Record Power RPB8 User guide

1
To register this product please visit
www.recordpower.info
It is important to register your product as soon as possible in order to receive efficient after sales
support and be entitled to the full 5 year guarantee. Your statutory rights are not affected.
Please see back cover for contact details.
Original Instruction Manual
RPB8 8” Buffing Machine
Important
For your safety read instructions carefully before
assembling or using this product.
Save this manual for future reference.
Always wear safety glasses when
using woodworking equipment.
Always read the instructions
provided before using
woodworking equipment.
i
Kg
Version 3.1
May 2021
71800

2
Contents
1 Explanation of Symbols
2 General Health and Safety Guidance
3 Additional Health and Safety Guidance for Buffing Machines
4 Record Power Guarantee
5 Specifications
6 Contents of the Package
7 Assembly
8 Operation
9 Maintenance
10 Dust Extraction
11 Troubleshooting
12 Electrical Connection and Wiring Diagram
13 Parts List and Diagram
EU Declaration of Conformity

3
THE SYMBOLS AND THEIR MEANINGS SHOWN BELOW MAY BE USED THROUGHOUT THIS MANUAL. PLEASE ENSURE THAT YOU
TAKE THE APPROPRIATE ACTION WHEREVER THE WARNINGS ARE USED.
1. Explanation of Symbols
i
Kg
i
Kg
i
Kg
i
Kg
i
Kg
i
Kg
i
Kg
i
Kg
Mandatory
Instructions
Warning
Read and fully understand the instruction manual
before attempting to use the machine.
Indicates an instruction that requires particular attention
Wear protective eyewear
Use respiratory protective equipment
Use suitable protective footwear
Use hearing protection
Use protective work gloves
Indicates a risk of severe personal injury or
damage to the machine
Indicates a risk of severe personal injury
from electrical shock
Risk of personal injury from lifting of heavy items
Indicates a risk of severe personal injury from
airborne objects
Risk of fire
i
Kg
i
Kg
i
Kg
i
Kg

4
Ensure that you carefully read and fully understand the
instructions in this manual before assembly, installation and use
of this product. Keep these instructions in a safe place for future
reference.
WARNING: for your own safety, do not attempt to operate this machine
until it is completely assembled and installed according to
these instructions.
WARNING: When using any machine, basic safety precautions should
always be followed to reduce the risk of fire, electric shock and
personal injury.
Safe Operation
1. Use Personal Protective Equipment (PPE)
• The operation of any machine can result in foreign objects being thrown
into your eyes, which can result in severe eye damage. Protective eyewear
or other suitable eye protection or face shield should be used at all
times. Everyday spectacles only have impact resistant lenses. They are not
protective eyewear and do not give additional lateral protection.
• Use respiratory protective equipment (dust mask etc.) if the machining
operation creates dust. Exposure to high levels of dust created by
machining hardwoods, softwoods and man made composite boards can
result in serious health problems. Some imported hardwoods give off
highly irritating dust, which can cause a burning sensation. The use of
respiratory protective equipment should not be seen as an alternative
to controlling the risk of exposure at source by using adequate dust
extraction equipment.
• The use of ear plugs or ear defenders is recommended when the machine
is in use, particularly if the noise level exceeds 85 dB.
• Wear suitable protective gloves when handling cutting tools or blades.
Gloves should NOT be worn when using the machine as they can be
caught in moving parts of the machine.
• Non-slip safety footwear is recommended when using the machine and
handling large work pieces.
2. Dress appropriately
• Do not wear loose clothing, neckties or jewellery; they can be caught in
moving parts of the machine.
• Roll up long sleeves above the elbow.
• Wear protective hair covering to contain long hair.
3. Safety warnings
• Find and read any warning labels on the machine.
• It is important that any labels bearing health and safety warnings are
not removed, defaced or covered. Replacement labels can be obtained by
contacting our Customer Service Department.
4. Familiarise yourself with the machine
• If you are not thoroughly familiar with the operation of this machine,
obtain advice from your supervisor, instructor, or other qualified person or
contact your retailer for information on training courses. Do not use this
machine until adequate training has been undertaken.
5. Take care when moving or positioning the machine
• Some machines can be very heavy. Ensure the floor of the area in which
the machine is to be used is capable of supporting the machine.
• The machine and its various components can be heavy.
Always adopt a safe lifting technique and seek assistance when lifting
heavy components. In some cases it may be necessary to use mechanical
handling equipment to position the machine within the work area.
• Some machines have optional wheel kits available to allow them to be
manoeuvred around the workshop as required. Care should be taken to
install these according to the instructions provided.
• Due to the nature of the design of some machines the centre of gravity
will be high making them unstable when moved. Extreme care should be
taken when moving any machine.
• If transportation of the machine is required then all precautions relating
to the installation and handling of the machine apply. In addition, ensure
that any vehicles or manual handling equipment used for transportation
are of adequate specification.
6. The machine should be level and stable at all times
• When using a leg stand or cabinet base that is designed to be fitted to
the machine, always ensure that it is securely fastened to the machine
using the fixings provided.
• If the machine is suitable to be used on a workbench, ensure that the
workbench is well constructed and capable of withstanding the weight
of the machine. The machine should always be securely fastened to the
workbench with appropriate fixings.
• Where possible, floor standing machines should always be secured to the
floor with fixings appropriate to the structure of the floor.
• The floor surface should be sound and level. All of the feet of the
machine should make contact with the floor surface. If they do not, either
re-locate the machine to a more suitable position or use packing shims
between the feet and the floor surface to ensure the machine is stable.
7. Remove adjusting keys and wrenches
• Ensure that all adjusting wrenches and keys are removed before
switching the machine ‘ON’. There is a risk of severe personal injury or
damage to the machine from airborne objects.
8. Before switching the machine ‘ON’
• Clear the machine table of all objects (tools, scrap pieces etc.)
• Make sure there is no debris between the work piece and the table /
work support.
• Ensure that the work piece is not pressed against, or touching the saw
blade or cutting tool.
• Check all clamps, work holding devices and fences to ensure that they
are secure and cannot move during machining operations.
• Plan the way that you will hold and feed the work piece for the entire
machining operation.
9. Whilst machining
• Before starting work, watch the machine while it runs. If it makes
an unfamiliar noise or vibrates excessively, switch the machine ‘OFF’
immediately and disconnect it from the power supply. Do not restart until
finding and correcting the source of the problem.
10. Keep the work area clear
• Working clearances can be thought of as the distances between
machines and obstacles that allow safe operation of every machine
without limitation. Consider existing and anticipated machine needs, size
of material to be processed through each machine and space for auxiliary
stands and/or work tables. Also consider the relative position of each
machine to one another for efficient material handling. Be sure to allow
yourself sufficient room to safely operate your machines in any
foreseeable operation.
• Cluttered work areas and benches create the risk of accidents. Keep
benches clear and tidy away tools that are not in use.
• Ensure that the floor area is kept clean and clear of any dust and debris
that may create trip or slip hazards.
11. Consider the work area environment
• Do not expose the machine to rain or damp conditions.
• Keep the work area well lit and ensure that there is artificial lighting
available when there is insufficient natural light to effectively light the
work area. Lighting should be bright enough to eliminate shadow and
prevent eye strain.
• Do not use the machine in explosive environments e.g. in the presence of
flammable liquids, gases or dust.
• The presence of high levels of dust created by machining wood can
present a risk of fire or explosion. Always use dust extraction equipment
to minimise the risk.
12. Keep other persons away (and pets)
• The machine is designed to be used by one person only.
• Do not let persons, especially children, touch the machine or extension
cable (if used) and keep visitors away from the work area.
• Never leave the machine running unattended. Turn the power supply off
and do not leave the machine unattended until it comes to a complete
2. General Health and Safety Guidance

5
stop.
• If the work area is to be left unattended, all machinery should be
switched ‘OFF’ and isolated from the mains power supply.
13. Store machines safely when not in use
• When not in use, machines should be stored in a dry place, out of reach
of children. Do not allow persons unfamiliar with these instructions or
with the machine to operate it.
14. Do not overreach
• Choose a working position that allows your body to remain balanced and
feed the work piece in to the machine without overreaching.
• Keep proper footing and balance at all times.
15. Electrical supply
• Electrical circuits should be dedicated to each machine or large enough to
handle combined motor amp loads. Power outlets should be located near
each machine so that power or extension cables are not obstructing high-
traffic areas. Observe local electrical guidelines for proper installation of
new lighting, power outlets or circuits.
• The machine must be connected to an earthed power supply.
• The power supply must be equipped with a circuit breaker that provides
short circuit, overload and earth leakage protection.
• The voltage of the machine must correspond to the voltage of the mains
power supply.
• The mains plug fitted to the machine should always match the power
outlet. Do not modify the plug in any way. If a replacement plug is
required it should be fitted by a competent person and of the correct type
and rating for the machine.
• If you are unsure about any electrical connections always consult a
qualified electrician.
16. Avoid unintentional starting of the machine
• Most machines are fitted with a no-volt release (NVR) switch to prevent
unintentional starting. If in doubt always ensure the machine switch
is in the ‘OFF’ position before connecting it to the power supply. This
means the machine will not automatically start up after a power cut or
switching on of the power supply, unless you first reset the start switch.
17. Outdoor use
• Your machine should not be used outdoors.
18. Extension cables
• Whenever possible, the use of extension cables is not recommended.
If the use of an extension cable is unavoidable, then it should have a
minimum core cross section of 2.5 mm² and limited to a maximum length
of 3 metres.
• Extension cables should be routed away from the direct working area to
prevent a trip hazard.
19. Guard against electric shock
• Avoid body contact with earthed or grounded surfaces such as pipes
and radiators. There is an increased risk of electric shock if your body is
earthed or grounded.
20. Always work within the machine’s intended capacities
• Operator safety and machine performance are seriously adversely
affected if attempts to make the machine perform beyond its limits
are made.
21. Do not abuse the power cable
• Never pull the power cable to disconnect it from the power socket.
Always use the plug.
• Keep the power cable away from heat, oil and sharp edges.
• Do not use the power cable for carrying or moving the machine.
22. Secure the work piece
• Ensure that the work piece is securely held before starting to machine it.
• When working within 300 mm of the machining area, always use a push
stick to feed the work piece in to the blade or cutting tool. The push stick
should have a minimum length of 400 mm. If the push stick becomes
damaged, replace it immediately.
• Use extra supports (roller support stands etc.) for any work pieces large
enough to tip when not held down to the table top.
• Do not use another person as a substitute for a table extension, or as
additional support for a work piece that is longer or wider than the basic
table, or to help feed, support, or pull the work piece.
• Do not attempt to machine more than one work piece at a time.
• When feeding the work piece towards the blade or cutting tool never
position your hands in direct line of the cutting path. Avoid awkward
operations and hand positions where a sudden slip could cause your
hand or fingers to move into the machining area.
23. Stay alert
• Safety is a combination of operator common sense and alertness at all
times when the machine is being used.
• Use all machines with extreme care and do not use the machine when
you are tired or under the influence of drugs, alcohol or medication.
24. Use the correct tool for the job
• Do not use the machine for any purpose other than which it
was designed.
• When selecting replacement cutting tools and blades, always ensure that
they are designed to cut the material that you intend to use them for. If
in any doubt seek further advice from the manufacturer.
25. Connect dust extraction equipment
• Always use dust extraction equipment. The dust extractor should be of
suitable size and capacity for the machine that it is connected to and
have a filtration level appropriate to the type of waste being collected.
Refer to the relevant section of the manual for details of the specific dust
extraction requirements for this machine.
• The dust extractor should be switched ‘ON’ before starting the machine
that it is connected to. The dust extractor should be left running for 30
seconds after the last machining operation is complete in order to clear
any residual waste from the machine.
26. Ensure that the machine is correctly guarded
• Never use the machine if any of the standard safety guards and
equipment are removed or damaged.
• Some machines incorporate safety interlocks to prevent the machine
from being used without the guards in place. Never attempt to bypass or
modify the interlocks to allow the machine to be used without the guards
in place.
27. Maintain your machine with care
• This manual gives clear instructions on installation, set up and
operation of the machine and also details any routine and preventative
maintenance that should be performed periodically by the user.
• Remember always to switch off and unplug the machine from the power
supply before carrying out any setting up or maintenance operations.
• Follow any instructions for the maintenance of accessories
and consumables.
• Do not use compressed air to clean the machine. Always use a brush to
dislodge dust in places that are awkward to reach and a dust extractor to
collect the waste.
• Inspect electric cables periodically and, if damaged, have them replaced
by an authorised service facility or qualified electrician.
• Inspect extension cables (if used) periodically and replace if damaged.
28. Keep cutting tools sharp and clean
• Correctly maintained cutting tools are easier to control and less likely
to bind.
• Cutting tools and blades can become hot during use. Take extreme care
when handling them and always allow them to cool before changing,
adjusting or sharpening them.
29. Disconnect the machine from the power supply
• When not in use, before servicing, changing blades etc. always disconnect
the machine from the power supply.
30. Check for damaged parts
• Before each use of the machine, it should be carefully checked to
determine that it will operate properly and perform its
2. General Health and Safety Guidance

6
intended function.
• Check for alignment of moving parts, binding of moving parts, breakage
of parts and any other conditions that may affect the operation of the
machine.
• A guard or other part that is damaged should be properly repaired
or replaced by a qualified person unless otherwise indicated in this
instruction manual.
• Do not use the machine if the switch does not turn the machine ‘ON’ and
‘OFF’.
• Have defective switches replaced by a qualified person.
31. Warning!
• The use of any accessory or attachment, other than those recommended
in this instruction manual, or recommended by our Company may present
a risk of personal injury or damage to the machine and invalidation of
the warranty.
32. Have your machine repaired by a qualified person
• This machine complies with the relevant safety rules and standards
appropriate to its type when used in accordance with these instructions
and with all of the standard safety guards and equipment in place. Only
qualified persons using original spare parts should carry out repairs.
Failure to do this may result in considerable danger to the user and
invalidation of warranty.
33. Caution! Motor may become hot during use
• It is normal for motors on some machines to become hot to the touch
during use. Avoid touching the motor directly when in use.
2. General Health and Safety Guidance

7
3. Additional Health and Safety Guidance for
Buffing Machines
1. Safe Operation
• The buffing machine should always be level and stable.
• Never attempt to lift the buffing machine while the wheels are in motion
– the centrifugal force created can cause the machine to be unstable and
could cause serious personal injury.
2. Before Switching the Machine ON
• Visually check the buffing wheel for signs of damage or excessive wear.
Replace any defective buffing wheels immediately.
• When fitting the buffing wheel to the machine, always ensure the
clamping flanges are clean and free of any foreign bodies.
• Never attempt to modify a wheel to make it fit your machine.
• The buffing machine is only designed to accept buffing wheels. Do not fit
other accessories such as grinding wheels, wire wheels etc.
• Take care not to over tighten the locking nut to secure the buffing wheel.
3. Dress appropriately
• Do not wear loose clothing, neckties or jewellery; they can be caught in
moving parts of the machine.
• Roll up long sleeves above the elbow.
• Wear protective hair covering to contain long hair.
4. Whilst Buffing
• Never stand directly in line with the buffing wheels when first starting
the machine. Stand with your head and body to one side of the machine.
• Always let the machine run up to speed and run for a minute before
applying work to it. If the machine vibrates excessively, switch the
machine ‘OFF’ immediately. Do not use the machine until the cause of the
vibration has been identified and rectified.
• Do not buff on the side of the wheel.
• Ensure that the work piece is applied into the Buffing wheel as advised in
the manual.
• When switching the machine ‘OFF’ allow the Wheel to slow down
naturally. Do not apply pressure to the wheel in order to slow the
machine down more quickly. Do not leave the machine until it has
completely stopped.
5. Maintenance:
• Check the condition of your power cable.
• The wheels are locked in place.
• The condition of the wheels.
• Keep your machine clean.
• Store in a dry location when not in use.
• Regularly check the overall condition of your machine for any damage,
and that it is fixed in place before usage.
6. This machine falls under the scope of the ‘Health and Safety at Work
etc. Act 1974’, and the ‘Provision and Use of Work Equipment Regulations
1998’. We recommend that you study and follow these regulations.

8
4. Record Power Guarantee
“Products” means the Products sold by Record Power subject to these
terms and conditions;
“Record Power” is Record Power Limited, whose company registration
number is 4804158 and registered office address is Centenary House, 11
Midland Way, Barlborough Links, Chesterfield, Derbyshire S43 4XA and sells
through a network of Authorised Dealers;
“Authorised Distributor” is the nominated importer for your region
who will generally sell through a network of Authorised Dealers. Details of
Authorised Distributors for specific countries can be found in the Product
manual or at www.recordpower.info;
“Authorised Dealer” is a retailer or business authorised to sell Record
Power Products to end users.
1 Guarantee
1.1 Record Power guarantees that for a period of 5 years from the date
of purchase the components of qualifying Products (see clauses 1.2.1
to 1.2.9) will be free from defects caused by faulty construction or
manufacture.
1.2 During this period Record Power, its Authorised Distributor or
Authorised Dealer will repair or replace free of charge any parts
which are proved to be faulty in accordance with paragraphs 1.1
above provided that:
1.2.1 you follow the claims procedure set out in clause 2 below;
1.2.2 Record Power, our Authorised Distributor or Authorised Dealer are
given a reasonable opportunity after receiving notice of the claim to
examine the Product;
1.2.3 if asked to do so by Record Power, its Authorised Distributor or
Authorised Dealer, you return the Product, at your own cost, to
Record Power's premises or other approved premises such as those
of the Authorised Distributor or supplying Authorised Dealer, for the
examination to take place;
1.2.4 the fault in question is not caused by industrial use, accidental
damage, fair wear and tear, wilful damage, neglect, incorrect
electrical connection, abnormal working conditions, failure to follow
our instructions, misuse, or alteration or repair of the Product without
our approval;
1.2.5 the Product has been used in a domestic environment only;
1.2.6 the fault does not relate to consumable Products such as blades,
bearings, drive belts or other wearing parts which can reasonably
be expected to wear at different rates depending on usage (for full
details contact Record Power or your local Authorised Distributor);
1.2.7 the Product has not been used for hire purposes, by you or by a
previous owner;
1.2.8 the Product has been purchased by you as the guarantee is not
transferable from a private sale.
1.2.9 where the Product has been purchased from a retailer, the 5
year guarantee is transferable and begins on the date of the first
purchase of the Product and in the event of a claim under this
guarantee proof of the original purchase date will be required to
validate the warranty period.
2 Claims Procedure
2.1 In the first instance please contact the Authorised Dealer who
supplied the Product to you. In our experience many initial problems
with machines that are thought to be due to faulty parts are actually
solved by correct setting up or adjustment of the machines. A
good Authorised Dealer should be able to resolve the majority of
these issues much more quickly than processing a claim under the
guarantee.
2.2 Any damage to the Product resulting in a potential claim under the
guarantee must be reported to the Authorised Dealer from which it
was purchased within 48 hours of receipt.
2.3 If the Authorised Dealer who supplied the Product to you has been
unable to satisfy your query, any claim made under this Guarantee
should be made directly to Record Power or its Authorised Distributor
(for details of the Authorised Distributor in your country please see
your Product manual or check www.recordpower.info for details).
The claim itself should be made in a letter setting out the date and
place of purchase, and giving a brief explanation of the problem
which has led to the claim. This letter should then be sent with
proof of the purchase date (preferably a receipt) to Record Power or
its Authorised Distributor. If you include a phone number or email
address this will help to speed up your claim.
2.4 Please note that it is essential that the letter of claim reaches Record
Power or its Authorised Distributor on the last day of this Guarantee
at the latest. Late claims will not be considered.
3 Limitation of Liability
3.1 We only supply Products for domestic and private use. You agree not
to use the Product for any commercial, business or re-sale purposes
and we have no liability to you for any loss of profit, loss of business,
business interruption or loss of
business opportunity.
3.2 This Guarantee does not confer any rights other than those expressly
set out above and does not cover any claims for consequential loss
or damage. This Guarantee is offered as an extra benefit and does
not affect your statutory rights as a consumer.
4 Notice
This Guarantee applies to all Products purchased from an Authorised
Dealer of Record Power within the United Kingdom of Great
Britain and Northern Ireland. Terms of Guarantee may vary in other
countries – please check with the Authorised Distributor in your
country (details of the Authorised Distributor for your country can be
found in the manual or at www.recordpower.info).

9
5. Specifications
6. Contents of the Package
1 Main machine 1
2 Power cable with UK plug 1
3 Power cable with European plug 1
4 Buffing wheel 2
5 Flange washers 4
6 Spacer collar 2
7 L/H 16 mm nut 1
8 R/H 16 mm nut 1
No. Item Quantity
Wheel size: 200 mm
Wheel bore: 15.9 mm
Motor input P1: 300 W
Motor output P2: 160 W
Speed: 1490 rpm
Voltage: 230-240 V
Frequency: 50 Hz
Full load current: 1.5 A
Weight: 10 kg
Shaft diameter: 15.9 mm
1
5
2
6 7
3
8
4

10
7. Assembly
Fig 8.3
Before switching the machine ON ensure that the machine is fixed to
the work bench. There are two holes located in the base of the machine
to secure in place, do not over tighten any fixings as this could cause
vibration. There are four pre-installed rubber feet which will act as shock
absorbers.
Note: Ensure the machine is unplugged before assembly.
Attaching each wheel to the machine.
Firstly, attach the flange washer to the machine shaft in the correct
orientation, as shown in Fig 8.1. Next attach the buffing wheel onto the
machine shaft, as shown in Fig 8.2.
Then, attach the flange washer and spacer collar to the machine, followed
by the R/H 16 mm nut by rotating clockwise, as shown in Fig 8.3. Do not
fully tighten.
Repeat the process for the opposing side and attach the L/H 16 mm nut by
rotating anti-clockwise.
Both the L/H and R/H 16 mm nuts can now be fully tightened.
i
Kg
Fig 8.1
Fig 8.2
Flange washer
Buffing
wheel
Spacer collar
R/H 16 mm
nut
Flange
washer

11
8. Operation
The buffing wheels are designed to achieve a high level of finish, together
with the required buffing compound.
Using your Buffing Machine.
When buffing, items must be held below the centre line of the wheel, as
this reduces the likelihood of loss of grip, Fig 9.1.
Whilst in operation, the workpiece is required to be moved frequently
across the wheel face, as shown in Fig 9.2. This will wear the wheel equally
and reduce the build-up of uneven surfaces, maintaining the life span of the
wheel.
Note: Ensure that only light pressure is applied during any
buffing operation to avoid damage to the machine.
Additional care should be taken when buffing an item with sharp edges as
these have the potential to catch, resulting in loss of grip and danger to the
user.
When applying buffing compounds only add a small amount at a time.
i
Kg
i
Kg
i
Kg
Fig 9.1
Fig 9.2

12
9. Maintenance
Before starting a new buffing machine, it is recommended to check the
general condition of each wheel and that the nuts are securely fastened.
Check that the power cable is in good condition before use. Always keep
the machine clean by clearing any excess ready for next use. Use only the
correct sized buffing wheels for the machine, do not attempt to add any
other type of wheel to this machine.
10. Dust Extraction
Due to the small amounts of waste created when buffing, no dust extraction
is necessary. It is recommended that users wear appropriate PPE protection
i.e. protective eyewear and respiratory protective equipment. It is also
recommended that long hair is tied back appropriately, and loose clothing,
neckties and jewellery are not worn.
Any debris which accumulates on the machine can be removed with a
domestic vacuum cleaner, wet and dry vacuum or HPLV dust extractor.

13
11. Troubleshooting
Warning: For your own safety, always turn off and unplug
the machine before carrying out any troubleshooting.
i
Kg
i
Kg
Problem Cause Solution
Tool operates slowly. 1. Extension cord too long. 1. Eliminate use of extension cord.
Machine will not start. 1. Power cord not connected.
2. No power at outlet.
3. Internal damage.
1. Check that the cord is plugged into machine.
2. Check the power at outlet. If outlet is
unpowered, turn off tool and check circuit
breaker.
3. Have technician service machine.
Excessive machine noise. 1. Internal damage or wear. 1. Have technician service machine.

14
12. Electrical Connection and Wiring Diagram
Machines supplied for use in the UK are fitted with a 3 pin plug conforming
to BS1363, fitted with a fuse conforming to BS1362 and appropriate to the
current rating of the machine.
Machines supplied for use in other countries within the European Union are
fitted with a 2 pin Schuko plug conforming to CEE 7/7.
Machines supplied for use in Australia and New Zealand are fitted with a 3
pin plug conforming to AS/NZS3112.
In all cases, if the original plug or connector has to be replaced for any
reason, the wires within the mains power cable are colour coded as follows:
230 V (Single Phase)
Brown: Live (L)
Blue: Neutral (N)
Green and Yellow: Earth (E)
The wire coloured brown must always be connected to the terminal marked
‘L’ or coloured red.
The wire coloured blue must always be connected to the terminal marked ‘N’
or coloured black.
The wire coloured green and yellow must always be connected to the
terminal marked ‘E’ or with the earth symbol or coloured green / green and
yellow.
Earth Symbol Double Insulated Symbol
It is important that the machine is effectively earthed. Some machines will
be clearly marked with the double insulated logo. In this case there will not
be an earth wire within the circuit.
In the case of the BS1363 plug for use in the UK, always ensure that it is
fitted with a fuse conforming to BS1362 appropriate to the rating of the
machine. If replacing the original fuse, always fit a fuse of equivalent rating
to the original. Never fit a fuse of a higher rating than the original. Never
modify the fuse or fuse holder to accept fuses of a different type or size.
Where the current rating of the machine exceeds 13 A at 230 V, or if the
machine is designated for use on a 400 V 3 phase supply a connector
conforming to BS4343 (CEE17 / IEC60309) will be used.
230 V machines will be fitted with a blue 3 pin connector. The wiring for this
type of this connector will be the same as shown above.
400 V, 3 phase machines will be fitted with a red 4 or 5 pin connector. The
wiring for this type of connector is as shown below:
400 V (3 phase)
Brown: Live (L1)
Black: Live (L2)
Grey: Live (L 3)
Blue: Neutral (N)
Green and Yellow: Earth (E)
The wire coloured brown must always be connected to the terminal marked
‘L1’.
The wire coloured black must always be fitted to the terminal marked ‘L2’.
The wire coloured grey must always be connected to the terminal marked
‘L3’.
The wire coloured blue must always be connected to the terminal marked ‘N’
or coloured black.
The wire coloured green and yellow must always be connected to the
terminal marked ‘E’ or with the earth symbol.
If in doubt about the connection of the electrical supply, always consult a
qualified electrician.

15
13. Parts List and Diagram
1 L/H M16 nut 1
2 Flange washer 4
3 Buffing wheel 1
4 Spacer collar 2
5 Screw M5 x 200 2
6 End cap 2
7 Spring washer 1
8 Bearing 2
9 Switch face plate 1
10 Socket base plate 4
11 Rotor 1
12 R/H M16 nut 1
13 Motor stator 1
14 Rotor shaft 2
15 Locking washer 1
16 Screw M4 x 8 2
17 Cable grommet 1
18 Switch 1
19 Screw M4 x 8 4
20 Switch cover 1
21 Base 1
22 M8 nut 1
23 Capacitor bracket 1
24 Capacitor 1
25 Screw M6 x 20 2
26 Base cover 1
27 Rubber feet 4
28 Screw M4 x 12 4
29 Screw M3 x 10 2
30 EU plug and cable 1
31 UK plug and cable 1
No. Description Quantity No. Description Quantity
Buffing Machine

16
EC Declaration of Conformity
Cert No: EC / RPB8 / 3
Record Power Ltd, Centenary House, 11 Midland Way,
Barlborough Links, Chesterfield, Derbyshire S43 4XA
declares that the machinery described:-
1. Type: Buffing Machine
2. Model No: RPB8
3. Serial No: Engineering Sample
Conforms with the following directives:-
MACHINERY DIRECTIVE: 2006/42/EC
ADDITIONAL USED EC DIRECTIVES: EMC Directive 2014/30/EU
USED HARMONIZED STANDARDS: EN 62841-1:2015
EN 55014-1:2017
EN IEC 61000-3-2:2019
EN 61000-3-3:2013+A1:2019
EN 55014-2:2015
and complies with the relevant essential health and safety requirements and conforms to the machinery example for which the EC Type-Examination
certificate number SHEM201000845601 has been issued at: SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd, 588 West Jindu Road, Songjiang
District, Shanghai 201612, China
Signed..........................................................Dated: 06/05/2021 – Chesterfield / U.K.
Andrew Greensted
Managing Director
Technical file held by Andrew Greensted, Record Power Ltd, Centenary House, 11 Midland Way, Barlborough Links, Chesterfield, Derbyshire, S43 4XA, United
Kingdom
Record Power B.V., Verlengde Poolseweg 16, 4818 CL BREDA, Netherlands, Tel: [phone]
EC REP

17

18

19

20
Woodworking Machinery and Accessories
Record Power Ltd, Centenary House, 11 Midland Way, Barlborough Links, Chesterfield, Derbyshire S43 4XA
Tel: [phone] Fax: [phone] www.recordpower.co.uk
To register a product and find your local stockist visit
recordpower.info
Made in China
