About Your Monitor
Dell™SP2309W Flat Panel Monitor User's Guide
Package Contents
Your monitor comes with all the items shown below. Ensure that you have all the items. If something is missing, contact Dell.

Package Contents
Product Features
Identifying Parts and Controls
Monitor Specifications
Universal Serial Bus (USB) Interface
Plug and Play Capability
Camera -MIC Specifications
Maintenance Guidelines
NOTE: Some items may be optional and may not ship with your monitor. Some features or media may not be available in
certain countries.

lMonitor with stand
lPower cable
lVGA cable
lDVI cable


Product Features

The SP2309Wflat panel display has an active matrix, thin-film transistor (TFT), liquid crystal display (LCD). The monitor features include:
■23 inches(585mm) diagonal.
■2048x1152resolution,plusfull-screen support for lower resolutions.
■Wide viewing angle to allow viewing from a sitting or standing position, or while moving from side-to-side.
■Tilt adjustment capabilities.
■Removable pedestal and Video Electronics Standards Association (VESA) 100 mm mounting holes for flexible mounting solutions.
■Plug and play capability if supported by your system.
■On-Screen Display (OSD) adjustments for ease of set-up and screen optimization.
■Software and documentation media which includes an information file (INF), Image Color Matching File (ICM), and product documentation.
■Security lock slot.
■2.0 Mega pixel internal webcam with integrated microphone.
Identifying Parts and Controls
Front View
lUSB up stream cable (enables the USB ports on the
monitor)
lUSB down stream cable (optional)
lDocumentation (Safety Information, Quick Start Guide
and CD)
Front View
Label
Description
1
Power Control (Touch Sensor)
2
Capacitive touch keys (For more information, see Operating the Monitor)
3
Webcam
4
Microphone

Back View

Side View

Bottom View
Back view
Back View with monitor stand
Label
Description
Use
1
VESA mounting holes (100mm)
(Behind attached VESA plate)
To mount the monitor.
2
Barcode serial number label
To contact Dell for technical support.
3
Security lock slot
To help secure your monitor.
4
Dell soundbar mounting brackets
To attach the optional Dell Soundbar.
5
Regulatory rating label
Lists the regulatory approvals.
6
Cable management slot
To organize cables by placing them through the slot.
Leftview
Right view
Label
Description
1
USB downstream port

Bottom view
Label
Description
1
AC power cord connector
2
HDMI connector
3
DVI connector
4
VGA connector
5
Audio Line-in
6
Audio Line-out
7
USB upstream port
8
USB downstream ports(2)
Monitor Specifications
The following sections give you information about the various power management modes and pin assignments for various connectors of your monitor.
Power Management Modes
If you have VESA's compliance display card or software installed in your PC, the monitor can automatically reduce its power consumption when not in use. This is referred to as
If the computer detects input from keyboard, mouse, or other input devices, the monitor automatically resumes functioning. The following table shows the power consumption and signaling of this
automatic power saving feature:
Activate the computer and 'wake up' the monitor to gain access to the OSD.
ZeropowerconsumptioninOFFmodecanonlybeachievedbydisconnectingthemaincablefromthemonitor.
VESA Modes
Horizontal Sync
Vertical Sync
Video
Power Indicator
Power Consumption
Normal operation and USB active
Active
Active
Active
White
75 W (maximum)
Normal operation
Active
Active
Active
White
65 W (typical)
Active-off mode
Inactive
Inactive
Blanked
Amber
Less than 2 W
Switch off
-
-
-
Off
Less than 1 W
NOTE: The OSD functions in the 'Normal operation' mode. One of the following messages appears when the menu key is touched in Active-
off mode.
or

Pin Assignments
VGA Connector
Pin
Number
15-pin Side of the Connected Signal Cable
1
Video-Red
2
Video-Green
3
Video-Blue

DVIConnector
HDMIConnector
4
GND
5
Self-test
6
GND-R
7
GND-G
8
GND-B
9
Computer 5V
10
GND-sync
11
GND
12
DDC data
13
H-sync
14
V-sync
15
DDC clock
Pin
Number
24-pin Side of the Connected Signal
Cable
1
TMDS RX2-
2
TMDS RX2+
3
TMDS Ground
4
Floating
5
Floating
6
DDC Clock
7
DDC Data
8
Floating
9
TMDS RX1-
10
TMDS RX1+
11
TMDS Ground
12
Floating
13
Floating
14
+5V power
15
Selftest
16
Hot Plug Detect
17
TMDS RX0-
18
TMDS RX0+
19
TMDS Ground
20
Floating
21
Floating
22
TMDS Ground
23
TMDS Clock+
24
TMDS Clock-

Pin
Number
19-pin Side of the Connected Signal
Cable
1
T.M.D.S. Data 2-
2
T.M.D.S. Data 2 Shield
3
T.M.D.S. Data 2+
4
T.M.D.S. Data 1+
5
T.M.D.S. Data 1 Shield
6
T.M.D.S. Data 1-
7
T.M.D.S. Data 0+
8
T.M.D.S. Data 0 Shield
9
T.M.D.S. Data 0-
10
T.M.D.S. Clock +
11
T.M.D.S. Clock Shield
12
T.M.D.S. Clock -
13
CEC
14
Reserved(N.C. on device)
15
SCL
16
SDA
17
DDC/CEC Ground
18
+5V Power
19
Hot Plug Detect
