Rane AM1 User manual

AUTOMIXER
AM1
CONTENTS (in order of appearance)
Important Safety Instructions
AM1 Manual
AM1 & AM2 Data Sheet
Sound System Interconnection
Rane Professional Installation Audio Products
Warranty
Declaration of Conformity
22268
AM1
AUTOMIXER
POWERLOCATE
PHONESMIX
SIG OL SIG OLLEVEL SIG OLLEVEL SIG OLLEVEL
MIC MIX
SIG OLLEVEL
AUX 1
SIG OLLEVEL
AUX 2
SIG OLLEVEL
USB
SIG OLLEVEL
OUTPUT
SIG OLLEVEL
AUX 2
AUX 1 USB
MICS OUTPUT
SOURCE
LEVELLEVEL
MIC INPUTS
1
234

ATTENTION: RISQUE DE CHOCS ELECTRIQUE - NE PAS OUVRIR
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
To reduce the risk of electrical shock, do not open the unit. No user
serviceable parts inside. Refer servicing to qualied service personnel.
e symbols shown below are internationally accepted symbols
that warn of potential hazards with electrical products.
is symbol indicates that a dangerous voltage
constituting a risk of electric shock is present
within this unit.
is symbol indicates that there are important
operating and maintenance instructions in the
literature accompanying this unit.
WARNING
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, registers, stoves, or other apparatus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A
grounding-type plug has two blades and a third grounding prong. e wide blade or third prong is provided for your safety. If the provided plug
does not t into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord and plug from being walked on or pinched particularly at plugs, convenience receptacles, and the point where it exits from
the apparatus.
11. Only use attachments and accessories specied by Rane.
12. Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply
cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
15. e plug on the power cord is the AC mains disconnect device and must remain readily operable. To completely disconnect this apparatus from
the AC mains, disconnect the power supply cord plug from the AC receptacle.
16. is apparatus shall be connected to a mains socket outlet with a protective earthing connection.
17. When permanently connected, an all-pole mains switch with a contact separation of at least 3 mm in each pole shall be incorporated in the
electrical installation of the building.
18. If rackmounting, provide adequate ventilation. Equipment may be located above or below this apparatus, but some equipment (like large power
ampliers) may cause an unacceptable amount of hum or may generate too much heat and degrade the performance of this apparatus.
19. is apparatus may be installed in an industry standard equipment rack. Use screws through all mounting holes to provide the best support.
WARNING: To reduce the risk of re or electric shock, do not expose this apparatus to rain or moisture. Apparatus shall not be exposed to dripping
or splashing and no objects lled with liquids, such as vases, shall be placed on the apparatus.
NOTE: is equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
ese limits are designed to provide reasonable protection against harmful interference in a residential installation. is equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modications not expressly approved by Rane Corporation could void the user's authority to operate the equipment.
CAN ICES-3 (B)/NMB-3(B)
Shielded CAT5e or better cables are required in order to comply with the FCC Rules part 15 limits for a Class B digital device.
WARNING: is product may contain chemicals known to the State of California to cause cancer, or birth defects or other reproductive harm.

ATTENTION: RISQUE DE CHOCS ELECTRIQUE - NE PAS OUVRIR
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
An d’éviter tout risque de choc électrique, ne pas ouvrir l’appareil.
Aucune pièce ne peut être changée par l’utilisateur. Contactez un
SAV qualié pour toute intervention.
Un câble blindé de CAT5 ou de qualité équivalente voir meilleure sont nécessaires an de se conformer à
la réglementation de la FCC chapitre 15 sur les limites concernant les appareils numériques de classe B.
Les symboles ci-dessous sont reconnus internationalement
comme prévenant tout risque électrique.
Ce symbole indique que cette unité utilise un
voltage élevé constituant un risque de choc
électrique.
Ce symbole indique la présence d’instructions
d’utilisation et de maintenance importantes dans le
document fourni.
ATTENTION
INSTRUCTIONS DE SÉCURITÉ
1. Lisez ces instructions.
2. Gardez précieusement ces instructions.
3. Respectez les avertissements.
4. Suivez toutes les instructions.
5. Ne pas utiliser près d’une source d’eau.
6. Ne nettoyer qu’avec un chion doux.
7. N’obstruer aucune évacuation d’air. Eectuez l’installation en suivant les instructions du fabricant.
8. Ne pas disposer près d’une source de chaleur, c-à-d tout appareil produisant de la chaleur sans exception.
9. Ne pas modier le cordon d’alimentation. Un cordon polarisé possède 2 lames, l’une plus large que l’autre. Un cordon avec tresse de masse possède
2 lames plus une 3è pour la terre. La lame large ou la tresse de masse assurent votre sécurité. Si le cordon fourni ne correspond pas à votre prise,
contactez votre électricien.
10. Faites en sorte que le cordon ne soit pas piétiné, ni au niveau du l, ni au niveau de ses broches, ni au niveau des connecteurs de vos appareils.
11. N’utilisez que des accessoires recommandés par Rane.
12. N’utilisez que les éléments de transport, stands, pieds ou tables spéciés par le fabricant ou vendu avec l’appareil. Quand vous utlisez une valise de
transport, prenez soin de vous déplacer avec cet équipement avec prudence an d’éviter tout risque de blessure.
13. Débranchez cet appareil pendant un orage ou si vous ne l’utilisez pas pendant un certain temps.
14. Adressez-vous à du personnel qualié pour tout service après vente. Celui-ci est nécessaire dans n’importe quel cas où l’appareil est abimé : si le
cordon ou les ches sont endommagés, si du liquide a été renversé ou si des objets sont tombés sur l’appareil, si celui-ci a été exposé à la pluie ou
l’humidité, s’il ne fonctionne pas correctement ou est tombé.
15. La che du cordon d’alimentation sert à brancher le courant alternatif AC et doit absolument rester accessible. Pour déconnecter totalement
l’appareil du secteur, débranchez le câble d’alimentation de la prise secteur.
16. Cet appareil doit être branché à une prise terre avec protection.
17. Quand il est branché de manière permanente, un disjoncteur tripolaire normalisé doit être incorporé dans l’installation électrique de l’immeuble.
18. En cas de montage en rack, laissez un espace susant pour la ventilation. Vous pouvez disposer d’autres appareils au-dessus ou en-dessous de celui-
ci, mais certains (tels que de gros amplicateurs) peuvent provoquer un buzz ou générer trop de chaleur au risque d’endommager votre appareil et
dégrader ses performances.
19. Cet appareil peut-être installé dans une baie standard ou un chassis normalisé pour un montage en rack. Visser chaque trou de chaque oreille de
rack pour une meilleure xation et sécurité.
ATTENTION: an d’éviter tout risque de feu ou de choc électrique, gardez cet appareil éloigné de toute source d’humidité et d’éclaboussures quelles
qu’elles soient. L’appareil doit également être éloigné de tout objet possédant du liquide (boisson en bouteilles, vases,…).
REMARQUE: Cet équipement a été testé et approuvé conforme aux limites pour un appareil numérique de classe B, conformément au chapitre 15
des règles de la FCC. Ces limites sont établis pour fournir une protection raisonnable contre tout risque d’interférences et peuvent provoquer une
énergie de radiofréquence s'il n'est pas installé et utilisé conformément aux instructions, peut également provoquer des interférences aux niveaux
des équipements de communication. Cependant, il n'existe aucune garantie que de telles interférences ne se produiront pas dans une installation
particulière. Si cet équipement provoque des interférences en réception radio ou télévision, ceci peut être detecté en mettant l'équipement sous/hors
tension, l'utilisateur est encouragé à essayer de corriger cette interférence par une ou plusieurs des mesures suivantes:
• Réorienter ou déplacer l'antenne de réception.
• Augmenter la distance entre l'équipement et le récepteur.
• Connecter l'équipement à une sortie sur un circuit diérent de celui sur lequel le récepteur est branché.
• Consulter un revendeur ou un technicien radio / TV expérimenté.
ATTENTION: Les changements ou modications non expressément approuvés par Rane Corporation peuvent annuler l'autorité de l'utilisateur à
manipuler cet équipement et rendre ainsi nulles toutes les conditions de garantie.
CAN ICES-3 (B)/NMB-3(B)
Cartons et papier à recycler.

Manual-1
AM1
AUTOMATIC MIXER
OPERATORS MANUAL
WEAR PARTS: is product contains no wear parts.
QUICK START
If you’re setting up the AM1 automixer, but your life depends
on getting back to Twitter® feeds and Facebook® posts, then this
Quick Start is for you. It’s intended to get your audio working
quickly in slightly more than 140 characters.
Plug microphones into the Mic Inputs using standard XLR
mic cables. Condenser mics need the MIC +48V switch posi-
tion. Use the MIC +0V middle position for dynamic mics. Use
the WIRELSS MIC position when a wireless receiver output is
connected.
When using the USB Charge-Only port, connect charg-
ing MP3 player audio into AUX 1 or AUX 2. Other line-level
sources (e.g., DVD/CD) may also use AUX 1 or AUX 2. Use the
USB Charge-Only port for keeping the iPod’s battery charged
during playback.
Connect the Main Output XLR to your amplier or powered
loudspeaker and select the LINE switch position. If the Main
Output feeds a microphone input, select the MIC position.
Connect the computer’s USB port to the USB Audio jack.
Once the Windows® or Apple® operating system recognizes the
AM1 as a stereo I/O device, the rear green USB light illuminates.
Start with all the front panel gray knobs turned all the way
down – fully counterclockwise. One at a time for each mic, talk
very loudly with a microphone at an appropriate distance for the
application and adjust the corresponding front panel LEVEL
control so only the loudest speech just barely ickers the red
overload (OL) indicators. Once the input gains are set, the AM1
automatically controls the mic mix to avoid feedback. (You won’t
need to ride these controls.)
Sources with output volume controls (e.g., iPods) need to be
turned up most of the way to get the hottest signal, but without
making the AM1 overload lights ash.
AM1
AUTOMIXER
POWER
LOCATE
PHONES
MIX
SIG
OL
SIG
OL
LEVEL
SIG
OL
LEVEL
SIG
OL
LEVEL
MIC MIX
SIG
OL
LEVEL
AUX 1
SIG
OL
LEVEL
AUX 2
SIG
OL
LEVEL
USB
SIG
OL
LEVEL
OUTPUT
SIG
OL
LEVEL
AUX 2
AUX 1
USB
MICS
OUTPUT
SOURCE
LEVELLEVEL
MIC INPUTS
1
2
3
4
Play audio from your computer’s audio software application
and select the Rane AM1 as the playback and/or recording de-
vice (See USB Audio later in this Manual). If the software oers
playback volume, turn it up all the way.
Turn on the amplier/loudspeaker and turn it up about
half way. Also turn the AM1 OUTPUT gray knob up until the
volume is appropriate for your application. Use the four gray Mix
knobs to adjust the relative volume of the sources.
If the system feeds back (that horrible squeal), something is
turned up too much. First try moving the mics farther from the
loudspeaker and/or pointing the mics and loudspeakers away
from each other. If this does not reduce feedback, don’t reach for
the black Mic Input knobs, instead turn down the gray Mic Mix
knob. While turning down the output or amplier may help,
this also turns down the iPod, CD or USB Audio, only hiding
the feedback problem.
If your system uses the AM1’s rear panel RAD Port, connect
a shielded CAT 5e cable (or better) from the AM1 to either the
wall plate RJ-45, or to a Rane HAL, EXP or Mongoose RAD
port. See the Rane RADX product for useful RJ-45 wall plates.
When cascading one or more AM2 automixers into the
AM1, be certain each Cascade In connection feeds a Cascade
Out. In a cascaded chain, the AM1 must be the last device
before the analog audio connection to the ampliers, powered
loudspeaker, or the digital RAD connection to a Rane HAL,
EXP or Mongoose RAD port. Only one AM1 can be included in
a cascaded system of AM1s and AM2s. And only the AM2 can
be cascaded into Halogen’s Gain-Sharing Auto Mixer and Room
Combine Processor DSP blocks.
Now you can tweet that your AM1 is working ne.

Manual-2
FRONT PANEL DESCRIPTION
1MIC INPUT LEVEL controls adjust the mic input gain. e green Signal indicators inform of audio presence. Overload
indicators warn of excessive signal levels.
2MIC MIX LEVEL control adjusts the volume of all mixed microhones, including all upstream microphones when cascading
additional mics from a Rane AM2 (sold separately). Signal and Overload indicators inform and warn.
3AUX 1 & AUX 2 MIX LEVEL controls alter the mix volume of the Aux 1 and Aux 2 inputs, respectively. Corresponding Signal
and Overload indicators ank each.
4USB MIX LEVEL control adjusts the mix volume of the USB audio received from a computer connected to the rear panel USB
Audio jack. Signal and Overload colors are reminiscent of holiday lights.
5Main OUTPUT LEVEL control adjusts the level of the mix exiting the XLR output and the RAD Port output. e Record
Output level is not aected by this control.
6PHONES SOURCE cue switch selects which audio is heard in the headphone outputs: the mix of all Mics, the Aux 1 input, the
Aux 2 input, the USB audio input, or the Main Output. is allows listening in headphones to any single input before turning
each up in the mix using the MIX controls, or listening to the main mix before turning it up in the PA for the world to hear.
7PHONES LEVEL control adjusts the volume of both the 3.5 mm and ¼" headphone jacks.
8PHONES include both 3.5 mm and ¼" headphone jacks for either size headphone plug.
9LOCATE indicator helps system installers identify a specic AM1 Automixer when using Rane’s Mongoose Tracker or Halogen
software.
0POWER indicator lights whenever adequate power is applied to the unit.
AM1
AUTOMIXER
POWER
LOCATE
PHONES
MIX
SIG
OL
SIG
OL
LEVEL
SIG
OL
LEVEL
SIG
OL
LEVEL
MIC MIX
SIG
OL
LEVEL
AUX 1
SIG
OL
LEVEL
AUX 2
SIG
OL
LEVEL
USB
SIG
OL
LEVEL
OUTPUT
SIG
OL
LEVEL
AUX 2
AUX 1
USB
MICS
OUTPUT
SOURCE
LEVELLEVEL
MIC INPUTS
1
2
3
4
1 2 5 84 6 7 903

Manual-3
REAR PANEL DESCRIPTION
1AC Power IEC input accepts electrons to power up the AM1. ough it is rst in this list, it’s best to connect it last.
2FAULT indicator lights when something goes awry.
LOCATE indicator ashes when toggled from the Mongoose Tracker or Halogen software. When using multiple AM1 devices in
a Rane Mongoose or HAL system, this uniquely identies a specic AM1.
USB indicator lights when a Windows or Apple operating system recognizes the AM1 as a stereo I/O sound card.
POWER indicator glows when owing electrons pass in and out of the AC Power IEC input.
3USB AUDIO connector allows simultaneous 16-bit, 48 kHz playback and recording via a computer. e AM1 registers as a
standard sound card with either Windows or Apple operating systems.
4CASCADE IN port permits adding up to 56 more microphones to the AM1’s 4 mic inputs using up to 7 Rane AM2 automixers,
sold separately. Use shielded Ethernet CAT 5e cable connected from the AM2’s Cascade Out.
5RAD PORT connects to either a Rane HAL or Mongoose Remote Audio Device port to transport the single-channel, Main Mix
of the AM1 to Rane’s expandable DSP or to a CobraNet network, respectively.
6CASCADE IN & RAD PORT status indicators prove that proper cable termination and device conguring has occurred when all
four indicators illuminate. If any of these are o or ashing, a conguration or wiring error is the culprit.
7MAIN OUTPUT XLR connector contains the main mix of all mics, Aux 1, Aux 2 and USB Audio input signals. e front panel
Output Level control adjusts the level exiting this jack.
MIC/LINE Output switch changes this Main XLR Output to mic-level, for feeding the output mix to a mic input device; or
line-level for feeding line-level input devices.
8RECORD Output RCA jacks contain the same audio mix as the Main Output. e signal is not aected by the Output Level
control.
9USB CHARGE-ONLY port powers and charges many USB devices such as iPods®.
0AUX INPUT 2 stereo 3.5 mm jack is internally monoed immediately and useful for connecting MP3 players of all kinds.
qAUX INPUT 1 dual RCA jacks are internally monoed immediately and enjoy being fed audio from CD, DVD, 8-Track tape
players, reel-to-reel machines, docking stations or iPhone®, iPod® or iPad® headphone jacks.
wMIC INPUTS 1 thru 4accept dynamic or condenser microphones, or the output of a wireless microphone receiver. ese inputs
are optimized for speech and have a xed 80 Hz low-cut and 7 kHz high-cut lter. Both lters are 2nd-order Butterworth lters.
e3-position switches support:
MIC +48V phantom power Mic position for condenser mics.
MIC +0V Mic position for dynamic mics.
WIRELESS MIC position intended for wireless mic receiver outputs.
1
2
3
4
5 8
9 q w
6 7 e0
100-240V
PATENT NO. 8,542,849
13 WATTS
50/60 Hz
USB
LOCATE
FAULT
POWER
MAIN OUTPUT
RAD PORT
AUX
INPUTS
MIC INPUTS
12341
2
RECORD
USB
AUDIO
POWER
COMM
AUDIO RX
AUDIO TX
MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC
5 VDC @ 500 mA
USB
CHARGE
ONLY
MIC LINE
CLASS 2 WIRING
CASCADE
SHIELDED CAT 5e OR BETTER • 24 VDC @ 100 mA
AM1
RANE CORPORATION

Manual-4
CONNECTION
Connect the AC power cord last to avoid loudspeakers hurting
your sensitive ears.
MIC INPUTS
e four mic jacks are balanced XLR inputs. Unbalanced mics
or wiring can also be used with their inherent lower quality and
higher potential for hum and noise. Standard microphone cable
with a two-conductor twisted pair plus a shield is best. Rane
follows the AES recommended practice of pin 2 positive (hot),
pin 3 negative, and pin 1 to shield. If your microphone is unbal-
anced (only two conductors), see the Sound System Interconnec-
tion RaneNote elsewhere in this manual or on Rane’s website for
the proper cable to use. Or better yet, get a balanced mic.
For condenser microphones which require phantom power,
use the MIC +48V switch position. Dynamic mics use the cen-
ter, MIC +0V position. When connecting a wireless microphone
receiver, use the WIRELESS MIC position.
AUX INPUTS
e two Aux inputs accept line-level audio for connection to
CD/DVD players and portable MP3 players utilizing the USB
Charge-Only port or its external charger.
While the physical ¼" and 3.5 mm jacks are both stereo, the
internal audio on both Aux inputs is immediately monoed since
the AM1 Mix is mono.
USB CHARGE-ONLY PORT
e USB Charge-Only port supplies 5 volts DC at up to 500
mA to charge iPods® and many other USB-powered devices. e
3.5 mm Aux 2 input is optimized to accept audio from devices
plugged in to the USB Charge-Only port.
RECORD OUTPUT
e RCA line-level outputs are unbalanced. Both RCA jacks
contain the same mono mix of the Mic, Aux, and USB Audio
inputs.
MAIN OUTPUT
e Main Output is a mono balanced XLR jack. Connect the
Main Output XLR using mic cable to your amplier or powered
loudspeaker and select the LINE position on the adjacent switch.
If the Main Output feeds a microphone snake or mic input,
select the MIC switch position.
USB AUDIO PORT
Connect a USB cable from this port to the computer’s USB port.
Once the operating system recognizes the AM1 as a stereo input
and output “sound card,” the rear panel USB indicator lights.
e AM1 can simultaneously playback and record via a com-
puter using this USB audio port.
RAD PORT
If your audio system delivers the AM1’s Main Output audio
mix using Rane’s digital audio transport technology exiting the
RAD Port, connect a shielded Ethernet patch cable to the RAD
Port. When the Rane Mongoose or HAL at the other end of
this connection recognizes the AM1’s RAD Port, audio nirvana
is achieved and all four adjacent RAD Port Status indicators
illuminate.
CASCADE IN
Connect a shielded Ethernet patch cable from the CASCADE
IN port to a Rane AM2’s CASCADE OUT port to add more
mics to the mic mix of an AM1. All four CASCADE IN Status
Indicators illuminate when the two devices recognize each other.
Connect up to seven Rane AM2 Automixers to add up to 56
more mics. Be certain to connect CASCADE OUT to CAS-
CADE IN throughout – otherwise, nirvana won’t be achieved.
Note: Only one AM1 Automixer is permitted in a cascaded
system. When cascading mixers, the AM1 must be the device
that feeds the Mongoose or HAL. In other words, the AM1
RAD Port wires to the Mongoose or HAL, and up to seven
AM2 mixers chain together into the AM1’s CASCADE IN. See
the illustration below.
CASCADE
RAD PORT
USB
DATA
OUTPUT MIC INPUTS
12345678
100-240V
13 WATTS
50/60 Hz
MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC
INOUT
USB
LOCATE
FAULT
POWER
CLASS 2 WIRING
MIC LINE
SHIELDED CAT 5e OR BETTER • 24 VDC @ 100 mA
PATENT NO. 8,542,849
AM2
RANE CORPORATION
CASCADE
RAD PORT
USB
DATA
OUTPUT MIC INPUTS
12345678
100-240V
13 WATTS
50/60 Hz
MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC
INOUT
USB
LOCATE
FAULT
POWER
CLASS 2 WIRING
MIC LINE
SHIELDED CAT 5e OR BETTER • 24 VDC @ 100 mA
PATENT NO. 8,542,849
AM2
RANE CORPORATION
CASCADE
RAD PORT
USB
DATA
OUTPUT MIC INPUTS
12345678
100-240V
13 WATTS
50/60 Hz
MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC
INOUT
USB
LOCATE
FAULT
POWER
CLASS 2 WIRING
MIC LINE
SHIELDED CAT 5e OR BETTER • 24 VDC @ 100 mA
PATENT NO. 8,542,849
AM2
RANE CORPORATION
CASCADE
RAD PORT
USB
DATA
OUTPUT MIC INPUTS
12345678
100-240V
13 WATTS
50/60 Hz
MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC
INOUT
USB
LOCATE
FAULT
POWER
CLASS 2 WIRING
MIC LINE
SHIELDED CAT 5e OR BETTER • 24 VDC @ 100 mA
PATENT NO. 8,542,849
AM2
RANE CORPORATION
CASCADE
RAD PORT
USB
DATA
OUTPUT MIC INPUTS
12345678
100-240V
13 WATTS
50/60 Hz
MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC
INOUT
USB
LOCATE
FAULT
POWER
CLASS 2 WIRING
MIC LINE
SHIELDED CAT 5e OR BETTER • 24 VDC @ 100 mA
PATENT NO. 8,542,849
AM2
RANE CORPORATION
CASCADE
RAD PORT
USB
DATA
OUTPUT MIC INPUTS
12345678
100-240V
13 WATTS
50/60 Hz
MIC +48V MIC +0V
WIRELESS MIC
MIC +48V MIC +0V
WIRELESS MIC
MIC +48V MIC +0V
WIRELESS MIC
MIC +48V MIC +0V
WIRELESS MIC
INOUT
USB
LOCATE
FAULT
POWER
CLASS 2 WIRING
MIC LINE
SHIELDED CAT 5e OR BETTER • 24 VDC @ 100 mA
PATENT NO. 8,542,849
AM2
RANE CORPORATION
100-240V
PATENT NO. 8,542,849
13 WATTS
50/60 Hz
USB
LOCATE
FAULT
POWER
MAIN OUTPUT
RAD PORT
AUX
INPUTS
MIC INPUTS
12341
2
RECORD
USB
AUDIO
POWER
COMM
AUDIO RX
AUDIO TX
MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC
5 VDC @ 500 mA
USB
CHARGE
ONLY
MIC LINE
CLASS 2 WIRING
CASCADE
SHIELDED CAT 5e OR BETTER • 24 VDC @ 100 mA
AM1
RANE CORPORATION
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
REMOTE AUDIO DEVICES & DRs
DIGITAL REMOTES
EXPANSION BUS
ETHERNET
REMOTE AUDIO DEVICES
DIGITAL REMOTES
123412345678
4
12345678
321
LINK
LAN
LINK
COMM
POWER
COMM
POWER
AUDIO TX
AUDIO RX
MIC / LINE INPUTS
LINE OUTPUTS
8
7
6
5
4
3
2
1
8
7
6
5
4
3
2
1
RELAY OUT
LOGIC IN
C
NC
NO
C
NC
NO
G
4
3
2
1
G
2
1
SHIELDED CAT5e OR BETTER 24 VDC @ 100 mA24 VDC @ 50 mA
HAL1 X
100-240 V
50/60 Hz 55 WATTS
CLASS 2 WIRING
RANE CORPORATION
AM1 Automixer
HAL Multiprocessor
AM2 Automixer
AM2 Automixer
AM2 Automixer
AM2 Automixer
AM2 Automixer
AM2 Automixer (up to seven)

Manual-5
MIC INPUTS
e rear panel three-position switch sets the appropriate gain for
condenser, dynamic and wireless microphones as well as select-
ing phantom power for condenser microphones. e Mic Inputs
are automatically mixed using a gain-sharing algorithm. Set
the inputs using the black knobs so they do not (or rarely) clip.
en, sit back and relax. If you’ve already set up the inputs and
someone starts talking louder/closer than you expected, feel free
to turn them down a little.
e green Signal indicators should easily light for soft talk-
ers even at relatively low Level settings. e Overload indicator
should light only occasionally for only the loudest talkers.
e gray Mic Mix knob adjusts the level of the automatic
mix of all Mic Inputs. Use it to change the mix of all the Mics
relative to the Aux 1, Aux 2 and USB Audio Line Inputs. Even
when multiple Rane AM2 Automixers are cascaded into an AM1
providing additional microphones, the Mic Mix knob on the
AM1 still adjusts the overall mix of all microphones – up to 60
mics when using seven AM2s. e Overload indicator adjacent
to the Mic Mix knob indicates that the mix of all mics is getting
too loud for the internal circuitry. It can light occasionally, but
only during the loudest talking.
Since these Mic Inputs and their underlying gain-sharing au-
tomix algorithm are designed and optimized for speech signals,
do not use these Inputs with non-speech audio signals such as
musical instruments or CD/DVD.
AUX INPUTS
e 3.5 mm Aux 2 input jack is optimized for use with devices
connected to the adjacent USB Charge-Only port. For other
audio sources , use the Aux 1 RCA jacks. Since the AM1 mix is
mono, audio at these two stereo inputs is monoed upon entering
the AM1. Adjust the front panel Aux Level controls for Aux 1
and Aux 2 to set the relative mix of these sources. e Overload
indicators light when the incoming audio is getting too loud.
Only the very loudest audio sources should occasionally light the
Overload indicator.
If you’re using an iPod® or other aux/line source that allows
output volume adjustments, turn the volume up as far as possible
without lighting the Overload indicator too often.
MIXING
e Mic Inputs are automatically mixed. Use the four gray Mix
knobs to adjust the relative volume of the four inputs: Mic Mix,
Aux 1, Aux 2 and USB Audio from the PC. e red overload
indicators should light only when the loudest source sounds are
running at full-tilt boogie.
OUTPUTS
All the AM1 audio outputs, digital and analog, contain a mono
mix of the automatically mixed Mics and manually mixed Line
Inputs from the four gray Mix knobs.
RECORD OUTPUT
e level or volume of the Record Output is not altered by the
AM1’s front panel Output level control. is permits consistent
recording levels on your favorite recording device, while adjust-
ing the volume in the room / PA system.
MAIN OUTPUT
e front panel Output Level control adjusts the level of this
output.
HEADPHONE AND CUEING
Plug in headphones and adjust the Phones Level knob to a com-
fortable volume. All headphone audio is mono – just like all the
other AM1 outputs.
e Source knob allows cueing each mix source indepen-
dently. is allows verication that a source is working properly
before bringing it into the mix.
With the Source set to Output, the entire mix is heard. Use
the four gray Mix knobs to adjust the relative volume of each
source. Select Mic Mix to hear the automatic mix of all micro-
phones in the system. Select Aux 1, Aux 2 or USB to hear each
of these inputs individually.
Use only one of the headphone jacks at a time.
AM1
AUTOMIXER
POWER
LOCATE
PHONES
MIX
SIG
OL
SIG
OL
LEVEL
SIG
OL
LEVEL
SIG
OL
LEVEL
MIC MIX
SIG
OL
LEVEL
AUX 1
SIG
OL
LEVEL
AUX 2
SIG
OL
LEVEL
USB
SIG
OL
LEVEL
OUTPUT
SIG
OL
LEVEL
AUX 2
AUX 1
USB
MICS
OUTPUT
SOURCE
LEVELLEVEL
MIC INPUTS
1
2
3
4
OPERATION

Manual-6
CASCADE IN PORT
e Cascade Input allows more mics to be added to the gain-
sharing mic mix algorithm of the AM1’s four Mic Inputs. When
a shielded Ethernet patch cable fed from an AM2 is connected
here, all cascaded AM2 microphones are automatically added to
the automatic Mic Mix of the AM1. (US Patent Pending.)
Cascade audio is 24-bit, 48 kHz, xed-point for the curious
audio nerd.
To add more microphones to your system, use a Ethernet
patch cable to connect an AM2 CASCADE OUT port to the
AM1 CASCADE IN port. Doing so allows all 12 mixed micro-
phones (eight AM2 + four AM1) to be heard at the AM1’s Main,
Record, USB Audio and RAD Port Outputs.
When all four Cascade Status indicators light, this means
the cable is wired properly. If any of the Status indicators are
ashing, the cable is not wired properly or damaged. In this case,
perhaps an Ethernet crossover cable was accidentally connected,
or the cable crimp has an error.
We recommend using shielded twisted-pair for the best EMI
performance.
CASCADE IN Status indicators are dened below:
AUDIO TX LED – lights when the AM1’s audio is successfully
transmitted to, and received by, the AM2. If this is o, check
the cable.
AUDIO RX LED – lights when the connected AM2 successfully
sends audio which also proves this twist in the cable is correct.
COMM LED – lights green when the AM2’s Cascade Out is
properly communicating with the AM1 and proves that the
twisted pair for Comm in the cable is good. If this indicator is
o, the cable is not a happy camper.
POWER LED – is always on when the AM1 is powered. If the
AM1 is powered and this is o, make sure the power twisted
pair in the connected cable is not shorted.
RAD PORT
e RAD Port contains a Rane-specic digital audio transport
protocol allowing audio delivery to either a Rane HAL, EXP or
Mongoose RAD port (each sold separately). e audio exiting
the RAD Port contains the main mix and is attenuated by the
AM1’s front panel Output Level control. is port can only be
used to connect to a Rane Mongoose or HAL.
For inquisitive technophiles, RAD Port audio is 24-bit,
48kHz, xed-point.
RAD PORT Status indicators are dened below:
AUDIO TX LED – lights green when communications with the
Mongoose or HAL has been established and is receiving the
AM1’s Tx audio. If this indicator is o, either the cable is bad,
or there is a communications error between the Mongoose or
HAL and AM1 RAD Port (see COMM LED below).
AUDIO RX LED – lights green when the RAD Port successfully
receives audio from the Mongoose or HAL. If this indicator is
o, you may have a bad cable, or the Mongoose or HAL at the
other end of the cable is not powered or connected.
COMM LED – lights green when communication is established
between the Mongoose or HAL and the AM1. is indicator
turns o if the RAD Port cannot communcate with the
Mongoose or HAL for some reason – most likely due to a
faulty cable.
POWER LED – lights green when the RAD Port is receiving 24
volt power from the Mongoose or HAL. is also indicates
that the twisted pair for power within the cable is wired and
crimped properly. If the Power LED is o and the other end
of the cable is plugged into a powered Mongoose or HAL,
there is a problem with the cable.
100-240V
PATENT NO. 8,542,849
13 WATTS
50/60 Hz
USB
LOCATE
FAULT
POWER
MAIN OUTPUT
RAD PORT
AUX
INPUTS
MIC INPUTS
12341
2
RECORD
USB
AUDIO
POWER
COMM
AUDIO RX
AUDIO TX
MIC +48V MIC +0V
WIRELESS MIC
MIC +48V MIC +0V
WIRELESS MIC
MIC +48V MIC +0V
WIRELESS MIC
MIC +48V MIC +0V
WIRELESS MIC
5 VDC @ 500 mA
USB
CHARGE
ONLY
MIC LINE
CLASS 2 WIRING
CASCADE
SHIELDED CAT 5e OR BETTER • 24 VDC @ 100 mA
AM1
RANE CORPORATION

Manual-7
USB AUDIO I/O
Since the AM1 appears as a standard Windows or Mac stereo
playback and record device, you can simultaneously record the
AM1 Main Mix and playback audio via the USB. is makes
many popular audio software programs instantly compatible
with the AM1. Once the computer’s operating system nishes
registering the AM1 via USB, the rear panel USB indicator
lights. e AM1 always registers as a 16-bit, 48 kHz device.
Most audio programs work after setting the AM1 as a default
device, but a few programs may need their preferences manually
set to play or record at 16-bit, 48 kHz.
Play audio from your computer’s audio software applica-
tion and select the Rane AM1 as the playback and/or recording
device. If your audio software oers a playback volume control,
turn it up most or all of the way, but without ashing the front
panel USB input Overload indicator too much. e front panel
USB Mix Level knob adjusts the mix volume of the incoming
USB audio.
WINDOWS OPERATION
When Windows detects the AM1 it automatically sets it as the
default Recording and Playback device. With Windows XP® and
Vista®, any audio applications currently running will continue to
use the previously selected default device. Restart the application
to make it use the AM1 for recording or playback. Windows7®
and 8® automatically switch a running application to the newly
connected AM1. To avoid surprises, we recommend turning the
USB Level down while connecting.
Remember that Windows likes to play dierent bleeps and
bloops when updates install, devices are plugged in and un-
plugged, or other operating system events happen. If you do
not want these sounds played into your mix, turn o Windows
system sounds. is can be found in:
Start -> Control Panel -> Sound -> Sounds (tab) -> Sound Scheme -> No Sounds.
Finding the audio properties and devices in Windows varies
slightly with each version.
Windows XP:
Classic View
Start -> Control Panel -> Sounds and Audio Devices -> Audio (tab)
Category View
Start -> Control Panel -> Sounds, Speech, and Audio Devices -> Sounds and Audio
Devices -> Audio (tab)
Windows Vista:
Classic View
Start -> Settings -> Control Panel -> Sound -> Playback (tab) and Record (tab)
Control Panel Home
Start -> Control Panel -> Hardware and Sound -> Sound -> Playback (tab) and
Record (tab)

Manual-8
©Rane Corporation 10802 47th Ave. W., Mukilteo WA 98275-5000 TEL [phone] FAX [phone] WEB rane.com
112067
Windows 7 and 8:
Small/Large Icon View
Start -> Control Panel -> Sound -> Playback (tab) and Record (tab)
Category View
Start -> Control Panel -> Hardware and Sound -> Sound -> Playback (tab) and
Record (tab)
Tip: to quickly access these screens, right-click on the loudspeak-
er icon at the lower right corner of your desktop (next to the
clock). Choose “Playback Devices” or “Recording Devices.”
MACINTOSH OPERATION
When OSX® detects the AM1, it adds it to the list of audio
input and output devices, but does not automatically set it as
the default device. Some Macintosh® applications allow you to
select the device you want to use. Other applications only use
the device specied as the OSX default. We recommend that you
set the default audio input and output device to the AM1 before
starting the application you want to use.
Congure the default audio device in OSX by navigating to:
System Preferences -> Sound -> Output (tab) and Input (tab).
CobraNet is a trademark of Cirrus Logic Inc.
Windows XP, Vista and 7 is either a registered trademark or a trademark of Microsoft Corporation in the United States and/or other countries.
Apple, Mac, Macintosh, iPod, iPad, iPhone and iTunes are trademarks of Apple Computer, Inc., registered in the US and/or other countries.

AM1 & AM2
AUTOMIXERS
Data Sheet - 1
DATA SHEET
AM1 Features
INPUTS:
• Gain-Sharing Automatic Mic Mixing:
• 4 XLR Inputs with Level controls & Sig/OL indicators.
• Select Mic, Mic with 48V phantom, or Line-level.
• Manually Mix:
• Overall Mic Mix.
• Two Aux Inputs: dual RCA & 3.5 mm, independently monoed.
• USB Audio Input (16-bit, 48 kHz).
OUTPUTS (all mono):
• XLR Main with Mic/Line switch, Level control & Sig/OL.
•Dual RCA Record.
• Headphone ¼” and 3.5 mm Outputs with Level control:
• Source select cues Mics, Aux 1, Aux 2, USB Input or Output.
• USB Audio Output (16-bit, 48 kHz).
• USB Charge Port for iPod® or other USB-powered devices.
• Rane RAD and Cascade IN RJ-45 Ports:
• Cascade In Port connects up to seven Rane AM2 Automixers.
• RAD Port sends Output to Rane HAL or Mongoose Systems.
AM2 Features
INPUTS:
• Gain-Sharing Automatic Mic Mixing:
• 8 XLR Inputs with Level controls & Sig/OL indicators.
• Select Mic, Mic with 48V phantom, or Line level.
OUTPUTS (all mono):
• XLR Main with Mic/Line switch, Level control & Sig/OL.
• Rane RAD and Cascade IN RJ-45 Ports:
• Cascade In Port connects up to seven Rane AM2 Automixers.
• RAD Port may send Output to Mongoose (CobraNet).
• RAD Port may send Output to HAL (DSP/control). It is possible
to cascade the AM2 mix into Halogen's Gain-Sharing Auto Mixer
or Room Combine Processor DSP, so that all mics connected to
HAL may gain-share (does not work with the AM1).

AM1 & AM2
AUTOMIXERS
Data Sheet - 2
AM1 and AM2 Common Features
e Rane AM1 and AM2 may be each be used on their own as a
standalone mixer, or add more gain-shared mics using up to seven
AM2 Automixers.
Each of the XLR Mic Inputs oers front panel input Level
controls feeding a gain-sharing automatic mixer. e AM1 has
four Mic Inputs, the AM2 has eight. Rear panel, 3-position
switches for each Mic Input support dynamic mics (no phantom
power), condenser mics (48 V), or wireless receiver outputs (+12
dBV max). A front panel Mic Mix Level control adjusts the vol-
ume of all automixed mics.
e Mic Inputs are optimized for automixing speech. ey
have a xed 80 Hz to 7 kHz bandpass lter (2nd-order Butter-
worth) to provide the best voice-only automatic mixing using a
gain-sharing algorithm.
Signal and Overload indicators monitor every Input Level
control and the Output Mix Level. Indicators ank each corre-
sponding Level control.
e XLR Main Output can be set to Mic- or Line-level to feed
a mic snake or a +20 dBu max balanced input. e front panel
Output Level control aects the XLR Output and the RAD Port
output.
AM2 mixers may be cascaded, but only one AM1 may be
used, and it must be the nal unit in a chain of no more than
eight AMs. Simply connect Cascade OUT ports to Cascade IN
ports and the nal Output level on the last AM controls the main
mono output mix.
Use the RAD Port to transport the main output mix digitally
via shielded CAT 5e to either a Rane HAL’s RAD Port for further
signal processing and control, or to a Mongoose for potential
routing to a CobraNet network.
Both the RAD and the Cascade IN port have status indicators
to aid setup and troubleshooting. Rear panel Fault, Locate, USB
and Power indicators inform head-scratchers of device errors, the
AM’s physical location, positive USB audio device OS registration
and AC power status. Duplicate Locate and Power indicators are
on the front and rear.
Universal IEC power on the rear supports 100 to 240 VAC
and 50/60 Hz.
AM1 Unique Features
e Rane AM1 is part gain-sharing automatic mic mixer, part
manual line mixer, part USB audio I/O device, and simultane-
ously a Rane RAD. Use it as a standalone mic/line mixer with
up to four mics, or add more gain-shared mics using up to seven
AM2 Automixers for up to 60 gain-shared mics.
ree manually-mixed audio inputs provide a simple user
interface and installation. e Aux 1 Input dual RCA and Aux 2
3.5 mm jacks are independently mono’ed, each with a front panel
Level control. A dedicated USB Charge port adjacent to Aux 2
provides power to USB devices such as iPods® or other USB-pow-
ered devices. e separate orange USB Audio Input also oers a
front panel Level control for the 16-bit, 48 kHz digital audio that
is mono’ed immediately upon entry.
e AM1 appears in Windows and Apple OS X computers
as a standard USB Audio Device, immediately compatible with
dozens of audio recording and playback audio applications. e
AM1 registers with the OS as a 16-bit 48 kHz device for both
incoming and outgoing audio. e USB Audio port doubles as a
rmware update port if future updates become available.
e front panel Output Level control aects the XLR Output
and the RAD Port output. e analog RECORD RCA Outputs
and the digital USB Audio output are both mono, pre-Output
Level, containing the same mix as the Main Output.
A front panel pre-Output Selector permits headphone cueing
so users can verify input and output operation before bringing
new sources into the live Output mix. Both ¼" & 3.5 mm head-
phone jacks with a Level control are provided.
AM2 Unique Features
e Rane AM2 is both an 8 channel, gain-sharing automatic mic
mixer and simultaneously a Rane RAD. Use it as a standalone
mic-only mixer, or add more gain-shared mics using up to seven
additional AM2 Automixers for up to 64 gain-shared mics.
When an AM2 is used standalone, both the XLR Output
and the RAD Port output audio are aected by the front panel
Output Level control. When the AM2’s Cascade Output feeds a
downstream Rane AM1 or AM2, the front panel Output Level
control only aects the XLR Output.
e USB port is solely used as a rmware update port if future
updates are needed.

AM1 & AM2
AUTOMIXERS
Data Sheet - 3
Cascaded AM System Example
CASCADE
RAD PORT
USB
DATA
OUTPUT MIC INPUTS
12345678
100-240V
13 WATTS
50/60 Hz
MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC
INOUT
USB
LOCATE
FAULT
POWER
CLASS 2 WIRING
MIC LINE
SHIELDED CAT 5e OR BETTER • 24 VDC @ 100 mA
PATENT NO. 8,542,849
AM2
RANE CORPORATION
CASCADE
RAD PORT
USB
DATA
OUTPUT MIC INPUTS
12345678
100-240V
13 WATTS
50/60 Hz
MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC
INOUT
USB
LOCATE
FAULT
POWER
CLASS 2 WIRING
MIC LINE
SHIELDED CAT 5e OR BETTER • 24 VDC @ 100 mA
PATENT NO. 8,542,849
AM2
RANE CORPORATION
CASCADE
RAD PORT
USB
DATA
OUTPUT MIC INPUTS
12345678
100-240V
13 WATTS
50/60 Hz
MIC +48V MIC +0V
WIRELESS MIC
MIC +48V MIC +0V
WIRELESS MIC
MIC +48V MIC +0V
WIRELESS MIC
MIC +48V MIC +0V
WIRELESS MIC
INOUT
USB
LOCATE
FAULT
POWER
CLASS 2 WIRING
MIC LINE
SHIELDED CAT 5e OR BETTER • 24 VDC @ 100 mA
PATENT NO. 8,542,849
AM2
RANE CORPORATION
100-240V
PATENT NO. 8,542,849
13 WATTS
50/60 Hz
USB
LOCATE
FAULT
POWER
MAIN OUTPUT
RAD PORT
AUX
INPUTS
MIC INPUTS
12341
2
RECORD
USB
AUDIO
POWER
COMM
AUDIO RX
AUDIO TX
MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC MIC +48V MIC +0V WIRELESS MIC
5 VDC @ 500 mA
USB
CHARGE
ONLY
MIC LINE
CLASS 2 WIRING
CASCADE
SHIELDED CAT 5e OR BETTER • 24 VDC @ 100 mA
AM1
RANE CORPORATION
USB cable
Ethernet (CAT 5e)
Audio cable
Powered
Speaker
MENU
MP3/
Phone
Wireless Receiver
AM1 Automixer
AM2 Automixer
To HAL (optional)
Any combination of
wired or wireless mics
AM2 Automixer
Additional AM2s (up to seven) All additional mics will gain-share
DVD
Record to or playback from
your computer on USB.

AM1 & AM2
AUTOMIXERS
Data Sheet - 4
RADs
An entire family of RAD models interface with HAL or Mon-
goose Systems for digital conversion at the wall. Each converts
analog audio to and/or from 24-bit, 48 kHz digital audio.
Shielded CAT 5e (or better) cable and termination transport four
digital audio channels – two channels each direction – as well as
power, ground and a communications channel, with status indica-
tors at each RAD, host unit, and host software. All RADs are
both “location-aware” and hot-swappable with 500-foot homerun
connections (66% farther than Ethernet). Most RADs mount in
standard US electrical boxes, and are available in white, ivory, or
black, with a matched Decora™ plate cover included.
Mongoose
Mongoose can replace the analog mic and line level portions of an
audio system with digitized audio over shielded CAT 5e cable (or
better). Mongoose can be used with or without CobraNet.
e Mongoose’s 32-by-32 digital audio matrix router receives
its rst 16 audio channels from up to eight RADs via the eight
rear panel 8P8C (RJ-45) Remote Audio Device ports. e second
16 matrix input channels come from two eight-channel CobraNet
receive (Rx) Bundles via standard CobraNet Primary and Second-
ary/backup ports. e 32 matrix router outputs transmit 16
channels to eight RADs and 16 more channels to two CobraNet
transmit (Tx) Bundles. Mic inputs can be greatly increased by
connecting a RAD output from an AM1 and/or cascaded AM2s.
Find out more at rane.com/mongoose
HAL1
Meet HAL, an expert in room combining, paging and distributed
audio systems. is groundbreaking architecture is dimensions
beyond any other solution. HAL easily guides even novice us-
ers through what used to be complex tasks in just minutes. No
intricate matrix mixing or presets are required for room combin-
ing and paging. No virtual wiring required to distribute pages and
background music to multiple zones.
AM1 and AM2 as RADs with Mongoose or HAL
Seamlessly interface HAL to your facility with a broad variety
of peripheral devices including smart Digital Remotes, RADs,
portable and in-rack automixers, audio I/O and control logic ex-
pansion devices, wall sensors, ambient sensing mics, small remote
ampliers, and an advanced Paging Station.
e HAL and Halogen software check the status, location,
CAT 5 wiring integrity, and that audio is owing in all peripheral
devices, so you know your system is properly connected and ready
to go. HAL is more than just another DSP drag-and-drop system
— it has revolutionized system design and installation.
ree HAL Multiprocessors provide various audio I/O and
control options for both large and small installations, with
expandable systems capable of hundreds of mics (HAL1) or eco-
nomical and adaptable 4 in x 8 out (HAL3).
Find out more at rane.com/hal
AM Automixers with HAL
An AM1 is a RAD, and an AM2 is a RAD, and the nal output
of cascaded AM mixers is a RAD. Any of these allow the manu-
ally created mono mix to be sent digitally to a Rane HAL’s RAD
port via a shielded CAT 5e cable (or better). e Rane RADX
supports doing so portably – with the AM mixer(s) in a padded
rack or on a portable AV cart, for example. Once the AM mix is
in the HAL, additional signal processing such as EQ and com-
pression can be added. Control of the mix’s level using Rane’s
DR1 or DR3 Digital Remotes is a breeze.
AM1 use with HAL
e AM1 does not have a Cascade Out Port, therefore it is not
possible to cascade the AM1 mix into Halogen’s Gain-Sharing
Auto Mixer or Room Combine Processor. You must use the AM2
mixer for cascading with these DSP blocks.
AM2 use with HAL
e AM2 mixer digitally cascades into Halogen’s Gain-Sharing
Auto Mixer or Room Combine Processor. is means the gain-
sharing algorithm automatically treats AM2 microphones and any
other microphone wired into these DSP blocks as being part of
the same gain-share. is provides superior gain before feedback
since all mics in the room, regardless of where and how they are
plugged in to the audio system, all work as one. is maintains
your feedback stability margin.
To maintain PAG & NAG like you never have before, connect
the AM2’s Cascade Out jack with a shielded CAT 5e (or better)
cable into any HAL’s RAD port. In Halogen software, in the Pro-
cessing Workspace, drag the AM2 onto the Cascade In on either a
Gain-Sharing Auto Mixer or a Room Combine Processor.
You can cascade as many AM2 mixers into these two DSP
blocks as you have RAD Ports available. With a maximum of 36
total RAD ports in a HAL1 full with EXP1s, and a maximum of
8 AM2s cascaded externally, over two thousand possible channels
are possible!

AM1 & AM2
AUTOMIXERS
Data Sheet - 5
Features and Specifications
XLR Inputs Mono, Balanced, Mic/Line Selectable
Phantom Power +48V per IEC 60268-15, Selectable in Mic mode
Maximum Input -18 dBV / -6 dBV / +12 dBV (Dynamic / Condenser / Wireless)
Input Impedance 2.01k, 1%
Input Gain Range (Mic/Wireless) -80 to +34 dB / -80 to +26 dB
Frequency Response 80 Hz to 7 kHz, 2nd-order Butterworth, +0/-3 dB, -20 dBFS, Extended vocal range
AM1 Aux Inputs 1 / 2 Dual Mono, Unbalanced, RCA / 3.5 mm TRS
Maximum Input +8 dBu
Input Impedance 18.8 k, 1%
Gain Range -80 to +12 dB
Frequency Response 20 Hz to 20 kHz, +0/-0.25 dB
Main Output Mono, Balanced, XLR
Maximum Output (Mic/Line) -20 / +20 dBu, 10 k load
Output Impedance (Mic/Line) 51 / 300 , 1%
Output Gain Range -80 to 0 dB
Dynamic Range (Line) 101 dB re +20 dBu, 20 kHz BW, A-weighted, 0 dB gain, 10 k load
AM1 Frequency Response 23 Hz to 20.5 kHz, +0/-3 dB
AM2 Frequency Response 80 Hz to 7 kHz, +0/-3 dB, -20 dBFS
AM1 THD+N < 0.01%, 22 Hz to 20 kHz, A-weighted, +4 dBu, 0 dB gain, 10 k load
AM2 THD+N < 0.02%, 100 Hz to 7 kHz, A-weighted, +4 dBu, 0 dB gain, 10 k load
AM1 Record Output Dual Mono, Unbalanced, RCA
Maximum Output +12 dBu, 10 k load
Output Impedance 602 , 1%
Frequency Response 23 Hz to 20.5 kHz, +0/-3 dB
Dynamic Range 101 dB re +12 dBu, 20 kHz BW, A-weighted, 0 dB gain, 10 k load
THD+N < 0.01%, 22 Hz to 20 kHz, A-weighted, +4 dBu, 0 dB gain, 10 k load
AM1 Headphone Output Dual Mono, Unbalanced, ¼" and 3.5mm TRS
Maximum Output +9 dBu, 150  load
Maximum Output Power 30 mW into 150 
Output Gain Range -63 to +16 dB
Frequency Response 23 Hz to 20.5 kHz, +0/-3 dB
Dynamic Range 101 dB re +9 dBu, 20Hz to 20 kHz BW, A-weighted, 0 dB Gain, 150  load
THD+N < 0.06%, 22 Hz to 20 kHz, A-weighted, +4 dBu, 0 dB gain, 150  load
LED Meters Mono, peak detecting
Signal -50 dBFS, Green LED, Peak-Reading
Overload -0.5 dBFS, Red LED, Peak-Reading
RAD / Cascade In / Out 8P8C (RJ-45) Connector. e AM2 has a Cascade Output, the AM1 does not.
Sample Rate and Resolution 48 kHz @ 24 bits, xed-point
AM1 USB Digital Audio Dual Mono In/Out, USB-B connector
Sample Rate and Resolution 48 kHz @ 16 bits
AM1 USB Charge Only Port USB-A Connector
Output Voltage and Current +5 V max @ +500 mA max
Unit All Steel Construction
Universal Line Voltage 100 to 240 VAC, 50/60 Hz, 13 W
Conformity CE, FCC, CSA
U.S. Patent No. 8,542,849
Size 1U 1.75"H x 19"W x 8.5"D (4.4 cm x 48.3 cm x 21.6 cm)
Weight 5 lb 4 oz (2.4 kg)
Shipping Size 4.5" x 20.3" x 13.75" (11.5 cm x 52 cm x 35 cm)
Shipping Weight 9 lb (4.1 kg)
Note: 0 dBu = 0.775 Vrms

AM1 & AM2
AUTOMIXERS
Data Sheet - 6
Applications
Facilities and rental agencies are called upon to provide either
equipment, or equipment and operators, for meetings or con-
ferences needing A/V support. e equipment providers must
ensure audio quality throughout the event to get repeat business.
However, the provided equipment may be operated by present-
ers who have no audio experience. If an operator is sent with the
equipment to set up and manage the system during the presen-
tation, that operator may have little audio experience. Pitfalls
abound when interconnecting the system, and managing multi-
microphone gain before feedback, mixing and volume. Handling
iPod and laptop playback and/or recording adds even more
complexity. Enter the Rane AM Automixer.
e AM1 makes it easy for an inexperienced operator to
quickly set up and manage audio for a multimedia presentation
involving up to four participants with microphones (wired or
wireless) and several program audio sources (e.g., DVD, Laptop,
MP3 player).
e AM2 easily handles an eight-person discussion panel or
board meeting. Additional AM2 mixers easily handle more mics
when needed, all gain-sharing, making operation simple.
e AM1 provides line audio sources, manually mixed since
there is no acoustic feedback potential. e AM1’s exible line
input combination of RCA, 3.5 mm and separate USB Charge
and Audio I/O ports makes integration and cabling easy. And
since the USB Audio port can simultaneously playback audio and
record the AM1’s output, the same laptop can be a source and a
recording device to document AV meetings, presentations, train-
ings, and family karaoke nights for AV contractor employees.
e AM Automixer oers a professional integrated solution
that provides superior automatic gain before feedback while
eliminating operator error with simple controls. e microphone
gain-sharing algorithm automatically and appropriately attenuates
mics not in use while maintaining the 3 dB per doubling of mics
for dierent (noncoherent) talkers, and 6 dB per doubling for the
same (coherent) talker who is directly between two mics. ink of
the person wearing a live lavalier or headset, while approaching a
live podium mic...no problem!
AM1 Architectural Specifications
e 1U audio device shall provide 4 rear-mounted XLR inputs
automatically mixed using a gain-sharing algorithm. Each input
shall permit independently selectable mic, mic with 48 volt
phantom power, or line input level intended for wireless receiver
output. Front panel mic input level controls for each input shall
indicate signal and overload and an overall mic mix level control
with signal and overload shall be provided.
ree manually-mixed inputs shall include dual RCA inputs,
a 3.5 mm stereo jack and dedicated USB charge port, and an
independent USB audio input; all three shall be monoed before
mixing. Front panel mix level controls for all three inputs shall
supply signal and overload indication.
Accommodation for two, post-level audio outputs shall be
provided. One on a single XLR male balanced analog output with
mic/line selector switch and the second via a Rane RAD Port on
RJ-45 providing 24-bit, 48 kHz PCM digital audio transport. A
mono, pre-output level mix shall be provided on dual-mono RCA
jacks and via a USB Audio port providing 16-bit, 48 kHz PCM
audio.
e USB Audio I/O port shall be recognized by Windows and
Apple OS X devices as a standard USB audio device permitting
simultaneous playback and recording to and from the device.
A cascade input RJ-45 shall permit gain-sharing mic mix ex-
pansion in groups of 8 channels from external automixer devices.
Up to 60 gain-shared mics shall be supported.
A front panel pre-level selector shall provide headphone cueing
with level control of either the mic mix, the RCA input, 3.5 mm
input, the USB audio input, or the main output mix. Headphone
outputs shall be provided on both ¼" and 3.5 mm jacks.
Universal 100 to 240 volt AC, 50 or 60 Hz operation shall be
provided via an IEC rear panel plug.
e unit shall be a Rane AM1.
• AV Rental Systems • Hotels
•Auditoriums • School AV Nerds
•Conference Centers •Panel Discussions
•Houses of Worship •Podcasting

AM1 & AM2
AUTOMIXERS
Data Sheet - 7
A
UX 1 INPUT
A
UX 2 INPUT
USB INPUT
PHONES
SOURCE
USB OUTPUT
USB OUTPUT (MONO, 48 kHz, 16-BIT)USB INPUT (MONO, 48 kHz, 16-BIT)
LEVEL
4.5 dB
RCA RECORD OUTPUT
RAD PORT CHANNEL 1 OUTPUT
MAIN OUTPUT
1/4
”
3.5m
m
HEADPHONES
TIP
RING
3.5m
mTIP
RING
TIP
RING
1
2
3
INPUT 3
LEVEL
MIC
MIX
LEVEL
1
2
3
INPUT 4
CASCADE INPUT
LEVEL
MONO
MONO
1
2
3
LEVEL
OUTPUT
LEVEL
4.5 dB
PHONES
LEVEL
MIC/LINE
1
2
3
INPUT 2
LEVEL
1
2
3
INPUT 1
LEVEL
+48V PHANTOM / MIC / WIRELESS
+48V PHANTOM / MIC / WIRELESS
+48V PHANTOM / MIC / WIRELESS
+48V PHANTOM / MIC / WIRELESS
AUTO
GAIN-
SHARING
MIX
MANUAL
MIX
SIG/OL
SIG/OL
SIG/OL
SIG/OL SIG/OL
SIG/OL
SIG/OL
SIG/OL
SIG/OL LEVEL
MICS
AUX 1
AUX 2
USB
OUTPUT
STATUS
STATUS
AM1 Block Diagram

AM1 & AM2
AUTOMIXERS
Data Sheet - 8
©Rane Corporation 10802 47th Ave. W., Mukilteo WA 98275-5000
TEL [phone] FAX [phone] WEB rane.com
Specications subject to change without notice. 9-2015
RAD PORT / CASCADE OUTPU
T
OUTPU
T
1
2
3
INPUT
3
LEVEL
1
2
3
INPUT
4
CASCADE INPUT
LEVEL
1
2
3
OUTPUT
LEVEL
MIX OUT
CASCADE OUT
1
2
3
INPUT
2
LEVEL
1
2
3
INPUT
1
LEVEL AUTO
GAIN-
SHARING
MIX
1
2
3
INPUT
5
LEVEL
1
2
3
INPUT
6
LEVEL
1
2
3
INPUT
7
LEVEL
1
2
3
INPUT
8
LEVEL
SIG/OL
SIG/OL
SIG/OL
SIG/OL
SIG/OL
SIG/OL
SIG/OL
SIG/OL
SIG/OL
STATUS
+48V PHANTOM / MIC / WIRELESS
+48V PHANTOM / MIC / WIRELESS
+48V PHANTOM / MIC / WIRELESS
+48V PHANTOM / MIC / WIRELESS
+48V PHANTOM / MIC / WIRELESS
+48V PHANTOM / MIC / WIRELESS
+48V PHANTOM / MIC / WIRELESS
+48V PHANTOM / MIC / WIRELESS
STATUS
MIC/LINE
AM2 Block Diagram
AM2 Architectural Specifications
e 1U audio device shall provide 8 rear-mounted XLR inputs
automatically mixed using a gain-sharing algorithm. Each input
shall permit selectable mic, mic with 48 volt phantom power,
or line input level intended for wireless receiver outputs. Front
panel mic input level controls for each input shall indicate signal
and overload and an overall output level control with signal and
overload shall be provided.
When used standalone without cascading addition mics, ac-
commodation for two, post-level audio outputs shall be provided.
One on a single XLR male balanced analog output with mic/line
selector switch and the second via a Rane RAD Port on RJ-45
providing 24-bit, 48 kHz PCM digital audio transport to a Rane
Mongoose or HAL. When cascading additional gain-shared mics
downstream, the front panel output level control only aects the
XLR Output.
A USB data port shall be provided to support rmware updates
should they be needed.
A cascade input RJ-45 shall permit gain-sharing mic mix ex-
pansion in groups of 8 channels from external automixer devices.
Up to 64 gain-shared mics with a maximum of eight 1U devices
shall be supported. To input line audio sources or perform head-
phone cueing, a Rane AM1 is supported.
Universal 100 to 240 volt AC, 50 or 60 Hz operation shall be
provided on an IEC rear panel plug.
e unit shall be a Rane AM2.

Interconnection-1
Introduction
is note, originally written in 1985, continues to be
one of our most useful references. It’s popularity stems
from the continual and perpetual difficulty of hooking
up audio equipment without suffering through all sorts
of bizarre noises, hums, buzzes, whistles, etc.— not to
mention the extreme financial, physical and psycholog-
ical price. As technology progresses it is inevitable that
electronic equipment and its wiring should be subject
to constant improvement. Many things have improved
in the audio industry since 1985, but unfortunately
wiring isn’t one of them. However, finally the Audio
Engineering Society (AES) has issued a standards
document for interconnection of pro audio equip-
ment. It is AES48, titled “AES48-2005: AES standard
on interconnections —Grounding and EMC practices
— Shields of connectors in audio equipment containing
active circuitry.”
Rane’s policy is to accommodate rather than dic-
tate. However, this document contains suggestions for
external wiring changes that should ideally only be
implemented by trained technical personnel. Safety
regulations require that all original grounding means
provided from the factory be left intact for safe op-
eration. No guarantee of responsibility for incidental
or consequential damages can be provided. (In other
words, don’t modify cables, or try your own version of
grounding unless you really understand exactly what
type of output and input you have to connect.)
Rane Technical Staff
RaneNote 110
© 1985, 1995, 2006, 2007, 2011 Rane Corporation
Sound System
Interconnection
• Cause & prevention of ground loops
• Interfacing balanced & unbalanced
• Proper pin connections and wiring
• Chassis ground vs. signal ground
• Ground lift switches
RaneNote
SOUND SYSTEM INTERCONNECTION
