RECALM ANCOR User manual
V1.0 | 05.2021
Operating manual
ANCOR
Active Noise Cancelling offered by recalm
recalm GmbH
Harburger Schloßstraße 6–12
21079 Hamburg, Germany
Phone: +49 40 766 29 -3881
Email: service@recalm.com
Web: http://www.recalm.com
Service requests: http://service.recalm.com
© Copyright recalm GmbH:
These operating manual may only be reproduced, translated
or made accessible to third parties with the express permission
of recalm GmbH.
Original operating manual
Table of contents
ANCOR V1.0 | 05.2021 Page 3 of 59
Table of contents
1About this operating manual.....................................................5
1.1 Relevant documents and web links.....................................5
1.2 Presentation of information .................................................6
1.2.1 Warnings.................................................................6
1.2.2 Abbreviations used .................................................7
1.2.3 Symbol....................................................................7
2Important safety instructions....................................................9
2.1 Intended use........................................................................9
2.2 Non-intended use..............................................................10
2.3 Qualification of users.........................................................11
2.4 General safety instructions................................................11
2.5 Work on electrical equipment............................................13
2.6 Behavior in an emergency.................................................13
2.7 Behavior under increased noise pollution.........................13
3Specifications ...........................................................................15
3.1 ANCOR..............................................................................15
3.2 A2B-Sensor.......................................................................18
4Scope of delivery......................................................................19
5Device description....................................................................20
5.1 Device Overview ...............................................................20
5.2 Function.............................................................................23
5.3 LED Overview ...................................................................24
6Assembly...................................................................................25
6.1 Disassemble the headrest.................................................25
6.2 Mount ANCOR on the headrest ........................................27
6.3 Mounting A2B sensors......................................................29
7Commissioning.........................................................................30
7.1 Connecting the supply cable.............................................30
7.2 Producing a power supply.................................................31
8Service 33
8.1 Activate and deactivate ANC on the button ......................33
Table of contents
ANCOR V1.0 | 05.2021 Page 4 of 59
8.2 Operation of the ANCOR app ...........................................34
8.2.1 Connect your mobile device via Bluetooth............35
8.2.2 Configuring ANCOR for Vehicle Variant...............37
8.2.3 Live View User Interface.......................................40
8.2.4 Enable and disable ANC in the app.....................41
8.3 Retrieve statistical data (optional).....................................42
9Cleaning and maintenance......................................................44
9.1 Cleaning ANCOR ..............................................................44
9.2 Maintain ANCOR...............................................................44
10 Troubleshooting .......................................................................45
10.1 Measures to remedy faults................................................45
10.2 Read error codes and submit service requests ................47
10.3 Troubleshoot Bluetooth connection issues .......................49
10.4 Uncheck over-temperature shutdown...............................50
10.5 Fix ANC feature limitation..................................................50
11 Decommissioning and dismantling........................................52
11.1 Decommissioning ANCOR................................................52
11.2 Disassemble the headrest.................................................53
11.3 Detach ANCOR from the headrest....................................54
12 Storage
13 Disposal.....................................................................................57
About this operating manual
ANCOR V1.0 | 05.2021 Page 5 of 59
1 About this operating manual
These operating instructions apply to the acoustic system ANCOR,
which is used for active noise reduction. It contains information on
correct installation, commissioning, operation and troubleshooting.
This operating manual is aimed at people who integrate the ANCOR
into a vehicle, put it into operation and operate it for the first time.
1.1 Relevant documents and web links
The QR code next to it opens the web link
https://www.recalm.com/datasheets. Current and
supplementary information on the ANCOR can be
viewed there, e.B data sheets and this operating
instructions.
The ANCOR app is required to configure the
ANCOR. This contains supplementary
documentation and guides the user through all the
necessary steps of configuring the ANCOR. The
QR code next to it leads to the download of the
ANCOR app from the App Store.
All approved vehicle variants on which the ANCOR
can be used are stored in the ANCOR app as part
of the configuration settings or can be viewed via
the web link https://www.recalm.com/machine-
directory.
About this operating manual
ANCOR V1.0 | 05.2021 Page 6 of 59
Service requests can be made via the web link
https://service.recalm.com.
1.2 Presentation of information
For fast and safe work with the ANCOR, uniform warnings, symbols,
terms and abbreviations are used in this operating manual. For a
better understanding, these are explained in the following chapters.
1.2.1 Warnings
In these operating instructions, warnings are provided before a se-
quence of actions in which there is a risk of personal injury or proper-
ty damage. The described security measures must be complied with.
Warnings are structured as follows:
The signal words have the following meaning:
Signalword
Meaning
DANGER
Indicates a danger that is sure to lead to death or
serious injury if you do not avoid the danger.
WARNING
Indicates a danger that can lead to death or seri-
ous injury if you do not avoid the danger.
SIGNAL WORD
Type or source of danger!
Consequences of non-observance.
Security measure.
About this operating manual
ANCOR V1.0 | 05.2021 Page 7 of 59
Signalword
Meaning
CAUTION
Indicates a hazard that can lead to mild to moder-
ate injuries if you do not avoid the danger.
ATTENTION
Indicates possible damage to property. The envi-
ronment, property or the device itself can be dam-
aged if you do not avoid the danger.
1.2.2 Abbreviations used
ANC
Active Noise Cancelling (aktive Geräuschunterdrü-
ckung)
EVEN
Active Noise Cancelling offered by recalm
A2B
Automotive Audio-Bus(interface for data transmis-
sion for noise cancellation)
CAN-Bus
Controller Area Network bus (interface for data ex-
change between several ECUs)
dB
Dezibel (logarithmic unit of measurement of the
sound pressure level; an increase of 10 dB corre-
sponds to twice the volume)
dB(A)
Dezibel by frequency rating filter A(sound pressure
level in dB calculated according to A rating and de-
pending on the distance and frequency range of the
sound source)
GND
Ground (voltage designation of the ground)
WINE
Input voltage (input voltage)
1.2.3 Symbol
If this information is not observed, the device cannot be
used or operated optimally.
About this operating manual
ANCOR V1.0 | 05.2021 Page 8 of 59
Instructions for action: Describes activities that must be
performed.
Result: Describes the result of an executed instruction.
QR code: Indicates further web links or access to the
ANCOR app.
Menu
Menu items of the ANCOR app are displayed in italics.
[button]
Buttons of the ANCOR app are shown in square
brackets.
Important safety instructions
ANCOR V1.0 | 05.2021 Page 9 of 59
2 Important safety instructions
The ANCOR has been manufactured according to the recognized
rules of technology. Nevertheless, there is a risk of personal injury
and property damage if the following basic safety instructions and
the warnings before instructions for action in these operating instruc-
tions are not observed.
Read this instruction manual thoroughly and completely before
using the ANCOR.
Keep the instruction manual so that it is legible. Ensure that it is
accessible to all users at all times.
Always pass on the ANCOR to third parties together with these
operating instructions.
2.1 Intended use
The ANCOR is an acoustic device for active noise reduction in
closed vehicle cabins and is mounted on the headrest of the vehicle
for operation.
The ANCOR may only be used by competent persons and in the
industrial or commercial sector.
The ANCOR may only be used in construction and land vehicles that
recalm GmbH considers permissible and stored as a configuration
setting in the ANCOR app.
In order to ensure effective use, the ANCOR must be configured
before operation for the respective vehicle variant on which the de-
vice is used.
The operating conditions specified in the technical data must always
be complied with.
Important safety instructions
ANCOR V1.0 | 05.2021 Page 10 of 59
Noise reduction by means of the ANCOR is only possible in a limited
range of frequencies and sound pressure levels, see section "Field of
Applicationin chapter "3Specifications".
The ANCOR may only be used together with the approved parts
from the scope of delivery.
The intended use also includes that these operating instructions and
in particular the chapter "2Important safety instructionsare read and
understood in full.
2.2 Non-intended use
Any improper use is prohibited. A non-intended use shall be deemed
to be if:
•the ANCOR is used differently from that described inIntended
use"2.1 Intended use",
•the ANCOR is used under operating conditions which differ from
those described in these instructions,
•of the ANCOR or parts of the scope of delivery are converted or
technically modified.
If the ANCOR is not used as intended, all warranty claims expire.
The manufacturer is not liable for damage to the ANCOR or for per-
sonal injury caused by improper use.
Important safety instructions
ANCOR V1.0 | 05.2021 Page 11 of 59
2.3 Qualification of users
The activities described in this owner's manual require knowledge of
the functioning and structure of the vehicle on which the ANCOR is
used. Therefore, in order to ensure operational safety, these activi-
ties may only be carried out by a person who is sufficiently instructed
in handling the vehicle and, if necessary, safety precautions and who
has a suitable driving license.
The ANCOR may only be assembled, put into operation and operat-
ed by persons who have familiarized themselves with the use of the
ANCOR and the associated dangers on the basis of these operating
instructions.
2.4 General safety instructions
Be sure to follow the instructions in this owner's manual in order
to exclude hazards and avoid damage.
Carry out assembly, commissioning and cleaning work as well as
possible troubleshooting at the ANCOR only when the vehicle is
switched off.
Use the ANCOR and all supplied components only in technically
perfect condition and exclusively in the performance range speci-
fied in the technical data (see Chapter 3).
Do not use the ANCOR in explosive or corrosive environments.
Do not expose the ANCOR to radiation, e.g. microwave, UV
,laser or X-ray radiation.
Protect the ANCOR from damage caused by the ingress of solid
foreign bodies or liquids and from fiber flight.
If the vehicle is not in operation for a long time, disconnect the
ANCOR from the power supply. Depending on the vehicle vari-
ant, the on-board voltage socket is supplied with voltage even
when the ignition of the vehicle is switched off.
Important safety instructions
ANCOR V1.0 | 05.2021 Page 12 of 59
Maintenance and repair work on the ANCOR is not carried out
independently. This work may only be carried out by recalm-
Service.
Ensure that the driver's field of vision remains sufficiently illumi-
nated on all sides even after the ANCOR has been installed. Use
devices for indirect vision on the vehicle, e.g. reversing cameras
or mirrors.
If the driver's seat is rotated or the position of the backrest is
changed, collisions may occur between the mounted ANCOR
and parts of the vehicle cabin. The vehicle operation can be trig-
gered accidentally. Avoid collisions within the vehicle cabin as
well as unwanted operation and starting the vehicle.
Do not hold on to the ANCOR when entering the vehicle, as this
can lead to damage to the device.
In the event of severe weather or strong winds, noise and
measurement errors may occur on the A2B sensors and on the
microphones of the ANCOR. In this case, do not use the AN-
COR.
Ensure that the speakers and microphones on the device frame
are not obscured by garments or other textiles.
Important safety instructions
ANCOR V1.0 | 05.2021 Page 13 of 59
2.5 Work on electrical equipment
Any modifications to the electrical equipment of the device may only
be made by the recalm service.
The device may only be opened by the recalm service.
Regularly check the ANCOR and the supplied components for
obvious defects, e.g. loose bindings or damage to the insulation.
In case of defects in the electrical equipment, disconnect the
power supply from the ANCOR and contact the recalm service.
Never remove or damage the seallabel at the service interfaces
of the ANCOR. The use of the service interface is reserved for
the recalm service.
2.6 Behavior in an emergency
Malfunctions or dangerous situations may lead to an immediate risk
of injury to persons or to a risk of damage to the ANCOR or other
devices in the working environment.
If necessary, stop the vehicle and put it out of service.
Disconnect the ANCOR from the power supply.
If necessary, leave the vehicle and seek help.
Have malfunctions eliminated by the recalm service.
2.7 Behavior under increased noise
pollution
In rare cases, the sound pressure level of the interference source
can be increased by a malfunction of the ANCOR. Sound pressure
levels of up to 105 dB(A) can be emitted. If a person is exposed to
such noise exposure for more than 5 minutes, there is a risk of per-
manent hearing damage.
Important safety instructions
ANCOR V1.0 | 05.2021 Page 14 of 59
Be careful not to expose yourself to noise pollution for more than
5 minutes. If the problem cannot be eliminated by the following
action steps, leave the vehicle cabin and move away from the
sound source.
If the ANCOR does not deactivate the ANC automatically, deac-
tivate the ANC manually via the button on the device frame or
via the ANCOR app (see Chapter 8.1
Re-enable the ANC.
If the malfunction persists:
Deactivate the ANC again and disconnect the ANCOR from the
power supply.
Contact the recalm service.
Specifications
ANCOR V1.0 | 05.2021 Page 15 of 59
3 Specifications
3.1 ANCOR
General data
Dimensions (W x H x D)
560 mm x 250 mm x 230 mm
Weight
3.5 kg
Protection class housing
IP54
Environmental and operating conditions
Distance of head restraint rods
(center to center)
min. 112 mm
Max. 193.5 mm
Diameter of the headrest rods
min. 10 mm
Max. 14 mm
Headrest width
Max. 30 cm
Application
Frequency band: 50 to 500 Hz
Sound level: up to 100 dB(A)
Operating temperature
-40 to +70 °C
relative humidity
Max. 70%
Overtemperature shutdown
from 75 °C with 10 °C hystere-
sis (transition to normal opera-
tion from 65 °C)
Use in earthquake zones
Yes
Vibration resistance according
to DIN EN 60068-2-64/-27
Random vibration: up to 2.97 g
Shock vibration: up to 25 g
Keeping clean according to
cleanroom/cleanroom class
no
Specifications
ANCOR V1.0 | 05.2021 Page 16 of 59
Storage
Temperature
-55 to +105 °C
relative humidity
Max. 70%
Electrical data
Connection of supply cable
Deutsch DT06-6S-CE 13, 6-polig
Supply voltage
8–24 V DC
Power consumption
Max. 120 th /m
Short-circuit strength
yes, individual pins from the
supply plug to GND and to the
supply voltage
Reverse polarity protection
Yes
Dew protection
Yes
Interfaces
1x A2B
1x CAN-Bus
1x Ethernet
1x RS232
1x USB
Specifications
ANCOR V1.0 | 05.2021 Page 17 of 59
Electromagnetic compatibility
Current injection test (BCI)
according to ISO 11452-4:2011
Class A(up to 60mA, Pmax 25 W)
Test pulses on supply lines
according to ISO 7637-2:2011
and ISO 7637-3:2007
1: Class C
2a: Class A
2b: Class C
3a: Class A
3b: Class A
a + b: Class A
Test pulses on supply lines
according to ISO 16750-2:2012
Starting impulse: Class A
Load Dump Pulse: Class C
Immunity test against electro-
static discharges (ESD)
according to ISO 10605:2008
Class A
Interference emissions
30 to 75 MHz, BB
64 to 54 dB(μV/m)
75 to 400 MHz, BB
54 to 65 dB(μV/m)
400 to 1000 MHz, BB
65dB( μV/m)
In accordance with
EMC Directive 2014/30/EU
DIN EN ISO 13766-1:2018: Arithmetic and construction machinery
–EMC of machines with internal electrical on-board electrical sys-
tem –Part 1: General EMC requirements
DIN EN ISO 14982:2009: Agricultural and forestry machinery –
EMC –Test methods and evaluation criteria
Specifications
ANCOR V1.0 | 05.2021 Page 18 of 59
3.2 A2B-Sensor
General data
Dimensions (W x H x D)
44,5 mm x 36 mm x 110 mm
Weight
90 g
Protection class housing
IP67
Operating temperature
-40 to +105 °C
Electrical data
Connection
I know SAL8 RSC3
Short-circuit strength
no
Dew protection
Yes
Interface A2B
1x Input
1x Output
Scope of delivery
ANCOR V1.0 | 05.2021 Page 19 of 59
4 Scope of delivery
The scope of delivery includes:
•One Acoustic unit ANCOR
•One A2B sensor
(optional: additional A2B sensors incl. sensor cable)
•a supply cable
•two clamping rings
•an operating manual
