Real Media Center User manual

HD 1080P Media Center
User Manual
（
（（
（Please read this operation manual carefully and keep it for daily use）
））
）

HD 1080P MEDIA PLAYER
Index
1.
Function and features………………………………………………………2
2.
List of accessories ………………………………………………………....2
3.
Install of HDD…………………………………………………………………3
4.
Indications of the player……………………………………………………4
5.
Description of remote controller………………………………………….5
6.
Connect to other devices…………………………………………………..7
6.1 Connect to PC ……………………………………………………….....7
6.2 Connect to display devices……………………………………………8
7. Display mode……………………………………………………………….10
8. Operation reference……………………………………………………….11
9.1 Operation setup menu………………………………………………11
9.2 Play mode select interface………………………………………....12
9.2.1 Video interface……………………………………………………..12
9.2.2 Music interface……………………………………………………..14
9.2.3 Photo interface……………………………………………………..15
9.3 Copy and delete functions……………………………………….....
2

HD 1080P MEDIA PLAYER
17
9. Troubleshooting guides……………………………………………………18
10. Specifications………………………………………………………………..19
Function and Features
AS a multifunctional HDD media player, compact and easy, it will become a
3

HD 1080P MEDIA PLAYER
good companion
for both your office work and home entertainment.
1.
Mobile HDD: USB2.0 interface enables it as a USB mobile HDD with
SATA HDD installed. Special design makes it easy to connect to any PC
USB port, no external power supply needed. Compatible with both
Windows and MAC OS.
2.
USB HOST: can drive external USB storage devices such as USB
mobile hard disk or USB pen drive, and play or manage their files.
3. Directly read SD/SDHC/MMC card, and play or manage their files.
4.
Video types:
RM，RMVB，AVI，DIVX，MKV，MOV，HDMOV，MP4，M4V，PMP
，AVC，FLV，VOB，MPG，DAT，MPEG，TS，TP，M2TS，WMV
(H.264,H.263,WMV9/VC-1,MPEG1/2/4).
5.
Audio types: MP3，WMA，OGG，AAC，FLAC，APE ，
AC3，DTS，ATRA.
6.
Photo：JPEG，TIF，PNG，BMP.
7.
Resume play function: auto play from the break point.
8.
File management: can manage the files in devices connected to,
manage delete or copy between each others.
4

HD 1080P MEDIA PLAYER
9.
Support Repeat, Zoom，FF，BF，Rotate functions.
10.
Support HDMI, CVBS ,YPbPr video output.
11.
Stereo L/R, S/PDIF optical audio output.
12.
Dimension (net): 142*95*23 mm.
List of accessories
Remote controller 1 USB cable 1 AC/DC Power adapter 1
AV /YPbPr cable 2 User manual 1 Screws and screw driver 1 set
HDMI cable (Optional) 1
Note: All the information contained in this manual was correct at the time of publication.
However, as our engineers are always updating and improving the product, your device’s
software may have a slightly different appearance or modified functionality than presented
in this manual.
Install of HDD
This product is special designed to support built-in 2.5” SATA HDD.
* Install a hard disk( refer to the following steps and pictures)：
1. Move the screw 1 and screw 2 with attached screw driver.
2. Then pull out the plastic crust together with circuit board and turn over,
5

HD 1080P MEDIA PLAYER
then you will see the SATA port in the PCBA.
3. Install the HDD, lock HDD with attached screws.
4. Put back and restore.
(Note: please format HDD before installation）
6

HD 1080P MEDIA PLAYER
Indications of the player
7

HD 1080P MEDIA PLAYER
Description of remote controller
8

HD 1080P MEDIA PLAYER
9

HD 1080P MEDIA PLAYER
Function of remote key table
POWER Power Standby MENU Menu
MUTE Audio mute FUNCTION Special Function
MOVIE Movie mode hot key HOME Return to root
menu
MUSIC Music mode hot key EXIT Return
PHOTO Photo mode hot key SUB-T Subtitle
TXT Reserved
▲▼
Up, Down,
Right ,Left
VGA Reserved ENTER Enter / Confirm
CVBS CVBS output hot key VOL+/- Volume up/down
YPbPr YPbPr output hot key █Stop
HDMI HDMI output hot key Play/Pause
OSD Reserved ROTATE Photo rotate
16
：
9/4
：
3
Display aspect ratio MODE Video output
mode
ZOOM Display Zoom in/out Fast
forward/backward
AUDIO Choose audio track Skip to next/previous
10

HD 1080P MEDIA PLAYER
Connect to other devices
*Connect to PC
ⅠConnect the player with PC with 5pin USB cable.
ⅡOpen “My computer”, you can see storage of built-in hard disk in the
player.
11
11

HD 1080P MEDIA PLAYER
12

HD 1080P MEDIA PLAYER
*Connect to display devices
1. AV interface to TV
Use the AV cable to connect player with TV through AV interface.
Refer to picture below:
13
11

HD 1080P MEDIA PLAYER
2. YPbPr interface to TV
Use the YPbPr cable to connect player with TV through the YPbPr
interface, and use the AV audio cable(red, white) to connect the AV
interface of the player with the TV audio interface(red, white).(Refer to
picture below)
14

HD 1080P MEDIA PLAYER
15

HD 1080P MEDIA PLAYER
3. HDMI interface to TV
Use the HDMI cable to connect the player with a HDTV. (Refer to picture
below)
16

HD 1080P MEDIA PLAYER
Display mode
1. Set up TV display mode.
2. Set up the player output mode as same as TV by remoter (CVBS, YPbPr,
HMDI).
Operation reference
After power on, it will enter into the main menu. (Refer to picture1)
17

HD 1080P MEDIA PLAYER
Operation setup menu
1.
Select the setting option by pressing the LEFT/RIGHT key in root menu,
then press the ENTER key to confirm. (Refer to picture2, picture3)
18

HD 1080P MEDIA PLAYER
Output：Set up the output mode: NTSC、PAL, HDMI mode.
SPDIF: ON or OFF selection for optical output.
Language ：Set up different languages. Such as ：S-Chinese, English, T-
Chinese.
Keytone: ON or OFF selection for keytone.
Restore default: restore the factory setting.
Play mode select interface
*Video interface
1. Select the movie option by pressing the LEFT/RIGHT key in root menu, then
press the ENTER key to enter into the video interface. (Refer to picture4)
2. Select the device from which you prefer to play the movie, press ENTER
19

HD 1080P MEDIA PLAYER
key to confirm, please refer to picture5.
20
