R&T V2600 User manual

V2600/V2601
Installation Manual
Thank you for choosing our products.Please read the instructions carefully before
installation and keep it available for future maintenance or reference.

1.Checking the power and water supply
2.Function illustration of keys in main unit and actuator
Parts identification
Usage instruction
01
03
04
05
06
08
10
12
Content
Important safeguards
Technical specification
Daily maintenance
1.Main unit maintenance
2.Spray nozzle maintenance
Troubleshooting Guide
List of packing
3.Inlet filter cleaning
Installation instructions
1.Installation dimension
2.Installation of mounting plate
3.Installation and disassembly of main unit
4.Connecting the water supply pipe
4.Tank anti-freezing and anti-bacterial maintenance
noitcudortnI noitarepO

01
IMPORTANT SAFEGUARDS
READ ALL INSTRUCTIONS BEFORE USING
When using electrical products, especially when children are present, basic safety
precautions should always be followed, including the following:
1.The appliance is not to be used by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction.
2.Children being supervised not to play with the appliance.
3.This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved.
4.Children shall not play with the appliance.
5.Cleaning and user maintenance shall not be made by children without supervision.
DANGER–To reduce the risk of electrocution:
1. Do not use while bathing.
3. Do not place in or drop into water or other liquid.
4. Do not reach for a product that has fallen into water. Unplug immediately.
5. Do not wash the main unit or electrical plug with water or detergent.
6. Do not handle the electrical plug with wet hands.
7. Do not put a hand or other staff over the outlet of air dryer or block the outlet of air dryer.
8. Never disassemble,repair or modify this product.
9. During installation, disassembly, repaire and maintenance of the product,the power plug
must be switched off and water supply be shut off.
WARNING–To reduce the risk of burns, electrocution, fire, or injury to persons.
1. Close supervision is necessary when this product is used by, on, or near children or
invalids.
2. Use this product only for its intended use as described in this manual. Do not use
attachments not recommended by the manufacturer.
3. Never operate this product if it has a damaged cord or plug, if it is not working properly,
if it has been dropped or damaged, or dropped into water. Return the product to a
service center for examination and repair.
4. Keep the cord away from heated surfaces.
5. Never use while sleeping or drowsy.
6. Never drop or insert any object into any opening or hose.
7. Do not use outdoors or operate where aerosol (spray) products are being used or
where oxygen is being administered.
8. Connect this product to a properly grounded outlet only. See Grounding Instructions.
9. Do not throw cigarettes and other burning stuff into toilet, otherwise it might cause fire.
10.This product is electric appliance, so it must be placed far away from water. Please
don’t drench urine and other liquid to it.
11.Do not lay on side or upside the product during the electrical circuit.
12.It is prohibited to use other electric appliances in the same socket.
13.It is forbidden to use the power extension or unstable loose outlet.
14.The old aging water supply hose can not be used, otherwise it might cause leakage,
fire or electrical shock.Installation of the bidet seat should include specified components
and new water supply hose.
2. Do not place or store product where it can fall or be pulled into a tub or sink.

02
IMPORTANT SAFETY INSTRUCTIONS
1. Do not install or use the product in wet places as steam room etc.
2. It is recommended to use water-proof electrical outlet which should be lnstalled in the place
where is not easily got wet.
3. This product should be used with 110V-120V,50/60Hz electrical current only,load current
is at least 15A. Power plug must be equipped with ground fault circuit interrupter or ground
fault electrical leakage protector or similar high sensitive, rapid type leakage switch
(Rated sensitive current under 6mA).
4. When it thunders,it is strongly recommended to pull out the power plug.
5. Do not stand on ceramic toilet.
6. Ceramic toilet must install floor fixing bolt.
7. Do not stand on product unit,seat and cover.
8. Do not lean against the seat cover when using the product,to avoid damage.
9. This product is equipped with soft-closing seal cover.Heavy pressing or pushing may damage
the soft-closing damper.
10. Do not use lacquer thinner,petrol,liquid medicine,detergent,insecticide,toilet cleanser and
scrubbing brush to clean the product.
11.Exposure to direct sunlight is prohibited.
12.Only use tap water or potable water;otherwise it may cause chafing.
13.Do not connect water supply to heater outlet.Make sure inlet water temperature at 3~35℃.
14.When the room temperature is under zero degree,please dry up the water tank,to avoid
freezing.
15.Raise rest room temperature to prevent the toilet from damage due to freezing.
16.When move the product from cold or wet environment into normal room temperature,wait for
2 hours until the condensation water is fully volatilized.Doing so can prevent the product from
electrical short-circuit.
17.When not using the product over three(3) days,drain the water out of the container and pull
the electrical plug from the wall outlet.
18.Stop using the product and shut off the power when product malfunctions,please contact the
service people for professional service.
CAUTION–Indicates that failure to follow the instruction may cause body injury or
property damage.
GROUNDING INSTRUCTIONS
This product should be grounded. In the event of an electrical short circuit, grounding reduces
the risk of electric shock by providing an escape wire for the electric current. This product is
equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged
into an outlet that is properly installed and grounded.
DANGER –Improper use of the grounding plug can result in a risk of electric shock.
If repair or replacement of the cord or plug is necessary, do not connect the grounding wire to
either flat blade terminal. The wire with insulation having an outer surface that is green with or
without yellow stripes is the grounding wire.
This product is factory equipped with a specific electric cord and plug to permit connection to a
proper electric circuit. Make sure that the product is connected to an outlet having the same
configuration as the plug. No adapter should be used with this product. Do not modify the plug
provided — if it will not fit the outlet, have the proper outlet installed by a qualified electrician. If
the product must be reconnected for use on a different type of electric circuit, the reconnection
should be made by qualified service personnel.
SAVE THESE INSTRUCTIONS

03
600ml
Container capacity
1000W
250W
Rating power
Technical Specification
Main Unit
Rating pressure
Water pressure
range
Electrical wire length is about 1.0m
Minimum water pressure 0.07MPa (20L/min. flowing pressure).
Maximum water pressure 0.8MPa (Hydrostatic pressure)
1050-12500W
110-120V, 50/60Hz
Heating power
Water
temperature
Water volume
Cleansing mode
Spray cleansing
location
Water pressure
protector
Cleaning
device
Anti-fouling device
Safety device
4 different level adjustment
5 different level adjustment
5 different level adjustment
Rear cleaning/Rear massage, Front cleaning for ladies
Pressure stabilize , Automatic pressure discharging
Speedy water discharge device, Automatic nozzle cleaning,
Anti-siphon device, Anti-backflow device, Filter device
Warm wind speed
Warm wind
temperature
Heating power
Safety device
Drying
device
4 different level adjustment
＞4m/s
Temperature sensor, Temperature controller, Thermal fuse
Temperature controller, Thermal fuse, Ground protection,
Leakage protection device, burning preventer
Model V2600 V2601
50W
Heated seat
Surface
temperature
Heating power
Open and close
device
Prevent low
temperature burn
Safety device
Soft close
After 10 minutes of use, the seat temperature will
automatically drop to a low level
Seat sensor, emperature sensor, Temperature controller,T
Thermal fuse
Caring
device
Night light
assembly
Seat
Cover
Smart on / off; In the off state
Differ in
shape
Noise-free
setting The buzzer is off at night to avoid noise
Round
Round
Elongated
Elongated
4 different level adjustment

04
Packaging List
Base Plate
Parts
Water Supply
Assembly
Installation
paperboard
Installtion
Manual
Installtion Manual
T-connector
(1pcs)
Installation
paperboard
Installtion
Manual
Installation
paperboard
Main Unit
pcs
pcs
pcs
pcs
pcs
Base plate

Main unit identification
Water inlet
connector
Lid
Socket
Water
discharging cover
Main unit
disassembly
button
Drying device
Base plate Night light
Spray
nozzle
Seat
Wand
Hole for rear
cleaning
Hole for ladies’
front cleaning
Control panel
05
RESET
REMETTRE
TEST
TESTBEFORE EACH USE
1.PLUG INTO RECEPTACLE
2.PRESS RESET BUTTON:
VISUAL INDICATOR APPEARS.
3.PRESS TEST BUTTON:
VISUAL INDICATOR DISAPPEARS.
4.PRESS RESET FOR USE.
DONOT USE IF ABOVE TEST FAILS.
WARNING:

06
Installation lnstruction
Installation dimension
Note: Please check if the installation dimension matching the user’s toilet.
Press the expansion nuts into the installation holes in the toilet, then install the base plate,
plastic plates, flat washers and bolt as per the drawing and tighten the bolts.
Installation of mounting plate
The black pin frontward
and groove upwards.
Installation direction
Tip
Bolt
Washer
Plastic plate
Base plate
Expansion nut
Installation
paperboard
Note:
Unfold the installation paperboard, align the paperboard well fit ceramic
bowl from the tip, and then insert base plate to the paperboard
breach to make sure base plate allign with paperboard breach.

07
Installation and disassembly of main unit
Installation
Place the toilet seat on the base plate
until a "click" is heard.
Disassembly
Press the “removal button” ,until a “click”
is heard, and pull it out.
Installation Disassembly
Note:
Before pulling out the seat, release hand from “removal button”.
1. Side inlet: Install the T-connector onto angle valve, then attach the water supply hose
and tank inlet hose into T-connector.
2. Bottom inlet: Connect water supply on the inlet connector, then put supply hose and
power line through the relevant holes, finally install seat cover.
Connecting the water supply pipe
Power line hole
Water supply hole
Do not distort or damage the supply hose to avoid any leakage.
Do not use water supply hose and other accessories of other brands, which may cause danger.
Do not recommend to use our old water supply hose and accessories, which may cause danger.
Note:
T-connector
Water supply hose
Connect with seat water supply hose Connect with seat water supply hose
click
click
Method 1 Method 2
Water supply hose
T-connector

3. Smart self-checking start: one beep – one flash
of all indicator lights on control panel –power light
on – ECO light off - self-checking starting.
4. Smart self-checking finish: one beep –water temp
indicator on – wind & seat temp indicator off – two
grade indictor on – self-checking finished.
Installation instruction
Checking the power and water supply
1. Connect the water supply hose and turn on the
angle valve. Check if any leakage.
Turn on
*Applicable to the type with leakage protection plug.
5. Water begins to fill the tank of the bidet seat.
Wait 3 minutes for water heating.
Heating
Water inlet Wait for 3
minutes
2. Insert power plug into power socket, press
protection switch. Indicator light is on which
means there is electricity. (Prior to usage, press
leakage test button, protection switch bumps to
show that protection function works normally)
08
*Press the TEST button (then RESET button) every
month to assure proper operation.
* Please refer to the actual product.
Current detection
test button
Reset switch
Indicator light
RESET
REMETTRE
TEST
TEST BEFORE EACH USE
1. PLUG INTO RECEPTACLE
2. PRESS RESET BUTTON:
VISUAL INDICATOR APPEARS.
3. PRESS TEST BUTTON:
VISUAL INDICATOR DISAPPEARS.
4. PRESS RESET FOR USE.
DO NOT USE IF ABOVE TEST FAILS.
WARNING:

09
Mode & indicator instruction: 1. Power light on ECO light off means in normal mode;
2. ECO light on power light off means in ECO mode; 3. All lights off means in standby mode.
Default settings are moderate/middle level for all functions. Adjustable by control panel.
Control panel introduction
Rear/
Massage
When seated, short press “Rear/Massage” to wash
hip; short press “Rear/Massage” again to start
massage function.
Hip wash shall automatically switch to drying if
remain seated. The drying action will also finish
automatically.
When off seat, short press “Rear/Massage” to
start nozzle self-clean (nozzle will keep inside), then
nozzle will stretch out for a manually wipe clean.
Long press “Rear/Massage” to start a 90
seconds self-clean(nozzle will keep inside)
Front/
Massage
Dry
Water flow switcher
Water temp
button
Wind temp
button
Seat temp
button
Light button
Power/
ECO
Stop+Rear/Massage
When seated, short press “Front/Massage” to spray
wash the vagina; short press “Front/Massage” again
to start massage function. bidet shall automatically
switch to drying if remain seated. The drying action
will also finish automatically.
Short press “Dry” to start drying function. It will
stop automatically or when leaving the seat.
Short press “Water temp” to activate mild water, keep
short presses to switch water temp among “neutral-
Level1-Level2-Level3” .
Short press “Wind temp” to activate mild temp wind,
keep short presses to switch wind temp among
“neutral-Level1-Level2-Level3” .
Short press “Seat temp” to activate mild temp seat,
keep short presses to switch seat temp among
“neutral-Level1-Level2-Level3” .
Short press“Light” to turn on the light, short press
again to turn off the light. Long press“Light”, light
flashes twice and buzzer beeps once, then the light
turns on to enter “smart 7 hours” mode; Long press
“Light” again, light flashes twice and buzzer beeps
once, then the light turns off to exit “smart 7 hours”
mode.
When off seat, short press “Power/ECO” to enter
ECO mode, short press again to start normal mode,
long press to enter standby mode.
Mute mode operation: long press “Stop” then swift
press “Rear/Massage” to turn on mute mode.
Repeat the operation to switch back to normal mode.
Stop Cancel all actions/functions including rear cleaning,
front cleaning and drying.
If the product is not used for 72 hours, the water in the tank will automatically
discharge and replaced by fresh water.
Remark:
During “Rear” or “Front”, press water pressure
button of “+” and “-”, to adjust pressure for rear
and front cleaning.
Spray nozzle
position adjustment
During “Rear” or “Front”, press spray nozzle
button of “ < ” and “ > ”, to move the position
forward and backward.

10
Daily maintenance
Main unit maintenance
1. Shut of power supply at maintenance.
2. Turn the seat upward open, press down the button located on the right side of main
unit and pull out the seat.Wipe the stain with a soft damp cloth.
3. After cleaning, re-install the seat back.
Note:
Do not pour the water on the product.
Spray nozzle maintenance
Do the following to clean the wand.
Note:
1. Do not apply force when pushing or pulling the wand, as this may damage the mechanism.
2. Spray nozzle can be disassembled and cleaned.
1. Short press “Rear/Massage” to stretch out nozzle for a manually wipe clean using cloth
or banister brush.
2. Long press “Rear/Massage” start nozzle automatic self-clean without stretching out.
3. Short press “Rear/Massage” or “Stop” to finish clean action.

Inlet filter cleaning
1. Pull out electrical plug, then shut off water supply valve and remove water supply hose.
2. Remove the filter. Use the brush to clean the filter.
3. Put the filter back into inlet after cleaning. Then connect the water supply pipe.
Remove the filter.
Use the brush to
clean the filter.
When room temperature is under zero and electricity is disconnected, or user is away for a
long time. The water inside the tank should be discharged.
1. Open the tank cover, press the discharge button, turn on valve to discharge the water.
2. Slightly press the discharge button protruding part to turn off discharging valve and cover.
Tank anti-freezing and anti-bacterial maintenance
Turn on cover
Press downward the
protruding part
Press inward the
discharging button
Note: Before water discharging, the power must be cut off !
11

Switch to function mode, and
then wash after 3 minutes
Troubleshooting Guide
Problem Cause Solution
No flushing
Water supply hose buckling
causes block
Fill valve is off
Water supply is cut off
Poor flushing
Water supply hose buckling
causes partial block
Fill valve is not fully turned on
Filter is dirty and causes block
The water is not hot
The water temperature is setted
on normal temperature level
Solve the buckling
Turn on the fill valve
Connect water supply and
wait for the water
Solve the buckling
Turn on the fill valve fully
Clean the filter
Reset the water temperature
Seat temperature
is not hot
The seat temperature is setted
on normal temperature level
In standby mode
Reset the seat temperature
Shift to function mode for
3 minutes
No wind out
Spray wand
cannot retracted
Spray wand
cannot stretch out
The wind temperature is setted
on normal temperature level
In standby mode or power
save mode
Power off
Get stuck by impurities
Do not sit in sensing area Sit right in the sensing area
Re-connect the power
Clear away the impurities
Push back the wand lightly and
wait for the power
Shift to function mode to use
dry function
Reset the wind temperature
Power off
In standby mode or power
save mode
Wind temperature
is not hot
Caution
If the problems cannot be solved as per above methods,
please shut-off the power, and contact service providers for
maintenance.
If the leakage circuit breacker often trips off, it means the
product has electricity leakage, please shut-off the power,
and contact service provider for maintenance.
12

The picture of product may not entirely consistent with actual appearance and color
because of products improvement, please in kind prevail.
ASVFA26000002A-1.9
Xiamen R&T Plumbing Technology Co.,Ltd.
Add: No. 18, Houxiang Road, Haicang District, Xiamen, China
Tel: [phone]
Fax: [phone]
Http: //www.rtplumbing.com
E-mail: [email protected]
