DEFINITIONS
Tahoma: The common platform for the current Apantac family of Multiviewers
Tahoma LE: The LE series is capable of auto-detecting composite, SD-SDI, HD-SDI
and 3G inputs. Each input is directly corresponded in a window on a
display
Tahoma LI: The LI series comes with LOOPING INPUTS. It is capable of auto-
detecting SD-SDI, HD-SDI and 3G inputs. There is also a composite only
model. Each input is directly corresponded in a window on a display
Tahoma LX: The LX series has a built in MATRIX ROUTING SWITCHER. It is capable
of auto-detecting SD-SDI, HD-SDI and 3G inputs. Any input can be
assigned to any output.
Tahoma LC: The LC series is an entry level FIXED QUAD SPLIT only Multiviewer. It is
capable of auto-detecting SD-SDI, HD-SDI and 3G inputs. Each input is
directly corresponded in a window
Tahoma DE: The DE series is a Multiviewer with UNIVERSAL inputs. It is capable of
auto-detecting HDMI, DVI, VGA, composite and component inputs. SD-
SDI, HD-SDI and 3G inputs are also available. Each input is directly
corresponded in a window on a display
4B
APANTAC LLC ●7556 SW BRIDGEPORT ROAD ●PORTLAND, OR 97224, USA
Page 8 of 67
INTRODUCTION TO TAHOMA MULTIVIEWERS
The Apantac Tahoma Multiviewer platform displays multiple auto-detecting video inputs at
different formats on a high resolution display up to resolutions of 2048x1080. The Tahoma
Platform combines the display of video windows, audio meters, label/UMD, tallies, alarms and
indicators in a very space efficient package. Depending on the model, the Tahoma Platform
supports auto-detecting of analog composite, SD-SDI, HD-SDI, HDMI, DVI, VGA, component,
YC, YPbPr video.
5B
HARDWARE
The Apantac Tahoma Multiviewer Platform consists of 4 different sizes of mechanical frames to
serve the needs of broadcast, professional AV and surveillance markets. These frames are ½
width of 1 RU, 1 RU, RU and 3RU. Each Multiviewer frame has a unique IP address, which
allows a PC/laptop to easily connect and configure the display layouts.
The Tahoma LE consists of 4 electronic elements;
1. VPM -> Video Processing Module
2. URM -> Universal Receiver Module
3. CPM -> Control module
4. PSM -> Power Supply Module.
The URM module allows flexible field upgrades from composite video all the way to 3G HD-SDI
by simply swapping out a board. Future upgrades to computer/data inputs and network (ASI)
inputs are also available.
APANTAC LLC ●7556 SW BRIDGEPORT ROAD ●PORTLAND, OR 97224, USA
Page 9 of 67
6B
TAHOMA PLATFORM PRODUCT LINE
LE Series
Three types of mechanical frames are available for the Tahoma LE family:
1. Tahoma-LE-4: The ½ 1RU LE-4 accepts up to 4 various video standards (from analog
composite to HD-SDI) and comes standard with 16 channels of embedded audio per every
SDI video input. The LE-4 outputs DVI/HDMI (1.2/1.3) / VGA at user selectable
resolutions up to 2048x1080. Analog or AES audio options can be added at any time
during or after the purchase.
2. Tahoma-LE-8 / LE16: The 1 RU LE-16 accepts up to 16 various video standards (from
analog composite to HD-SDI) and comes standard with 16 channels of embedded audio
per every SDI video input. The LE-16 has 4 flexible DVI/HDMI (1.2/1.3)/VGA outputs*
with user selectable resolutions up to 2048x1080. Analog or AES audio options can be
added at any time during or after the purchase.
*Flexible Outputs – LE-16 examples:
Output(s)
1 2 3 4
Inputs 4 4 4 4
Inputs 4 4 8
Inputs 8 8
Inputs 12 4
Inputs 16
3. Tahoma-LE-20 / LE-24 / LE-28 / LE 32: The 2RU LE-32 accepts up to 32 various
video standards (from analog composite to HD-SDI) and comes standard with 16 channels
of embedded audio per every SDI video input. The LE-32 has 8 flexible DVI/HDMI
(1.2/1.3) / VGA outputs* at user selectable resolutions up to 2048x1080. Analog or AES
audio options can be added to the LE-32 at any time during or after the purchase.
APANTAC LLC ●7556 SW BRIDGEPORT ROAD ●PORTLAND, OR 97224, USA
Page 10 of 67
*Flexible Outputs – LE-32 examples:
Output(s)
1 2 3 4 5 6 7 8
Inputs 4 4 4 4 4 4 4 4
Inputs 4 4 4 4 4 4 8
Inputs 4 4 4 4 8 8
Inputs 4 4 8 8 8
Inputs 4 4 4 4 8 12
Inputs 8 8 8 8
Inputs 8 16 4 4
Inputs 4 8 8 12
Inputs 4 4 8 16
Inputs 8 12 12
Inputs 4 12 16
Inputs 8 8 16
Inputs 4 8 20
Inputs 4 4 24
Inputs 4 28
Inputs 8 24
Inputs 12 20
Inputs 16 16
Inputs 32
LI Series
Note: The LI series does not support composite, SD-SDI, HD-SDI simultaneously. The LI-
xxHD, supports both SD-SDI and HD-SDI, the LI-xxCV supports analog composite.
Two types of mechanical frames are available for the Tahoma LI family:
1. Tahoma-LI4 / LI-8: The 1 RU Tahoma LI accepts 4-8 SD-SDI, HD-SDI signals, has a
looping output for every input, and comes standard with 16 channels of embedded audio
per every SDI video input. The LI-8 has two flexible DVI/HDMI (1.2/1.3) / VGA outputs*
with user selectable resolutions up to 2048x1080. Analog or AES audio options can be
added at any time during or after the purchase.
APANTAC LLC ●7556 SW BRIDGEPORT ROAD ●PORTLAND, OR 97224, USA
Page 11 of 67
*Flexible Outputs – LI-8 examples:
Output(s)
1 2
Inputs 4 4
Inputs 8
Tahoma-LI-12 / LI-16: The 2RU Tahoma LI accepts 8-16 SD-SDI, HD-SDI signals, has a
looping output for every input, and comes standard with 16 channels of embedded audio per
every SDI video input. The LI-12 / LI16 has four flexible DVI/HDMI (1.2/1.3)/VGA outputs*
with user selectable resolutions up to 2048x1080. Analog or AES audio options can be added
at any time during or after the purchase.
*Flexible Outputs – LI-16 examples:
Output(s)
1 2 3 4
Inputs 4 4 4 4
Inputs 4 4 8
Inputs 8 8
Inputs 12 4
Inputs 16
LX Series
Note: The LX series does not support analog composite inputs.
Two types of mechanical frames are available for the Tahoma LX family:
1. Tahoma-LX-4 / LX-8 / LX16: The 1 RU Tahoma LX-4 / LX-8 / LX16 has a built-in
16x16 SDI routing matrix switch that supports any input to any output. It accepts 4-16
various video standards (SD-SDI to HD-SDI) and comes standard with 16 channels of
embedded audio per every SDI video input. The LX-4 / LX-8 / LX16 has up to 4 flexible
DVI/HDMI (1.2/1.3) / VGA outputs* with user selectable resolutions up to 2048x1080.
Analog or AES audio options can be added at any time during or after the purchase.
APANTAC LLC ●7556 SW BRIDGEPORT ROAD ●PORTLAND, OR 97224, USA
Page 12 of 67
*Flexible Outputs – LX-4 / LX-8 / LX16 examples:
Output(s)
1 2 3 4
Inputs 4 4 4 4
Inputs 4 4 8
Inputs 8 8
Inputs 12 4
Inputs 16
2. Tahoma-LX-16/32 / LX-20 / LX-24 / LX-28 / LX-32: The 3 RU LX-16–32 / LX-20 /
LX-24 / LX-28 / LX-32 has a built-in 32x32 router which supports any input to any output.
It accepts 16-32 various video standards (SD-SDI to HD-SDI) and comes standard with 16
channels of embedded audio per every SDI video input. The LX-16–32 / LX-20 / LX-24 /
LX-28 / LX-32 have up to 8 flexible DVI/HDMI (1.2/1.3) / VGA outputs* with user
selectable resolutions up to 2048x1080. Analog or AES audio options can be added to the
LX-16 at any time during or after the purchase.
APANTAC LLC ●7556 SW BRIDGEPORT ROAD ●PORTLAND, OR 97224, USA
Page 13 of 67
*Flexible Outputs – LX-16-32 / LX-20 / LX-24 / LX-28 / LX-32 examples:
Output(s)
1 2 3 4 5 6 7 8
Inputs 4 4 4 4 4 4 4 4
Inputs 4 4 4 4 4 4 8
Inputs 4 4 4 4 8 8
Inputs 4 4 8 8 8
Inputs 4 4 4 4 4 12
Inputs 8 8 8 8
Inputs 18 16 4 4
Inputs 4 8 8 12
Inputs 4 4 8 16
Inputs 8 12 12
Inputs 4 12 16
Inputs 8 8 16
Inputs 4 8 20
Inputs 4 4 24
Inputs 4 28
Inputs 8 24
Inputs 12
20
Inputs 16 16
Inputs 32
APANTAC LLC ●7556 SW BRIDGEPORT ROAD ●PORTLAND, OR 97224, USA
Page 14 of 67
DE Series
Two types of mechanical frames are available for the Tahoma DE family:
1. Tahoma-DE-4 / DE-8: The 1 RU Tahoma DE-4 / DE-8 accepts 4-8 video inputs
including from HDMI, DVI, VGA, composite, YC, component, SD-SDI to HD-SDI. The
DE-4 / DE-8 has two flexible DVI/HDMI (1.2/1.3) / VGA outputs* with user
selectable resolutions up to 2048x1080. Analog or AES audio options can be added
at any time during or after the purchase.
*Flexible Outputs – DE-4 / DE-8 examples:
Output(s)
1 2
Inputs 4 4
Inputs 8
2. Tahoma-DE-12 / DE-16: The 2 RU Tahoma DE-12 / DE-16 accepts 4-16 video
inputs including HDMI, DVI, VGA, composite, YC, component, SD-SDI to HD-SDI.
The DE-12 / DE-16 has four flexible DVI/HDMI (1.2/1.3) / VGA outputs* with user
selectable resolutions up to 2048x1080. Analog or AES audio options can be added
at any time during or after the purchase.
*Flexible Outputs – DE-12 / DE-16 examples:
Output(s)
1 2 3 4
Inputs 4 4 4 4
Inputs 4 4 8
Inputs 8 8
Inputs 12 4
Inputs 16
APANTAC LLC ●7556 SW BRIDGEPORT ROAD ●PORTLAND, OR 97224, USA
Page 15 of 67
LC Series
Tahoma-LC-4HD: The LC-4HD Quad-Split accepts up to 4 various video inputs including
analog composite, SD-SDI, HD-SDI and comes standard with 4 channels of embedded
audio per every SDI video input. The LC-4HD supports 4 outputs DVI/HDMI (1.2/1.3) /
VGA at user selectable resolutions up to 2048x1080. Analog or AES audio options can be
added at any time during or after the purchase.
TECHNICAL SPECIFICATIONS
•3G ready. Upgradable to 3Gbit/s HD inputs
•Auto detect HD-SD/SDI/CV 50/60Hz (available formats depends on the model)
•Auto detect HDMI/DVI/VGA/CV/YC/component (available formats depends on the model)
•Output resolution up to 2048x1080 (720x480 – 2048x1080)
•Digital and Analog clocks can be synchronized with NTP or LTC (timecode)
•Up to 30 presets for display layout
•Presets can be recalled via GPI, front panel buttons or ASCII protocol via network or serial
•On Screen Display (OSD) for labels, border and alarms can be customizable via Apantac skin
technology with industry standard graphical tools
•Auto-detect aspect ratio between 16x9 and 4x3
•Communication interface via IP or RS232
•Supports Apantac eXtended Protocol (AXP)
•Supports direct TSL tally/UMD interface
•Supports multiple languages (including 2 byte characters)
•Supports SDI output (optional)
APANTAC LLC ●7556 SW BRIDGEPORT ROAD ●PORTLAND, OR 97224, USA
Page 16 of 67
Table 1: Serial Video input
Standards Upgradable to 3Gb/s (SMPTE 424M)
HD-SDI (SMPTE 292M)
SD-SDI (SMPTE 259M-C)
PAL/NTSC
Connector BNC
Equalization Automatic to 140m (Belden 1694A)
Return Loss 15db up to 270mb/s
Embedded Audio SMPTE 272-A
Table 2: Video Formats supported
480i 720p/30 1080p/23.98 2048x1080p/23.98
480p 720p/50 1080p/24 2048x1080p/24
576i 720p/59.94 1080p/25
576p 720p/60 1080p/29.97
720p/23.98 1035i/59.94 1080p/30
720p/24 1035i/60 1080sf/23.98
720p/25 1080i/50 1080sf/24
720p/29.97 1080i/59.94 1080sf/30
Table 3: Computer Formats supported (50/60Hz)
720x480 852x480 1024x768 1280x768
800x600 1280x960 1280x1024 1360x768
1280x800 1400x900 1400x1050 1600x1200
1366x768 1920x1080 1920x1200 1680x1050
Table 4: Audio input
Type Default Option
AES 75 Ωunbalanced via BNC 110 Ωbalanced via XLR
Analog Stereo Unbalanced via BNC balanced via XLR
APANTAC LLC ●7556 SW BRIDGEPORT ROAD ●PORTLAND, OR 97224, USA
Page 17 of 67
Table 5: Display Output
Standards DVI-D, HDMI 1.2/3, VGA up to 2048x1080,
SDI
Connector RJ45 (with transmitter), BNC
Impedance 100Ω, 75Ω
Table 6: Audio Outputs
Type Number/type/connector Location Adjustment
AES 1 / unbalanced / BNC Rear Panel None, Line Level
Stereo Analog 1 / unbalanced / phone jack Rear Panel None, Line Level
Stereo Analog 1 / unbalanced / phone jack Front Panel Front Panel knob
Table 7: Output Resolution (50 and 60Hz)
720x480 852x480 1024x768 1280x768
800x600 1280x960 1280x1024 1360x768
1280x800 1400x1050 1600x1200 1680x1050
1366x768 1920x1080 1920x1200 2048x1080
TabLE-8: General Purpose Interface I/O
Number On VPM On CPM
Inputs 8, assignable to input or
output
8, assignable to input or
output
Outputs 8, assignable to input or
output
8, assignable to input or
output
Connector DB9 RJ50 to DB9
APANTAC LLC ●7556 SW BRIDGEPORT ROAD ●PORTLAND, OR 97224, USA
Page 18 of 67
Figure 1: GPI/O Electrical Characteristics
Table 9: Serial Port
Number of Ports 1 x RS232
Adapter RS232 to RS422 or RS485 (optional)
Connector RJ45
Baud Rate Up to 115200
UMD support Native to TSL and TSI, other third party
protocols via Apantac UIM*
Table 10: Ethernet
Network Type Fast Ethernet 100 Base-TX
Connector RJ45
Cable Auto-detect. Either straight or crossed cable
will work
UMD support Native to TSL and TSI, other third party
protocols via Apantac UIM*
*UIM – Universal Interface Module. The UIM is a small footprint router protocol translator that
acts s a bridge between the Tahoma platform of Multiviewers and other third party router, tally
and UMD protocols. The UIM can support third-party TCP/IP, UDP as well as serial protocols.
The UIM can also act as an SNMP agent for the Apantac Tahoma Multiviewers.
APANTAC LLC ●7556 SW BRIDGEPORT ROAD ●PORTLAND, OR 97224, USA
Page 19 of 67
Table 11: Timecode
Timecode LTC
Connector BNC
Figure 2: LTC Electrical Characteristics
8B
APANTAC LLC ●7556 SW BRIDGEPORT ROAD ●PORTLAND, OR 97224, USA
Page 20 of 67
PHYSICAL SPECIFICATIONS
24BTahoma LE-4
Table 12: Tahoma LE-4 Physical Specifications
Size H: 1.75 in (4.45 cm, 1RU), W: 8.5 in (21.6
cm), D: 13 in (33 cm)
Rack installation ½ of standard 19-inch equipment rack. 2
Tahoma LE-4’s can be connected together
with the interconnect kit mounted in a single
RU, or a blank panel is provide to mount a
single Tahoma LE on a single RU.
Weight 6 lbs. (2.8kg)
Power 90/250 VAC, 60/50Hz, 25 W, internal auto
switchable
Operating Temperature 0 – 40°C (32 - 104°F)
Noise Level Maximum 32 db. Tahoma LE has temperature
sensor to regulate fan speed, actual noise
level may be much lower
Figure 3 - 4 show the front and back panels of the Tahoma LE-4.
