Key features
• Stylish Aluminium enclosure
• Powerful Media Chip RealTek RTD1073 inside
• Including DTS, Dolby Digital, WMA and
AAC downmix support
• Supports: LAN 10/100 Mbps, RJ-45
• Supports: up to WiFi iEEE802.11n
(optional WiFi USB dongle required)
• Integrated Web radio function (MMS based)
• Video: MPEG-1, MPEG-2, MPEG-4: Xvid, WMV9, ISO, VOB,
IFO, MP4, DAT, MOV, AVI, MKV, H.264, TS, TP, M2TS, FLV
• Audio: MP3/OGG/WMA/WAV/AAC
• Image: HD-JPEG, JPG, BMP
• Supported cards: SD/SD-HC/MMC/MS
• Audio out: Stereo 2 Ch (RCA), SPDIF (optical)
• Video out: HDMI 1.3, Composite, Component
• File System: NTFS/FAT32
• Transfer rates: USB 2.0 up to 480 Mbit/s
• Supports Windows up to XP/Vista/Windows7, MAC OS >9/X,
• Controllable by remote control
IB-MP305A-B
Full HD Network Multimedia Adapter
Video formats AVI/MKV/TS/M2TS/MPG/MP4/MOV/VOB/
ISO/IFO/DAT/WMV/RM/RMVB,
FLV resolution up to 720p/1080i/1080p
Subtitle formats SRT, SMI, SSA, SUB, IDX+SUB
Subtitle codes UNICODE (UTF8), Western, Turkish,
Central European, Greek, Cyrillic,
Hebrew, SE European
Language support (GUI) English, Spanish, French, German,
Italian, Portuguese, Dutch, Czech,
Slovenian
Audio formats MP3/OGG/WMA/WAV/AAC
Picture formats HD-JPEG, JPG, BMP
Supported Video codecs MPEG-1
HD MPEG-2
HD MPEG-4 SP/ASP/AVC (H.264)
WMV9 (VC-1)
RealNetworks (RM/RMVB) 8/9/10,
up to 720p
Supported Audio codecs MP2/3, OGG Vorbis,
WMA Standard
(DRM, and Advanced Profile
not supported),
PCM, LPCM, AAC, RA, AC3, DTS
Technical data
Model IB-MP305A-B
Article No. / EAN code 25307 / 4250078184447
Colour Black
Brand ICY BOX
Article text Full HD Network Multimedia Adapter
Processor/System board RealTek RTD1073
Network support LAN 10/100 Mbps,
RJ-45, WLAN up to WiFi iEEE802.11n
(by optional WiFi dongle)
Network protocol SAMBA (SMB), UPnP
WEB function Webradio (MMS based)
File system NTFS/FAT32
Intergrated card reader SD, SD-HC/MMC/MS
External data interface 2x USB2.0 host,
1x card slot
External video interface Composite,
output Component,
HDMI 1.3a (up to 1920x1080p)
External audio interface Stereo L/R, SPDIF (optical)
Power supply Wall power supply:
AC 100-240 V, 50-60 Hz, 35 W, DC 5 V, 2,4 A
RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany
Telefon: +49-(0)4102 – 468 900 (Vertrieb) • Fax: +49-(0)4102 – 468 901 • www.raidsonic.de
Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted. RaidSonic
STORAGE SOLUTIONS WITHOUT LIMITS
Distinguished Performance
ICY BOX IB-MP305 is the media adapter which virtually
fulfills every need. It is a specialist for Full High definition
formats.
This means resolution of 1920 x 1080 p. It supports all
common video and audio formats, including Flash video,
Dolby Digital and DTS, the latter are delivered also through
HDMI. The ideal stage for its employment is a Full-HD
TV set or a home cinema system with demanding audio
components.
Even in the future the IB-MP305 will be in the lead as its
firmware is updatable. Media files are fed to the ICY BOX
via LAN, WiFi, USB or cardreader. Metal casing.
Packing content: IB-MP305A-B, power supply, A/V cable, component cable, remote control (incl. battery),
manual (German/English), quick installation guide (multilanguage)
Rear viewFront view / Side view
Logistical Data
Packing unit: 8 pcs./carton Dimension/carton: 498x385x288 mm Import tax: 8521 9000 90
Total weight: 11.8 kg/carton Dimension of packing box: 204x180x130 mm
Gross weight (incl. packing): 1.35 kg Dimension of article: 190x45x125 mm
Net weight: 0,585 kg Country of origin: China
1. Power supply IN 5. Stereo L/R interface
2. RJ-45 10/100 Mbp/s interface 6. Component interface
3. HDMI 1.3 interface 7. USB host interface
4. Composite interface 8. S/PDIF optical interface
1. USB LED
2. Power LED
3. Infrared window
4. Power button
5. USB host interface
6. Memory card slot
6.
1. 2. 4.3. 5. 7. 8.
1. 2. 3. 4.
5. 6.
