RADWAG WWG-2 Series User manual

WWG-2
USER MANUAL
ITKU-07-03-05-22-EN
LARGE-SIZE DISPLAY

2
MAY 2022

3
CONTENTS
1. GENERAL INFORMATION................................................................................................................................5
2. WARRANTY CONDITIONS ...............................................................................................................................5
3. MAINTENANCE .................................................................................................................................................5
3.1. Cleaning Stainless Steel Components........................................................................................................5
3.2. Cleaning ABS Components.........................................................................................................................6
4. SERVICE AND REPAIR.....................................................................................................................................6
5. RECYCLING.......................................................................................................................................................7
6. MECHANICAL DESIGN.....................................................................................................................................7
6.1. Dimensions..................................................................................................................................................7
6.2. Fixing Method..............................................................................................................................................7
6.3. Models .........................................................................................................................................................8
6.4. Technical Specifications..............................................................................................................................8
7. START-UP..........................................................................................................................................................8
8. COMMUNICATION WITH WEIGHING INDICATOR .........................................................................................8
9. COMMUNICATION PROTOCOL.......................................................................................................................9

4
PRECAUTIONS
Prior to installation, operation, or maintenance activities, carefully read this user
manual. Follow the instructions strictly.
Prior to the first use, carefully read this user manual. Use the device only
as intended.
The device must not be used in environments with explosive gases
or dust.
In the case of damage, immediately unplug the device from the mains.
The device to be decommissioned must be decommissioned
in accordance with valid legal regulations.

5
1. GENERAL INFORMATION
The WWG-2 large-size display is used to display mass from industrial scales
in challenging ambient conditions with strong external lighting (sunlight) and at
a great distance from the weighing indicator.
For use in harsh industrial environments, the display is housed in a stainless
steel housing. An additional bracket allows the display to be mounted on the
wall. The WWG-2 features a white diode backlight and a clear display
indicating digits of 4.4" (11.2 cm) in height. Communication with the weighing
indicator is established via the RS232 interface. The display is supplied with
230VAC.
2. WARRANTY CONDITIONS
A. RADWAG is obliged to repair or exchange all elements that appear to be
faulty by production or by construction.
B. Defining defects of unknown origin and methods for eliminating them can
only be accomplished with the assistance of the manufacturer and user
representatives.
C. RADWAG does not bear any responsibility for damage or losses
resulting from unauthorised or inadequate performing of production or
service processes.
D. The warranty does not cover:
damage from improper exploitation, thermal and chemical damage,
and damage caused by lightning, power grid overvoltage, or other
random event;
inappropriate cleaning habits.
E. Loss of warranty takes place if:
a repair is carried out outside RADWAG authorised service point,
the service claims intrusion into mechanical or electronic construction
by unauthorised people,
the device does not bear security seal stickers.
F. Contact with the central authorised service: [phone].
3. MAINTENANCE
In order to clean the large-size display risk-free, it is necessary to disconnect
it from the mains.
3.1. Cleaning Stainless Steel Components
Avoid using cleansers containing any corrosive chemicals, e.g. bleach
(with chlorine). Do not use cleansers containing abrasive substances.

6
Always remove the dirt with a microfiber cloth. Do it to avoid damage
to the protective coating.
Daily cleaning routine (removal of small stains):
1. Remove the dirt with a cloth dipped in warm water.
2. For best results, add a little bit of dishwashing detergent.
3.2. Cleaning ABS Components
To clean dry surfaces and avoid smudging, use clean, non-colouring cloths
made of cellulose or cotton. You can use a solution of water and detergent
(soap, dishwashing detergent, glass cleaner).
Gently rub the dirty surface and let it dry. Repeat the cleaning process
if necessary.
In the case of hard to remove contamination, e.g. residues of adhesive, rubber,
resin, polyurethane foam, etc., you can use special cleaning agents based on
a mixture of aliphatic hydrocarbons that do not dissolve plastics.
We recommend conducting tests before using the cleanser on all surfaces.
Do not use cleansers containing abrasive substances.
4. SERVICE AND REPAIR
In the event of a problem with the device's proper operation, contact
the nearest manufacturer's service point.
In the case of any sign of damage, it is necessary
to disconnect the device from the mains immediately.
The damaged component must be replaced or repaired by
RADWAG service directly.
In the case of defects, deliver the faulty product to the manufacturer's service
point. If the product cannot be delivered to the manufacturer's service point, call
the service and report the defect. A repair scope and method will be set up.
The user is NOT ALLOWED to carry out any kind of repair on
the device himself/herself. Any attempt at device
modification, repair, etc. by unauthorised persons will result
in the loss of validity of manufacturer-issued certificates,
declarations, and warranty.

7
5. RECYCLING
The device must be recycled; it should not be disposed of as regular household
waste. The device to be decommissioned must be decommissioned
in accordance with valid legal regulations.
6. MECHANICAL DESIGN
6.1. Dimensions
Fig.1. Dimensions of the WWG-2 large-size display
6.2. Fixing Method
Fig. 2. Way of fixing the WWG-2 large-size display.

8
6.3. Models
Symbol
Socket
Cable length
(standard)
Cable length
(maximum)
Housing
Associated
equipment
WWG-2/4
M12 8P
3m
10m
stainless steel
PUE H315, PUE HX7,
PUE HY10, PUE 5
WWG-2/5
DSUB 15
3m
10m
stainless steel
PUE 7.1, PUE C32
WWG-2/6
M12 8P
3m
10m
stainless steel
DWT
WWG-2/7
DB9/F
3m
10m
stainless steel
PUE C315
6.4. Technical Specifications
Housing
Stainless steel
Digit height
4.4” (11.2 cm)
Communication
RS232
Connection
Socket
Power supply
230VAC
Ingress protection
IP66/67
Operating temperature
- 20 °C ÷ + 40 °C
Dimensions (without handle)
635x195x48mm
7. START-UP
The WWG-2 large-size display should be connected to the scale's RS232 port
and then to the mains supply. When communication with the scale
is established, the background of the display is backlit and the mass value
is displayed.
8. COMMUNICATION WITH WEIGHING INDICATOR
The software manuals for individual weighing indicators
contain detailed instructions for configuring their
parameters for cooperation with the WWG-2 large-size
display.

9
9. COMMUNICATION PROTOCOL
The display supports a communication frame sent as a continuous
transmission.
Frame format supported by the display:
1
2
3
4
5
6
7-15
16
17
18
19
20
21
S
I
space
stability
marker
space
character
mass
space
unit
CR
LF
Command
3 characters, left justification
Stability marker
[space] if stable
[?] if unstable
[^] if high limit is out of range
[v] if low limit is out of range
Character
[space] for positive values
[-] for negative values
Mass
9 characters with decimal point, right justification
Unit
3 characters, left justification
