Razor Dirt Quad User manual

OWNER’S MANUAL
Read and understand this entire manual before using!
For assistance contact Razor. DO NOT RETURN TO STORE.
Item Number:
25117460
DIRT QUAD
DIRT QUAD

WARNING:
Riding an electric four wheeler can be a hazardous
activity. Certain conditions may cause the equipment to fail without
fault of the manufacturer. Like other electric vehicles, the Dirt
Quad can and is intended to move, and it is therefore possible to
lose control, fall off and/or get into dangerous situations that no
amount of care, instruction or expertise can eliminate. If such things
occur you can be seriously injured or die, even when using safety
equipment and other precautions.
RIDE AT YOUR OWN RISK AND
USE COMMON SENSE.
This manual contains many warnings and cautions concerning the
consequences of failing to maintain, inspect or properly use your
electric four wheeler
. Because any incident can result in serious injury
or even death, we do not repeat the warning of possible serious
injury or death each time such a possibility is mentioned.
APPROPRIATE RIDER USE AND PARENTAL SUPERVISION
This manual contains important safety information. It is your
responsibility to review this information and make sure that all riders
understand all warnings, cautions, instructions
and safety topics and
assure that young riders are able to safely and responsibly use this
product. Razor USA recommends that you periodically review and
reinforce the information in this manual with younger riders, and that
you inspect and maintain your children’s vehicle to insure their safety.
The recommended rider age of 8 years
is only an estimate, and can
be affected by the rider’s size, weight or skills. Any rider unable to fi t
comfortably on the Dirt Quad should not attempt to ride it.
A parent’s decision to allow his or her child to ride this
product should be based on the child’s maturity, skill and
ability to follow rules.
Keep this product away from small children and remember that this
product is intended for use only by persons who are, at a minimum,
completely comfortable and competent while operating the vehicle.
DO NOT EXCEED THE WEIGHT LIMIT OF 120
pounds
.
Rider weight does
not necessarily mean a person’s size is appropriate to fi t or maintain
control of the Dirt Quad.
Do not touch the brakes or electric motor on your electric four
wheeler
when in use as they can become very hot.
Refer to the following section on safety for additional warnings.
ACCEPTABLE RIDING PRACTICES AND CONDITIONS
Always check and obey any local laws or regulations which
may affect the locations where the Dirt Quad may be used.
Ride defensively. Watch out for potential obstacles that could catch
your wheel or force you to swerve suddenly or lose control. Be careful
to avoid pedestrians, skaters, skateboards, scooters, bikes, children
or animals who may enter your path, and respect the rights and
property of others.
The Dirt Quad is meant to be used on private property and on closed
courses and not on public streets or sidewalks. Do not ride your
electric four wheeler in any areas where pedestrian or vehicle traffi c
is present.
Do not activate the speed control on the hand grip unless you are on
the electric four wheeler and in a safe, outdoor environment suitable
for riding.
This product was manufactured for performance and durability but
are not impervious to damage. Jumping or other aggressive riding can
over-stress and damage any product, including the Dirt Quad, and the
rider assumes all risks associated with high-stress activity.
Be careful and know your limitations. Risk of injury increases as
the degree of riding diffi culty increases. The rider assumes all risk
associated with aggressive riding activities.
Maintain a hold on the handlebars at all times.
Never carry passengers or allow more than one person at a time to
ride the electric four wheeler.
Never use near steps or swimming pools.
Keep your fi ngers and other body parts away from the drive chain,
steering system, wheels and all other moving components.
Never use headphones or a cell phone when riding.
Never hitch a ride with another vehicle.
Do not ride the Dirt Quad in wet or icy weather and never immerse
the electric four wheeler in water, as the electrical and drive
components could be damaged by water or create other possibly
unsafe conditions.
Wet, slick, bumpy, uneven or rough surfaces may increase risks of
use. Do not drive the electric four wheeler in mud, ice, puddles or
water. Avoid excessive speeds that can be associated with downhill
rides. Never risk damaging surfaces such as carpet or fl ooring by use
of an electric four wheeler indoors.
Do not ride at night or when visibility is limited.
PROPER RIDING ATTIRE
Always wear proper protective equipment such as an approved safety
helmet (with chin strap securely buckled), elbow pads and kneepads.
A helmet may be legally required by local law or regulation in your
area. A long-sleeved shirt, long pants and gloves are recommended.
Always wear athletic shoes (lace-up shoes with rubber soles), never
drive barefooted or in sandals, and keep shoelaces tied and out of the
way of the wheels, motor and drive system.
USING THE CHARGER
The charger supplied with the electric four wheeler should be
regularly examined for damage to the cord, plug, enclosure and other
parts, and in the event of such damage, the bike must not be charged
until the charger has been repaired or replaced.
Use only with the recommended charger.
The charger is not a toy.
Always disconnect from the charger prior to wiping down and
cleaning your electric four wheeler with liquid.
FAILURE TO USE COMMON SENSE AND HEED THE ABOVE
WARNINGS INCREASES RISK OF SERIOUS INJURY. USE WITH
APPROPRIATE CAUTION AND SERIOUS ATTENTION TO SAFE
OPERATION.
SAFETY WARNINGS
Safety Warnings
.................................................................................
1
Before You Begin
.................................................................................
2
Assembly and Set-Up
......................................................................
3-4
Repair and Maintenance
.................................................................
4-6
Troubleshooting Guide
....................................................................
7-8
1
Parts List
........................................................................................
9-10
Safety Reminders
..............................................................................
12
Warranty Information
........................................................................
12
CONTENTS

Remove contents from box. Remove the foam separators that protect the components from damage during
shipping. Inspect the contents of the box for scratches in the paint, dents or kinked cables that may have
occurred during shipping. Because the Dirt Quad was 95 percent assembled and packed at the factory,
there should not be any problems, even if the box has a few scars or dents.
Estimated Assembly and Set-Up Time
Razor recommends assembly by an adult with experience in bicycle mechanics.
Allow up to 20 minutes for assembly, not including initial charge time.
Allow up to 12 hours for initial charge (see page 3 for charging information).
BEFORE YOU BEGIN
2
WARNING:
DO NOT USE NON-RAZOR
PRODUCTS WITH YOUR RAZOR
DIRT QUAD
. The Dirt Quad
has been built to certain Razor
design specifi cations. The
original equipment supplied at
the time of sale was selected
on the basis of its compatibility
with the frame, fork and all
other parts. Certain aftermarket
products may or may not be
compatible.
Required Tools
Some tools may be supplied; however, we recommend the use of mechanic’s grade tools. Use the supplied
tools only as a last resort.
Need Help?
Visit our web site for updates and a list of authorized service centers at
www.razor.com
or call toll-free
at
866-467-2967
Monday - Friday 8:00 AM - 5:00 PM Pacifi c Time.
2.5
mm
,
5mm and 6mm
hexagonal key
wrenches
(included)
Brake Lever
Brake Lever
Adjuster
Wheel
Tire
Speed Control
Drive
Chain
Front Fork
Charger
Charger
Plug
Charger
Port
Phillips
screwdriver
10
mm w
rench
Bicycle-style tire pump for
Schrader valve tires, with
pressure gauge
or
Bolt Assembly
Torque Chart
ft-lb (Standard Metric 8.8
hardware for Razor Products)
The torque values in the
table are based on the use of
lubricated threads. Reduce
15% for dry threads.
Size (mm) Torque in Ft-lb
6 5
7 9
8 17
10 33
12 60
N•m (Standard Metric 8.8
hardware for Razor Products)
The torque values in the
table are based on the use of
lubricated threads. Reduce 15%
for dry threads.
Size (mm) Torque in N•m
6 9
7 14
8 23
10 45
12 80

ASSEMBLY AND SET-UP
1
Using the 6mm hexagonal
key wrench, remove bolts
from handlebar clamp.
2
Place handlebars in handle-
bar clamp
in upright
, vertical
position.
3
Insert bolts and tighten
securely. When properly
tightened, the handlebars
should not move forward or
back.
Note:
The gap between
the upper clamp and lower
clamp should be equal on both
sides of handlebar.
Attaching the Handlebars
WARNING:
Failing to properly adjust and
tighten the bolts that affi x the
handlebars
can cause you to
lose control and crash.
Charging the Battery
Your electric four wheeler may not have a fully charged battery; th
erefore it
is a good
idea
to charge the
battery prior to use.
•
I
nitial charge time: 12 hours
•
Run time: up to 40 minutes
•
Average battery life:
250 charge/discharge cycles
1
Align the groove on the p
lug
of the charger port
and plug
into the port on the Dirt Quad.
Tighten the threads to secure
the plug.
The charger works
with the power switch in either
the on or off position.
2
P
lug the charger plug into a
wall outlet.
WARNING:
A
lways disconnect
your electric
four wheeler from the charger
before cleaning with liquid.
Note:
If your charger does not
look like the one illustrated,
your unit has been supplied
with an alternative charger.
The specifi cations and charging
procedure would not change.
The charger has a small window
with one LED or two LEDs to
indicate the charge status. Refer
to the illustration on the charger
unit for the actual “charging” and
“charged” status indications for
your model charger.
C
hargers have built-in over-charge
protection to prevent battery from
being over-charged.
Be sure to properly align the
groove on the charger input
port with the corresponding
socket on the Dirt Quad and
tighten threads; otherwise, no
charging action will occur.
Charger
Plug
Charger
Port
3
•
Recharge time:
Always
remember to turn the
power switch off and recharge for at least 8 hours
after each use.
When vehicle is not in regular
use, recharge battery at least once a month until
normal use is resumed. If you have left the power
switch on or your product has not been charged
for a long period of time the battery may reach a
stage at which it will no longer hold a charge.





WARNING:
The brake is capable of causing
the electric four wheeler
to skid the tire throwing an
unsuspecting rider. Practice
in an open area free from
obstacles until you are familiar
with the brake function. Avoid
skidding t
o a stop as this can
cause you to lose control or
damage the rear t
ire.
4
REPAIR AND MAINTENANCE
Check the Razor web site for any updates on the latest
repair and
maintenance procedures.
Turn power switch off before conducting any maintenance procedures.
q
Adjusting the Brake
1
To adjust the play, thread the
brake lever adjuster in or out
1/4 to 1/2 turn until the desired
brake adjustment is attained.
Most adjustments are complete
at this step. If brake still needs
further adjustment, proceed to
step 2 for rear brake
.
Infl ating the Tires
Ti
res are infl ated when shipped, but they invariably lose some pressure between the point of
manufacturing and your purchase. Always infl ate the tires to the correct PSI before fi rst time use.
Note:
The pressuri
zed a
ir
supplies found at gasoline
stations are designed to infl ate
high-volume automobile tires.
If you decide t
o use
such an
air supply to infl ate your tires,
fi rst make sure the pressure
gauge is working, then use very
short bursts to infl ate to the
correct PSI. If you inadvertently
over-infl ate the tire, release the
excess pressure immediately.
Using a bicycle-style tire pump equipped for a Schrader-type valve, infl ate the front tire to the PSI indicated
on the sidewall of the tire.
Testing the Brake
To use the brake, squeeze the lever to increase the pressure on the brake. The brake lever is fi tted
with a cable adjuster to compensate for cable stretch and/or to fi ne-tune the lever movement to brake
engagemen
t. If brake is not engaging properly, follow instructions for adjusting the brakes outlined below.
ASSEMBLY AND SET-UP
2
Locate the rear brake caliper
and disk brake behind the right
rear wheel. The distance of the
brake wire
between the end of
the cable and the anchor bolt
should be between 37 and 44
mm.
If the rear brake has too
much slack, loosen the rear
anchor bolt with a hexagonal
wrench and pull the brake wire
tighter (direction indicated with
arrow).
3
If the brake rotor is
dragging on the brake pads
use your fi ngers to twist the
caliper adjuster in either
direction until rotor is
centered between pads
.
Backside
Backside
view of
view of
disk brake
disk brake
Rotor
Pads
Caliper adjuster

5
REPAIR AND MAINTENANCE
q
Replacing the Fuse
WARNING:
To prevent shock or short circuit,
please follow the instructions
accordingly and do not skip or
combine any steps.
2
Under the f
ront fender and
t
hro
ugh the
frame
,
l
ocate the
fuse cover attached to the top
of the battery casing.
3
Open the fuse cover
to
exp
ose the fuse.
4
Rem
ove the fuse and replace
with a new one of equal
amperage.
Note:
Amperage rating is
located on
top of
fuse. Fuse
must be replace
d with one of
equal amperage.
5
Close the fuse cover
.
Amperage
number
q
Replacing the Chain
Tools required:
6
mm hexagonal key wrench, 10mm wrench and Phillips screwdriver.
1
Make
sure the power switch
is turned off.
2
Remove the bolt
on the
inside of the rear w
heel.
Remove nut and
pu
ll bolt out
of axle.
3
Remove the 3 screws from
the top half of the chain gu
ard
and remove from frame.
1
Remove the bolt on the
outside of the rear wheel.
5
Spread the chain tensioner
apart to loosen chain.
6
Remove chain from both
spro
ckets and replace with new
chain.
4
Remove the
2
screws from
the bottom half of the chain
guard and remove from frame.
WARNING:
Do not touch motor a
fter use.
Motor is (or can be) very hot.

6
REPAIR AND MAINTENANCE
q
Chain and Sprocket
The chain will typically have a “loose spot” and “tight spot” corresponding with a particular sprocket
rotational position.
This is normal and common to all chain-driven vehicles due to run-out tolerances of the
freewheel and sprocket.
Proper chain alignment must be maintained. If the chain is noisy or rough running,
check the lubrication, tension and alignment of the sprockets, in that order. The tensioner arms must be
aligned and free from binding and the tensioner spring(s) must be operating correctly.
q
Battery Care and Disposal
Do not store the battery in temperatures above 75° F or below -10° F.
CONTAINS SEALED LEAD BATTERY. BATTERY M
UST B
E RECYCLED.
Disposal:
Your Razor product uses sealed lead-acid batteries which must be recycled or disposed of in
an environmentally sound manner. Do not dispose of a lead-acid battery in a fi re. The battery may explode
or leak. Do not dispose of a lead-acid battery in your regular household trash. The incineration, land fi lling
or mixing of sealed lead-acid batteries with household trash is prohibited by law in most areas. Return
exhausted batteries to a federal or state approved lead-acid battery recycler or a local seller of automotive
batteries. If you live in Florida or Minnesota, it is prohibited by law to throw away lead-acid batteries in the
municipal waste stream.
q
Charger
The transformer/charger supplied with the bike should be regularly examined for damage to the cord, plug,
enclosure and other parts, and, in the event of such damage, the Dirt Quad must not be charged until it has
been repaired or replaced.
Use ONLY with the recommended charger.
q
Replacement Parts
The most frequently requested replacement parts (wheels, tires, tubes, batteries and chargers) are
available for purchase at some Razor retail partners or online at www.razorama.com. For other parts
contact an authorized Razor repair center.
q
Repair Centers
For a list of authorized Razor repair centers:
• Check online at www.razor.com.
• Send an e-mail to [email protected] or call 866-467-2967 for the center nearest you.
WARNING:
To avoid a pinch or injury, keep
fi ngers away from moving
sprockets and chain.
WARNING:
If a battery leak develops, avoid
contact with the leaking acid
and place the damaged battery
in a plastic bag. Refer to the
disposal instructions at left. If
acid comes into contact with
skin or eyes, fl ush with cool
water for at least 15 minutes
and contact a physician.
8
Position bottom half of the
chain gu
ard to align mounting
holes and screw to frame.
9
Position
top half of the
ch
ain
guard to align mounting holes
and screw to frame.
7
R
eset chain tensioner.
11
On t
he outside of the
wheel r
eplace washers and
secure with bolt.
10
O
n the inside of the wheel
s
lide bolt through
wheel and
axle and secure with nut.

7
Vehicle does not run
Vehicle was running but
suddenly stopped
Short run time (less than
30 minutes per charge)
Vehicle runs sluggishly
TROUBLESHOOTING GUIDE
Problem Possible Cause Solution
V
ehicle is rolling backwards
Undercharged battery
Charger is not working
Loose wires or connectors
Burned-out fuse
Motor or electrical switch damage
Undercharged battery
Battery is old and will not accept full
charge
Brakes are not adjusted properly
Driving conditions are too stressful
Tires are not properly infl ated
Vehicle is overloaded
Throttle will not engage if the vehicle is rolling backwards. Come to a
complete stop and then activate the throttle.
Charge the battery. A new battery should have been charged for at
least 12 hours before using the vehicle for the fi rst time and up to 8
hours after each subsequent use.
Check all connectors. Make sure the charger connector is tightly
plugged into the charging port, and that the charger is plugged into
the wall.
Make sure power fl ow to the wall outlet is on.
You may check to see if your charger is working by using a volt meter or
asking your local Razor authorized service center to test your charger
for you.
Check all wires and connectors to make sure they are tight.
The fuse will burn out and automatically shut off the power if the
motor is
overloaded.
An excessive overload, such as too heavy a rider or too steep a hill, could
cause the motor to overheat.
Refer to replacing the fuse instructions
on page 5 of this manual.
Correct the conditions that caused the fuse
to burn out and avoid repeatedly burning out fuse.
Contact your local Razor authorized service center for diagnosis and
repair.
Charge the battery. A new battery should have been charged for at
least 12 hours before using the vehicle for the fi rst time and up to 8
hours after each subsequent use.
Check all wires and connectors. Make sure the battery connector is
tightly plugged into the charger connector, and that the charger is
plugged into the wall.
Make sure power fl ow to the wall outlet is on.
Even with proper care, a rechargeable battery does not last forever.
Average battery life is 1 to 2 years depending on vehicle use and
conditions. Replace only with a Razor replacement battery.
Refer to brake adjustment instructions on page 4 of this manual.
Use only on solid, fl at clean and dry surfaces such as pavement or
level
ground.
The tires are infl ated when shipped, but they invariably will lose some
pressure between the point of manufacturing and your purchase. Refer
to instructions on page 4 of this manual to properly infl ate tires.
Make sure you do not overload the vehicle by allowing more than
one rider at one time, exceeding the maximum weight limit, going up
too steep a hill or towing objects behind the vehicle. If the vehicle is
overheated, the temperature circuit protector will slow motor down
and if the condition continues, will shut off power to the motor. Correct
the driving conditions that caused the overheating, wait 5-10 minutes
and then resume riding. Avoid repeatedly overheating the unit.

8
Sometimes the vehicle
doesn’t run, but other
times it does
Charger gets warm
during use
Vehicle does not stop
when applying the brake
Vehicle makes loud
noises or grinding
sounds
Need Help?
Visit our web site for updates and a list of authorized service centers at
www.razor.com
or call toll-free
at
866-467-2967
Monday - Friday 8:00 AM - 5:00 PM Pacifi c Time.
Problem Possible Cause Solution
Loose wires or connectors
Motor or electrical switch damage
Normal response to charger use
Brakes are not adjusted properly
Chain is too dry
Check all wires around the motors and all connectors to make sure
they are tight.
Contact your local Razor authorized service center for diagnosis and
repair.
No action required. This is normal for some chargers and is no cause
for concern. If your charger does not get warm during use, it does not
mean that it is not working properly.
Refer to instructions on page 4 of this manual to properly adjust
brakes.
Apply a lubricant such as 3 in 1
TM
or Tri-Flow
TM
to the chain.
TROUBLESHOOTING GUIDE

9
Keep your Dirt Quad running for years with genuine Razor parts. Visit our web site or e-mail us for more information on spare part
availability. (Specifi cations subject to change without notice.)
DIRT QUAD PARTS
1. Grip, 1/2 length right side
2. Throttle 1/2 grip type w/twist control
3. Handlebar
4. Brake Lever, left side w/cut-off switch
5. Grip, left side
6. Steering tube weldment assembly
7. Cover plug for steering tube
8. Cross-bar pad
9. SHCS (socket head cap screw) 8mm for handlebar clamp
10. Split washer 8mm
11. Handlebar clamp upper
12. Handlebar clamp lower
13. Screw
14. Pad
15. Battery hold down strap
16. Battery set (2 ea 12v 7AH)
17. Battery cover screw
18. Battery cover, left side
19. Cover, charger input port
20. Charger input receptacle
21. Nut
22. Main on/off switch
23. Plastic Body
24. Washer
25. Footrest platform, left side
26. Screw
27. Battery cover, right side
28. SHCS (socket head cap screw), battery cover base
29. Footrest platform, right side
30. Screw, for electronic control module
31. Electronic control module
32. Spindle arm, right side
33. Nut, self-locking for spindle arm
34. Bushing, for steering spindle
35. Nut, for tie-rod
36. Tie-rod
37. Screw for tie-rod
38. Steering bushing
39. Control arm
40. Washer for steering control arm
41. Lock washer for steering control arm
42. SHCS (socket head cap screw) for steering control arm
43. Screw for body attachment top
44. Washer
45. Screw for body attachment side
46. Washer
47. Bolt, Suspension mounting
48. Nut
49. Main Frame
50. Washer
51. Nut for seat mounting
52. Shock
53. Brake caliper assembly
54. Screw, brake caliper mounting
55. Motor w/gear reduction 350W
56. Screw, for brake disc
57. Screw for chain cover
58. Chain cover half top
59. Chain cover half bottom
60. Screw for chain cover
61. SHCS steering pivot
62. Screw for tie-rod
63. Washer
64. Spindle arm, left side
65. Tire & Wheel assembly front
65-1. Axle Nut front
65-2. Washer
65-3. Bearing
65-4. Spacer
65-5. Rim nut
65-6. Rim half, outside
65-7. Inner tube 13 in
65-8. Tire
65-9. Rim half, inside front
65-10. Rim bolt
66. Swing arm axle
67. Washer
68. Nut, for swing arm
69. Bushing, for swing arm
70. Motor mount screw
71. Split washer
72. Washer
73. Swing arm weldment
74. Brake disc
75. Brake disc hub
76. Screw, for sprocket
77. Split washer
78. Flat washer
79. Sprocket
80. Sprocket hub
81. Chain
82. Screw, for drive hub
83. Wheel fl ange
84. Rear Wheel assembly
84-1. Axle Nut Rear
84-2. Split washer
84-3. Washer
84-4. Spacer
84-5. Rim nut
84-6. Wheel half outside
84-7. Inner tube 13 in
84-8. Tire
84-9. Wheel half, inside rear
84-10. Rim bolt
85. Nut
86. Spacer tube rear axle
Items Not shown
87. Charger
88. Tool Kit

10
DIRT QUAD PARTS

11
SB 1918 (CALIFORNIA) DECLARATION
YOUR INSURANCE POLICIES MAY NOT PROVIDE COVERAGE FOR ACCIDENTS INVOLVING
THE USE OF THIS SCOOTER/ELECTRIC VEHICLE. TO DETERMINE IF COVERAGE IS
PROVIDED, YOU SHOULD CONTACT YOUR INSURANCE COMPANY OR AGENT.

Razor Limited Warranty
The manufacturer warranties this product to be free of manufacturing
defects for a period of 90 days from date of purchase. This Limited
Warranty does not cover normal wear and tear, tires, tubes or
cables, or any damage, failure or loss caused by improper assembly,
maintenance, or storage or use of the Razor Dirt Quad.
This Limited Warranty will be void if the product is ever:
• used in a manner other than for recreation;
• modifi ed in any way;
• rented.
The manufacturer is not liable for incidental or consequential loss or
damage due directly or indirectly to the use of this product.
Razor does not offer an extended warranty. If you have purchased an
extended warranty, it must be honored by the store at which it was
purchased.
WARRANTY
Need Help?
Visit our web site for updates and a list of authorized service centers at
www.razor.com
or call toll-free
at
866-467-2967
Monday - Friday 8:00 AM - 5:00 PM Pacifi c Time.
Printed in China for:
Razor USA LLC
PO Box 3610
Cerritos, CA 90703
© Copyright 2006 Razor USA. All rights reserved.
062006
For your records, save your original sales receipt with this manual and
write the serial number below.
__________________________________________
Item Number:
25117460
SAFETY REMINDERS
12
DO NOT RETURN TO STORE
Do not use this vehicle for the fi rst time until you
have infl ated the tires to the correct PSI and
charged the battery for at least 12 hours.
Failure to follow these instructions may damage
your vehicle and void your warranty.
Tire Infl ation
Periodically inspect the tires for excess wear, and regularly
check the tire pressure
and re-infl ate as necessary. If you
get a fl at tire, the inner tube can be patched or a new tube
can be purchased from Razor or an authorized repair center.
Safety Gear
Always wear proper protective equipment such as an
approved safety helmet, elbow pads and kneepads. Always
wear shoes (lace-up shoes with rubber soles), never drive
barefooted or in sandals, and keep shoelaces tied and out
of the way of the wheels, motor and drive system.
Loose Parts
Check and secure all fasteners before every ride. Make
sure steering stem clamp bolts are locked properly in place.
There should not be any unusual rattles or sounds from
loose parts or broken components. If you are not sure, ask
an experienced mechanic to check.
Brake
Check the brake for proper function. When you squeeze
the lever, the brake should provide positive braking action.
When you apply the brake with the speed control on, the
brake cut-off switch will stop the motor.
Frame, Fork and Handlebars
Check for cracks or broken connections. Although broken
frames are rare, it is possible for an aggressive driver to
bash into a curb or wall and wreck and bend or break a
frame. Get in the habit of inspecting yours regularly.
❑
❑
❑
❑
❑
PRE-RIDE CHECKLIST
