RCS RSB1 User manual

Model # A- Width B- Depth C- Height
RSB1 8 1/2" 15 1/2" 2"
RJCSSB 10 3/4" 21" 8"
RJCSSBL 10 3/4" 21" 8"
RDB1 12" 19" 8"
RDB1EL 12" 19" 8"
Propane Gas Connection:
RCS side burners have 3/8" male flare connection
Minimum horizontal clearance from sides and back of the unit to adjacent vertical combustible construction extending above top of unit, 24 inches
from side and 24 inches from back. Do not locate under any overhead combustible construction.
Side Burner Owner's Manual
Safety and Installation Instructions
Side Burner Installation
This gas side burner must be installed in accordance with all local codes and is for outdoor use only.
If installation is planned in an area with no local codes, the gas side burner must be installed in accord with the National Fuel Gas Code ANSI
Z223.1 and storage and handling of liquefied petroleum gases, ANSI/NFPA 58 or CSA B149.1 natural gas and propane installation code.
CALIFORNIA PROPOSITION 65 WARNING
The burning of gas cooking fuel generates some by-products which are on the list of substances which are known by the State of California to
cause cancer or reproductive harm. California law requires businesses to warn customers of potential exposure to such substances. To minimize
exposure to these substances, always operate the unit according to the use and care manual, ensuring you provide good ventilation when
cooking with gas.
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage, and void the warranty.
Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment.
Clearances
Combustible Construction
Natural Gas Connection:
Appliance pressure 4” W.C.
Appliance pressure 10” W.C.
Inlet pressure 5” – 14” W.C.
Inlet pressure 11” – 14” W.C.
Non-Combustible Construction
Sides of the side burner can be 0” from non-combustible wall, below the cooking surface.
Built-in Installation
For non-combustible cabinet enclosure installation only. Follow the cut-out dimensions as shown. ALL outdoor kitchen cabinets MUST include
ventilation. We recommend 12 square inches of opening for each (running) 4 feet of counter top. See Item # RVNT1 for approved vents.
Cut Out Dimensions
www.RCSGasGrills.com

Before Lighting:
Check gas line/hose for signs of wear, abrasion or cuts. If evidence of deterioration is visible, replace the part prior to use.
If you smell gas, check for leaks. If odor continues, immediately call for service.
RSB1 RJCSSB/L RDB1 RDB1EL
7mm 7mm 7mm 7mm
3. The clicking sound is the electrode sparking near the burner ring. This will ignite the gas to the burner.
2. Push and turn burner knob to ‘HI/IGN’ position. You will hear a clicking sound w/ Sure Strike Valves or you must push the igniter button
depending which side burner you have.
Check for leaks with a soapy water solution every time the cylinder is replaced or reconnected. All leaks must be corrected immediately.
Never use an open flame to check for leaks.
Lighting Instructions
Keep your face and body away from the burner top when lighting or operating.
5. Inside the space you will find the orifice (brass fitting), screwed into the end of the valve stem.
4. Where the burner was located going through a hole in the basin and connecting to the valve is now evacuated space.
*DO NOT LEAVE YOUR SIDE BURNER UNATTENDED WHILE IN OPERATION.*
4. If there is no ignition after trying, turn the knob back to the “OFF” position and repeat steps 2-3.
1. Open lid before lighting. Make sure all knobs are in the ‘OFF’ position.
Socket Size
Side Burner
Fuel Conversion for Side Burners: RSB1, RJCSSB, RDB1 & RDB1EL
1. Find the extra set of orifices that came with the side burner. (RSB2 does not come with extra orifice, must purchase separately)
3. Pull up and slide burner to the side to expose the orifice in the bottom of the venturi. Repeat for each burner.
2. You must remove all grates to expose the main burner or burners on the side burner.
If you have any questions please give us a call at: 1-800-833-5998
www.RCSGasGrills.com
Follow the picture on the right to
hook up side burner to grill
connections.
6. Remove the orifice with a socket and extension. (These are extremely fragile when turning. Be extremely gentle when removing).
7. Replace orifice with new orifice, (repeat for all burners). When re-installing orifice do not over tighten or you will strip the brass fitting. Little
pressure is needed!!!
8. Replace burners then grates.
