RAMVAC OWL Instruction Manual

OWL
(On Wall Logic)
User Guide
and
Installation

SOF_7.2.3-02-152
Effective date: 30-May-08
User Guide OWL
Thank you for selecting a RAMVAC OWL to serve your dental facility.
The RAMVAC OWL provides industry leading technology for convienient and efficient control of your utility room equip-
ment. While we’ve designed the OWL with the ability to control most brands of utility room equipment, its full capa-
bilities are realized when matched with intelligent controllers like those found on RAMVAC manufactured utility room
equipment.
Everything you need to install, operate and program your OWL is found in this manual, so here is all you need to do to
get started:
1. Take a few minutes to read the OWL Overview and OWL Features sections of this manual, to learn mor
about the capabilities of the OWL.
2. The Installation section should answer most of your questions on how to locate and install your OWL in
your facility. But if you do hit a snag, take comfort in knowing our industry leading Technical Service
professionals are just a phone call away and are always glad to help.
3. Once installed, the Operation and Programming sections will make using your OWL a breeze.
We at RAMVAC appreciate your business and take a personal interest in your complete satisfaction. Please let us
know how the system is working for you, by giving us a call or dropping by one of our exhibits at any major dental show.
Please accept my personal invitation to visit our manufacturing facility if you are ever in the beautiful Black Hills of South
Dakota.
Matt Olson
General Manager, RAMVAC Dental Products, Inc.
(800) 5-RAMVAC
Safety and Regulatory Information
RAMVAC’s meet the most current and highest safety standards. RAMVAC products are manufactured in an FDA regis-
tered, ISO 9001:2000 and ISO 13485:2003 certified facility.
Here is what you need to do to ensure the safety potential of this equipment is achieved:
· Make sure your equipment is installed according to the instructions found in this manual.
· Always use a RAMVAC supplied power source for powering any component in the OWL.
· Read and follow all local, state and federal codes and regulations pertaining to these types of installations.
· Never connect the OWL to any voltage higher than those recommended in this manual.
Inside Front Cover

Page 1SOF_7.2.3-02-152
Effective date: 30-May-08
OWL User Gude
Table of Contents
OWL User Interface Page 1
OWL and Compatible Controls Page 2
OWL Overview Page 3
OWL Feature Page 3
System Schematics Page 4-5
Electrical Connections Page 6
Operation and Monitoring
Main Level Operation Page 8-9
Unit Staus Operation Page 10-11
System Staus Operation Page 12-13
Owl Configuration Operation Page 14-15
Multiple Unit System
Understanding the System Page 18
Low Voltage Electrical Connections Page 19
System Layout for 2 Units Page 20
System Layout for 3-8 Units Page 21
Adjusting Vacuum Pressure Page 22
Overhead Piping Adjustments Page 23
RAMVAC Product Support Services Inside Back Cover
OWL User Interface
LCD Screen -
Displays OWL
menus and utility
room equipment
status
Run / Stop
Buttons & LED
Indicators - Use to
start / stop the
corresponding utility
room equipment.
LED Indicators
provide equipment
status.
Menu Buttons -
Use to navigate
the various OWL
menus to check
utility room
equipment status.

SOF_7.2.3-02-152
Effective date: 30-May-08
User Gude OWL
Page 2
OWL and Compatible Controls
OWL – Mounts in any convenient location.
Provides user control and interaction with
utility room equipment.
Interface Control – Provides
interface / communication between an OWL
and non-RAMVAC utility room equipment.
OWL Interface Control
S1 Electrols
C1 Control
OWL – Mounted controls on the RAMVAC vacuum
pumps and communicates with the OWL.
C1 Control – Mounted controls on the
CustomAirby RAMVAC air compressor and
communicates with the OWL.

Page 3SOF_7.2.3-02-152
Effective date: 30-May-08
OWL User Gude
OWL Overview
The OWL is a multi-functional, integrated electronic system designed to monitor and control dental utility room equip-
ment from a remote location. When used in conjunction with RAMVAC electronic controls, the OWL provides monitor-
ing, control, and displays alarms. The OWL is also flexible enough to provide start/stop functions for all other brands
of utility room equipment. The compact, attractive, easy to mount control panel features an easy to read LCD screen,
equipment control buttons, program navigation buttons, and LED indicator lights.
(OWLs are individually programmed at the RAMVAC manufacturing facility to meet the specific requirements of each facility)
OWL Features
For RAMVAC equipment:
· Automatic, sequential starting and stopping of up to 8 air compressors and 8 vacuum units based on user demand.
This feature continually sequences equipment on and off to meet varying system needs. The OWL also simplifies
maintenance by apportioning run time on each machine to balance equipment run hours. The OWL can also
simultaneously start and stop up to 8 water control valves.
· Programmable shut-off timer stops equipment at user-defined interval.
· Provides alerts when scheduled maintenance is due.
· Provides alerts when equipment has experienced a fault condition.
· Provides historical operating and fault data.
· Monitors run status of individual equipment.
For non-RAMVAC equipment:
· An Interface Control enables remote start/stop functions for up to 8 air compressors, 8 vacuum pumps, and 8 water
control valves.
· Programmable shut-off timer stops equipment at user-defined interval.

SOF_7.2.3-02-152
Effective date: 30-May-08
User Gude OWL
Page 4
System Schematics
Thin (Red) Solid Line - Power wires (2 – 18 ga. wires)
Thick (Black) Solid Line - Communication wires (3 – 18 ga. wires)
Dashed (Blue) Line – Other wiring
Typical applications
shown
Schematic 1: OWL and RAMVAC equipment (with water valve option)
Note: Transformer supplied with Interface Control
Wiring to water
valve solenoid
OWL
Interface Control
for Water Valve
S1 Electrols
C1 Control
Schematic 2: OWL and non-RAMVAC equipment (with water valve option)
Note: Transformer supplied with Interface Control
Interface Control
for Vacuum Unit
Interface Control for
Air Compressor
Interface Control
for Water Valve
OWL
Wiring to water
valve solenoid
Wiring to water
valve solenoid
Wiring to water
valve solenoid

Page 5SOF_7.2.3-02-152
Effective date: 30-May-08
OWL User Gude
S1 Electrols S1 Electrols
C1 Control
C1 Control
Interface Control
for Water Valve
Schematic 3: OWL and multiple RAMVAC controls (with water valve option and autowash)
Note: Transformer supplied with Interface Control
Schematic 4: Interface Control Connection for Water Valve
Interface Control
for AutoWash
Solenoid
R Y
Interface
Control
Supply Voltage
24 Volt Max
Wiring to water
valve solenoid
Wiring to
AutoWash
Vacuum Pessure Switch
Wired to S1
Electrols Node 1
S1 Electrols Node
Designation on top
OWL
C1 Control Node
Designation on top

SOF_7.2.3-02-152
Effective date: 30-May-08
User Gude OWL
Page 6
Electrical Connections
Communication Wires
The OWL communicates to the utility room equipment using a RS485 communication protocol across linked communication wires. RAMVAC
recommends using 4 conductor 18 gauge shielded wire , to provide communication and power to the OWL. The A terminal on the OWL must
attach to the A terminal on each of the equipment controls in the system. Likewise, the B terminal will connect to the B terminals on the equipment
controls. The C terminal on the OWL will connect to the shield on the wire. The shield will then connect to the C terminal on the S1 Electrols and
C1 Control, but does not connect to any Interface Controls in the system. Connections A2 and B2 on the OWL are not used.
Power for the OWL
The OWL requires a 12v DC power source to operate. On most systems (see Schematic 1) the power source can be either the S1 Electrols
or the air compressor C1 Control. If using the S1 or C1 for power, connect the 5 terminal on the S1/C1 to the 5 terminal on the OWL and the 6
terminal on the S1/C1 to the 6 terminal on the OWL. (1) These wires can be included in the wire bundle with the communication wires, but
will be connected to only ONE of the RAMVAC equipment controls in the system.
In systems that do not have RAMVAC controls (see Schematic 2), a wall transformer is supplied to provide power to the OWL. Connect the black
with white stripe wire from the transformer to the 5 terminal on the OWL and the black wire with text from the transformer to the 6 terminal on the
OWL.
Interface Control Wiring
The communication wires attach to the A and B terminals per the “Communication Wires” section above, but remember the shield does not
connect to any terminal on the remote module.
(2) A wall transformer is supplied with each Interface Control as a power source. Connect the black with white stripe wire from the
tranformer to the 5 terminal on the Interface Control and the black wire with text from the transformer to the 6 terminal on the Interface Control.
The Interface Control R and Y connections act as a switch to turn on and off any equipment and can handle up to 24 V. See (Schematic 4) for
a typical attachment to a solenoid. In most applications the interface control can be connected in place of the low voltage remote switch typically
used to turn on and off the equipment.
Note: An Interface Control must be used to operate any piece of equipment without a RAMVAC control.
Note: Systems with the optional AutoWash feature require a special Interface Control to control the AutoWash
function. Function of the AutoWash feature is then controlled through the OWL controller instead of the
S1 Electrols.
RAMVAC
OWL
Connections
RAMVAC
S1
Connections
CustomAirby RAMVAC
C1
Connections
RAMVAC
Interface Control
Connections
Communication
RS485 A A A A
RS485 B B B B
shield / gnd C C C N/A
DC + Voltage 5 5(1) See Power for Owl 5(1) See Power for Owl 5(2) See Interface Control Wiring
DC Gnd 6 6(1) See Power for Owl 6(1) See Power for Owl 6(2) See Interface Control Wiring
Low Voltage
Switching N/A N/A N/A R
Y

Page 7SOF_7.2.3-02-152
Effective date: 30-May-08
OWL User Gude
Notes

SOF_7.2.3-02-152
Effective date: 30-May-08
User Gude OWL
Page 8
Main Level Flow Chart
the Enter and Press Esc keys to change levels
Press the Next and Prev keys to change catagories
Maximum 4 presses on the esc button takes you back to the top level
Press Esc button
Press Enter button
RAMVAC OWL
ALL UNITS NORMAL
UNIT STATUS
SYSTEM STATUS
OWL CONFIGURATION
RAMVAC SUPPORT
800-572-6822
UNIT IN FAULT
ENTR FOR DETAILS
See Unit Staus
(enter)
*** Screen shows for 3 seconds on power-up***
See Unit Staus
See Unit Staus
See Unit Staus
(enter)
(enter)
(enter)
See Unit Staus
(enter)
(prev button)
(prev button)
(prev button)
(prev button)
(prev button)
OPERATION AND MONITORING
RAMVAC
REV 1.00

Page 9SOF_7.2.3-02-152
Effective date: 30-May-08
OWL User Gude
Main Level Descriptions
1. When power is applied, the OWL will show the OWL name and the revision number for 3 seconds.
2. After self test the OWL display will show one of the following 2 screens.
a. ALL UNITS NORMAL
i. All units connected are in the normal run or standby condition.
b. UNIT IN FAULT
i. One or more of the units are in fault and need attention.
ii. Select Enter on the keypad for more information. See UNIT STATUS page for FAULT HISTORY.
Select the Prev Button
3. UNIT STATUS
a. This path will lead to the individual status of a specified unit.
b. Select Enter on the keypad for second level. See UNIT STATUS page.
Select the Prev Button
4. SYSTEM STATUS
a. This path will lead to the status of the system as a whole.
b. Select Enter on the keypad for second level. See VACUUM SYSTEM STATUS page.
Select the Prev Button
5. OWL CONFIGURATION
a. This path shows the total hours of run time for the OWL system.
b. Select Enter on the keypad for second level. See OWL CONFIGURATION page.
c. Call RAMVAC [phone]
Select the Prev Button
6. RAMVAC SUPPORT
OPERATION AND MONITORING

SOF_7.2.3-02-152
Effective date: 30-May-08
User Gude OWL
Page 10
Unit Status Flow Chart
A=AVAIL M=MAINT
F=FAULT R=RUN
UNIT STATUS
UNIT IN FAULT
ENTR FOR DETAILS
UNIT STATUS
AIR WTR WSH
VAC
2 3 4
R A F
V1 MODE: AVAIL
NO FAULTS
V1 MODE: FAULT
“ fault description “
V1 MODE: RUNNING
NO FAULTS
V1 MODE: BYPASS
“ fault description “
FAULT HISTORY
MOST RECENT= 1
V1 UNIT LIFETIME
HOURS
V1 hours until
MAINT
VAC1 Hours
“ fault description “
01
01
VAC1 Hours
“ fault description “
02
2040
841
(enter) (enter)
(enter)
(enter)
(prev button)
(prev button)
(prev button)
Screen shows
for 3 secs.
Enter will show1 of the
following 4 options
Next or Prev button
changes the error
number
Use Prev and Next
buttons to move cursor
1
A
OPERATION AND MONITORING

Page 11SOF_7.2.3-02-152
Effective date: 30-May-08
OWL User Gude
Unit Status Description
1. UNIT STATUS
a. Enter on the keypad gives the UNIT STATUS equipment selection.
2. UNIT STATUS equipment selection
a. Gives a choice of the system equipment.
i. Next or Prev buttons on the keypad to toggle the equipment selection.
b. Enter on the keypad at the the equipment selection screen gives access to individual units and their mode status,
available in the selected equipment family.
Note: A mode description screen shows for 5 seconds before continuing to the individual unit selection.
A= Availible R= Run F = Fault
Note: This screen is accessed from two directions.
1. The normal direction outlined above.
2. From the UNIT IN FAULT screen on the first level.
c. The numbers 1,2,3,4 … in top row shows the unit numbers
d. The letters A,R,F below each number gives the status of the equipment selection in the system, corresponding to the number above it.
Note: The OWL only shows the equipment configured in the system.
e. Next or Prev arrow keys on the keypad to toggle the equipment selection.
f. Enter on the keypad produces one of four different screens.
g. Esc on the keypad returns to the UNIT STATUS screen.
Select Enter
3. EQUIPMENT MODE STATUS
a. Status - AVAIL The equipment selected is not running but is available to run if needed.
b. Status - RUNNING The equipment selected is running.
c. Status - FAULT The equipment selected is not running and is in fault.
d. Status - BYPASS The equipment selected is running but manually put in bypass.
i. This condition is reserved only for emergences. Running the pump during this condition will put the pump and warranty at risk.
Select the Prev Button
4. FAULT HISTORY
a. Enter on the keypad shows the unit selection history of faults starting with the most recent fault up to the last ten faults.
b. Next or Prev buttons on the keypad to toggle between the the range of faults.
c. Esc on the keypad gives the UNIT STATUS equipment selection screen.
Select the Prev Button
5. UNIT LIFETIME HOURS
a. Tells you how many hours the unit has run in its lifetime.
b. Esc on the keypad gives the UNIT STATUS equipment selection screen.
Select the Prev Button
6. UNIT HOURS UNTIL MAINTENANCE
a. Gives the number of run hours until maintenance is due on selected single units.
b. Esc on the keypad gives the UNIT STATUS equipment selection screen.
OPERATION AND MONITORING

SOF_7.2.3-02-152
Effective date: 30-May-08
User Gude OWL
Page 12
System Status Flow Chart
SYSTEM STATUS
SYSTEM STATUS
VACUUM SYSTEM HR DETAIL HOURS RUN WITH
UNITS HR
# #
(enter) (enter) (enter)
HOURS RUN WITH
UNITS HR
# #
FAULT HISTORY
MOST RECENT =
UNIT #1
FAULT
SYSTEM HR “of fault”
UNIT HR “of fault”
UNIT 1
FAULT
SYSTEM HR “of fault”
UNIT HR “of fault”
01
hr
hr
01
01 hr
hr
(enter) (enter)
(enter)
(prev button)
(prev button)
Next or Prev buttons toggles
the most recent system fault
Next or Prev buttons
toggles the number of
system units
OPERATION AND MONITORING

Page 13SOF_7.2.3-02-152
Effective date: 30-May-08
OWL User Gude
System Status Description
1. SYSTEM STATUS
a. Enter from the keypad gives the SYSTEM HOUR DETAIL screen.
b. Esc from the keypad returns to OWL startup screen.
2. VACUUM SYSTEM STATUS
a. Enter from the keypad produces the SYSTEM HOUR DETAIL screen.
b. Prev and Next buttons on the keypad to toggle the system from vacuum system to air system.
c. Esc from the keypad returns to the System Status screen.
Select Enter
3. SYSTEM HOUR DETAIL
a. Enter from the keypad produces a screen that shows the number of hours run by a selected number of units.
i. Next or Prev button on the keypad to toggle the number of units run from 1 to 8.
ii. Esc on the keypad returns to the SYSTEM HOUR DETAIL screen.
b. Next or Prev button on the keypad to go to the FAULT HISTORY SCREEN.
c. Esc from the keypad returns to the VACUUM SYSTEM STATUS screen.
Select Down Arrow
4. FAULT HISTORY – System
a. Enter from the keypad produces a screen wich shows the most recent fault is equal to 01.
i. Enter from the keypad produces a screen with the unit number with the most recent fault, the fault number,
and the name of the fault.
a. Enter from this screen gives the system hour and the unit hour the fault occurred for the selected fault number.
b. Esc from the keypad returns to the previous screen.
ii. Next or Prev button on the keypad to toggle through each unit and the fault numbers.
iii. Esc from the keypad returns to the FAULT HISTORY screen.
b. Esc from the keypad returns to the VACUUM SYSTEM STATUS screen.
OPERATION AND MONITORING

SOF_7.2.3-02-152
Effective date: 30-May-08
User Gude OWL
Page 14
OWL Configuration Flow Chart
OWL CONFIGURATION
OWL LIFETIME
HOURS ON HRS
#
REVISION
1.00
EDIT NODES
SYSTEM SHUTDOWN
DELAY = NONE HR
SYSTEM SHUTDOWN
DELAY = HRS
SYSTEM SHUTDOWN
DELAY = HRS
Next or Prev buttons toggles the hours
Enter locks it and Esc erases it
NONE
01
(enter)
(enter)
(prev button)
(prev button)
(prev button)
OPERATION AND MONITORING

Page 15SOF_7.2.3-02-152
Effective date: 30-May-08
OWL User Gude
OWL Configuration Description
1. OWL CONFIGURATION
a. Enter from the keypad produces the number of run hours over the OWL lifetime.
Select Prev Button
2. REVISION
a. Gives the revision number of the OWL.
Select Prev Button
3. EDIT NODES
a. No user information.
Select Prev Button
4. SYSTEM SHUTDOWN
a. Enter from the keypad produces the ability to set a timer for the run time of the system. Default is none.
b. Next or Prev buttons on the keypad to change the delay time (number of hours the system will run from 1 to 24 hours).
c. Esc from the keypad returns to OWL CONFIGURATION screen.
OPERATION AND MONITORING

SOF_7.2.3-02-152
Effective date: 30-May-08
User Gude OWL
Page 16
NOTES

Page 17SOF_7.2.3-02-152
Effective date: 30-May-08
OWL User Gude
NOTES

SOF_7.2.3-02-152
Effective date: 30-May-08
User Gude OWL
Page 18
The following pages contain information on multiple unit systems that will used
when installing and servicing the system.
Use these pages in conjunction with other applicable guides.
The OWL multiple unit system is an automated control system for the control of dental utility room equipment
from a centralized location, convenient to the dental office staff. The system automatically responds to demand so
that clinicians always have the power they need for safe, effortless operation while minimizing energy consumption
and hardware use.
Multiple units automatically selected to run by the computer minimize electrical consumption by operating
according to demand. Multiple pumps offer the advantage of extending service life by reducing the operating hours of
any one pump. Multiplexing inherently adds to backup capacity by decreasing dependency on any one device.
The Owl Controller requires a 12V DC power source to operate. On most systems, power can be provided by
an S1 Electrols or C1 Controller already in the system. On systems without an S1 or C1, a wall transformer provides
power for the OWL Controller.
In the system, the OWL is connected to one of the S1 Electrols mounted to one of the vacuum units or to one
of the C1 Controls mounted to one of the CustomAirby RAMVAC compressors. The system is turned on and off from the
OWL panel and automatically selects the pump with the lowest run-time.
With a 15 to 120 second period of “constant low pressure”, an adjustable pressure switch signals the
microprocessor to turn on units as needed to maintain desired vacuum strength. After the system returns to a
constant “normal vacuum strength” for a period of 15 minutes, unneeded power units are shut down. This “alternation
with record keeping” makes sure your pumps get used evenly with no individual pump working longer than the others.
When using the OWL with generic (other than RAMVAC) units, including vacuum pumps, air compressors,
or water valves, a RAMVAC Interface Control has to be used. It has the ability to communicate with the OWL to start
and stop the generic units but does not have the ability to collect any data. Therefore, for these units the OWL be-
comes a start/stop switch.
Understanding the System
MULTIPLE UNIT SYSTEMS
