Raysgem M2G User manual

USER MANUAL M2G
The picture is for reference only, the actual product may differ. No further
notice for the appearance modification.
M2G SMART MIRROR
10.1”

M2G SMART MIRROR

01
Quick Guide
Index
1
Installation
3
Dimension
4
5
Connection
2
Others
6
02~07
01
09
10-11
12
13
14
Thank you for purchasing this Smart mirror. Before installation, please read this user
manual first and keep it with you for later reference.
Note: In case of electric shock, please do not try to
open Smart mirror. When malfunction happens, please
consult a profession before you open Smart mirror .
Warning- In case of fire, please keep Smart mirror away from candles or any other fire or heat.
·Please keep Smart mirror away from any heat or under direct sun light.
·Please keep Smart mirror away from anything that can generate heat, such as candles, ashtrays, incensation,
combustible gas or explosive substance.
·Please do not overload your wall sockets, extension power cables.
·Please place the power cable properly without anything pressing again the power cable.
·For safety reasons, please unplug Smart mirror power in storm weather or when you won't be using Smart mirror
for a long time.
·Please use proper direct current supply for Smart mirror. Make sure your local DC power is within safety range.
·In case of any electric shock, please do not insert any metal object into Smart mirror sockets.
·Please make sure power jack is plugged in tightly into your power socket. Unplug power jack when you
disconnect Smart mirror.
·Please do not touch Smart mirror's power cable with wet hands.
·In case of any malfunction, especially when there's unusual sound or smell coming out of Smart mirror, please
unplug the power and contact your supplier immediately.
·If you'll be leaving Smart mirror unused for a very long time or traveling with our senior family members, children
and people with disabilities at home, please make sure to unplug Smart mirror.
·Too much dirt on the power socket or cable might generate heat and cause insulation aging, please keep it clean
in case of electric shock and fire.
·Please make sure your power socket is well grounded in case of electric shock or damage to Smart mirror.
·To unplug Smart mirror is to unplug from your power socket, for convenience, we recommend you to use power
socket with its own ON/OFF switch.
·Please do not allow children to play with Smart mirror.
·Please install Smart mirror in a safe place, any wobble or tilt installation puts Smart mirror in a vulnerable position.
·In case of fall and damage to Smart mirror, please unplug the power and contact your local supplier immediately.
·Unplug Smart mirror before you clean it. Use soft and dry cloth to wipe it clean. Do not use any chemical solution
on Smart mirror surface for it might erode Smart mirror.
This is a sign of high voltage danger. Any
contact with the internal parts can be
extremely dangerous.
This is for important notes of how to
maintain Smart mirror.
Warning
Do not try to open Smart mirror in case of electric shock

02 03
Standard Smart Mirror package contains the following items as below. Please
contact your local retailer if anything is missing. Some of the items in this manual
may differ because of customization or model.
Full HD display
Full touch on display area
ON/OFF
Left and right sides
Front View 1. Mirror panel
2. Display area
3. Touch area
4. Touch button
Speakers
Quick Guide
Package Introduction
Smart Mirror is a mirror that can serve you as a dressing mirror, but also comes
with touch screen, display and voice control. Mirror is an interactive terminal of
master control, and a comprehensive hub for all smart devices. Smart Mirror helps
to establish a smart home system for kitchen and bathroom. For more information,
please visit our website https://raysgem.com
Mirror*1
Screwhead *3
Dilating screw *3
Power adapter*1
User Manual*1 Installation Instruction*1
1
INSTALLATION
INSTRUCTION

04 05
Quick Guide
1、Start up & Shut down
① Start up: Press the power button for 2 seconds, Smart Mirror will boot up till
the home page appears.
② Re-start: Long press the power button for 10 seconds, Smart Mirror will Re-start
③ Turn ON/OFF the display: Single tap the power button to Turn ON/OFF the display.
Single tap on screen also can turn on The display.
④ Turn ON/OFF the LED light: Single tap the LED light button to turn ON/OFF the
LED light, single tap the LED light button quickly to switch Between the light colors,
Long press the LED light button to adjust the Light brightness. The LED light button
is in blue when the LED light is off, and it is in white when the LED light is on.
⑤ Turn ON/OFF the Anti-fog function: Single tap the anti-fog button to turn on the
anti-fog function, and single tap again to turn it off. The button is in blue when the
anti-fog is off, and it is in white when the anti-fog is on. The anti-fog will be turned
off automatically when it has been working for more than one hour.
Back View
2 Metal casing
1. Wall Anchor
Frosted surface
Wall mount support
USB type A DC 12V 4A
No. Port
DC DC 12V 4A
Description
USB USB type A
MIC
USB DC
Start up
Re-start
Press 2s
Press 10s
On/Off
Switch light colors
Adjust brightness
Single tap
Single tap quickly
Long press
On/OffSingle tap

06 07
5. Blue tooth
Enter Android system setting after the smart mirror is powered on, enter
connected devices and enter Connection preferences,
Enter Bluetooth and turn it on to search and pair with your Bluetooth devices.
6. Connect to your Smart Home
Install and Enter Google Home, enter Add and manage, create new home or set
up device in an existing home, Enter Work with Google to search and authorize
with your Smart Home brands. Use Google Home or Google assistant to control
the smart home devices after the authorization with your Google account.
Sleep monitor, Blood pressure
monitor, Blood sugar monitor,
skin monitor and etc..
Smart Devices
3. WLAN network setting
Enter Android system setting after the smart mirror is powered on, enter WLAN and
turn it on, Enter your WiFi password to connect with internet.
2. Voice Control
The smart mirror supports Google assistant voice control. Please sign in Google
assistant with your Google account. When the first time the smart mirror is powered
on. Set your own language and match your voice in Google assistant. Say“Hey
Google”to active Google assistant within 5 meters from the smart mirror.
4. App Installation
Enter Google Play Store after the smart mirror is powered on, log in Google
Play Store with your Google account at the first time, then search, download
and install your favorite apps.

Installation
Installation
3
Flush Mount
Open a recess as shown in the wall
where you want to install the Mirror, fix
Mirror to the wall.
Wall
Wall
Wall
Decorative Frame
Mirror
Mirror
Mirror
Wall Mount
Hang Mirror directly to the wall.
Customized Installation
Install the Mirror same as wall mount, add
customized frame around the mirror.
08 09
Connection
2
Connect to power
1. Connect Mirror to power as shown above.
2. Long press the power button to start up the smart mirror after the power
is successfully connected.
Power cable
Power
socket(100-240V)
USB
USB
Connect to USB device
USB drive
Portable hard drive
Insert USB drive or portable hard drive to Mirror through USB port.

Notes: Be careful during installation to avoid scratching the mirror surface.
Installation Demonstration
10 11
Fix the screws into the wall and
hang the Smart Mirror.
Wall Mount
133
600
Wallmount fixture 360mm
Wall mount screw*2
Wall mount fixture 500mm
Size/mm
No further notice on small changes on the same model.
Dimension
4
500
58
360
150
35
600
800
10.1”216
135
Front view Side view
Back view
Mirror Wall
Installation
instruction paper

5
Display
Others
6
Troubleshooting
Notes
Couldn't start up Smart Mirror
No image/sound or bad display
1. Use only original power cable that comes with the Smart Mirror.
2. Keep power cable in good shape and condition.
3. In any case of malfunction, unplug Smart Mirror immediately.
4. Unplug the Smart Mirror if you won't be using it for a long time.
In any case of malfunction, before sending Smart Mirror for maintenance, please
read the following instructions and solution.
1. Check if power jack is loose.
1. Make sure settings are properly adjusted.
2. Contact with your product and service provider for support.
12 13
Troubleshooting is only for users who are facing major operating issues on Smart
mirror. If users should have problems with specific functional page, please go to
your retailer to get user manuals on specific functions.
Display size
Display type
Resolution
Contrast ratio
Brightness
Viewing angle
Response time
10.1 inch
IPS
1920*1200
1000:1
650cd/m (Original LCD screen)
178°(H) * 178°(V)
25ms
CPU
GPU
RAM
ROM
Camera
WIFI
Bluetooth
LED lighting
Anti-fog film
Speaker
Touch screen
Voice Assistant
OS
2.0GHz A75*2 + 1.8GHz A55*6
Mali-G52
4GB
32G
No
Double frequency 2.4/5GHz IEEE 802.11a/b/g/n/ac
Bluetooth 5，Bluetooth Smart
Yes
Yes
2*3W
Yes(5 points)
Yes
Android 11
Dimension/Material/Process
General size
Thickness
Mirror panel
Material/Process
Gross weight
Net weight
Package dimension
800mm(H)x600mm(W)
35mm
Coated silver mirror
Metal housing
and Aluminum frame
13.7 kg
9.6 kg
930*740*170mm
Consumption
Interfaces
Power input
USB
Power input
Consumption
Standby
DC 12V 4A
≤48W
≤1W
DC 12V
Type A x 1
Configuration
Specifications
Radiodienst Betriebsfrequenz
(MHz)
Maximale Maximaler Antennengewinn
(dBi)
Ausgangsleistung(dBm)
Bluetooth LE 2402-2480
2402-2480
8.33,EIRP 5,87
5,87
5,87
6.36
7.54
9.30 Uhr
8.61
Bluetooth BR+EDR
WLAN 2.4 GHZ
IEEE 802.11 b/g/n (20/40 MHz)
RLAN 5 GHz
IEEE 802.11 a/n/ac(20/40/80 MHz)
SRD 58 GHz
IEEE 802.11 a/n/ac(20/40/80 MHz)
2412-2472 17.52, EIRP
16,84,EIRP
16,51,EIRP
16,95,EIRP
13.03,EIRP
6,75, EIRP
5180-5240
5260-5320
5500-5700
5745-5825

NOTE
14
Declaration of Conformity (DOC)
RAYSGEM ELECTRONICS & TECHNOLOGY CO., LTD, hereby declares that this product
conforms to Directive 2014/53/EU.
Disposal
This symbol must appear on any electrical and electronic equipment placed on the EU market.
This symbol indicates that this device should not be disposed of as unsorted municipal waste
at the end of its service life.
Owners of WEEE (Waste from Electrical and Electronic Equipment) shall dispose of it separately
from unsorted municipal waste. Spent batteries and accumulators, which are not enclosed by
the WEEE, as well as lamps that can be removed from the WEEE in a non-destructive manner,
must be removed by end users from the WEEE in a non-destructive manner before it is handed
over to a collection point.
