RDA LIGHTING BL S-LED Series User manual

INSTALLATION INSTRUCTIONS
RDA Lighting inc. December - 2021 Page 1of 2
BLxS-LED
WARNING
SAFETY
•Proper grounding is required to ensure personal safety.
•Fixture should be mounted in locations where unauthorized personnel will not readily subject it to tampering.
•Do not use this equipment for anything other than its intended purpose.
•Servicing this equipment should be performed by qualified service personnel.
•Save these instructions.
•This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
•Changes or modifications to this unit not expressly approved by the party responsible for compliance Could void the user
authority to operate the equipment.
•MIN 90 °C SUPPLY CONDUCTOR
INSTALLATION
WALL MOUNT
•Use expansion bolts to secure the fixture on mounting surface.
•Keep enough length wires to ensure adjusting angle unhindered.
•Connect the wire in same color (correspond to wire N, L and G) together
with a wire connector.
POLE MOUNT
•Connect the wire in same color (correspond to wire N, L and G) together
with a wire connector.
•Put one end of the tube into the U-slot, and then fix the tube with two hex
socket screws.
•Fixed -clamp on the pipe in a right position and make sure that the pipe will
not rotate.
•Install the light fixture on the wall with four screws.
Disconnect the Electrical supply power at the service panel (fuse or circuit breaker box). Failure to do so could result in serious
injury or death. Only qualified electricians should install this fixture and the installation MUST conform to the Electrical Code
and all local codes and ordinances. Ensure that only proper tools, materials, and equipment are used to complete the
installation.
ELECTRICAL SHOCK HAZARD
READ, UNDERSTAND
, and
FOLLOW
these instructions
before installing the equipment.

INSTALLATION INSTRUCTIONS
RDA Lighting inc. December - 2021 Page 2of 2
BLxS-LED
LUMEN SELECTABLE SWITCHES
The luminaire is designed with lumen selectable options, please follow the steps below:
1. Unscrew the knob cap before using the watt selectable function.
2. Toggle the DIP switch 1,2,3 as per the settings below.
3. Screw the power selectable cap back on. Ensure the cap is sealed properly.
WIRING
•Check that the line voltage is correct.
•Connect fixture GROUND (green) wire to power supply GROUND (green) wire.
•Connect fixture WHITE wire to power supply NEUTRAL wire.
•Connect fixture BLACK wire to power supply LINE wire.
