Cat. No. 12-240
OWNER’S MANUAL
Please read before using this equipment.
Weatheradiowith Alert
12-240.fm Page 1 Tuesday, July 6, 1999 3:08 PM

2
FEATURES
Your Radio Shack Weatheradio with Alert is designed to
receive National Weather Service broadcasts. These
broadcasts provide information about weather conditions
and forecasts 24 hours a day. Your radio receives these
transmissions from up to 50 miles away. Its features in-
clude:
Alert Mode — monitors weather broadcasts and sounds
an alert siren in emergency weather situations.
Optional Siren Lock — sets the siren to sound until you
turn it off.
Siren Test Button — lets you check the alert siren to
make sure the alert circuit is operating.
Two Antennas — give you the option of using the power
cord or the telescoping antenna for the best reception.
Batter
y
Backup — automatically switches to internal
battery power if AC power is interrupted.
Three Channels — let you choose the frequency that
provides the best reception.
Cr
y
stal-Controlled Tunin
g
— provides accurate tuning.
©1996 Tandy Corporation.
All Rights Reserved.
Radio Shack and Weatheradio are registered trademarks
used by Tandy Corporation.
12-240.fm Page 2 Tuesday, July 6, 1999 3:08 PM

3
Warning: To prevent fire or shock hazard, do not expose
this product to rain or moisture.
This symbolis intended to alert you to the presence of unin-
sulated dangerous voltage within the product’s enclosure
that might be of sufficient magnitude to constitute a risk of
electric shock. Do not open the product’s case.
This symbol is intended to inform you that important operat-
ing and maintenance instructions are included in the litera-
ture accompanying this product.
The graphical symbols with supplemental markings are
located on the bottom of the unit.
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER OR BACK. NO USER-SERVICE-
ABLE PARTS INSIDE. REFER SERVIC-
ING TO QUALIFIED PERSONNEL.
CAUTION !
!
12-240.fm Page 3 Tuesday, July 6, 1999 3:08 PM

4
CONTENTS
Power Sources ............................................................ 5
Connecting AC Power ............................................ 5
Installing a Backup Battery ..................................... 5
Operation ..................................................................... 6
Receiving Weather Broadcasts .............................. 6
Using the Alert Mode .............................................. 7
Testing Alert Operation ........................................... 8
Testing the Alert Circuit .................................... 9
Testing Alert Reception .................................. 10
Care and Maintenance .............................................. 11
FCC Statement ..................................................... 12
Specifications ............................................................ 13
12-240.fm Page 4 Tuesday, July 6, 1999 3:08 PM

5
POWER SOURCES
CONNECTING AC POWER
Plug the Weatheradio’s power cord into a standard AC
outlet.
Caution: To prevent electric shock, the plug’s blades are
polarized and fit only one way. If the plug will not fit easi-
ly, turn it over and try again. Do not force it.
INSTALLING A BACKUP BATTERY
The radio automatically switches to battery power if AC
power fails. Follow these steps to install a 9-volt battery
(not supplied), such as RadioShack Cat. No. 23-553.
1. Remove the battery compartment cover by pressing
the tab in the direction of the arrow and lifting up the
cover.
2. Snap the battery connector onto the battery contacts.
3. Place the battery in the compartment and replace the
compartment cover.
12-240.fm Page 5 Tuesday, July 6, 1999 3:08 PM

6
OPERATION
RECEIVING WEATHER
BROADCASTS
Follow these steps to receive National Weather Service
(NWS) broadcasts.
1. To turn on the radio, turn VOLUME to the right until it
clicks. The alert indicator lights. When you turn on
the radio, it is set to the alert mode.
2. Press WEATHER to set the radio to receive weather
broadcasts. The alert indicator turns off.
3. Set ANTENNA to LINE.
Note: If the signal is broken or noisy, set ANTENNA to
ROD. Then unsnap the telescoping antenna and
extend it to its full length. If reception is still not clear,
try locating the radio near an outside wall or window.
4. Set CHANNEL to the frequency that provides the best
reception.
12-240.fm Page 6 Tuesday, July 6, 1999 3:08 PM

7
5. Adjust VOLUME to a comfortable listening level.
6. To turn off the radio, turn VOLUME to the left until it
clicks.
USING THE ALERT MODE
You can set the Weatheradio to alert you when the Na-
tional Weather Service broadcasts an emergency signal,
without having to listen to continuous weather updates.
Follow these steps to set the radio to the alert mode.
1. To turn on the radio, turn VOLUME to the right until it
clicks. The radio is in the alert mode and the alert
indicator lights. Then set VOLUME to its center posi-
tion.
Note: If the radio is set to receive weather broad-
casts, simply press ALERT to set the radio to the alert
mode. The alert indicator lights and the receiver is
silent.
2. Set ALERT LOCK as follows:
ON — The siren sounds until you press WEATHER to
silence it.
OFF — The siren sounds only during the 10-second
alert signal broadcast.
12-240.fm Page 7 Tuesday, July 6, 1999 3:08 PM

8
Note: We suggest you use the OFF setting when you
will be away from the radio so the siren does not dis-
turb others if it sounds. When you return, the radio’s
alert indicator flashes to let you know that the radio
received an alert signal broadcast.
3. When the radio receives an alert signal and sounds
the alert siren, press WEATHER. The siren stops (if it
is still sounding), the alert indicator stops flashing,
and you hear the current weather broadcast.
4. To turn off the radio, turn VOLUME to the left until it
clicks.
Caution: If severe weather threatens, do not wait for an
alert; turn on your radio and monitor the latest weather in-
formation.
TESTING ALERT OPERATION
For your Weatheradio to be effective, you must place the
radio where you can hear its alert tone (see “Testing the
Alert Circuit”) and where it can receive an emergency
alert broadcast (see “Testing Alert Reception”).
Once you determine a location that meets these two con-
ditions, leave the radio there for the best protection.
12-240.fm Page 8 Tuesday, July 6, 1999 3:08 PM

9
Testing the Alert Circuit
The TEST button lets you hear the alert siren the Weath-
eradio produces, but does not guarantee your radio will
receive an emergency alert broadcast (see “Testing Alert
Reception”).
Follow these steps to sound the alert siren.
1. Turn on the Weatheradio.
2. Press ALERT. The alert indicator lights.
3. Press and hold TEST. The siren sounds.
If ALERT LOCK is set to ON, press WEATHER to stop
the siren.
If ALERT LOCK is set to OFF, the siren sounds only
while you hold down TEST.
12-240.fm Page 9 Tuesday, July 6, 1999 3:08 PM

10
Testing Alert Reception
The fact that you get clear voice reception or that the si-
ren sounds when you press TEST does not guarantee
that an emergency alert broadcast will trigger your
Weatheradio’s alert siren. Also, if you are in a fringe area,
your radio might be triggered by an alert broadcast in one
area, but not be triggered if you place it somewhere else
(even close by).
To verify actual reception, your radio must receive a test
or emergency alert broadcast. The National Weather
Service (NWS) broadcasts a test alert every week on
Wednesday between 11 AM and 12 noon. To find out the
specific test schedule in your area, contact your local Na-
tional Oceanic and Atmospheric Administration (NOAA)
or National Weather Service office. These offices are
usually listed in the telephone directory under “US Gov-
ernment, Department of Commerce.”
To verify that your Weatheradio receives the test alert
properly, press ALERT before the time when the test alert
is broadcast in your local area. If the test alert broadcast
does not trigger your radio’s alert siren, you are either out
of range of the broadcast, the power cord is disconnect-
ed, or your radio’s batteries are weak.
Note: If you use your Weatheradio when you travel, be
sure to test it at its new location.
12-240.fm Page 10 Tuesday, July 6, 1999 3:08 PM

11
CARE AND MAINTENANCE
Your Weatheradio is an example of superior design and
craftsmanship. The following suggestions will help you
care for your radio so you can enjoy it for years.
Keep the radio dry. If it gets wet, wipe it dry
immediately. Liquids might contain miner-
als that can corrode the electronic circuits.
Use and store the radio only in normal tem-
perature environments. Temperature ex-
tremes can shorten the life of electronic
devices and distort or melt plastic parts.
Keep the radio away from dust and dirt,
which can cause premature wear of parts.
Handle the radio gently and carefully.
Dropping it can damage circuit boards and
cases and can cause the radio to work im-
properly.
Use only fresh batteries of the required
size and type. Old batteries can leak chem-
icals that damage your radio’s electronic
parts.
12-240.fm Page 11 Tuesday, July 6, 1999 3:08 PM

12
Wipe the Weatheradio with a damp cloth
occasionally to keep it looking new. Do not
use harsh chemicals, cleaning solvents, or
strong detergents to clean the radio.
Modifying or tampering with the Weatheradio’s internal
components can cause a malfunction and mightinvalidate
your radio’s warranty and void your FCC authorization to
operate it. If your radio is not performing as it should, take
it to your local Radio Shack store for assistance.
FCC STATEMENT
Your Weatheradio might cause TV or radio interference
even when it is operating properly. To determine whether
your radio is causing the interference, turn it off. If the in-
terference goes away, your radio is causing it. Try to
eliminate the interference by:
• Moving your radio away from the receiver
• Contacting your local Radio Shack store for help
If you cannot eliminate the interference, the FCC requires
that you stop using the radio.
CLEANER
12-240.fm Page 12 Tuesday, July 6, 1999 3:08 PM

13
SPECIFICATIONS
Frequency Coverage................Channel A: 162.400 MHz
Channel B: 162.475 MHz
Channel C: 162.550 MHz
Power Output......................................Maximum 440 mW
Power Supply...................... 120 Volts, 60 Hz, 5 watts AC
Battery Backup Power....9-Volt Battery (Cat. No. 23-553)
Antenna .............................Line Cord or Telescoping Rod
Dimensions (HWD) ....................13/4×61/16 ×41/8Inches
(45 ×153 ×104 mm)
Weight...................................................................15.5 oz
(439 g)
Specifications are typical; individual unit might vary.
Specifications are subject to change and improvement
without notice.
12-240.fm Page 13 Tuesday, July 6, 1999 3:08 PM

14
NOTES
12-240.fm Page 14 Tuesday, July 6, 1999 3:08 PM

15
12-240.fm Page 15 Tuesday, July 6, 1999 3:08 PM

RADIO SHACK
A Division of Tandy Corporation
Fort Worth, Texas 76102
4A6 Printed in China
RADIO SHACK LIMITED WARRANTY
This product is warranted against defects for 90 days from date of pur-
chase from Radio Shack company-owned stores and authorized
Radio Shack franchisees and dealers. Within this period, we will repair
it without charge for parts and labor. Simply bring your Radio Shack
sales slip as proof of purchase date to any Radio Shack store. War-
ranty does not cover transportation costs. Nor does it cover a product
subjected to misuse or accidental damage.
EXCEPT AS PROVIDED HEREIN, RADIO SHACK MAKES NO
EXPRESS WARRANTIES AND ANY IMPLIED WARRANTIES ARE
LIMITED IN DURATION TO THE DURATION OF THE WRITTEN LIM-
ITED WARRANTIES CONTAINED HEREIN. Some states do not per-
mit limitation or exclusion of implied warranties; therefore, the
aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.
This warranty gives you specific legal rights and you may also have other rights
which vary from state to state.
We Service What We Sell
9/94
12-240.fm Page 16 Tuesday, July 6, 1999 3:08 PM
