Rapid Closet Solutions 110 User manual

110 RapidCloset
Wall Hung Closets Hanging Double
ASSEMBLY AND INSTALLATION GUIDE
www.rapidcloset.com

110 RapidCloset
Wall Hung Closets Hanging Double
ASSEMBLY AND INSTALLATION GUIDE
ASSEMBLY AND INSTALLATION INSTRUCTIONS
DOUBLE HANGING UNIT - 18" / 24" / 30" / 32"/ 36" / 42"
L
MNO
BA
C
D
G
F F
E
H IJ
FRONT FRONT
FINISHED EDGE
FINISHED EDGE
TOOLS REQUIRED
(not included)
1.1
1.2
Lay parts out on a protective surface to prevent damage.
Tip: Spread out the cardboard
packaging to use as a protective surface.
Inventory parts against the Parts List. Make sure all parts are present before proceeding.
1.3 Determine the mounting location for the unit.
K
PARTS LIST
A
B
C
D
E
F
Left Side Panel (Qty1)
Right Side Panel (Qty1)
Set Shelf (Qty 2)
Rail&Cover (Qty1+1)
Hanging Rod (Qty 2)
Oval Rod Support (Qty 4)
G
H
I
J
K
Bracket&Cover (Qty2+2)
Connector (Qty 8)
Outrigger (Qty 8)
Screw (Qty 4)
Rail Screw 3" (Qty 4)
L
M
Level
Stud Finder
N
O
Drill, 3/32" bit size
Phillips Screwdriver
1.3 Install the bracket on wall which desired location with using level, then drill pilot holes.

3.1 Assemble Set Shelves (C) onto Right Side Panel (B)
by sliding the Shelves onto the Connectors (H) on
Right Side Panel. BE SURE dowel pins in Shelves
engage drilled holes in Right Side Panel, and all parts
are pressed flush against Right Side Panel.
IMPORTANT NOTES
Install Set Shelves (C) with finished edges
facing forward (toward front of unit).
2.1 Install one Connector (H) into each
of the eight holes on Left Side Panel
(A) and Right Side Panel (B). Tighten
until Connectors are seated against Side Panels.
2.2 Install one Bracket (G) into each
of the two holes on Left Side Panel
(A) and Right Side Panel (B). Tighten
until Connectors are seated against Side Panels.
C
C
H
H
B
A
G
H
B
G
H

5.1
5.2
Insert Outriggers(I) in holes in Set Shelves (C), with arrow pointing toward Outrigger
opening. Be sure Outriggers engage Connectors, and are fully seated in Shelves.
Tighten Outriggers (I) clockwise to lock.
ARROW
TOWARD
CONNECTOR
OPENING
3.1 Install Left Side Panel (A) onto assembled Set Shelves (C).
BE SURE dowel pins in Shelves engage drilled holes in
Left Side Panel, and Left Side Panel is pressed flush
against Set Shelves.
H
H
I
II
IIC
C
H
B
C
C
H
B
A
A

7.1 Hang the unit over Bracket (D) and Cover (D).
D
G

8.1 Position upper Oval Rod Support (F) on Left Side Panel (A) and
secure each Bracket with two screws (J). Repeat for lower Oval
Rod Support (F).
8.2 Adjust the Cover over Bracket (D).
A
J
F
FD
F
J
J
J
F

A
F
E
E
F
Insert one end of upper Hanging Rod (E) into "U" Bracket (F).
Slide assembled Hanging Rod (E) and Oval Rod Support (F) into unit.
Rest free end of Hanging Rod in Oval Rod Support.
Secure Oval Rod Support (F) to Right Side Panel (B) with two Screws (J).
Repeat for lower Hanging Rod (E) and Oval Rod Support (F).
For watching installation video and more information please visit
www.rapidcloset.com
Use care when installing Hanging Rods (E) to avoid scratching finish
inside unit.
F
E
F
E
www.rapidcloset.com
J
J
