RCA L23W10 User manual

L23W10
23" (Diagonal) LCD Widescreen 
HDTV Monitor
Features  Benefits
Multi-Function Monitor with MultiTask Audio™ Can be used as a TV or a computer monitor. MultiTask 
Audio™ allows the user to listen to audio while in the PC 
mode.
Widescreen High Definition TV Monitor with 1280 x 720  Capable of viewing digital TV signals (480p, 720p, 1080i) 
High Resolution Panel and Exceptional Contrast and  in 720 progressive lines. Fast 12ms response time 
Brightness Performance yields crisp, clear, detailed images.
Comprehensive Connectivity Package Includes  Connect a wide array of sources for greater utility, from 
Composite Input with S-Video, SYNCROSCAN™ PLUS³^  VCR to Progressive Scan DVD Player, Digital TV Tuner, 
Component Input and PC D-Sub Input (RGB/VGA) Digital Cable Box, Satellite, Game, or Personal Computer.
Standard Definition NTSC Integrated Tuner Built-in analog TV tuner receives standard over-the-air 
television broadcasts and cable TV programming.
HD Input Capability with PC D-Sub Input (RGB/VGA) and  SYNCROSCAN™ PLUS inputs automatically detect video 
SYNCROSCAN™ PLUS³^ Component Video Inputs formats 720p, 1080i, 480p & 480i, thus eliminating need 
for user to manually change output device settings.
Auto Tune (One-Button Launch) - Provides One-Touch  Once set, Auto Tune powers on the LCD TV, and the 
Convenience source device, while switching to the appropriate source 
input – all at the touch of a single button.
VESA Wall Mount Compatible Allows the user to wall mount the unit with a universally 
standard VESA Wall Mount bracket.
TTE TECHNOLOGY, INC.
10330 N MERIDIAN ST
INDIANAPOLIS, IN 46290

L23W10
Technical Specifications
BRAND ACCESSORIES
Brand RCA AC Power Adapter & Power Cord Included
PICTURE Instruction Book English/French
Screen Size - diagonal (inch) 23 Tilt Base Included - Detachable
Category LCD TV
Display Type TFT LCD Revised 3/31/05
SDTV / EDTV / HDTV Compatibility HDTV Monitor
Aspect Ratio 16x9
Adjustable Color Temperature Yes
Backlight Adjustable Product Size (WxHxD) inches:
Brightness Adjustment Yes with stand: 25.7 x 18.3 x 11.4
Comb Filter Digital 5-Line without stand: 25.7 x 16.2 x 3.1
Format Control 4:3, 14:9 Zoom, 16:9 Zoom
Format Control (Additional) Cinerama, 16:9 Widescreen
Gamma Correction Yes
Panel Specifications 3^ - SYNCROSCAN PLUS component inputs automatically detect video formats 720p, 
Display Resolution WXGA (1280 x 768) 1080i, 480p and 480i without the need for consumer intervention.
Brightness (cd/m2) 500
Contrast Ratio 600:1 RCA and associated marks are trademarks of Thomson S.A. used under license
Response Time (Gray to Gray) 12 ms to TTE Corporation.
Viewing Angle - Horizontal/Vertical 176° / 176°
Picture Control Adjustable Photos and features subject to change without notice. Illustration of product finish may vary
Video Standard Control NTSC from actual color.

SOUND
Speakers (number) 2 - Side Mounted
Audio Power (Front Speakers) 3 Watts/Channel
Audio in PC Mode Yes - MultiTask Audio™
Second Audio Program (SAP) Yes
Sound Controls Yes - Volume, Mute
Sound Type MTS Stereo
Tone Control Bass & Treble

CONVENIENCE
Audio in PC Mode Yes - MultiTask Audio™
Auto Channel Search Yes
Auto Tune (One-Button Launch) Yes (Except VID2 Inputs)
Calendar Yes
Channel Labeling Yes
Clock / Timers Clock/Sleep/Alarm (Wake-Up)
Closed Caption Capability Yes
Multilingual On-Screen Display English/French/Spanish
OSD Positioning Yes
PC Compatibility Yes - via 15-Pin d-sub
Parental Control (V-Chip) Yes - USA & Canada
Picture Memory Presets Yes
Picture Reset Yes
Power ON / Standby Indicator (LED) ON-Green, Standby-Red
SIGNAL FORMAT CAPABILITY
RF Tuning Capability NTSC
Analog Video Formats (NTSC / 480i) AV / S-Video / Component
Digital Video Formats (480p,720p,1080i) Component, RGB
REAR CONNECTORS
Audio/Video Inputs (Composite) 2 L&R Audio, 2 Video
S-Video Input 1 - Auto Detectable
Component Video Input 1 Set - SYNCROSCAN™ PLUS³^
Audio Input for Component Video 1 Pr - L&R Audio (Phono)
PC Input (RGB) 1 VGA - 15-Pin D-Sub
Audio Input for RGB 1 (3.5mm)
RF Input (Antenna) 1 "F" Type
AC Power Input Yes
Headphone Jack Yes
SPECIFICATIONS
Detachable Base Yes
Finish on Front Silver
Finish on Back Silver
Finish on Stand Silver
Product Size (WxHxD) inches See End of Next Column
Packaging Size (WxHxD) inches 28.6 x 21.2 x 13.5
Weight: Product/Packaged, lbs 19.4 / 27.6
Power Options AC
VESA Wall Mount Compatible Yes
REMOTE CONTROL
Model Number RCR130TD1
Type TV Control
