.
ADJUSTING THE SOUND
Rotate TREBLE clockwise to boost or counter-
clockwise to cut high-range (treble) frequen-
cies (around 5 kHz). Boosting treble gives
your sound a clear high tone.
Rotate BASS clockwise to boost or counter-
clockwise to cut low-range (bass) frequencies
(around 80 Hz). Boosting the bass gives you a
heavier low tone.
Rotate MID clockwise to boost or counter-
clockwise to cut midrange frequencies
(around 800 Hz). Boosting the midrange gives
you a harmonic-rich sound.
Rotate VOLUME clockwise to increase or
counterclockwise to decrease the volume.
Rotate DISTORTION until you hear the amount
of distortion you want.
Here are examples of how to use the control
settings for different sounds. Experiment with
the settings until you find the combination that
best suits your style.
Heavy
Metal Rock Clear
Distortion 10 2 OFF
Volume 865
Treble 10 7 6
Mid 10 5 6
Bass 10 5 7

3
USING THE AMPLIFIER AS A
PORTABLE PUBLIC
ADDRESS (PA) SYSTEM
You can use the amplifier as a portable PA
system with a directional dynamic microphone
(not supplied) with a 1/4-inch plug. Simply in-
sert the microphone’s plug into the INPUT
jack.
CARE
Keep the amplifier dry; if it gets wet, wipe it dry
immediately. Use and store the amplifier only
in normal temperature environments. Handle
the amplifier carefully; do not drop it. Keep the
amplifier away from dust and dirt, and wipe it
with a damp cloth occasionally to keep it look-
ing new.
Modifying or tampering with the amplifier’s in-
ternal components can cause a malfunction
and might invalidate its warranty. If your am-
plifier is not performing as it should, take it to
your local RadioShack store for assistance.
Caution: You might permanently damage
your speaker by cleaning it with a vacuum
cleaner. Use a feather duster or a soft loose
cloth instead.
SPECIFICATIONS
Output Power ................................. 10 Watts,RMS
(4 Ohms, THD 10%)
Input Sensitivity ............................................ 50mV
(1 kHz; Max. Volume)
Treble, Mid, Bass set to 5
Distortion Off
Controls ................. Treble 10 kHz, ±12 dB Variable
Mid 2 kHz, ±12 dB Variable
Bass 40 Hz, ±15 dB Variable
Power Requirement ...................... 120 VAC, 60 Hz
Speaker ................................................. 8-inch, 4 Ω
Dimensions (HWD) ........... 13 ×121/2×51/4Inches
(33.5 ×31.5 ×13.5 cm)
Weight ......................................................... 5.2 kgs
(11.5 lbs)
Specifications are typical; individual units
might vary. Specifications are subject to
change and improvement without notice.

32-2045
08A00
Printed in China
RadioShack Corporation
Fort Worth, Texas 76102
Limited Ninety-Day Warranty
This product is warranted by RadioShack against manufacturing defects in material and workman-
ship under normal use for ninety (90) days from the date of purchase from RadioShack company-
owned stores and authorized RadioShack franchisees and dealers. EXCEPT AS PROVIDED
HEREIN, RadioShack MAKES NO EXPRESS WARRANTIES AND ANY IMPLIED WARRANTIES,
INCLUDING THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
ARE LIMITED IN DURATION TO THE DURATION OF THE WRITTEN LIMITED WARRANTIES
CONTAINED HEREIN. EXCEPT AS PROVIDED HEREIN, RadioShack SHALL HAVE NO LIABIL-
ITY OR RESPONSIBILITY TO CUSTOMER OR ANY OTHER PERSON OR ENTITY WITH RE-
SPECT TO ANY LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE
OR PERFORMANCE OF THE PRODUCT OR ARISING OUT OF ANY BREACH OF THIS WAR-
RANTY, INCLUDING, BUT NOT LIMITED TO, ANY DAMAGES RESULTING FROM INCONVE-
NIENCE, LOSS OF TIME, DATA, PROPERTY, REVENUE, OR PROFIT OR ANY INDIRECT,
SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, EVEN IF RadioShack HAS BEEN AD-
VISED OF THE POSSIBILITY OF SUCH DAMAGES.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limita-
tion of incidental or consequential damages, so the above limitations or exclusions may not apply to
you.
In the event of a product defect during the warranty period, take the product and the RadioShack
sales receipt as proof of purchase date to any RadioShack store. RadioShack will, at its option, un-
less otherwise provided by law: (a) correct the defect by product repair without charge for parts and
labor; (b) replace the product with one of the same or similar design; or (c) refund the purchase
price. All replaced parts and products, and products on which a refund is made, become the prop-
erty of RadioShack. New or reconditioned parts and products may be used in the performance of
warranty service. Repaired or replaced parts and products are warranted for the remainder of the
original warranty period. You will be charged for repair or replacement of the product made after the
expiration of the warranty period.
This warranty does not cover: (a) damage or failure caused by or attributable to acts of God, abuse,
accident, misuse, improper or abnormal usage, failure to follow instructions, improper installation or
maintenance, alteration, lightning or other incidence of excess voltage or current; (b) any repairs
other than those provided by a RadioShack Authorized Service Facility; (c) consumables such as
fuses or batteries; (d) cosmetic damage; (e) transportation, shipping or insurance costs; or (f) costs
of product removal, installation, set-up service adjustment or reinstallation.
This warranty gives you specific legal rights, and you may also have other rights which vary from
state to state.
RadioShack Customer Relations, 200 Taylor Street, 6th Floor, Fort Worth, TX 76102
We Service What We Sell 12/99
