TV/VCR COMBO
T25608
25"6-Head Stereo
Hi-Fi Combo
• 6-Head Stereo Hi-Fi VHS
• Full Stereo A/V In and Out,
Front and Rear
• MTS Broadcast Stereo/SAP
• Dark-Tint, High-Contrast Picture Tube
• Quick-Start VHS Transport Drive
• 3-Speed Visual Search
• Quality Slow Motion Video and
Special Effects
• 8-Event/1-Month Timer Control
• Trilingual On-Screen Display
• Sleep and Alarm Timers
• Stereo Headphone Jack
• Dual Stereo Speakers
diagonal

Specifications
• Cabinet
Eastern Metallic Silver.
• Dimensions: 233/12" H, 241/12" W, 192/12" D
• Approx. Shipping Weight: 68.3 Lbs.
Remote
• CRK76TYI
• Dark-Tint, High-Contrast Picture Tube
Dark glass picture tube delivers outstanding
picture contrast for blacker blacks, brilliant
whites and deep rich colors even in bright
room conditions.
• 181-Channel Tuning Capability1
Digitally controlled frequency tuning system
“locks on” to cable and standard signals with
unsurpassed accuracy.
Sound
• Two Stereo Front-Fired Speakers
Front-fired full-range frequency drivers
provide excellent imaging while localizing
voices at the screen.
• Second Audio Program (SAP)
Decodes the second audio program available
on some broadcasts.
• MTS Broadcast Stereo Reception
Receive and record stereo sound from MTS
(Multichannel Television Sound) stereo TV
broadcasts, where available.
Convenience
• Trilingual On-Screen Display
Allows the on-screen menu system to be
displayed in one of three languages (English,
French, or Spanish).
• On-Screen Menu System
On-screen displays make it easy to adjust
most picture, sound, and convenience
features from the remote control.
• Caption Vision Closed
Caption Capability2
Assists the hearing impaired, helps children
learn to read, and aids in the teaching of
English as a second language. Built-in Closed
Caption Decoder displays the audio portion
of a program as text on the TV screen (when
program is aired with the encoded signal).
• Programmable Timer System
Convenient scheduling system can be used in a
variety of ways:
– Sleep Timer
Automatically turns off the TV after a preset
time period—for those times when you drift
off to sleep in front of the television.
– Alarm Timer
Wake up to your favorite morning show or
turn on your television automatically to catch
your favorite program.
• Auto Clock Set3
The Auto Clock Set3circuitry reads the XDS
broadcast signal containing time of day and
date information, automatically setting the
clock during initial setup as well as after most
power interruptions.
• V-Chip Parental Control
Puts control back into the hands of the
viewer by blocking unwanted television
broadcasts with U.S. Government required
circuitry. Blocks three types of programs:
regular television programs, broadcast
movies and unrated programs.
Program rating information is sent by
the broadcaster continuously during the
program. The television will match program
rating to user preference and block the entire
program (when program is aired with the
encoded signal). User preference is secured
using a four-digit password.
VCR Capabilities
• 6-Head System
Four video recording and pick-up heads on
a single head drum provide improved special
effect performance. With the new SFX design,
you can visually pause on the tape at any
speed, and slow-motion effects are clearer
and more jitter-free. Two additional AFM
audio heads allow Stereo Hi-Fi recording
and playback. The combination of six heads
allows full theatre video and audio, and
allows full stereo performance copying from
all high-level consumer and professional
camcorders. Using a T-160 tape, up to eight
hours of stereophonic audio can be recorded
for extended playback, or six hours with any
standard T-120 VHS tape.
• 8-Event/1-Month Programmable Timer
The built-in timer memory can be preset up to
one month in advance to record as many as
eight different programs automatically.
• Digital Auto Tracking Plus
Combines the best performance of an
automatic digital tracking scan system, which
automatically “locks” on the best signal, with
the added convenience of manual override.
Manual up/down tracking is sometimes
preferred when rental tapes have been
damaged or recorded on older recorders
with tracking out of adjustment.
• Auto Repeat
Automatically rewinds at the end of the tape
and then begins replay.
• Auto Power On, Auto Play,
Auto Rewind
Simply inserting a cassette in the VCR turns it
on (Auto Power On). When a prerecorded
cassette is inserted in the VCR, it automatically
starts to play (Auto Play). When the end of the
tape is reached, Auto Rewind automatically
rewinds the tape.
• Clear Quality Slow Motion
Connections
• Front and Rear Audio/Video Inputs
Allows quick, easy access for direct audio and
video connections for additional VCR, video
game or video source.
• Fixed Audio Outputs
Connect TV to an external AV receiver or power
amplifier to create a true home theater setup.
• Front Panel
• Back Panel
• Stereo Headphone Jack
Listen privately with optional headphone.
Plus
• Limited Warranty
– 90 days for labor charges.
– One year for parts.
– Two years for picture tube.
– See RCA dealer or visit www.rca.com for
complete details.
1 Check your cable company’s compatibility requirements.
2 This television receiver provides display of television closed captioning in
accordance with §15.119 of the FCC rules. This television receiver does not
support color attributes of television closed captioning.
3 Subject to availability based on local off-air and cable broadcasts.
©2001 Thomson multimedia Inc.
Form S-T25608
Trademark(s) ® Registered
Marca(s) Registrada(s)
Photos and features subject to change
without notice. Illustration of product finish
may vary from actual color. Screen sizes
measured diagonally.
Printed in the U.S.A. 3/01
PC30096
GAC38930
T25608
AUDIO
LEFT
IN OUT
AUDIO
RIGHT
VIDEO
ANT/CABLE
75Ω
