Red Hen VMS-333 User manual

VMS-333 & VMS-Mobile
User Guide
VERSION 1.0

VMS-333 & VMS-Mobile User Guide
Version 1.0
2
Copyright © Red Hen Systems
Copyright and Trademarks
VMS-333 & VMS-Mobile User Guide
©2013 Red Hen Systems, LLC All rights reserved.
First Edition.
This material may not be reproduced or transmitted in whole or in part without the written permission
of Red Hen Systems, Drake Professional Park, 2627 Redwing Road, Suite 235, Fort Collins, CO 80526.
Trademark Notices
VMS-333 Video Mapping System™, VMS-Mobile, MediaMapper®, MediaMapper ELITE®, EZdiff™,
RHVoice are trademarks of Red Hen Systems, LLC.
All other trademarks listed in this document are the property of their respective owners.
Visit Red Hen Systems on the World Wide Web at www.redhensystems.com
Technical Support
Availability: Monday through Friday during business hours
Email: [e-mail]
Phone: [phone]
Feedback
Please email your comments and suggestions about the VMS-333 and documentation to:
[e-mail]

VMS-333 & VMS-Mobile User Guide
Version 1.0
3
Copyright © Red Hen Systems
FCC Notice
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee interference will not occur in a particular installation. If this equipment causes
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Re-orient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.

VMS-333 & VMS-Mobile User Guide
Version 1.0
4
Copyright © Red Hen Systems
Table of Contents
Preface.................................................................................................................................................... 7
Who is this guide for?.......................................................................................................................... 7
Why read this guide? ..........................................................................................................................7
How is this guide organized? ............................................................................................................... 7
Section 1. Introducing the VMS-333 ........................................................................................................ 8
1.1 What is VMS-333 and what does it do? .........................................................................................8
1.2 What is VMS-Mobile? .................................................................................................................... 8
1.3 Why use VMS-333 and VMS-Mobile?............................................................................................. 9
Section 2. Understanding the Equipment............................................................................................... 10
2.1 Equipment Handling .................................................................................................................... 10
2.2 Parts Inventory............................................................................................................................ 10
Hardware....................................................................................................................................... 10
Software........................................................................................................................................ 12
GIS................................................................................................................................................. 12
2.3 Parts Diagrams ............................................................................................................................ 13
All necessary parts ......................................................................................................................... 13
3. Getting to Know the Controls and Connectors ................................................................................... 15
3.1 Identify the VMS-333 components .............................................................................................. 15
Front ............................................................................................................................................. 15
Side ............................................................................................................................................... 16
Bottom .......................................................................................................................................... 17
3.2 NanoFLASH.................................................................................................................................. 18
Front ............................................................................................................................................. 18
4. Setting Up Your GPS Receiver ............................................................................................................ 19
4. 1 Wired (GPS unit shipped with VMS-333) ..................................................................................... 19
4.2 Wired (GPS unit in aircraft).......................................................................................................... 19
4.3 Unwired (Bluetooth).................................................................................................................... 19
5. Setting up the VMS-333 ..................................................................................................................... 20
5.2 Connect the VMS-333.................................................................................................................. 20
Scenario 1. Connect the VMS-333 to the video camcorder............................................................. 20
Scenario 2. Connect the VMS-333 to a DSLR still camera................................................................ 21
Scenario 3. Connect the VMS-333 External Feature Trigger cable to the DLSR camera PC connector.
...................................................................................................................................................... 22
Note: In standard use, you would EITHER use the Flash Feedback Cable -OR- use the External
Feature Trigger button; you would NOT use both. ......................................................................... 22
Scenario 4. Hook the VMS-333 to the NanoFLASH.......................................................................... 24
5.3 Test your setup............................................................................................................................ 25
6.0 Using the VMS-333 with Video Recorders ........................................................................................ 26
6.1 Turn on the device and record what you see while traveling........................................................ 26
6.2 Adjust the speaker volume .......................................................................................................... 26
6.3 Adjust the headphone volume..................................................................................................... 26
6.4 Use the feature trigger to mark features of interest..................................................................... 26

VMS-333 & VMS-Mobile User Guide
Version 1.0
5
Copyright © Red Hen Systems
6.5 Make an audio note..................................................................................................................... 26
6.6 Upload recorded data to the computer. ...................................................................................... 27
6.7 View your recorded data ............................................................................................................. 27
6.8 Pay attention to indicators .......................................................................................................... 27
Light indicators (LEDs).................................................................................................................... 27
Audio indicators............................................................................................................................. 28
7.0 Using an Android Device with the VMS-333 and DSLR Cameras ....................................................... 29
7.1 Connect the Android device to the VMS-333 ............................................................................... 29
7.2 Optional: Connect the Android device directly to a Nikon DSLR camera....................................... 29
7.3 Start up VMS-Mobile and examine the home screen ................................................................... 30
7.3 Upload new firmware to the VMS-333......................................................................................... 31
7.4 Load the offline map you want to access from VMS-Mobile......................................................... 32
7.4 Work with offline maps ............................................................................................................... 36
7.5 Load KML and KMZ files............................................................................................................... 37
7.6 Mark a feature of interest ........................................................................................................... 40
7.7 Customize the feature triggers .................................................................................................... 41
7.8. Control the way the VMS-333 feature triggers behave................................................................ 42
7.9 Determine if the camera is running properly ............................................................................... 43
7.10 Control the behavior of the DSLR camera .................................................................................. 44
7.11 Set intervalometry parameters.................................................................................................. 45
7.12 Configure VMS-333 data............................................................................................................ 47
7.13 Configure VMS-333 parameters................................................................................................. 48
7.14 Configure VMS-333 buttons....................................................................................................... 48
7.15 Get familiar with the VMS-Mobile folder structure .................................................................... 49
8.0 Troubleshooting .............................................................................................................................. 50
8.1 Most Common Fixes .................................................................................................................... 50
8.2 Red Hen Systems Support Team .................................................................................................. 51
Appendix A. Quick Reference for VMS-Mobile Screens .......................................................................... 52
Home................................................................................................................................................ 52
Home > Control Camera.................................................................................................................... 52
Home > Mark Features...................................................................................................................... 53
Home > Configure ............................................................................................................................. 53
Home > Configure > Data .................................................................................................................. 54
Home > Configure > Data (long press) ............................................................................................... 54
Home > Configure > Buttons ............................................................................................................. 55
Home > Configure > Buttons > Internal Feature Trigger ..................................................................... 55
Home > Configure > Buttons > External Feature Trigger .................................................................... 55
Home > Configure > Offline Maps > menu button.............................................................................. 55
Home > Configure > Parameters........................................................................................................ 56
Home > Configure > Parameters > Intervalometry Mode > Time ....................................................... 56
Home > Configure > Parameters > Intervalometry Mode > Distance.................................................. 56
Home > Configure > Parameters > Intervalometry Mode > Field of View ........................................... 56
Home > Configure > Feature Triggers ................................................................................................ 57
Home > Configure > Load KML .......................................................................................................... 57
Appendix B. Pin-out Diagrams ............................................................................................................... 58
B.1 Connectors on VMS-333 .............................................................................................................. 58

VMS-333 & VMS-Mobile User Guide
Version 1.0
6
Copyright © Red Hen Systems
FT .................................................................................................................................................. 58
GPS................................................................................................................................................ 58
PWR .............................................................................................................................................. 58
COM .............................................................................................................................................. 58
Appendix C. External GPS Receivers....................................................................................................... 59
C.1 NMEA 0183 Version 2.0 Interface ................................................................................................ 59
C.2 Trimble GPS Receivers................................................................................................................. 59
GGA. Global Positioning System Fix Data........................................................................................ 60
RMC. Recommended Maximum Specific GNSS Data ...................................................................... 61
Appendix D. VMS-333 Warranty ............................................................................................................ 62

VMS-333 & VMS-Mobile User Guide
Version 1.0
7
Copyright © Red Hen Systems
Preface
Who is this guide for?
This User Guide is for anyone who will be installing or using the VMS-333 and VMS-Mobile Android
application. If you are reading this, you are probably one of the following types of people:
Pilots with or without GIS and photography skills. You may even be a member of the Professional
Aeronautic Photography Association.
Vehicle drivers or vessel pilots with or without GIS or photography skills.
Operators who are skilled with GIS equipment and cameras (these individuals usually install and
maintain the VMS-333 equipment).
Why read this guide?
This guide provides you with step-by-step instructions for setting up your equipment, as well as
capturing geotagged media, and transferring it to your computer for examination.
How is this guide organized?
This manual is organized for ease-of-use to make things easy to find and read. This means it starts
with the basics (what you get with the product and how to recognize its parts), proceeds with
instructions for connecting everything, and then moves into using the VMS-333 and the VMS-Mobile
Android application. It even has a short trouble-shooting section to help you deal with any problems
you might encounter.
For those of you who prefer technical details, check out the appendices. There you can review pin-
out diagrams of connectors.

VMS-333 & VMS-Mobile User Guide
Version 1.0
8
Copyright © Red Hen Systems
Section 1. Introducing the VMS-333
1.1 What is VMS-333 and what does it do?
When it comes to right-of-way patrol, whether you are flying over power lines, boating along the coast,
or driving along a railroad line, the VMS-333 is the ideal device for geotagging audio and video data in
real time.
With VMS-333, you can capture both what you see, via an off-the-shelf camcorder, video recorder, or
Nikon DSLR camera (with a memory card or hard drive), and what you say, via a headset and
microphone. You can even take still photos of points of interest and make audio notes about them, if
necessary. The VMS-333 automatically geo-tags the captured data with location and time information,
using a GPS receiver.
VMS-333 works with various types of GPS receivers from hardwired external (NMEA) units to wireless
Bluetooth GPS devices. The GPS unit supplied with the VMS-333 is a wired “puck” style receiver
powered by the VMS-333 through a single cable. It also includes a magnetic mount for easy attachment
to the outside of the vehicle.
When connected to a Nikon DSLR camera, the VMS-333 acts as an intervalometer that controls how
often, how long, and how many shots are taken to create a collection of continuous corridor image
strips. It provides three modes of intervalometry functions:
Time. Triggers camera shots at specific time intervals.
Distance. Triggers camera shots at specific distances as measured by GPS.
Field of View. Triggers aerial camera shots that take in a specific coverage. For example, as altitude
decreases, more shots are taken, and as altitude increases, less shots are taken.
Note: Because the VMS-333 includes a Bluetooth wireless communications channel, you use an Android
tablet running the VMS-Mobile application to set the parameters associated with intervalometry and
camera control.
The GPS data and other metadata are encapsulated in the media files containing the captured audio and
video data. These data files are stored on the hard drive or memory card of the video recorder. You can
then transfer this data to your personal computer and display the results on a map through
MediaMapper. All you need to do is select any video trail on the map to watch the video or click any
marked point of interest on the map to view its associated still photo or listen to its audio notes.
This information can be very useful in corridor management of pipeline and electric transmission right of
ways. It is also beneficial in managing riparian areas along rivers and streams and other types of
corridors, both natural and man-made.
1.2 What is VMS-Mobile?
VMS-Mobile is an Android application that allows you to control the behavior of the VMS-333 and any
DSLR camera connected to it, as well as download and view maps.

VMS-333 & VMS-Mobile User Guide
Version 1.0
9
Copyright © Red Hen Systems
1.3 Why use VMS-333 and VMS-Mobile?
The VMS-333 benefits a wide variety of industries that do right-of-way patrol over highways, gas and
oil pipelines, transmission lines, shorelines, and rivers. You may want to use it because:
Compact, light, and mobile solution that can record more than 7 hours of video.
Expandable—you can connect up to four audio capable recording devices.
Accurate, easy to set up and operate, producing compliant content that is easy to review.
For ease of use, VMS-Mobile allows you to control the VMS-333 and DSLR camera without being
physically connected to it.
Note: If you purchased the Red Hen VMS HD-II, you also got a DVR called a NanoFLASH. You can connect
the VMS-333 to up to four NanoFLASH units.

VMS-333 & VMS-Mobile User Guide
Version 1.0
10
Copyright © Red Hen Systems
Section 2. Understanding the Equipment
This section deals with making sure you have all the parts you need before you get started.
2.1 Equipment Handling
It’s important to take care of the equipment you have purchased. Here are some things you should be
aware of.
VMS-333 hardware is designed to be rugged for portable use; however, it is not a
sealed unit and you should take care to protect the connectors and electronic
components.
If you use VMS-333 with 120 VAC power, use ONLY the adapter supplied with VMS-
333. Other models may specify 7-16 VDC output, but those may allow power surges
that will damage the hardware.
Make sure the power switch is in the OFF position when connecting to an external
power source.
2.2 Parts Inventory
This section identifies all the parts you need to properly operate the VMS-333. Photos of each part
appear in Section 2.3 Parts Diagrams.
Hardware
This is the hardware you must have in place to operate the VMS-333. (NA = not applicable)
Item
Notes
Primary parts
Red Hen Systems VMS-333 GPS hardware
Required, included
GPS receiver (wired or wireless)
Required, included
16 GB memory card
included if you purchased the Red Hen VMS
HD-II
Convergent Design NanoFLASH box
included if you purchased the Red Hen VMS
HD-II
Cables
LanC (2.5mm stereo) cable
NA
Microphone/Headphone (3.5 mm stereo)
cable
NA
Computer serial (9-pin) cable
NA

VMS-333 & VMS-Mobile User Guide
Version 1.0
11
Copyright © Red Hen Systems
Item
Notes
Flash feedback cable
Optional: Special Nikon DSLR cable that
connects the Camera PCI socket or the Camera
Flash Hot Shoe to the External Feature Trigger
cable.
Once connected, this cable provides positive
feedback to VMS-333 that the camera has
successfully captured a photo. The feedback
appears as a large green light on the VMS-
Mobile Home screen or on the Android LED
when Android screen is turned off
Cables continued
DC Cable with Cigarette Adapter
NA
COM Cable for Helicopter
NA
FT to Serial Cable
NA
Feature Trigger Cable
NA
Audio Cable 3.5mm Male to Male 3'
NA
Audio Cable 3.5mm Male to Male 4"
NA
Adapters and Power
Cigarette lighter adapter
included
120 VAC adapter (to convert 24V to 12V from
an external power source)
included
Accessories
Microphone headset
Required if using voice recognition, included
with complete system bundle.
Video capture device, internal PC, external
USB, or PCMCIA
Required for video capture or onscreen review,
included with complete system bundle.
Digital compass
Optional accessory, order separately
Cameras and monitors
NA
Camera (still or video, hi-def or regular)
NA
Monitor
NA
Video cable converter
Connect between camera and monitor, if
needed.

VMS-333 & VMS-Mobile User Guide
Version 1.0
12
Copyright © Red Hen Systems
Software
If you plan to display the videos and photos collected with VMS-333 on a map, you need Red Hen
MediaMapper, which is NOT included with VMS-333.
Item
Description
Operating system
Windows XP, Windows 7 Professional and above
Red Hen MediaMapper
Version 5.3
Red Hen MediaGeotagger
Geo-tag a video with an accompanying GPS log file
Red Hen VMS-Mobile
Set parameters that control intervalometry, data sent to digital
camera, feature triggers, digital camera behavior, and more.
GIS
When you use Red Hen MediaMapper, you need to load various map layers, some of which are included
with MediaMapper, but others are not.
Item
Description
Base layer
Default layers that come with MediaMapper include counties
and U.S. streets.
Note: You might also want to add other base layers, such as
photo or topo.
Reference layer
There are no default layers. You might add layers such as
county boundaries, rivers, railroads, etc. to suit your needs. Red
Hen Systems provides a map creation service.

VMS-333 & VMS-Mobile User Guide
Version 1.0
13
Copyright © Red Hen Systems
2.3 Parts Diagrams
This section shows you what each part in the hardware inventory looks like for easy recognition.
All necessary parts
Red Hen Systems VMS-333 GPS hardware
GPS receiver (wired)
Feature trigger cable
COM cable for helicopter
Flash Feedback cable

VMS-333 & VMS-Mobile User Guide
Version 1.0
14
Copyright © Red Hen Systems
All necessary parts (cont’d)
Computer serial (9-pin) cable
Cigarette lighter adapter
Audio cable 3.5mm male-to-male 4"
USB mini-B cable

VMS-333 & VMS-Mobile User Guide
Version 1.0
15
Copyright © Red Hen Systems
3. Getting to Know the Controls and Connectors
Now that you have all the necessary parts, we will show you how to identify the various controls and
connectors found on the VMS-333 and NanoFLASH. This will help when you later have to connect
everything to set up the VMS-333.
3.1 Identify the VMS-333 components
The VMS-333 has a variety of buttons and ports on the front and side of it, as well as some adjustable
screws on the bottom of it. The following photos and lists help you recognize each button and port.
Front
Note: Some units use the names FT, GPS, PWR, and COM to identify the ports on the right; others use
the letters A, B, C, D. The illustration shows the named ports, rather than the lettered ones; however
both names and letters are reflected in the explanations that follow. The letters appear in parentheses.
1. Connects to the external microphone port on the camera to store all VMS-333 data from the
camera’s storage unit. If the camera stores the data in a format other than mpeg2 you will have to
convert the data to mpeg2 before uploading it to MediaMapper.
Note: If you have the VMS HD-II, port 1connects to the external microphone port on the
NanoFLASH unit, where the VMS-333 data is automatically converted to mpeg2.
2. Connects to the external microphone port of a second camera or a second NanoFLASH, if you
have a VMS HD-II.
3. Connects to the external microphone port of a third camera or a third NanoFLASH, if you have a
VMS HD-II.
4. Connects to the external microphone port of a fourth camera or a fourth NanoFLASH, if you have
a VMS HD-II.
FT (A). Connects to cabled feature trigger. This is a cable with a thumb trigger you can press to
manually identify an important feature. The VMS-333 marks the location of that feature. After the
mission is completed, this location shows up as a special icon on the map in MediaMapper and in
VMS-Mobile (assuming the KML file is loaded into VMS-Mobile). Additionally, the KMZ file produced
by VMS-Mobile can also be viewed in Desktop Google Earth to FT locations as well. When you click
the icon, you see the still photo.
When you connect the optional Flash Feedback Cable to the External Feature trigger cable on the FT
port, the camera’s flash signal is sent from the DSLR camera to VMS-33 each time a photo is taken,
to indicate the camera is working properly. This means the camera’s battery is fine and is memory
card is not full.

VMS-333 & VMS-Mobile User Guide
Version 1.0
16
Copyright © Red Hen Systems
When you use VMS-Mobile, its Home screen briefly displays a large green light indicating successful
flash feedback. If the VMS-Mobile Android screen is off, the Android LED will blink green indicating
successful flash feedback.
Note: This port also connects to a laser range finder that lets you determine the distance between a
feature on the ground and your vehicle.
GPS (B). Connects to an external GPS receiver.
PWR (C ). Connects to power source of an aircraft, vessel, or vehicle. Can handle 12-28 volts.
Note: The electrical pin configuration of the PWR and COM ports allow you to plug a Nikon DSLR
camera into the PWR port while plugging a power supply for the VMS-333 into the COM port.
COM (D). Connects to the pilot or operator’s headset to record what you say as well as hear sounds
associated with the feature trigger. The right audio channel will record vocal dialogue and the left
audio channel records data from the VMS-333.
Side
Vol. Dial that controls the volume of the beeps that occur when you press the red Feature Trigger
button or press the cabled thumb trigger connected to the VMS-333 via the FT port.
Pwr. Power switch that turns the VMS-333 on and off. While it is on, the VMS-333 runs
continuously.
The power switch should NOT be in the On position when connecting to a power
adapter.
Data. Red LED Indicating the status of the data sent to the camera or computer. For details, see
section 6.8 Pay Attention to Indicators.
Gps. Blue LED Indicating the current status of the GPS fix. For details, see section 6.8 Pay Attention
to Indicators.
Note: Both the Data and GPS LEDs flash initially during self-diagnostic test until VMS-333 is powered
up. The red Data LED stays on momentarily
FT. Feature trigger button that you press to manually identify an important feature. The VMS-333
marks the location of that feature. Later, this location shows up as a special icon on the map in
MediaMapper and when you click the icon, you see the associated photo.
Note. If the VMS-333 unit is nearby, you can use the FT button instead of the cabled feature trigger.
You can even use both, since each will produce a different icon on the map.

VMS-333 & VMS-Mobile User Guide
Version 1.0
17
Copyright © Red Hen Systems
Bottom
Speaker. Outputs the status tones and clicks emitted by the VMS-333. For details on what the
sounds mean, see section 6.8 Pay Attention to Indicators.
InterComm. Refers to the pilot or operator’s head set connected to the VMS-333 via the COM port
on the side of the VMS-333
RecVol. Changes the volume of your voice as it is recorded (turn the screw clockwise to increase the
volume of your voice; turn the screw counterclockwise to decrease the volume).
OutVol. Changes the volume of the GPS audio signal alerts you will hear in the headphone (turn the
screw clockwise to increase the volume; turn the screw counterclockwise to decrease the volume).
Note: Additionally, you can use VMS-Mobile to set options that determine whether the hardware
should emit clicks when data is transferred. For details, see: Section 7.12 Configure VMS-333 Data

VMS-333 & VMS-Mobile User Guide
Version 1.0
18
Copyright © Red Hen Systems
3.2 NanoFLASH
Note: This section is only for those of you who purchased a VMS HD-II and have a NanoFLASH unit
mounted on top of the VMS-333.
Front
Microphone port. Connects to VMS microphone ports 1 to 4.
Status. Indicates the status of the NanoFLASH.
Audio port. Can be used to test the VMS-333 and NanoFLASH connection (connect this to the
headset or speaker to test).
Remote. Connects to a thumb trigger that lets you manually start and stop recording (this is useful if
the NanoFLASH box is too far away to press the red button on the side).
Note: If you have multiple NanoFLASH units, this cable should be one of multiple cables, one for
each NanoFLASH unit. Please contact the Red Hen Sales Team for a quote:
[e-mail]
Power. Connects to the power source of aircraft, vessel, or vehicle. It can only handle 12 volts. If the
power source is greater than 12 volts, you must connect this to a converter that in turn connects to
the power source.
SDI/ASI Out. Connects to monitor (standard or hi-definition). Used for video playback.
HDMI –Out. Connects to hi-definition monitor. Used for video playback.
SDI/ASI In. Connects to a camera (standard or hi-definition).
HDMI –In. Connects to hi-definition camera.

VMS-333 & VMS-Mobile User Guide
Version 1.0
19
Copyright © Red Hen Systems
4. Setting Up Your GPS Receiver
Before you can start recording, you need to configure your GPS receiver and place it properly. There are
two types of GPS receivers, wired and unwired. The steps you follow for each are a little different.
4. 1 Wired (GPS unit shipped with VMS-333)
1. There is no need to configure the receiver; it is preconfigured.
2. Place the receiver where it is unimpeded and has a clear view of the sky. The GPS receiver’s
magnetic base may be used to keep it in place on a magnetic surface.
4.2 Wired (GPS unit in aircraft)
1. VMS-333 is compatible with most external GPS, differential, or DGPS receivers through the GPS
connector. The GPS receiver must be set to output the following:
Setting
Value
Data Type
NMEA 0183, version 2.0 or higher
Baud Rate
4800
Bits
8
Parity
none
Stop Bits
1
NMEA strings
GGA and RMC
2. Place the receiver where it is unimpeded by anything metallic, and is facing the sky. See the earlier
diagram in Section 4.1 Wired GPS Unit for details.
4.3 Unwired (Bluetooth)
1. Activate an accompanying Bluetooth GPS Receiver, such as the GlobalSat BT GPS Receiver, in close
proximity to your VMS-333.
2. Once the GPS receiver has obtained a GPS fix, the data will be forwarded to the VMS-333, via the
Bluetooth connection. A GPS fix will then automatically be established on your
VMS-333.

VMS-333 & VMS-Mobile User Guide
Version 1.0
20
Copyright © Red Hen Systems
5. Setting up the VMS-333
You’re almost ready to start using the VMS-333. There are just a few more tasks to complete so
everything is set up.
5.2 Connect the VMS-333
You can connect the VMS-333 directly to several devices:
Video recorder
NanoFLASH
DLSR camera
Your can also connect the VMS-333 External Feature Trigger cable to:
DLSR camera.
What and how you connect depends on your situation and what you are trying to accomplish.
Scenario 1. Connect the VMS-333 to the video camcorder
This scenario is appropriate when you have a man pack or are operating on a smaller budget. You can
use most handheld camcorders that have an external microphone port.
1. Connect the 3.5mm stereo cable between port 1on the VMS-333 and the Microphone Input port on
the video camera.
IMPORTANT: Make sure the 3.5 mm stereo cable is connected to the Microphone Input on your
video, NOT the Headphone Output during recording.
2. Leave the GPS, PWR, and COM ports empty.
3. Install a charged battery.
