Raven Dash camera User manual

User Guide

Thank you for choosing Raven!
Raven is all the technology you need for your vehicle, packed into one
sleek super powerful device. Smart cameras, smart sensors,
smart navigation, smart diagnostics, and more.
Have a question about your Raven? Please contact our support directly.
WELCOME
EMAIL
[email protected]
PHONE
1 [phone]
WEB
ravenconnected.com

INDEX
Page
Page
Page
Page
Page
Page
Page
Page
Page
Page
4
5
6
8
10
11
12
13
14
16
CAPTURING TIME-LAPSE VIDEOS
SETTING UP AUTOMATIC VIDEO DOWNLOADS
DOWNLOADING CONTINUOUS TRIP VIDEOS
USING LIVE STREAMING CHECK-INS
CONFIGURING RAVEN DRIVER DISPLAYS
CONFIGURING RAVEN SPEEDING NOTIFICATIONS
USING RAVEN NAVIGATION
USING RAVEN TRIP CARDS
ADDING MULTIPLE USERS TO YOUR RAVEN ACCOUNT
CAPTURING SHORT CLIPS USING GESTURE-TRIGGERED VIDEOS
2

INDEX
3
Page
Page
Page
Page
Page
17
18
19
20
22
CONNECTING TO RAVENS WIFI HOTSPOT
SHARING TRIPS WITH OTHERS
SETTING UP GEOFENCES
USING THE RAVEN CONNECTED WEB APP
WARRANTY, FCC AND ICES

Raven can capture short clips of your trip by recognizing your gestures.
See something interesting during your trip? Take a Gesture-Triggered
video of the event and save it right to your phone for easy sharing.
With an open palm, move your hand towards Raven to capture a
50-second recording (20 seconds prior to your hand motion and 30
seconds after). Raven’s screens will flash and a brief tone will sound indicating that
the gesture has been recognized. A countdown timer will appear on the screen
indicating how much time remains on the recording.
Note:
●If you would like to capture a longer event, repeat the gesture and
Raven will continue recording.
●The countdown timer on Raven’s display will reflect the extra time when
the gesture is recognized.
CAPTURING SHORT CLIPS USING GESTURE-TRIGGERED VIDEOS
20 sec. 30 sec.
50 sec.
RECORDING
4

Raven automatically captures the memories of your trips with a Time-Lapse. Want to capture all the scenery from your road trip?
Regardless of the length of your journey, Raven will capture time-lapses of all of your trips.
To download a time-lapse to your mobile device:
CAPTURING TIME-LAPSE VIDEOS
1. HISTORY
From the Raven
Connected app, select
History.
2. CHOOSE TRIP
Choose the trip of
interest.
3. DOWNLOAD
Select Trip Time-Lapse
Available to Download.
OR
1. MEDIA MANAGER
Select Media Manager.
2. SELECT
Choose from the list of
time-lapses stored on
your Raven device. 5
APRIL 19

Raven can automatically download videos to your phone for easy sharing. Don’t have time to individually download the videos
from your Raven? Set up automatic downloads to access all of your videos on your mobile device.
To set up automatic downloads of Raven Event and Gesture-Triggered videos:
For Android users:
SETTING UP AUTOMATIC VIDEO DOWNLOADS
1. MEDIA MANAGER
From the Raven Connected
app, select Media Manager.
2. GRANT PERMISSION
Select the yellow information
box at the top of the screen to
grant permission.
3. COMPLETE SETUP
Follow the on-screen
instructions to complete
the set-up.
4. SELECT DOWNLOADS
Toggle which automatic
downloads you would like
to enable.
6
ROAD
CABIN

For iOS users:
1. MEDIA MANAGER
From the Raven
Connected app, select
Media Manager.
2. GRANT PERMISSION
Select the yellow bar at
the top of the screen.
3. CONNECT
Select Connect
to Raven.
4. COMPLETE SETUP
Follow the on-screen
instructions to complete
the set-up.
7
CONNECT
5. SELECT DOWNLOADS
Toggle which automatic
downloads you would like
to enable.
ROAD
CABIN

Raven captures continuous videos from both road and cabin-facing cameras while your vehicle is running.
Want to review the full footage of your trip? Download your continuous Raven videos to your computer.
To access video files using a micro USB cable:
DOWNLOADING CONTINUOUS TRIP VIDEOS
1. CONNECT RAVEN
Connect your Raven to your PC
using a micro USB cable.
2. FILE EXPLORER
Once your Raven is connected
and turned on, open the file
explorer on your PC.
3. SELECT RAVEN
Find and select your
Raven from the list.
4. INTERNAL STORAGE
Double-click Internal Storage.
The raw video files will appear
in the Videos folder.
RAVEN INTERNAL STORAGE
8

To access video files using a Micro SD card:
Make sure you’ve selected an SD Card that meets the minimum recommended recording requirements. To learn more, visit: http://bit.ly/RavenSD.
1. REMOVE SD CARD
Remove the Micro SD
card from your Raven.
2. INSERT INTO COMPUTER
Insert it into your computer
(use an adaptor if necessary).
3. FILE EXPLORER
Open the file explorer
on your PC.
4. SELECT SD CARD
Double-click the SD card.
The raw video files will
appear in the Videos folder.
SD CARD
9
