Raymarine CP370 User manual

CP370 / CP470 / CP570
INSTALLATION
INSTRUCTIONS

Trademarkandpatentsnotice
Raymarine,Tacktick,ClearPulse,Truzoom,HSB,SeaTalk,SeaTalkhs,SeaTalkng,Micronet,Raytech,
GearUp,MarineShield,Seahawk,Autohelm,Automagic,andVisionalityareregisteredorclaimed
trademarksofRaymarineBelgium.
FLIR,DownVision,SideVision,Dragony,Instalert,InfraredEverywhere,andTheWorld’sSixth
SenseareregisteredorclaimedtrademarksofFLIRSystems,Inc.
Allothertrademarks,tradenames,orcompanynamesreferencedhereinareusedforidenticationonly
andarethepropertyoftheirrespectiveowners.
Thisproductisprotectedbypatents,designpatents,patentspending,ordesignpatentspending.
FairUseStatement
Youmayprintnomorethanthreecopiesofthismanualforyourownuse.Youmaynotmakeanyfurther
copiesordistributeorusethemanualinanyotherwayincludingwithoutlimitationexploitingthemanual
commerciallyorgivingorsellingcopiestothirdparties.

Chapter1:Importantinformation
CertiedInstallation
Raymarinerecommendscertiedinstallationbya
Raymarineapprovedinstaller.Acertiedinstallation
qualiesforenhancedproductwarrantybenets.
ContactyourRaymarinedealerforfurtherdetails,
andrefertotheseparatewarrantydocumentpacked
withyourproduct.
Warning:Productinstallationand
operation
Thisproductmustbeinstalledand
operatedinaccordancewiththe
instructionsprovided.Failuretodoso
couldresultinpersonalinjury,damage
toyourvesseland/orpoorproduct
performance.
Warning:Potentialignitionsource
ThisproductisNOTapprovedforusein
hazardous/ammableatmospheres.Do
NOTinstallinahazardous/ammable
atmosphere(suchasinanengineroom
ornearfueltanks).
Warning:Productgrounding
Beforeapplyingpowertothisproduct,
ensureithasbeencorrectlygrounded,in
accordancewiththeinstructionsprovided.
Warning:Positivegroundsystems
Donotconnectthisunittoasystemwhich
haspositivegrounding.
Warning:Powersupplyvoltage
Connectingthisproducttoavoltage
supplygreaterthanthespecied
maximumratingmaycausepermanent
damagetotheunit.RefertotheTechnical
specicationsectionforvoltagerating.
Warning:Switchoffpowersupply
Ensurethevessel’spowersupplyis
switchedOFFbeforestartingtoinstallthis
product.DoNOTconnectordisconnect
equipmentwiththepowerswitchedon,
unlessinstructedinthisdocument.
Caution:Powersupplyprotection
Wheninstallingthisproductensurethe
powersourceisadequatelyprotected
bymeansofasuitably-ratedfuseor
automaticcircuitbreaker.
Warning:Highvoltage
Thisproductcontainshighvoltage.
Adjustmentsrequirespecializedservice
proceduresandtoolsonlyavailableto
qualiedservicetechnicians.Thereare
nouserserviceablepartsoradjustments.
Theoperatorshouldneverremovethe
coverorattempttoservicetheproduct.
Warning:Transducercables
Donotremovethetransducercablewhilst
theproductispoweredon,doingsocan
causesparks.Ifthetransducercableis
accidentlyremovedwhilsttheproductis
poweredon,switchtheproduct'spower
off,replacethecableandthenswitchthe
powerbackon.
Warning:Sonaroperation
•NEVERoperatethesonarwiththe
vesseloutofthewater.
•NEVERtouchthetransducerfacewhen
thesonarispoweredon.
•SWITCHOFFthesonarifdiversare
likelytobewithin7.6m(25ft)ofthe
transducer.
Caution:Donotcuttransducer
cables
•Cuttingthetransducercableseverely
reducessonarperformance.Ifthe
cableiscut,itmustbereplaced,it
cannotberepaired.
•Cuttingthetransducercablewill
voidthewarrantyandinvalidatethe
EuropeanCEmark.
Caution:Serviceandmaintenance
Thisproductcontainsnouserserviceable
components.Pleasereferallmaintenance
andrepairtoauthorizedRaymarine
dealers.Unauthorizedrepairmayaffect
yourwarranty.
Wateringress
Wateringressdisclaimer
Althoughthewaterproofratingcapacityofthis
productmeetsthestatedIPXstandard(refertothe
product’sTechnicalSpecication),waterintrusion
andsubsequentequipmentfailuremayoccurifthe
productissubjectedtocommercialhigh-pressure
washing.Raymarinewillnotwarrantproducts
subjectedtohigh-pressurewashing.
Importantinformation

Disclaimer
Raymarinedoesnotwarrantthatthisproductis
error-freeorthatitiscompatiblewithproducts
manufacturedbyanypersonorentityotherthan
Raymarine.
Raymarineisnotresponsiblefordamagesorinjuries
causedbyyouruseorinabilitytousetheproduct,
bytheinteractionoftheproductwithproducts
manufacturedbyothers,orbyerrorsininformation
utilizedbytheproductsuppliedbythirdparties.
EMCinstallationguidelines
Raymarineequipmentandaccessoriesconformto
theappropriateElectromagneticCompatibility(EMC)
regulations,tominimizeelectromagneticinterference
betweenequipmentandminimizetheeffectsuch
interferencecouldhaveontheperformanceofyour
system
CorrectinstallationisrequiredtoensurethatEMC
performanceisnotcompromised.
Note:InareasofextremeEMCinterference,
someslightinterferencemaybenoticedonthe
product.Wherethisoccurstheproductandthe
sourceoftheinterferenceshouldbeseparatedby
agreaterdistance.
ForoptimumEMCperformancewerecommend
thatwhereverpossible:
•Raymarineequipmentandcablesconnectedto
itare:
–Atleast1m(3ft)fromanyequipment
transmittingorcablescarryingradiosignalse.g.
VHFradios,cablesandantennas.Inthecase
ofSSBradios,thedistanceshouldbeincreased
to7ft(2m).
–Morethan2m(7ft)fromthepathofaradar
beam.Aradarbeamcannormallybeassumed
tospread20degreesaboveandbelowthe
radiatingelement.
•Theproductissuppliedfromaseparatebattery
fromthatusedforenginestart.Thisisimportantto
preventerraticbehavioranddatalosswhichcan
occuriftheenginestartdoesnothaveaseparate
battery.
•Raymarinespeciedcablesareused.
•Cablesarenotcutorextended,unlessdoingsois
detailedintheinstallationmanual.
Note:Whereconstraintsontheinstallation
preventanyoftheaboverecommendations,
alwaysensurethemaximumpossibleseparation
betweendifferentitemsofelectricalequipment,to
providethebestconditionsforEMCperformance
throughouttheinstallation
Suppressionferrites
•Raymarinecablesmaybepre-ttedorsupplied
withsuppressionferrites.Theseareimportantfor
correctEMCperformance.Ifferritesaresupplied
separatelytothecables(i.e.notpre-tted),you
musttthesuppliedferrites,usingthesupplied
instructions.
•Ifaferritehastoberemovedforanypurpose(e.g.
installationormaintenance),itmustbereplacedin
theoriginalpositionbeforetheproductisused.
•Useonlyferritesofthecorrecttype,suppliedby
Raymarineoritsauthorizeddealers.
•Whereaninstallationrequiresmultipleferritesto
beaddedtoacable,additionalcableclipsshould
beusedtopreventstressontheconnectorsdue
totheextraweightofthecable.
Connectionstootherequipment
Requirementforferritesonnon-Raymarinecables
IfyourRaymarineequipmentistobeconnected
tootherequipmentusingacablenotsuppliedby
Raymarine,asuppressionferriteMUSTalwaysbe
attachedtothecableneartheRaymarineunit.
IMOandSOLAS
Theequipmentdescribedwithinthisdocument
isintendedforuseonleisuremarineboatsand
workboatsNOTcoveredbyInternationalMaritime
Organization(IMO)andSafetyofLifeatSea
(SOLAS)CarriageRegulations.
CP370/CP470/CP570

Chapter2:Documentandproductinformation
Chaptercontents
•2.1 Document information
•2.2 Parts supplied
•2.3 Product overview
•2.4 Sonar technology
•2.5 Raymarine sonar modules
Documentandproductinformation

2.1Documentinformation
Thisdocumentcontainsimportantinformation
relatedtotheinstallationofyourRaymarineproduct.
Thedocumentincludesinformationtohelpyou:
•planyourinstallationandensureyouhaveallthe
necessaryequipment;
•installandconnectyourproductaspartofawider
systemofconnectedmarineelectronics;
•troubleshootproblemsandobtaintechnical
supportifrequired.
Applicableproducts
Thisdocumentisapplicabletothefollowingproducts:
PartnumberNameDescription
E70297CP370ClearPulseTM
sonarmodule
E70298CP470ClearPulseTM
CHIRP
broadband
sonarmodule
E70258CP570ClearPulseTM
CHIRP
dual-channel
broadband
sonarmodule
Note:Yourmultifunctiondisplay’sFishnder
applicationmenuoptionsandsettingswilldiffer
dependingonthetypeofsonarmoduleinuse.
Documentconventions
Thefollowingconventionsareusedthroughoutthis
documentwhenreferringto:
TypeExampleConvention
Proceduresfor
performingspecic
tasksusingthe
product’suser
interface.
SelectSet-Up.Theterm“Select”
isusedtoreferto
theactionof:
•Touchscreen
control—using
yourngerto
selectamenu
optionoritem
onthescreen.
•Physical
buttons—
Highlighting
anitemusing
thenavigational
buttonsand
conrmingthe
selectionby
pressingtheOK
button.
Proceduresfor
navigatingmenu
hierarchies.
1.Theinternal
sonarmodule
isturned
offfromthe
Fishnder
application
menu:Menu
>Set-up
>Sounder
Set-up>
Internal
Sounder.
2.Theinternal
GPScan
beswitched
offfrom
theSet-up
menu:Menu
>Set-up>
GPSSet-up
>Internal
GPS.
Menuhierarchies
areusedinthis
documentto
provideaquick
summaryon
howtoaccessa
particularfunction
ormenuoption.
Documentillustrations
Yourproductmaydifferslightlyfromthatshown
intheillustrationsinthisdocument,dependingon
productvariantanddateofmanufacture.
Allimagesareprovidedforillustrationpurposesonly.
CP370/CP470/CP570

Productdocumentation
Thefollowingdocumentationisapplicabletoyour
product:
DescriptionPartnumber
CP370/CP470/CP570Installation
instructions
InstallationofaCP370/CP470/CP570unit
andconnectiontoawidersystemofmarine
electronics.
87213/
88027
CP370andCP470Mountingtemplate
Mountingdiagramforsurfacemountinga
CP370/CP470
87240
CP570Mountingtemplate
Mountingdiagramforsurfacemountinga
CP570
87206
LightHouse™Operationinstructions
DetailstheoperationoftheCP370/CP470/
CP570andtheFishnderapplicationforthe
followingmultifunctiondisplays:
•aSeries
•cSeries
•eSeries
•eSSeries
•gSSeries
81360
Operationinstructions
Fordetailedoperationinstructionsforyourproduct,
refertothedocumentationthataccompaniesyour
display.
Transducerinstallationinstructions
Thisdocumentincludesinstallationinstructionsfor
thesonarmoduleonly.Forinstallationinstructions
foraconnectedtransducer,pleaserefertothe
documentationthataccompaniesthetransducer.
2.2Partssupplied
CP370—Partssupplied
D13267-2
4
1
2
3
5
ItemDescriptionQuantity
1Sonarmodule1
21.5m(5ft)power
cable
1
3No.8xingscrews4
4Documentation
pack
1
52m(6.56ft)
RayNet(Female)
toRayNet
(Female)network
cable
1
CP470—Partssupplied
D13268-3
6
1
2
3
7
4
5
ItemDescriptionQuantity
1Sonarmodule1
21.5m(5ft)power
cable
1
3No.8xingscrews4
4Cableferrite1
5Additional
ground-wirekit
1
6Documentation
pack
1
72m(6.56ft)
RayNet(Female)
toRayNet
(Female)network
cable
1
Documentandproductinformation

CP570—Partssupplied
D13310-3
5
1
2
6
4
x8
x4
x4
3
ItemDescriptionQuantity
1Sonarmodule1
21.5m(5ft)power
cable
1
3Fixingscrewkit1
4Cableferrite1
5Documentation
pack
1
62m(6.56ft)
RayNet(Female)
toRayNet
(Female)network
cable
1
2.3Productoverview
CP370productoverview
TheCP370isaClearPulseTMtraditionalsonar
module.Inconjunctionwithacompatible
multifunctiondisplay,theCP370providesadetailed
viewofthewaterbeneathyourvesselincluding
thebottom,enablingyoutoidentifyshandother
objects.
D13250-2
TheCP370hasthefollowingfeatures:
•SinglechannelClearPulseTMsonar(conical
beam).
•Upto1,500mdepthrange.
•Watertemperatureandspeedsensing.
•Supportfortransom,through-hullandin-hull
transducers.
•12Vor24Vdcoperation.
•WaterprooftoIPX6.
•Robustandwaterproofhigh-speednetwork
connection.
CP470productoverview
TheCP470isaClearPulseTMCHIRPbroadband
sonarmodule.Inconjunctionwithacompatible
multifunctiondisplay,theCP470providesadetailed
viewofthewaterbeneathyourvesselincluding
thebottom,enablingyoutoidentifyshandother
objects.
D13251-2
TheCP470hasthefollowingfeatures:
•ClearPulseTMCHIRPbroadbandsonar(conical
beam).
•Upto3,000mdepthrange.
•Watertemperatureandspeedsensing.
CP370/CP470/CP570

•Supportfortransom,through-hullandin-hull
transducers.
•SupportforWideBeamtransducers.
•12Vor24Vdcoperation.
•WaterprooftoIPX6.
•Robustandwaterproofhigh-speednetwork
connection.
CP570productoverview
TheCP570isaClearPulseTMCHIRPdual-channel
broadbandsonarmodule.Inconjunctionwitha
compatiblemultifunctiondisplay,theCP570provides
adetailedviewofthewaterbeneathyourvessel
includingthebottom,enablingyoutoidentifysh
andotherobjects.
D1331 1-1
TheCP570hasthefollowingfeatures:
•DualchannelClearPulseTMCHIRPsonar(conical
beam).
•Independentchannels(2transmit,2receive).
•Upto3,000mdepthrange
•Watertemperatureandspeedsensing.
•Supportfortransom,through-hullandin-hull
transducers.
•SupportforWideBeamtransducers.
•12Vor24Vdcoperation.
•WaterprooftoIPX6.
•Robustandwaterproofhigh-speednetwork
connection.
2.4Sonartechnology
Traditionalsonartechnology
Traditionalsonarusesasinglecarrierfrequencyor
carrierwaveforthesonarping.Thesonarworksby
measuringthetimeittakesthepingechotoreturnto
thetransducertodeterminetargetdepth.
D12600-2
CHIRPtechnology
CHIRPsonarsuseasweptfrequency'CHIRP'signal
whichcandistinguishbetweenmultipleclosetargets,
thisenablesthesonartodisplaymultipletargets
insteadoflargecombinedtargetsthatyouwouldsee
whenusingtraditionalnon-CHIRPsonar.
BenetsofCHIRPincludeimprovementstotarget
resolution,bottomdetectioneventhroughbaitballs
andthermoclinesanddetectionsensitivity.
D12601-2
Documentandproductinformation

2.5Raymarinesonarmodules
ThetablebelowlistsRaymarine’scurrentrangeof
sonarmodules.
SonarmoduleTechnology/Description
CP100CHIRPDownVision™/Sonar
external
CP200SideVision™external
CP300/CP370Traditional(1kW)external
CP450C/CP470CHIRPexternal
CP570CHIRPexternal
a68/a78/a98/a128/
eS78/eS98/eS128
CHIRPDownVision™/Sonar
internal
a67/a77/a97/a127/
c97/c127/e7D/e97
/e127/eS77/eS97/
eS127
Traditional(600W)internal
DSM30/DSM300Legacyexternal
DragonyCHIRPDownVision™/Sonar
internal
Note:SideVision™cannotbeusedasasource
ofdepthdata.
CP370/CP470/CP570

Chapter3:Planningtheinstallation
Chaptercontents
•3.1 Installation checklist
•3.2 Required additional components
•3.3 Compatible multifunction displays
•3.4 Software updates
•3.5 Tools required
•3.6 System examples
•3.7 Warnings and cautions
•3.8 General location requirements
•3.9 Product dimensions
Planningtheinstallation

3.1Installationchecklist
Installationincludesthefollowingactivities:
InstallationTask
1Planyoursystem.
2Obtainallrequiredequipmentandtools.
3Siteallequipment.
4Routeallcables.
5Drillcableandmountingholes.
6Makeallconnectionsintoequipment.
7Secureallequipmentinplace.
8Poweronandtestthesystem.
Schematicdiagram
Aschematicdiagramisanessentialpartofplanning
anyinstallation.Itisalsousefulforanyfuture
additionsormaintenanceofthesystem.The
diagramshouldinclude:
•Locationofallcomponents.
•Connectors,cabletypes,routesandlengths.
3.2Requiredadditionalcomponents
Thisproductformspartofasystemofelectronics
andrequiresthefollowingadditionalcomponentsfor
fulloperation.
•
For a list of transducer cables refer to 10.1 Spares
and accessories.
•
Compatible Raymarine multifunction display.
Refer to 3.3 Compatible multifunction displays for
a list of compatible products.
•
Data cables. Refer to Chapter 4 Cables and
connections for suitable cables. Some installations
may also require extensions to data, power or
transducer cables. Refer to the Chapter 4 Cables
and connections and Chapter 10 Spares and
accessories sections for more information.
CP370:EMCcompliance
Important:T oensureEMCCompliance,the
transducerslistedbelowareNOTcertiedtobe
usedwiththeCP370inthefollowingregions:
•Australia;
•NewZealand;
•anymemberstateoftheEuropeanEconomic
Area(EEA);
•EuropeanFreeTradeAssociationcountries
Iceland,Liechtenstein,NorwayandSwitzerland;
•anycountrythatrequiresEMCDirective
Compliance.
Ifindoubt,pleasecontactyourlocaldealeror
Raymarinetechnicalsupport.
TransducersNOTcertiedtobeusedwiththe
CP370intheregionslistedabove:
•E66054(P66,Plastic,Transommount)
•E66008(P79,Plastic,In-hull)
•A66091(B744V,Bronze,Through-hull)
•A66092(B744VL,Bronze,Through-hull)
•E66013(P319,Plastic,Through-hull)
•E66014(B117,Bronze,Through-hull)
•E66085(B60–20°,Bronze,Tiltedelement,
Through-hull)
•E66086(B60–12°,Bronze,Tiltedelement,
Through-hull)
CP370/CP470/CP570

3.3Compatiblemultifunctiondisplays
ThefollowingRaymarinemultifunctiondisplaysare
compatiblewithyoursonarmodule.
Multifunc-
tiondisplayCP370CP470CP570
gSSeries●●●
eSSeries●●●
eSeries●●●
cSeries●●●
aSeries●●●
E-Series
Widescreen
●Not
compatible
Not
compatible
C-Series
Widescreen
●Not
compatible
Not
compatible
G-Series●Not
compatible
Not
compatible
EClassic●Not
compatible
Not
compatible
CClassicNot
compatible
Not
compatible
Not
compatible
3.4Softwareupdates
Thesoftwarerunningontheproductcanbeupdated.
•Raymarineperiodicallyreleasessoftwareupdates
toimproveproductperformanceandaddnew
features.
•Youcanupdatethesoftwareforyourproductusing
aconnectedandcompatiblemultifunctiondisplay.
•Ifindoubtastothecorrectprocedureforupdating
yourproductsoftware,refertoyourdealeror
Raymarinetechnicalsupport.
Caution:Downloadingsoftware
updates
Thesoftwareupdateprocessiscarried
outatyourownrisk.Beforeinitiatingthe
updateprocessensureyouhavebacked
upanyimportantles.
Ensurethattheunithasareliablepower
supplyandthattheupdateprocessisnot
interrupted.
Damagecausedbyincompleteupdates
arenotcoveredbyRaymarinewarranty.
Bydownloadingthesoftwareupdate
package,youagreetotheseterms.
Planningtheinstallation

3.5Toolsrequired
Productinstallationrequiresthefollowingtools:
ItemDescriptionQuantity
Powerdrill1
Pozidrivescrewdriver1
Drillbitofappropriatesize*1
Adhesivetape1
Note:*Theappropriatedrillbitsizeisdependent
onthethicknessandmaterialofthemounting
surface.
3.6Systemexamples
Thesystemexamplesbelowapplytoyoursonar
module.
Example:Basicsystem
D13252-2
1
2
3
ItemDescription
1CompatibleRaymarinemultifunctiondisplay
2Sonarmodule(CP470illustrated)
3Transducer
CP370/CP470/CP570

Example:Extendedsystem
SeaTalkhs / RayNet
SeaTalkng
D13253-2
SeaTalkng
SeaTalkhs / RayNet
1
2
3
4
56
78
ItemDescription
1Sonarmodule(CP470illustrated)
2Raymarinenetworkswitch
3Digitalradome
4CompatibleRaymarinemultifunctiondisplay
5Transducer
6ActuatorControlUnit(ACU)
7EVunit
8SeaTalkngPilotcontroller
Note: For detailed information on sonar module
connections refer to Chapter 4 Cables and
connections.
3.7Warningsandcautions
Important: Before proceeding, ensure that you
have read and understood the warnings and
cautions provided in the Chapter 1 Important
information section of this document.
Planningtheinstallation

3.8Generallocationrequirements
Importantconsiderationswhenchoosingasuitable
locationforyourproduct.
Thisproductissuitableformountingaboveorbelow
decks.
Theproductshouldbemountedwhereitwillbe:
•protectedfromphysicaldamageandexcessive
vibration.
•wellventilatedandawayfromheatsources.
•awayfromanypotentialignitionsourcesuchasan
engineroom,nearfueltanksoragaslocker.
Whenchoosingalocationfortheproduct,
considerthefollowingpointstoensurereliableand
trouble-freeoperation:
•Access—theremustbesufcientspaceto
enablecableconnectionstotheproduct,avoiding
tightbendsinthecable.
•Diagnostics—theproductmustbemountedin
alocationwherethediagnosticsLEDiseasily
visible.
Note: Not all products include a diagnostics
LED. Refer to the Chapter 6 System checks
and troubleshooting for more information.
•Electricalinterference—theproductshouldbe
mountedfarenoughawayfromanyequipment
thatmaycauseinterferencesuchasmotors,
generatorsandradiotransmitters/receivers.
•Magneticcompass—refertotheCompass
safedistancesectioninthisdocumentforadvice
onmaintainingasuitabledistancebetweenthis
productandanycompassesonyourvessel.
•Power—tokeepcablerunstoaminimum,the
productmustbelocatedascloseaspossibleto
thevessel’sdcpowersupply.
•Mountingsurface—ensuretheproductis
adequatelysupportedonasecuresurface.Refer
totheweightinformationprovidedintheTechnical
specicationforthisproductandensurethatthe
intendedmountingsurfaceissuitableforbearing
theproductweight.DoNOTmountunitsorcut
holesinplaceswhichmaydamagethestructure
ofthevessel.
Cableroutingrequirements
Considerthefollowingbeforeinstallingthesystem
cables:
•Youwillneedtoattachpower,transducerand
networkcablestotheunit.
•Thetransducercableshouldonlybeextended
wherethesonarmodulecannotbeinstalled
closeenoughtothetransducertoallowadirect
connection.
•Allcablesshouldbeadequatelysecured,
protectedfromphysicaldamage,andprotected
fromexposuretoheat.
•Avoidsharpbendsincables.
•Useawatertightfeed-throughwherevera
cablepassesthroughanexposedbulkheador
deckhead.
•Securecablesinplaceusingtie-wrapsorlacing
twine.Coilanyextracableandtieitoutoftheway.
•DoNOTruncablesthroughbilgesordoorways,or
closetomovingorhotobjects.
•DoNOTruncablesneartoenginesoruorescent
lights.
Alwaysroutedatacablesasfarawayaspossible
from:
•otherequipmentandcables,
•highcurrentcarryingacanddcpowerlines,
•antennas.
Compasssafedistance
Topreventpotentialinterferencewiththevessel's
magneticcompasses,ensureanadequatedistance
ismaintainedfromtheproduct.
Whenchoosingasuitablelocationfortheproduct
youshouldaimtomaintainthemaximumpossible
distancefromanycompasses.Typicallythisdistance
shouldbeatleast1m(3ft)inalldirections.However
forsomesmallervesselsitmaynotbepossibleto
locatetheproductthisfarawayfromacompass.In
thissituation,whenchoosingtheinstallationlocation
foryourproduct,ensurethatthecompassisnot
affectedbytheproductwhenitisinapoweredstate.
CP370/CP470/CP570

3.9Productdimensions
CP370dimensions
AD
C
E
D13247-2
B
ItemDimension
A299.4mm(11.79in)
B188.0mm(7.4in)
C201.5mm(7.9in)
D84.4mm(3.3in)
E80.0mm(3.1in)
CP470dimensions
AD
C
E
D13247-2
B
ItemDimension
A299.4mm(11.79in)
B188.0mm(7.4in)
C205.6mm(8.1in)
D84.4mm(3.3in)
E80.0mm(3.1in)
CP570dimensions
AD
C
E
D13312-1
B
ItemDimension
A352.5mm(13.9in)
B235mm(9.3in)
C248.1mm(9.8in)
D109.9mm(4.3in)
E80.0mm(3.1in)
Planningtheinstallation

Chapter4:Cablesandconnections
Chaptercontents
•4.1 General cabling guidance
•4.2 Connections overview
•4.3 Power connection
•4.4 Transducer connections
•4.5 Network connection
Cablesandconnections

4.1Generalcablingguidance
Cabletypesandlength
Itisimportanttousecablesoftheappropriatetype
andlength
•Unlessotherwisestateduseonlystandardcables
ofthecorrecttype,suppliedbyRaymarine.
•Ensurethatanynon-Raymarinecablesareofthe
correctqualityandgauge.Forexample,longer
powercablerunsmayrequirelargerwiregauges
tominimizevoltagedropalongtherun.
Routingcables
Cablesmustberoutedcorrectly,tomaximize
performanceandprolongcablelife.
•DoNOTbendcablesexcessively.Wherever
possible,ensureaminimumbenddiameterof200
mm(8in)/minimumbendradiusof100mm(4in).
100 mm (4 in)
200 mm (8 in)
•Protectallcablesfromphysicaldamageand
exposuretoheat.Usetrunkingorconduitwhere
possible.DoNOTruncablesthroughbilgesor
doorways,orclosetomovingorhotobjects.
•Securecablesinplaceusingtie-wrapsorlacing
twine.Coilanyextracableandtieitoutoftheway.
•Whereacablepassesthroughanexposed
bulkheadordeckhead,useasuitablewatertight
feed-through.
•DoNOTruncablesneartoenginesoruorescent
lights.
Alwaysroutedatacablesasfarawayaspossible
from:
•otherequipmentandcables,
•highcurrentcarryingacanddcpowerlines,
•antennae.
Strainrelief
Ensureadequatestrainreliefisprovided.Protect
connectorsfromstrainandensuretheywillnotpull
outunderextremeseaconditions.
Circuitisolation
Appropriatecircuitisolationisrequiredfor
installationsusingbothACandDCcurrent:
•Alwaysuseisolatingtransformersoraseparate
power-invertertorunPC’s,processors,displays
andothersensitiveelectronicinstrumentsor
devices.
•AlwaysuseanisolatingtransformerwithWeather
FAXaudiocables.
•Alwaysuseanisolatedpowersupplywhenusing
a3rdpartyaudioamplier.
•AlwaysuseanRS232/NMEAconverterwith
opticalisolationonthesignallines.
•AlwaysmakesurethatPC’sorothersensitive
electronicdeviceshaveadedicatedpowercircuit.
Cableshielding
Ensurethatalldatacablesareproperlyshielded
thatthecableshieldingisintact(e.g.hasn’tbeen
scrapedoffbybeingsqueezedthroughatightarea).
Suppressionferrites
•Raymarinecablesmaybepre-ttedorsupplied
withsuppressionferrites.Theseareimportantfor
correctEMCperformance.Ifferritesaresupplied
separatelytothecables(i.e.notpre-tted),you
musttthesuppliedferrites,usingthesupplied
instructions.
•Ifaferritehastoberemovedforanypurpose(e.g.
installationormaintenance),itmustbereplacedin
theoriginalpositionbeforetheproductisused.
•Useonlyferritesofthecorrecttype,suppliedby
Raymarineoritsauthorizeddealers.
•Whereaninstallationrequiresmultipleferritesto
beaddedtoacable,additionalcableclipsshould
beusedtopreventstressontheconnectorsdue
totheextraweightofthecable.
CP370/CP470/CP570

4.2Connectionsoverview
Cableconnectorsforyoursonarmoduleareshown
below:
CP370sonarmodule
D13265-2
123
CP470sonarmodule
1234
D13264-2
CP570sonarmodule
D13314-2
123
ItemDescription
1Networkconnection
2Powerconnection
3Transducerconnection
4Additionalgroundingpoint(CP470only)
Makingconnections
Followthestepsbelowtoconnectthecable(s)to
yourproduct.
1.Ensurethatthevessel'spowersupplyisswitched
off.
2.Ensurethatthedevicebeingconnectedtothe
unithasbeeninstalledinaccordancewiththe
installationinstructionssuppliedwiththatdevice.
3.Ensuringcorrectorientation,pushthecable
connectorfullyontothecorrespondingconnector
ontheunit.
4.Turnthelockingcollarclockwisetosecurethe
cable.
4.3Powerconnection
Alwaysusethepowercableprovidedwithyour
product.
1
2
3
D13254-2
ItemDescription
1REDpositivewire
2Ground
3BLACKnegativewire
12
34
D13255-2
ItemDescription
1Powersupply
2Sonarmodule(CP470illustrated)
3Vessel'sRFground
4Transducer
Theunitisintendedforuseondc'negative'or
'oating'groundpowersystemsratedfrom10.2V
to32V.
Raymarinerecommendsthatallpowerconnections
aremadeviaadistributionpanel.Allequipment
mustbeeither:
•poweredfromacircuitbreakerorswitch,with
circuitprotection(5A),or
•poweredfromaslowblowin-linefuse(5A)
connectedtotheREDpositivewireofthepower
cable.
TheunitdoesNOThaveapowerswitch.Theunit
ispoweredwhenthepowercableisattachedtothe
vessel'spowersupply.
Cablesandconnections
