RAK 7205 User manual
2
RAK7205
2
RAK7258 Installation Guide V1.0
Table of Contents
1 Assembly list............................................................................................................................................. 3
2 Assembly....................................................................................................................................................4
3 Installation..................................................................................................................................................7
4 Contact Information.................................................................................................................................9
5 Revision History..................................................................................................................................... 10
6 Document Summary..............................................................................................................................10
3
RAK7205
3
RAK7258 Installation Guide V1.0
1Assembly list
Enclosure (1x) Installation Kit(1x)
LoRa Antenna (1x) GPS Antenna (1x)
Supporting plate (1x) Cable Gland Covers (4xM16, 2xM12)
PCB(1x) Battery and Adhesive Glue
4
RAK7205
4
RAK7258 Installation Guide V1.0
2Assembly
Step 1: Assemble the cover according to different requirements:
1) If there are no solar panels, plug the opening of the cover with M16
Dome plug.
2) If solar panel is needed, stick it to the cover with silicon glue.
Step 2: Installation of Supporting Plate with two M4*5 Screws
Step 3: Use three M16 Dome plugs and two M12 Dome plugs to plug the opening of the
bottom shell (left of the figure below). If an external antenna or an external interface is
needed, replace the corresponding hole with the corresponding cable (right or below).
5
RAK7205
5
RAK7258 Installation Guide V1.0
Step 4: PCB was fixed with three M2.5*4 screws.
Step 5: The Lora and GPS antennas are pasted into the bottom shell, in which the LORA
antenna is pasted above the M12 Dome plug and the GPS is pasted on the short side.
Step 6: Install two M2.5*15 hexagonal standoffs.
6
RAK7205
6
RAK7258 Installation Guide V1.0
Step 7: Plug the connector of the battery into the socket of the PCB. (If you use solar
panels, then connect the cable to the PCB). Then fix the supporting plate on the standoff
with two M2.5*4 screws.
Adhesive double-sided glue on the surface of the battery, and Adhesive the battery to the
supporting plate.
Caution: you must connect the battery cable first, otherwise you can't connect the cable after
installing the supporting plate.
Step 8: Install the cover.
7
RAK7205
7
RAK7258 Installation Guide V1.0
3Installation
3.1 Wall Mounting
Step 1: Fix the installation kit on the bottom of the enclosure with four M5*10 screws;
Step 2: Use Ø5mm drill head, drill 4 holes on the wall according to the dimension of the
following picture and then plug the srew anchors in the wall;
8
RAK7205
8
RAK7258 Installation Guide V1.0
Step 3: Use the tapping screws, attach the device to the wall.
3.2 Pole Mounting
Step 1: Fix the installation kit on the bottom of the enclosure with four M5*10 screws;
Step 2: Slide the Steel band clamps through the rectangular hole of the mount kit, wrap
the band clamps around the pole, lock them and then tighten the clamps using a
screwdriver.
9
RAK7205
9
RAK7258 Installation Guide V1.0
4Contact Information
Shenzhen Business
ken.yu@rakwireless.com
Room 506, Bldg B, New Compark, Pingshan First Road, Taoyuan Street, Nan
shan District, Shenzhen
Shenzhen Technical
steven.tang@rakwireless.com
0755-86108311
Room 506, Bldg B, New Compark, Pingshan First Road, Taoyuan Street, Nan
Shan District, Shenzhen
10
RAK7205
10
RAK7258 Installation Guide V1.0
5Revision History
Revision
Description
Date
1.0
Initial version
2019-01-15
6Document Summary
Document Name: Indoor LoRa Gateway RAK7258 Installation Guide
Product Name: Indoor LoRa Gateway
Release Date: January 2019
Revision Number: V1.0
Prepared by
Checked by:
Approved by:
Zenglei & Penn
Zenglei
About RAKwireless:
RAKwireless is the pioneer in providing innovative and diverse cellular and LoRa
connectivity solutions for IoT edge devices. It's easy and modular design can be used in
different IoT applications and accelerate time-to-market turnover.
For more information, please visit RAKwireless website at www.rakwireless.com.
