Raytheon E32001 User manual

Raystar112LPGPSTransducer
E32001, E32002
Raystar 112LP GPS Transducer Service Manual 83143-1 1
Warning
CE Marking of Equipment/Replacement Parts
IftheRaytheon equipmentunderrepair,test,calibration,installationorsettingtoworkcarriestheEuropeanCEmark,
onlypartsandcomponentssuppliedorapprovedforsuchusebyRaytheonshouldbeusedinordertomaintain
compliancewiththerelevantCErequirements.
Incorporation,useorattachment,byanymeans,ofpartsorcomponentsnotsuppliedforornotapprovedforsuchuseby
Raytheonor,ifsuppliedorapprovedforusebyRaytheon,notproperlyfittedinaccordancewithinstructionspublished,
providedorrecommendedbyRaytheon,maycausetheequipmenttomalfunctionand,inparticular,tobecomeunsafeor
tonolongermeettherelevantCErequirements.Inthesecircumstances,RaytheonMarineEuropeLtdexcludesliability
tothefullestextentpermissibleinlawforanylossordamageincludinganyliabilityforitscontributiontosuchlossor
damagebyitsnegligentactsoromissions.
E32001(SeaTalk),
E32002(NMEA),
Raystar112LP GPSTransducer
Service Manual
D4376-1

Raystar112LPGPSTransducer
E32001, E32002
2Raystar 112LP GPSTransducer Service Manual 83143-1
Chapter 1. Disassembly/Assembly
Gasket for
Surface Mounting Bracket for Pole/ Rail Mounting
1
10
7 (x3)
Torque
3lb/in
6
5
4
3
8
2 (x3)
Torque
3lb/in
11
12 (x2)
9
13
1. Top cover
2. Screw (x3), No.2 x 3/8 inch
3. Base
4. 'O' ring, inner case seal
5. Cable gland
6. Cable clamp
7. Screw (x3), No.2 x 5/16 inch
8. 'O' ring, outer case seal
9. Base gasket
10. PCB assembly (NMEA or SeaTalk)
11. Pole/rail mounting bracket
12. Screw (x2), M4 x 12 mm
13. Cable (NMEA and SeaTalk)
14. Stud (x2)
15. Thumbnut (x2)
Cable fitting dimensions
14 (x2)
15 (x2)
5mm (0.2 inch)
20mm
(0.8 inch)
Cable clamp
PCB assembly wiring
(NMEA or SeaTalk)
BrownRed Screen Yellow Green
ONLY use studs (14)
and thumbnuts (15)
when surface mounting.
D4375-1
Figure1: Raystar112LPGPSTransducerexplodedview

Raystar112LPGPSTransducer
E32001, E32002
Raystar 112LP GPS Transducer Service Manual 83143-1 3
1.1 Raystar 112LP GPS Transducer spare parts list
Theitem numbersreferto
Figure1:Raystar112LPGPSTransducerexplodedview
Item SpareDescription PartNo. Comments
Upperhousingassembly, including E38002
1 Topcover
2 Screw(x3),No.2x3/8inch Torque3lb/in
Lowerhousingassembly, including E38003
3 Base
4 ‘O’ring,innercaseseal AlsoinE38005
5 Cablegland AlsoinE38005,E38006
6 Cableclamp AlsoinE38006
7 Screw(x3),No.2x5/16inch Torque3lb/in
8 ‘O’ring,outercaseseal AlsoinE38005,E38006
9 Basegasket AlsoinE38005
10 PCBassembly
NMEA E38004
SeaTalk E38007
Pole/railmountingbracketkit, including E35001 Accessory
11 Mountingbracket
12 Screw(x2),M4x12mm
Cableassembly, including E38006
13 Cable(NMEA)
5 Cablegland AlsoinE38003,E38005
6 Cableclamp AlsoinE38003
7 Screw(x3),No.2x5/16inch AlsoinE38003
Sealkit, including E38005
4 ‘O’ring,innercaseseal AlsoinE38003
5 Cablegland AlsoinE38003,E38006
8 ‘O’ring,outercaseseal AlsoinE38003,E38006
9 Basegasket AlsoinE38003
1.2 Connections (NMEA and SeaTalk)
3Screen (0V/ground)
2Screen
(0V/ground)
1Red
(Power )
4Yellow
(NMEA out)
5Green
(NMEA in)
6Brown (RTCM in)
D4377-1
NMEA connection
D4378-1
Red (12V)
Yellow (SeaTalk input/output)
Brown (RTCM in)
Green (not connected)
Screen (0V/ground)
SeaTalk connection
(Socket removed for SeaTalk)

Raystar112LPGPSTransducer
E32001, E32002
4Raystar 112LP GPSTransducer Service Manual 83143-1
Chapter 2. PCB Details
2.1 PCB Layout – NMEA
Taken from Drawin
g
No: 4396-003 Issue: K Date: 10-06-98
D4379-1

Raystar112LPGPSTransducer
E32001, E32002
Raystar 112LP GPS Transducer Service Manual 83143-1 5
PCB Component List – NMEA
Taken from Drawin
g
No: 4396-003 Issue: K Date: 10-06-98
D4380-1

Raystar112LPGPSTransducer
E32001, E32002
6Raystar 112LP GPSTransducer Service Manual 83143-1
2.2 PCB Layout – SeaTalk
Taken from Drawin
g
No: 4396-005 Issue: K Date: 10-06-98
D4381-1

Raystar112LPGPSTransducer
E32001, E32002
Raystar 112LP GPS Transducer Service Manual 83143-1 7
PCB Component List – SeaTalk
Taken from Drawin
g
No: 4396-005 Issue: K Date: 10-06-98
D4382-1

Raystar112LPGPSTransducer
E32001, E32002
8Raystar 112LP GPSTransducer Service Manual 83143-1
Circuit Diagram – NMEA
D4385-1

Raystar112LPGPSTransducer
E32001, E32002
Raystar 112LP GPS Transducer Service Manual 83143-1 9
Circuit Diagram – SeaTalk
D4386-1

Raystar112LPGPSTransducer
E32001, E32002
