Range Master 58590 Instruction Manual

Elite
110 Dual Fuel Cooker*
Users Guide & Installation Instructions
*Splash back and cooker hood are available as optional extras
U1 390 02

2

3
Contents
Hotplate Burners Page 5
The Griddle Page 6
The Wok cradle Page 7
The Ovens Page 8
The Left Hand Oven Page 8
The Right Hand Oven Page 8
The Clock Page 9
Multi-function oven Page 11
The Handygrill Page 13
Using your Handygrill Page 13
Oven shelves Page 14
Oven light Page 14
Storage Page 15
Multi-function Oven cooking guide Page 16
Cooking chart Page 17
Cleaning your cooker Page 18
Troubleshooting Page 20
General Safety Instructions Page 22
Installation Page 24
Conversion to LP gas Page 32
Servicing Page 34
Circuit Diagram Page 37
Technical Data Page 38

4
Be safe
You need clean fresh air - so does your cooker. Burner flames
produce exhaust gases, heat and moisture. Make sure that the
kitchen is well ventilated: keep natural ventilation holes open or
install a powered cooker hood that vents outside. If you have
several burners on or use the cooker for a long time, open a
window or turn on an extractor fan. For more detail see the
Installation Instructions.
We recommend you read ‘General Safety Instructions‘ (especially
if you have not used a dual fuel cooker before) where we describe
some basic guidelines on how to use a duel fuel cooker safely.
Gas and Electricity on
Make sure that the gas supply is turned on and that the cooker is
wired in and switched on.
The cooker needs electricity.
Peculiar smells
When you first use your cooker it may give off a slight odour. This
should stop after a little use.

5
Hotplate Burners
The drawing by each knob indicates which burner
that knob controls. There is a spark ignition system
that works when the knob is pressed in. Each burner
also has a special safety device that stops the flow of
gas if the flame goes out.
Push in and turn a knob to the solid flame symbol ( ).
Keep holding the knob pressed in to let the gas
through to the burner for few seconds. The igniter
should spark and light the gas.
If, when you let go of the control knob, the burner
goes out, the safety device has not held in. Turn the
control to the off position and wait one minute, then
try again this time holding in the control knob for
slightly longer.
Adjust the flame height to suit by turning the knob.
On this cooker the low position is beyond high, not
between high and off. The outline flame symbol
marks the ‘low position’. Turn the knob towards it
after the contents of a pan have boiled.
Make sure flames are under the pans. Using a lid will
help the contents boil more quickly.
Pans and kettles with concave bases or down turned
base rims should not be used.
Simmering aids, such as asbestos or mesh mats, are
NOT recommended. They will reduce burner
performance and could damage the pan supports.
Avoid using unstable and misshapen pans that may
tilt easily and pans with a very small base diameter
e.g. milk pans, single egg poachers. The minimum
pan diameter recommended is 120mm (about 43/4").
The Wok burners are designed to provide even heat
over a large area. They are ideal for large pans and
stir frying. For heating smaller pans the smaller
burners may be more efficient.
When hotplate control knob is pressed in,
sparks will be made at every burner, this is
normal.
If after lighting, a hotplate burner’s flame goes
out, turn it off and leave it for one minute before
relighting it.
You can remove the burner cap and trim
rings for cleaning, see the ‘Cleaning your
cooker’ section.
You should wipe the enamel top surface of the
cooker around the hotplate burners as soon as
possible after spills occur. Try to wipe them off
while the enamel is still warm.
Note:
Use of aluminium pans may cause metallic
marking of the pan supports. This does not affect
the durability of the enamel and may be cleaned
off with a metal cleaner such as 'Brasso'.

6
The Griddle
The griddle fits the centre left pan support, front to
back. It is designed for cooking food on directly. Don’t
use pans of any kind on it. The griddle surface is non-
stick and metal cooking utensils (e.g. spatulas) will
damage the surface. Use heat resistant plastic or
wooden utensils.
Don’t put it crossways - it will not fit properly and will
be unstable.
Don’t put it on the Wok burners - it is not designed to
fit the Wok burner pan supports.
Position the griddle over the hotplate burners resting
on the pan support.
Check that it is securely located.
The griddle can be lightly brushed with cooking oil
before use. Light the hotplate burners. Adjust the
flame heights to suit.
Preheat the griddle for a maximum of 5 minutes
before adding food. Leaving it longer may cause
damage. The controls can be turned to a lower
position simply by turning the control knobs towards
the lower position marked with the small flame
symbol.
Always leave space around the griddle for the gases
to escape. Never fit two griddles side by side. Large
pans should also be spaced well apart.
Use the following heat settings as a guide for
griddle cooking.
High/medium:
Drop scones, Bacon, Chops, Steak, Burgers.
Medium/low:
Potato cakes, Eggs, Fish cakes.
Experience will soon familiarise you with the
correct setting to use for cooking.
After cooking allow the griddle to cool before
cleaning.
Don’t put it on a Wok burner - it is not designed
to fit the Wok burner pan supports.

7
The Wok cradle
The Rangemaster Wok cradle is designed to fit a
TyphoonTM Professional 14” Wok.
This is available from CookCraft
(www.cookcraft.com) and also from other retailers.
If you use a different Wok make sure that it fits the
cradle. Woks vary very widely in size and shape. It’s
important that the Wok sits down on the pan support
- but if the Wok is too small the cradle will not
support it properly.
The cradle should be used on the triple ring Wok
burner only.
When you fit the cradle check that the Wok is
properly located on the front and rear fingers and that
it is supported properly on a pan support.
Make sure the cradle is stable and that the Wok is
sitting level in the ring.
The cradle will get very hot in use - allow
plenty of time for it to cool before you pick it
up.
Care and Cleaning
Essential information
Never use paint solvents, washing soda, caustic
cleaners, biological powders, bleach, chlorine
based bleach cleaners, coarse abrasives or salt.
Recommended cleaning materials are hot soapy
water, a moistened soap pad, cream cleaner or a
nylon scourer.

8
The Left Hand Oven
The left hand oven is a Multi-function oven. As well
as the oven fan and fan element, it is fitted with two
extra heating elements, one visible in the top of the
oven and the second under the oven base. Take care
to avoid touching the top element and element
deflector when placing or removing items from the
oven. For more detail on this oven see the section
‘Multi-function oven’.
The Multi-function oven has two controls, a function
selector and a temperature setting knob.
Turn the function selector control to a cooking
function. This is the fan oven setting.
Turn the oven temperature knob to the temperature
you need.
The oven indicator light will glow until the oven has
reached the temperature you selected. It will then
cycle on and off during cooking.
The Right Hand Oven
The fan in the right hand oven circulates hot air
continuously, which means faster more even
cooking.
The recommended cooking temperatures for a
fanned oven are generally lower than a non-fanned
oven.
The right hand fan oven control is at the right hand
end of the control panel.
Turn the oven temperature knob to the temperature
you need.
The oven indicator light will glow until the oven has
reached the temperature you selected. It will then
cycle on and off during cooking.
The Ovens
During use the appliance becomes hot. Care should be taken to avoid the touching heating
elements inside the oven.
The clock must be set to the time of day before the ovens will work. See ‘The Clock’ section for
instructions on setting the time of day.

9
The Clock
You can use the timer to turn the ovens on and
off. The clock must be set to the time of day
before the ovens will work.
Setting the time of day
Timer knob Adjusting knob
When the clock is first connected the display will
flash ( ) and ( ) alternately.
To set the clock to read the time of day turn and
hold the Timer knob to the clock symbol ( ) and
at the same time turn the Adjusting knob left or
right until the clock shows the time of day.
Remember this is a 24 hour clock. Let go of the
Timer knob and it will spring back to the vertical
() oven manual setting.
To time something that’s cooking
(minute minder)
Turn the Timer knob to the right to the ( )
minute minder setting - it should click into
position. Use the Adjusting knob to set the time
you need as below
You can turn the knob back to the ( ) manual
setting to keep an eye on the time of day or leave
it in the ( ) minute minder position as the time
ticks down.
To stop the beeper when it sounds
Turn the Adjusting knob anticlockwise
To stop automatically
Use when you have started the oven manually.
Turn the Timer knob to the ( ) position. Use the
Adjusting knob to set the time you need as
below.
‘Stop Time’ shows. AUTO will show in the
display.
Turn the Timer knob to the (AUTO) setting. When
your cooking is finished the beeper sounds. Turn
the Timer knob to the vertical ( ) to return to
manual cooking.
To start and stop the oven
automatically
Before you set the clock, you must have two
numbers clearly in mind.
The ‘cook time’, which is the period of time you
want the oven to cook.
The ‘stop time’, which is the time of day you
want the oven to stop cooking.
You cannot set a start time directly - this is set
automatically by setting the cooking period and
stop time.
Turn the Timer knob to the ( ) position. Use the
Adjusting knob to set the ‘cooking time’ you need
as below.

10
Turn the Timer knob to the ( ) position. The
display will show the current time of day plus the
‘cook period’ you just set. Use the Adjusting knob
to set the ‘Stop time’ you need as below.
‘Stop Time’ shows. AUTO will show in the display.
Set the oven(s) to the cooking temperature you
need (don’t forget to set a function if using the
Multi-function oven).
Turn the Timer knob to the (AUTO) setting.
When your cooking is finished the beeper sounds.
Turn the Timer knob to the vertical ( ) to return to
manual cooking.
If you are out, don’t worry about the beeper going
off, it stops after a while. When you return, turn
the Timer knob to the vertical ( ) to return to
manual cooking. Turn the thermostat to the off
position.
AUTO is showing, you want to reset
to manual cooking.
You can cancel any automatic settings by turning
the Timer knob to the vertical manual symbol ( ).
Clock Special Features
Key Lock
When the key lock is activated, the clock can be
operated as usual but the ovens are locked and
will not come on. This means that your child could
select a cook program but the program will not be
activated and ovens will not switch on.
To activate the key lock
Turn and hold the Timer knob to the clock symbol
() for about 8 seconds. ‘On’ will appear on the
display.
Keep holding the Timer knob turned to the clock
symbol ( ) and turn the Adjusting knob
clockwise until the key symbol ( ) and ‘Of’ shows
on the display. Let go of the knobs.
The ovens are now locked. After a few seconds
the display will revert to show the time of day
and the key symbol.
To turn off the key lock
Turn and hold the Timer knob to the clock
symbol ( ) for about 8 seconds. ‘Of’ will appear
on the display.
Keep holding the Timer knob turned to the clock
symbol ( ) and turn the Adjusting knob
clockwise until the key symbol ( ) goes out on the
display. Let go of the knobs.
After a few seconds the display will revert to
show the time of day.
The ovens can now be used normally.
