Range Master Single Built in Oven User manual

Single Built in Oven
Users Guide
&
Installation & Servicing

Contents
Safety Instructions 3
Before first use 3
The Facia Panel 4
Oven accessories 4
Oven operation 4
Oven temperature 6
Oven cooking chart 7
Grilling in the oven 8
Grilling cooking chart 8
Cleaning and care 10
Solving problems 12
Installation 13
Technical Data 16

USERS GUIDE
Page 3
Safety Instructions
Please read these operating
instructions carefully for full
information on the safe
installation, use and care of your
new Rangemaster appliance.
•This appliance must be correctly
installed in accordance with the
manufacturer’s instructions by a suitably
qualified person.
• We cannot accept responsibility for
damage to persons or items due to poor
or incorrect installation of this
appliance.
• Make sure that the voltage and
frequency of the mains supply
correspond to the details on the rating
plate which can be found on the lower
part of the front of the oven.
Warning: this appliance must be earthed.
•We cannot accept any liability for
failures in the earth connection or for
earth connection that is not in
compliance with the regulations in force.
• Maintenance and servicing work must
only be carried out after the power
supply has been disconnected by
switching off at the on/off isolator or
removing the mains fuse.
• Due to our policy of continuous
innovation, we reserve the right to adjust
or modify our product without prior
notification.
• Do not use the oven to heat kitchen, not
only does this waste fuel but the control
knobs may become overheated.
• Do not let children near the oven during
use to avoid the danger of burns or
injury. Supervise the use of the oven by
the elderly or infirm.
• Never store flammable materials in a
drawer or cupboard beneath a built-in
oven as there is a risk of fire.
• Do not place heavy objects on the open
door or sit on it as this could cause
damage to the hinging.
• To avoid damage to the interior
enamel, do not place the oven pan or
baking trays on the bottom of the oven
and do not line the base of the oven
with aluminium cooking foil.
• During cooking, food naturally
produces steam, which is vented away
to prevent an excessive build-up within
the oven. As this steam can condense
to water droplets on the cool outer trim
of the oven, it may be necessary during
cooking to wipe away any moisture
with a soft cloth. This will also help to
prevent soiling and discoloration of the
oven exterior by cooking vapours.
Before first use
Before using for your oven for the first
time clean it thoroughly. Switch off the
oven at the on/off isolator or remove the
mains fuse before cleaning. Remove any
packaging and the oven accessories from
the ovens. Wipe the oven interior using
hot water and a mild detergent. Rinse
carefully using a damp cloth. Wash the
oven shelves and accessories in a
dishwasher or using hot water and a mild
detergent, and dry thoroughly.
Slide the oven shelves and the oven pan
onto the runners, close the doors and
heat the ovens to maximum temperature
for 30 minutes to eliminate any residues
from the manufacturing process.

Page 4
USERS GUIDE
The Facia Panel
Oven accessories
The oven is supplied with a full range of
accessories. Depending on the model,
this comprises either 2 or 3 wire shelves
2 enamelled oven pans with 2 trivets and
a handle. The wire shelves and oven
pans slide into the shelf supports located
on either side of the oven interior (see
diagram). The shelf must be located the
right way up. See the figure.
The shelf supports are numbered from 1-
5, position 1 being the lowest.
The oven pan can be used for roasting or
grilling in the oven. When grilling, fit
the handle to the oven pan to slide it in
or out of the oven.
Oven operation
Your new Rangemaster oven
incorporates a multifunction cooking
system, enabling you to select the most
appropriate heating method for the type
of food you are preparing. We suggest
you keep a careful eye on your cooking
until you are familiar with each function.
Remember - not all functions will be
suitable for all food types. Please
remember that all cookers vary -
temperatures in your new oven may
differ to those in your previous cooker.
The function required is selected by
turning the oven function selector knob
in a clockwise direction to the chosen
symbol. The interior light of the selected
oven will illuminate and the ‘On’
indicator light will glow. The oven
functions and their symbols are:

USERS GUIDE
Page 5
Light only
The oven interior light comes on.
Base heat plus fan
The fan operates with the element under
the floor of the oven. The oven should
be pre-heated before use until the
temperature indicator light goes out.
This function is ideal for baking quiches
and pastry tarts so that the base of the
item cooks and crisps. In this case, the
food should be cooked with the oven
shelf on the lowest shelf position.
Conventional oven
(top and base heat)
This function combines the heat from the
top and base elements. It is particularly
suitable for roasting and baking pastry,
cakes and biscuits.
The oven should be pre-heated before
use until the temperature indicator light
goes out. It is recommended that food is
only placed on one shelf position when
cooking with the conventional heating
function. Do not use the lowest or
highest shelf positions or the food may
overcook.
Fan assisted oven
This function operates the fan,
circulating air heated by the elements at
the top and the base of the oven. The
combination of fan and conventional
cooking (top and base heat) makes this
function ideal for cooking large items
that need thorough cooking, such as a
large meat roast. It is also possible to
bake on two shelves at one time,
although they will need to be swapped
over during the cooking time, as the heat
at the top of the oven is greater than at
the base, when using this function.
This is a fast intensive form of cooking;
keep an eye on the food cooking until
you have become accustomed to this
function.
Single Circuit Grill
The centre of the grill element in the
roof of the oven operates. The oven
should be pre-heated for 5-10 minutes
before use. The oven pan should be used
on one of the upper shelf positions. Fit
the handle when sliding the oven pan in
or out of the oven. Grilling must always
take place with the oven door closed in
order to ensure correct performance of
this function. Check your food regularly
to avoid over cooking.
Dual Circuit Grill
Same procedure as single circuit grill,
but the whole grill element operates
giving you a larger area for grilling.
Fanned grilling
This function operates the fan whilst the
top grill element is on. It produces a
more even, less fierce heat than a
conventional grill. For best results, place
the food to be grilled, on a grid over a
roasting tin, which should be smaller
than a conventional grill pan. This
allows greater air circulation. Thick
pieces of meat or fish are ideal for
grilling in this way, as the circulated air
reduces the fierceness of the heat from
the grill. The oven door should be kept
closed whilst grilling is in progress, so

Page 6
USERS GUIDE
saving energy. You will also find that
the food needs to be watched and turned
less than for normal grilling. Pre-heat
this function before cooking.
Fan oven
This function operates the fan and the
heating element around it. An even heat
is produced throughout the oven,
allowing you to cook large amounts
quickly.
Fan oven cooking is particularly suitable
for baking on several shelves at one time
and is a good ‘all-round’ function. It
may be necessary to reduce the
temperature by approximately 10°C for
recipes previously cooked in a
conventional oven.
If you wish to pre-heat the oven, wait
until the indicator light has gone out
before inserting the food.
Defrost
This function operates the fan to
circulate cold air only. No heat is
applied. This enables small items such as
desserts, cream cakes and pieces of
meat, fish and poultry to be defrosted.
Defrosting in this way speeds up the
process and protects the food from flies.
Pieces of meat, fish and poultry should
be placed on a rack, over a tray to catch
any drips. Be sure to wash the rack and
tray after defrosting.
Defrost with the oven door closed.
Large items, such as whole chickens and
joints should not be defrosted in this
way. We recommend this be carried out
in a refrigerator.
Defrosting should not be carried out in a
warm oven.
Ensure that dairy foods, meat and
poultry are completely defrosted
before cooking.
Oven temperature
The oven temperature is set by turning
the appropriate oven temperature
selector knob clockwise to the required
level. An oven temperature must be set
for all functions except defrost and light.
Temperatures can be set from 50°C to
250°C. Once a temperature has been
selected, the appropriate temperature
indicator light will glow. When the oven
has reached the required temperature,
the light will go out. If pre-heating is
recommended, food can now be placed
in the oven. During cooking, the light
will occasionally glow as the heating
element(s) operate to maintain the oven
temperature. The temperature selector
should be reset to zero by turning anti-
clockwise after use.
Temperature Conversion Chart
In order to convert existing recipes for use
in your oven, use this chart as a guide.
Gas ºF ºC
1 275ºF 140°C
2 300ºF 150°C
3 325ºF 160°C
4 350ºF 180°C
5 375ºF 190°C
6 400ºF 200°C
7 425ºF 220°C
8 450ºF 230°C
9 475ºF 240°C

COOKING GUIDE
Page 7
Oven cooking chart
Conventional Oven Fan Oven
Shelf Cooking Shelf Cooking
Food Temp ºC Position time/mins. Temp ºC Position time/mins
Victoria sponge 180 2 20-25 160 1 or 1 & 2 25-30
Scones 230 1 10-15 210 1 or 1 & 2 10-15
Small sponge cakes 180 2 15-20 160 1 or 1 & 2 15-20
Shortcrust pastry 200 1 30-45 180 1 35-45
Choux pastry 200 1 20-30 180 1 or 1 & 2 25-35
Puff or flaky pastry 230 1 15-30 210 1 or 1 & 2 20-35
Biscuits 200 2 10-15 180 1 or 1 & 2 15-20
Bread 220 1 20-40 200 1 25-45
Lasagne 200 1 30-40 180 1 35-45
Pizza 220 1 20-25 200 1 25-30
Roast beef 200 1 20-30/500g+20 180 1 20-30/500g+20
Roast pork 200 1 30/500g+30 180 1 30/500g+35
Roast lamb 190 1 25/500g+20 170 1 25/500g+25
Roast chicken 190 1 20/500g+20 170 1 20/500g+25
Roast duck 190 1 30/500g 170 1 35/500g
Roast goose 180 1 25/500g 170 1 25/500g
Roast turkey 170 1 25/500g 160 1 25/500g
Vegetable bake 200 2 30-40 180 1 35-45
Beef casserole 160 1 2-3hours 150 1 2-4hours
500g is approximately 1lb (1lb 2oz)
Fan oven Temperature Conversion Chart
When converting conventional oven recipes for use
with the fan oven function, the oven temperature is
reduced by approximately 10°C. The following chart
gives a guide to correct temperatures in °C.
Please note that the recommendations contained in
these charts are given as a guide only.
Conventional Fan Oven
50ºC 50ºC
75ºC 70ºC
100ºC 90ºC
125ºC 100ºC
150ºC 125ºC
175ºC 160ºC
200ºC 180ºC
225ºC 200ºC

COOKING GUIDE
Page 8
Grilling in the oven
Depending on the amount to be cooked select either the single or dual circuit grill.
Whenever the grilling function is selected, set the appropriate temperature selector
knob at maximum and pre-heat the oven for 5-10 minutes before use.
Food should be arranged on a wire shelf on one of the upper shelf positions. The oven
pan should be placed into the oven with the trivet in place to collect any juices. Fit the
handle to the oven pan when sliding it in or out of the oven.
Grilling must always take place with the oven door closed in order to ensure
correct performance of this function. Check your food regularly to avoid over
cooking.
Grilling cooking chart
Shelf Cooking
Food Temp ºC Position time/mins.
Sausages Max. 5 5-10/side
Bacon rashers Max. 5 5-10/side
Burgers Max. 5 5-10/side
Chop or steak Max. 4 or 5 10-15/side
Chicken portions Max. 4 or 5 10-15/side
Trout Max. 4 10-15/side
Salmon steaks Max. 4 5-10/side
Cheese on toast Max. 5 - 10
Browningtoppings Max. 10 - 15
Please note that the recommendations contained in this chart are given as a guide only.

USERS GUIDE
Page 9
Electronic digital 24-hour clock
The oven has an electronic digital 24
hour clock and automatic timer (see
diagram)
Setting the time of day
When the oven is first connected to the
mains electricity supply or following a
power failure, three zeros will flash in
the time display. To set the time of day
press and hold the ( ) and ( )
buttons and at the same time press the +
or - buttons to set the correct time using
the 24 hour clock system. The speed at
which the digits change increases the
longer the + or - button is held. Release
the buttons once the time has been set to
start the clock running.
Manual oven operation
In order that the oven can be used
manually, the timer must be set to
‘manual’. If the automatic cooking
indicator ( ) is flashing, press the ( )
button until the time display reads zero
then press the ( ) button again. The
indicator will stop flashing. The oven
can now be used manually.
Setting the minute minder
The minute minder can be used to time
any period from 1 minute to 23 hours 59
minutes. To set the minute minder press
and hold the ( ) button and at the same
time press the + or - buttons to set the
required time. Release the buttons once
the time has been set to start the minute
minder running. The time display will
show the time of day and the ( )
indicator will appear.
To check the remaining time on the
minute minder at any point, press the
() button. The time display will show
the remaining time on the minute minder
until the button is released.
Once the time has elapsed the ( )
indicator disappears and a buzzer
sounds. This can be switched off by
pressing the ( ) button.
Setting the timer to turn the oven
off automatically
Either: Press and hold the ( ) button
and at the same time press the + or -
buttons to set the required cooking time.
Or: Press and hold the ( ) button and
at the same time press the + or - buttons
to set the required time at which cooking
should end.
Release the buttons once the time has
been set. The time display will show the
time of day and the ( ) and (AUTO)
indicators show.
Set the oven function and temperature
selector to the required positions. The
oven will turn on immediately and
operate for the period selected on the
timer, then switch off automatically.
Once the cooking time has elapsed the
(AUTO) indicator disappears and a
buzzer sounds. This can be switched off
by pressing the ( ) button. Turn the
oven function and temperature selector
knobs to zero. Press the ( ) button to
reset the oven to manual operation. The

Page 10
USERS GUIDE
flashing ( ) indicator will disappear.
The oven can now be used manually.
Setting the timer to turn the oven
on and off automatically
Press and hold the ( ) button and at
the same time press the + or - buttons to
set the required cooking time. Release
the buttons once the time has been set.
The time display will show the time of
day and the ( ) and (AUTO) indicators
will flash.
Now press and hold the ( ) button and
at the same time press the + or - buttons
to set the time at which cooking should
end. Release the buttons once the time
has been set. The time display will show
the time of day, the (AUTO) indicator
will disappear and the ( ) indicator will
flash.
Set the oven function and temperature
selector knobs to the required positions.
The oven will switch on at the
appropriate time, operate for the period
selected on the timer, then switch off
automatically. Once the oven switches
on, the (AUTO) indicator will flash to
show that automatic cooking is in
progress.
When the oven switches off, the
(AUTO) indicator disappears and a
buzzer sounds. This can be switched off
by pressing the ( ) button. Turn the
oven function and temperature selector
knobs to zero. Press the ( ) button to
reset the oven to manual operation. The
flashing ( ) indicator will disappear.
The oven can now be used manually.
Cancelling an automatic cooking
programme
An automatic cooking programme can
be cancelled at any moment by pressing
and holding the ( ) or ( ) button
until the time display reads zero. Press
the ( ) button to reset the oven to
manual operation. The flashing ( )
indicator will disappear. The oven can
now be used manually.
Cleaning and care
Warning: Switch off the mains
electricity supply to the oven during
cleaning.
Control panel and oven door front
The exterior of the oven should be
regularly wiped over using a soft, damp
cloth and a mild detergent solution,
rinsed, then dried with a soft, lint-free
cloth. Do not allow water to run down
the front of the appliance during
cleaning. On no account should abrasive
or caustic cleaning agents be used, as
these would damage the surface finish.
Removing the oven door
To aid cleaning and make access to the
oven interior easier, the oven door can
be simply removed (see diagram).
To facilitated cleaning of the oven, the
door can be removed via the hinges as
follows.
Hinges with locking toggle
The hinges A, have locking toggles B.
Fully open the door and swivel the
locking toggles on both hinges forward
to the locking position.

USERS GUIDE
Page 11
Grip the sides of the door and lift it
upwards and slide it forward to remove.
To refit the door, slide the hinges into
their slots. Before closing the door,
remember to rotate the two toggles B,
used to lock the two hinges, fully back.
Do not immerse the door in water
Clean the enamelled interior surface and
the glass using a damp cloth and a
proprietary mild cream cleaner, rinse, then
dry carefully using a soft cloth. If
necessary, the inner door glass can be
removed by unscrewing the two fixing
screws. Make sure that the glass is dried
thoroughly before re-fitting. Take care not
to over tighten the fixing screws when re-
fitting.
Removing the shelf support
Some models have detachable shelf
support, which can be removed, from the
oven for cleaning by hand or in a
dishwasher. Grasp the shelf support and
press downwards to release from the clip
device on the lowest runner (see diagram).
The shelf support can then be hinged
upwards and lifted from the mounting
holes in the upper corners of the oven
prior to removal. To re-fit the shelf
supports, reverse the procedure ensuring
that the clip device engages firmly on the
lowest runner.
Oven accessories
The oven shelves, oven pans and trivets
should be washed in hot water with a mild
detergent then dried carefully, or they can
be washed in a dishwasher.
Cleaning the oven interior
The interior of the oven has an enamelled
finish. In order to make cleaning easier,
any spillage’s should be wiped away as
soon as possible after they occur. Clean
the enamelled interior surfaces using a
damp cloth and a proprietary mild cream
cleaner, rinse, then dry carefully using a
soft cloth. Any burnt-on soiling can be
carefully removed using a plastic scourer.
Do not use caustic or abrasive cleaning
agents, knives or other metal
implements as these could damage the
oven.

Page 12
USERS GUIDE
Catalytic stay-clean liners
(optional extra)
Catalytic stay-clean liners for the sides
and rear of the oven only are available as
an optional extra for some models.
Please contact your Rangemaster dealer
for details. With catalytic liners fitted,
only the roof, floor and door of the oven
require conventional cleaning (see page
11). Splashes from food onto the side
and rear panels are broken down during
normal use of the oven at temperatures
above 200° C, so little manual cleaning
should be necessary. Do not use any type
of cleaning agent on the catalytic linings
or permanent damage could occur. In
cases of heavy soiling (e.g.: after
roasting or grilling fatty meat) the oven
can be cleaned using an additional
special process. Clean the enamelled and
glass parts of the oven interior and
remove the shelf supports (see page 11).
Close the door and switch on the oven
using the fan assisted oven setting at the
maximum temperature for l- 11/2hours,
depending on the level of soiling.
Cleaning the oven interior
Once the oven has cooled, the base can
be wiped with a damp cloth and the shelf
supports replaced (see page 11).
Solving problems
This appliance must only be repaired
by a qualified technician appointed by
the manufacturer. Unauthorised
repairs could be dangerous and would
invalidate any warranty.
Minor faults can be remedied as follows:
The oven does not work at all.
Check that the electricity supply is
connected and switched on.
Has the fuse blown? If so, have the fuse
replaced with the correct type.
The oven does not heat up
Has a temperature been set using the
temperature selector knob?
Has the defrost function been selected ?
These functions do not operate with
heating elements.
Is the oven set to automatic operation
(see pages 9-10)?
The oven heats up but the light bulb
does not work
The light bulb is faulty and needs
replacing. Please note that light bulb
failure is not covered under the
manufacturer’s warranty.
Replacing the oven light bulb
Warning : Switch off the mains
electricity supply to the oven.
The oven light is positioned in the top
left hand corner of the oven interior. If
the light bulb needs replacing, unscrew
the protective cover by turning it
anticlockwise and remove the faulty bulb
(see diagram).

USERS GUIDE
Page 13
Fit the replacement bulb and replaced
the protective cover, screwing it firmly
into place.
The catalytic liners (if fitted) are heavily
soiled and difficult to clean.
To ensure that the stay-clean linings
operate effectively, the oven should be
heated to at least 200°C whenever heavy
soiling has occurred during roasting or
grilling. If this is not done, the soiling
burns onto the linings and they become
black and shiny. In this case new liners
must be purchased from your
Rangemaster dealer. For after sales
service see the ‘Customer Care’ leaflet.
Installation
Warning: This appliance must be
correctly installed by a suitably
qualified person strictly in accordance
with the manufacturer’s instructions.
The manufacturers decline
responsibility for injury or damage to
person or property as a result of
improper installation of this
appliance.
This appliance conforms to DC No 13/4/
89 and the standards of CEE DTD 87/
308 of 2/6/1987 regarding the
elimination of radio interference.
Electrical connection
Electrical Installation must comply with
all relevant local and national regulation.
Make sure that the voltage supply is the
same as the rating given on the data
plate positioned on the lower part of the
front of the oven. This appliance must be
connection to an A.C. single phase 230
V, 50 Hz electricity supply. The total
rated load is 2,95 kW. The oven must be
connected to a 16 amp power supply via
a suitable isolator with an on-off switch,
and protected by a 16 amp fuse. The
isolator should be easily accessible in
case of maintenance or emergency. A
suitable cable, which complies with all
local and national regulations, must be
used. This should be of type H05 RR-F,
3- core, and with a minimum sectional
area of 1,5 mm.
The connection clamp for the cable is at
the rear of the appliance. Unscrew and
remove the cover then insert the cable by
way of the cable clip and connect.
Warning: This appliance must be
earthed.
The earth conductor of the mains cable
must be longer than the other two
conductors; in order that the it would
become disconnected last should the
cable be pulled or work loose following
installation. Secure the cable by
tightening the cable clip screws fully,
then replace and secure the cover.

Page 14
USERS GUIDE
Built-in installation
This appliance is designed for building-
in to a standard 600mm wide oven
housing. The housing, adjacent furniture
and all materials used in installation
must be able to withstand a minimum
temperature of 80°C plus ambient
temperature during periods of operation.
In addition, adjacent furniture cabinet
doors must be at least 8mm from the
appliance at all points. Certain types of
vinyl or laminate kitchen furniture
cabinetry are particularly prone to heat
damage and discolouration, any
delamination or discolouration of
materials which occurs below 80°C plus
ambient temperature or where materials
are less than 8mm from the appliance
will be the liability of the owner. The
housing into which the appliance is
installed must incorporate a full depth
shelf positioned 85 : 90mm below the
support shelf for the appliance. For
building-under a worktop, the
installation dimensions are as follows:

USERS GUIDE
Page 15
Ventilation
The appliance housing used must
provide adequate ventilation in
accordance with the manufacturer’s
recommendations as detailed in the
installation diagrams above. For built-in
installation, a minimum ventilation cut-
out of 400cm² must be incorporated into
the support shelf beneath the oven
together with a 500mm x 15mm cut-out
along the upper edge of the housing
unit’s plinth. A further ventilation space
of 85 90mm must exist between the rear
of the appliance and the back of the
housing or an adjacent wall. If a tall
housing is to be installed flush with the
ceiling, a 20cm² ventilation cut -out must
be provided at the top of the housing.
When placing the oven in the housing,
do not use the oven door as a lever for
lifting the oven as damage may result.
Once the oven has been positioned in the
housing it should be secured in place at
the four corners of the oven doorframe
using suitable screws (see diagram).

Technical Data
Electrical ratings
Total rated load 2.95 kW
Grill element 2.3 kW
Upper element 2.0 kW
Lower element 1.3 kW
Oven interior volumes
Volume 59 litres
Overall appliance dimensions
Height 591mm
Width 598mm
Depth 525mm
Total appliance weight
Net 42 kg
Gross 39 kg
09/03
