RCS AUDIO-SYSTEMS TRT-200A User manual

OPERATING INSTRUCTIONS – QUICK GUIDE - ENGLISH
EN
54-17
certified
TRT-200 A RINGBUS ISOLATOR
The VARES-LOOP – Ringbus Isolator Module is the successor in our range
of loudspeaker loop-isolator devices that are using our patent technology to
deliver a higher level of security of evacuation loudspeaker lines that are in-
stalled according to the return-loop principle.
A loudspeaker failure in a faulty section between any two TRT-200 A’s in the loop is
automatically detected and isolated in order to ensure maximum availability of the
remaining loudspeakers on that same loop. The Ringbus Isolator Module protects
the loop integrity against any wire-to-wire short circuit and detects open line on
T-Branch.
Compatible with:
ƒ1500
ƒ2000
ƒ3000

RINGBUS ISOLATOR
2
The TRT-200 A is equipped with clearly market connectors. It has a LOOP-FEED and LOOP-
RETURN connection that are not sensitive for feeding direction. LOOP has a DC-carrier for
charging and communication purpose.
Please observe correct connectivity:
RED = PHASE / PLUS
BLUE = ZERO / MINUS
GREEN = GROUND (If applicable)
NOTE: The maximum number of loudspeakers between TRT-200 A’s is not limited within
the maximum LOOP-load of 800W, however, national standards may limit the amount of
loudspeakers between Isolators. Earth connector is available for optional earth-wire loop
detection.

RINGBUS ISOLATOR
3
The TRT-200 A is equipped with a power capacitor that is charged by the LDB and has
enough capacity to run at least two measurement cycles without the need for re-charging.
The LED indicator(s) on the TRT-200 A are flashing with intervals to indicate quiescent or
fault condition. The TRT-200 A has a RESET button and EOL-enable switch. Please refer to
the User and Installation manual for detailed information.
The maximum number of loudspeakers between any two TRT-200 A’s is restricted by the
maximum loop-load of 800W. National standards might call for restrictions. The T-Branch
has a load limit of 50W. If multiple loudspeakers are connected to the T-branch, the EOL
switch need to be set on: ENABLE and a EOL resistor has to be applied.
The TRT-200 A has two indicators that are related to the status of either LOOP-A or LOOP-B
side (Loop feed). If both indicators are flashing alternately, the fault information is related to
the T-Branch status. Please refer to the User and Installation manual for detailed information
on the various indications of these indicators.
The TRT-400 A is equipped with WAGO
push-terminals that accept up to 2,5 mm2
core installation cable. A special tool is
provided to quickly remove all three wires
in one run. (Release-tool is included)

© Copyright by RCS AUDIO-SYSTEMS GmbH. Veröffentlichung und Vervielfältigung der enthaltenen Daten, auch auszugsweise, nur mit unserer Genehmigung.
RCS06.10.2020
RINGBUS ISOLATOR
Technical data TRC-200 A
Electrical
DC Power supply (from LDB) 19 - 30 VDC, nominal 30 VDC
DC Power consumption
Idle current 100 μA continious
Max. power consumption 20mW
LOOP connection
DC 30V
AC Voltage 100Vrms
Max. AC load 800W
AC Frequency range 40Hz - 20kHz (-3dB)
T-Branch output 50W / EOL = 47kOhm / 0,25W or higher
Wiring 2-wire. Max. 2,5mm2 / Max. Loop length: 1000m
Grounding optional earth loop through third connection pin
Loop relay contact rating max. 250VAC / 8A (Dual state type)
Loudspeaker type only with DC-blocking capacitor
Maximum # of loudspeakers
Between two TRT’s Infinite within the maximum loop-load of 800W
(National standard may limit the number of loudspeakers between TRT’s)
T-branch Infinite within the maximum T-branch load of 50W
(National standard may limit the number of loudspeakers)
Detection Short, wire-to-wire / Open T-Branch / Earth leakage T-Branch
Mechanical
Housing PP plastic with transparent cover
Dimensions (WxHxD) IP 21 housing, 110 x 130 x 55 mm (Basic)
IP 33 extension included. 110 x 180 x 55 mm (Optional)
Ordering information. Part No.
TRT-200 A 1x IP21 housing with transparent cover and PCB
1 x release tool
1 x compression gland for speaker mounting
Certification and Approvals
Complies with EN54-17:2005 - 0560-CPR-142190002
European patent EP 0967833B1
