Redline RDL-3000 SC User manual

70-00158-01-08 Proprietary Redline Communications © 2011 Page 1of 150 December 7, 2011
RDL-3000 Family
Broadband Wireless Radio Platforms
RDL-3000 SC / SU Enterprise RDL-3000-M
User Manual
1Important Notices.................................................................11
2Functional Description.........................................................18
3Web Interface........................................................................33
4CLI Interface..........................................................................97
5Diagnostics & Troubleshooting.........................................124
6Security...............................................................................135
7Appendices.........................................................................141

RDL-3000 FAMILY USER MANUAL
70-00158-01-08 Proprietary Redline Communications © 2011 Page 2of 150 December 7, 2011
Copyright Information
All rights reserved December 2, 2011. The information in this document is proprietary to
Redline Communications Inc. This document may not in whole or in part be copied,
reproduced, or reduced to any medium without prior consent, in writing, from Redline
Communications Incorporated.
Contact Information:
Redline Communications Inc.
302 Town Centre Blvd.
Markham, ON
Canada L3R 0E8
Web site:
http://www.rdlcom.com
Email:Inquiries: [email protected]
Support: [e-mail]
Training: [e-mail]
Document Control:
70-00158-01-08-RDL-3000_User_Manual-20111202a.doc
Disclaimer
The statements, configurations, technical data, and recommendations in this document
are believed to be accurate and reliable, but are presented without express or implied
warranty. Additionally, Redline makes no representations or warranties, either expressed
or implied, regarding the contents of this product. Redline Communications shall not be
liable for any misuse regarding this product. The information in this document is subject
to change without notice. No part of this document shall be deemed to be part of any
warranty or contract unless specifically referenced to be part of such warranty or
contract within this document.
Software Versions
This manual describes operation using software release v2.xx. This document may
include references to features that are different or unavailable in previous software
releases. Refer to the product Release Notes for information about specific software
releases.

RDL-3000 FAMILY USER MANUAL
70-00158-01-08 Proprietary Redline Communications © 2011 Page 3of 150 December 7, 2011
TABLE OF CONTENTS
1Important Notices.................................................................11
1.1 Service & Safety...............................................................................................11
General Warnings.....................................................................................11
Safety Warnings........................................................................................11
Warning Symbols......................................................................................12
1.2 Installation Safety............................................................................................12
Professional Installation / Installations Professionnel.................................12
Safety Precautions....................................................................................12
Lightning Protection / Protection Contre la Foudre ....................................12
Electrocution Hazard / Risque D’électrocution...........................................13
Radio Frequency Safety / Sécurité des Fréquences Radio .......................14
Electrical Safety ........................................................................................14
Electrical Safety Compliance / Conformité à la Sécurité Electrique ...........14
UL Information...........................................................................................14
1.3 Regulatory Notices ..........................................................................................15
FCC & IC Notices: Deployment in USA and Canada / Avis de la FCC et IC:
Déploiement aux Etats-Unis et le Canada.................................................15
WEEE Product Return Process.................................................................17
1.4 Service & Warranty Information......................................................................17
2Functional Description.........................................................18
2.1 Overview...........................................................................................................18
2.2 PMP Mode.........................................................................................................18
2.2.1 Overview.........................................................................................................18
Features.......................................................................................................18
Classification................................................................................................19
Links and Services.......................................................................................19
2.2.2 Wireless Links.................................................................................................19
2.2.3 Services and Service Groups..........................................................................20
Overview......................................................................................................20
Services.......................................................................................................21
Service Groups............................................................................................22
2.2.4 Setting Wireless Rates....................................................................................23
2.2.5 Pass through Mode.........................................................................................24
2.2.6 Subscriber-to-Subscriber Traffic......................................................................25
2.2.7 VLAN Tagged Management............................................................................26
2.2.8 PMP Configurations........................................................................................27
VLAN Services.............................................................................................27
Default Groups and Services.....................................................................27
VLAN Mapping..........................................................................................28

RDL-3000 FAMILY USER MANUAL
70-00158-01-08 Proprietary Redline Communications © 2011 Page 4of 150 December 7, 2011
Strict VLAN Tagging..................................................................................29
TLS (Transparent LAN Services) .................................................................30
Extended TLS and Double Tagging...........................................................30
Port-by-Port Tagging.................................................................................31
2.3 PTP Mode .........................................................................................................32
3Web Interface........................................................................33
3.1 System Menus..................................................................................................33
3.2 Network Connection........................................................................................34
3.3 Dashboard Display ..........................................................................................36
General Information .....................................................................................36
Wireless Leds ..............................................................................................36
Ethernet LEDs..............................................................................................36
3.4 Status Screens.................................................................................................37
3.4.1 General Information ........................................................................................37
System.........................................................................................................37
Ethernet.......................................................................................................38
3.4.2 System Status.................................................................................................39
Wireless System ..........................................................................................39
Wireless Summary.......................................................................................41
Wireless Ethernet Statistics..........................................................................41
Ethernet Port Statistics.................................................................................41
3.4.3 Subscriber Links Summary .............................................................................43
3.4.4 Subscriber Link Status....................................................................................45
General........................................................................................................45
Wireless.......................................................................................................46
Wireless Packets..........................................................................................46
3.4.5 Services Summary (SS only) ..........................................................................47
3.4.6 System Messages (Log) .................................................................................48
Event Messages........................................................................................48
3.5 Configuration Screens.....................................................................................52
3.5.1 System Screen................................................................................................52
System Identification....................................................................................52
Basic Ethernet Configuration........................................................................53
Advanced Ethernet Configuration.................................................................53
3.5.2 RADIUS Setup................................................................................................56
3.5.3 SNMP Configuration .......................................................................................57
SNMP Communities.....................................................................................57
SNMPv2: Edit SNMP Community Settings................................................58
SNMP v2: Trap Destination Settings............................................................58
SNMP v2: Edit Trap Destinations..............................................................59
SNMP v3: Trap Destination Settings............................................................59
SNMP v3: Edit Trap Configuration.............................................................60
SNMP Trap Configuration............................................................................60

RDL-3000 FAMILY USER MANUAL
70-00158-01-08 Proprietary Redline Communications © 2011 Page 5of 150 December 7, 2011
3.5.4 Wireless Configuration....................................................................................61
Basic Wireless Configuration........................................................................61
Advanced Wireless Configuration ................................................................63
Redundancy Configuration (SC only)...........................................................67
Frequency Management Screen..................................................................68
Add ...........................................................................................................68
Delete........................................................................................................68
Local Frequency Ranges...........................................................................68
3.5.5 Wireless Security............................................................................................70
3.6 Provisioning Screens ......................................................................................72
3.6.1 Subscriber Links .............................................................................................72
Subscriber Link Configuration ......................................................................74
Basic Subscriber Link Configuration..........................................................74
Advanced Subscriber Link Configuration...................................................75
3.6.2 Service Groups...............................................................................................77
Service Group Status...................................................................................78
General.....................................................................................................78
Broadcast Ethernet packets ......................................................................78
Service Group Configuration........................................................................79
Basic Service Group Configuration............................................................79
Advanced Service Group Configuration.....................................................80
QoS Group Configuration..........................................................................80
Controls.....................................................................................................81
3.6.3 Subscriber Services........................................................................................82
Subscriber Service Status............................................................................82
General.....................................................................................................82
Ethernet Packets.......................................................................................82
Subscriber Service Configuration.................................................................83
Basic Service Configuration ......................................................................83
Advanced Service Configuration ...............................................................84
QoS Configuration.....................................................................................84
3.7 Utilities Screens...............................................................................................86
3.7.1 Spectrum Sweep.............................................................................................86
Spectrum Sweep Configuration....................................................................86
Spectrum Sweep Chart................................................................................87
Performing a Sweep.....................................................................................87
3.7.2 Users Management.........................................................................................88
System Users...............................................................................................88
Manage User Settings..................................................................................88
New User.....................................................................................................89
Main Menu Access Permissions...................................................................90
3.7.3 Product Options..............................................................................................92
3.7.4 Antenna Alignment Screen..............................................................................94
3.7.5 Firmware Management Screen.......................................................................95

RDL-3000 FAMILY USER MANUAL
70-00158-01-08 Proprietary Redline Communications © 2011 Page 6of 150 December 7, 2011
Firmware Version.........................................................................................95
Firmware Upgrade .......................................................................................95
4CLI Interface..........................................................................97
4.1 Quick Reference...............................................................................................97
4.2 Telnet Access...................................................................................................98
4.3 Command Set...................................................................................................98
4.3.1 apply...............................................................................................................98
4.3.2 arp ..................................................................................................................98
4.3.3 chgver.............................................................................................................99
4.3.4 clear................................................................................................................99
4.3.5 del...................................................................................................................99
4.3.6 enable...........................................................................................................100
4.3.7 disable ..........................................................................................................100
4.3.8 freq ...............................................................................................................100
4.3.9 generate........................................................................................................101
4.3.10 get.................................................................................................................101
4.3.11 load...............................................................................................................104
4.3.12 logout............................................................................................................105
4.3.13 new...............................................................................................................106
4.3.14 ping...............................................................................................................106
4.3.15 reboot ...........................................................................................................106
4.3.16 reset..............................................................................................................106
4.3.17 save..............................................................................................................107
4.3.18 script.............................................................................................................107
4.3.19 set.................................................................................................................107
4.3.20 show.............................................................................................................119
4.3.21 snmpcommunity............................................................................................121
4.3.22 snmptrap.......................................................................................................121
4.3.23 upgrade.........................................................................................................122
4.3.24 user...............................................................................................................122
4.3.25 whoami .........................................................................................................123
5Diagnostics & Troubleshooting.........................................124
5.1 Interface Connection Issues .........................................................................124
5.2 Testing Configuration Changes....................................................................124
5.3 Status Code Definitions.................................................................................125
5.4 Working with System Parameters.................................................................125
Parameters Overview.................................................................................125
Factory Default Settings.............................................................................126
5.5 Long Reset (Lost Password or IP)................................................................128
Long Reset Using Telnet............................................................................128
Restore Default Passwords Only................................................................129
Restore Factory Configuration....................................................................130

RDL-3000 FAMILY USER MANUAL
70-00158-01-08 Proprietary Redline Communications © 2011 Page 7of 150 December 7, 2011
5.6 Classification: Services and Service Groups ..............................................131
Packet Classification at the Sector Controller.............................................131
Packet Classification at the Subscriber ......................................................133
VLAN (802.1Q) Field Definitions ................................................................134
6Security...............................................................................135
6.1 Overview.........................................................................................................135
Authentication............................................................................................135
Management Security................................................................................135
Data Security .............................................................................................135
Physical Security........................................................................................135
6.2 Wireless Authentication ................................................................................136
Out-of-Box Operation.................................................................................136
Generate X.509 Certificate and Key Files...................................................136
Load Wireless X.509 Certificates and Keys................................................136
Enabling Authentication..............................................................................136
6.3 AES Encryption..............................................................................................137
Out of Box Operation .................................................................................137
Enabling AES.............................................................................................137
6.4 SSH for Secure CLI........................................................................................137
Out-of-Box Operation.................................................................................138
Enabling SSH.............................................................................................138
Loading an SSH Key File...........................................................................138
SSH Key Generate Utility...........................................................................138
6.5 HTTPS for Secure Web..................................................................................138
Out-of-Box Operation.................................................................................139
Enabling HTTPS/SSL.................................................................................139
Loading HTTPS/SSL Certificates and Keys................................................139
7Appendices.........................................................................141
7.1 Technical Specifications...............................................................................141
7.2 ID Mapping .....................................................................................................142
7.3 FCC & IC Certified Antennas.........................................................................143
4.9 GHz Radio: FCC & IC Antennas...........................................................143
5.8 GHz Radio: FCC & IC Antennas...........................................................143
7.4 Regional Codes..............................................................................................145
7.5 Setting Up Rapid Auto Provisioning (RAP)..................................................146
Configure Subscriber .................................................................................146
Enter the STID Name and Password.......................................................146
Configure Sector Controller........................................................................146
Step 1: Install RAP Enabled Options Key................................................146
Step 2: Create an STID Link Template....................................................146
Step 3: Create a RAP Service Group ......................................................147

RDL-3000 FAMILY USER MANUAL
70-00158-01-08 Proprietary Redline Communications © 2011 Page 8of 150 December 7, 2011
Step 4: Create a Service for this STID.....................................................147
Configuration Complete..............................................................................148
LIST OF TABLES
Table 1: Notice - Electrical safety specifications............................................................14
Table 2: Avis - Spécifications de sécurité électrique......................................................14
Table 3: Notice - FCC/IC RF Recommended Safe Separation Distances......................15
Table 4: Avis - FCC/IC RF Distances de séparation sécuritaire recommandées............16
Table 5: Web - Operation - Traffic Classification............................................................20
Table 6: Web - Operation - Wireless Rates ...................................................................23
Table 7: Web - Sector Controller and Subscriber Menus...............................................33
Table 8: Web - Wireless LED Indications.......................................................................36
Table 9: Web - Ethernet LED Indications.......................................................................36
Table 10: Web - System Log Messages........................................................................48
Table 11: Web - Required FreeRadius Files..................................................................56
Table 12: Web - Fixed Frame Settings ..........................................................................65
Table 13: Web - Radio Enable - RF Port Settings..........................................................66
Table 14: Web - SISO / MIMO-A Mode: Uncoded Burst Rates (UBR)...........................66
Table 15: Web - MIMO-A / MIMO-B Mode: Uncoded Burst Rates (UBR).......................66
Table 16: Web - Screens and User Access...................................................................90
Table 17: Web - Defaults with No Options Key..............................................................93
Table 18: CLI - Command Summary.............................................................................97
Table 19: CLI - Root Mode Commands .........................................................................98
Table 20: Diag. - Web Interface Diagnostics................................................................124
Table 21: Diag. - PMP Status Code Bits......................................................................125
Table 22: Diag. - Status Codes....................................................................................125
Table 23: Diag. - Parameters Overview.......................................................................125
Table 24: Diag. - Factory Default Settings...................................................................126
Table 25: Spec. - Classification: Packet Received on SC Ethernet Port ......................131
Table 26: Spec. - Classification: Packet Received on SC Wireless Interface...............132
Table 27: Spec. - Classification: Packet Received on SS Ethernet Port.......................133
Table 28: Spec. - Classification: Packet Received on SS Wireless Interface...............133
Table 29: Spec. - 802.1Q Tag Field.............................................................................134
Table 30: Spec. - RDL-3000 Technical Specifications.................................................141
Table 31: Spec. - RDL-3000 ID Ranges ......................................................................142
Table 32: Spec. - FCC & IC Antennas: 4.94 - 4.99 GHz PTP Operation......................143
Table 33: Spec. - FCC & IC Certified Antennas: 5.8 GHz PTP Operation....................143
Table 34: Spec. - FCC & IC Certified Antennas: 5.8 GHz PTP Band Edge Operation .144
Table 35: Spec. - FCC & IC Certified Antennas: 5.8 GHz PMP Operation...................144
Table 36: Spec. - Regional Identification Codes..........................................................145
LIST OF FIGURES
Fig. 1: Notice - WEEE Logo...........................................................................................17
Fig. 2: Function - Distributed L2 VLAN-Aware Wireless Switch .....................................18
Fig. 3: Function - Wireless Subscriber Links..................................................................19

RDL-3000 FAMILY USER MANUAL
70-00158-01-08 Proprietary Redline Communications © 2011 Page 9of 150 December 7, 2011
Fig. 4: Function - Services and Service Groups.............................................................20
Fig. 5: Function - Services (Subscriber).........................................................................21
Fig. 6: Function - Service Groups (Sector Controller) ....................................................22
Fig. 7: Function - Wireless Rates...................................................................................23
Fig. 8: Function - Pass through Mode............................................................................24
Fig. 9: Function - Subscriber-to-Subscriber Unicast Traffic............................................25
Fig. 10: Function - VLAN Tagged Management.............................................................26
Fig. 11: Function - VLAN Services: Default Groups and Services..................................27
Fig. 12: Function - VLAN Services: VLAN Mapping.......................................................28
Fig. 13: Function - Strict VLAN Tagging.........................................................................29
Fig. 14: Function - TLS - Extended TLS and Double Tagging........................................30
Fig. 15: Function - Tagged Traffic - Port-by-Port Tagging..............................................31
Fig. 16: Function - PTP Mode Configuration..................................................................32
Fig. 17: Web - Connecting the Ethernet Port to a PC.....................................................34
Fig. 18: Web - Login Screen..........................................................................................35
Fig. 19: Web - Dashboard Display.................................................................................36
Fig. 20: Web - General Information Screen ...................................................................37
Fig. 21: Web - Sector Controller System Status Screen ................................................39
Fig. 22: Web - Subscriber System Status Screen..........................................................42
Fig. 23: Web - Sector Controller: Subscriber Links Summary Screen............................43
Fig. 24: Web - Subscriber: Subscriber Link Status Screen.............................................45
Fig. 25: Web - Services Summary Screen.....................................................................47
Fig. 26: Web - Example of System Event Messages .....................................................48
Fig. 27: Web - Config - PMP SC System Configuration Screen.....................................52
Fig. 28: Web - VLAN Tagged Management...................................................................55
Fig. 29: Web - VLAN Tagged Management Example ....................................................55
Fig. 30: Web - RADIUS Configuration Screen ...............................................................56
Fig. 31: Web - SNMP v2 Configuration Screen..............................................................57
Fig. 32: Web - SNMP v2: Community Configuration Screen..........................................58
Fig. 33: Web - SNMP v2: Trap Destinations Screen......................................................58
Fig. 34: Web - SNMP v2: Trap Configuration Screen.....................................................59
Fig. 35: Web - SNMP v3: Trap Destinations Screen......................................................59
Fig. 36: Web - SNMP v3: Trap Configuration Screen.....................................................60
Fig. 37: Web - Wireless Configuration Screen -- Sector Controller ................................61
Fig. 38: Web - Wireless Configuration Screen -- Subscriber..........................................63
Fig. 39: Web - Redundancy Configuration.....................................................................67
Fig. 40: Web - Frequency Management Screen ............................................................68
Fig. 41: Web - Wireless Security Screen - Sector Controller..........................................70
Fig. 42: Web - Wireless Security Screen - Subscriber ...................................................71
Fig. 43: Web - Subscriber Links Screen.........................................................................72
Fig. 44: Web - Subscriber Link Configuration Screen ....................................................74
Fig. 45: Web - STID Subscriber Template Configuration Screen...................................75
Fig. 46: Web - Service Groups Screen..........................................................................77
Fig. 47: Web - Service Group Status Screen.................................................................78
Fig. 48: Web - Service Group Configuration Screen......................................................79
Fig. 49: Web - Service Group Configuration - 802.1p Settings.......................................81
Fig. 50: Web - Subscriber Service Status Screen..........................................................82

RDL-3000 FAMILY USER MANUAL
70-00158-01-08 Proprietary Redline Communications © 2011 Page 10 of 150 December 7, 2011
Fig. 51: Web - Subscriber Service Configuration Screen...............................................83
Fig. 52: Web - Service Configuration - 802.1p Settings .................................................85
Fig. 53: Web - Spectrum Sweep Screen........................................................................86
Fig. 54: Web - Users Management Screen....................................................................88
Fig. 55: Web - Product Options Screen .........................................................................92
Fig. 56: Web - Antenna Alignment Tool Screen.............................................................94
Fig. 57: Web - Firmware Management Screen ..............................................................95
Fig. 58: Diag: - Saving Parameters in Non Volatile RAM.............................................126
Fig. 59: Diag. - Recovering Lost IP Address................................................................128
Fig. 60: App. - RAP - SU Wireless Configuration.........................................................146
Fig. 61: App. - RAP - SC Link Template Configuration ................................................147
Fig. 62: App. - RAP - SC Service Configuration...........................................................148

RDL-3000 FAMILY USER MANUAL
70-00158-01-08 Proprietary Redline Communications © 2011 Page 11 of 150 December 7, 2011
1 Important Notices
1.1 Service & Safety
General Warnings
Redline recommendations for maximum safety include the following:
1. Do not operate microwave equipment without first having proper training or
knowledge of microwave radio operation.
2. Do not operate the microwave equipment without an appropriate antenna port
termination, or antenna.
3. Check to ensure that the area around the antenna is clear of personnel prior to
turning the transmitter on.
4. Do not look into or stand in front of an antenna.
5. Do not swing or aim an antenna at nearby persons while the equipment is operating.
6. Where a structure or rooftop has existing antennas installed, do not proceed with an
installation without first determining the RF/µW exposure risk. Where necessary
have the relevant transmitters turned off or wear a protective suit for the duration of
the installation.
Safety Warnings
1. Installation of the system must be contracted to a professional installer.
2. PoE power adapter caution:
Warning to Service Personnel:48 VDC
Customer equipment including personal computers, routers, etc., must be
connected only to the INPUT (DATA) port on the PoE unit.
Only the outdoors Ethernet interface cable connecting to the unit can be safely
connected to the OUTPUT (DATA & POWER) connector. Connecting customer
premises Ethernet equipment directly to the OUTPUT (DATA & POWER)
connector on the Power-over-Ethernet power adapter may damage customer
equipment.
3. Read this manual and follow all operating and safety instructions.
4. Keep all product information for future reference.
5. The power requirements are indicated on the product-marking label. Do not exceed
the described limits.
6. The unit must not be located near power lines or other electrical power circuits.
7. Disconnect the power before cleaning, or when the unit is not be in-use for an
extended period.
8. The system must be properly grounded to protect against power surges and
accumulated static electricity. It is the user’s responsibility to install this device in
accordance with the local electrical codes: correct installation procedures for
grounding the unit, mast, lead-in wire and discharge unit, location of discharge unit,
size of grounding conductors and connection requirements for grounding electrodes.
Chapter 1

RDL-3000 FAMILY USER MANUAL
70-00158-01-08 Proprietary Redline Communications © 2011 Page 12 of 150 December 7, 2011
Warning Symbols
These symbols may be encountered during installation or troubleshooting. These
warning symbols mean danger. Bodily injury may result if you are not aware of the safety
hazards involved in working with electrical equipment and radio transmitters. Familiarize
yourself with standard safety practices before continuing.
Electro-Magnetic Radiation
High Voltage
1.2 Installation Safety
Professional Installation / Installations Professionnel
Redline RDL-3000 devices require professional installation. It is the responsibility of the
installer to be sure that all building and safety codes are met and that the installation is
complete and secure.
The RDL-3000 shall be installed according to local Electrical Safety Codes.
For Canadian installations, the entire equipment installation must comply with
Canadian Standard CSA 22.2, No. 60950, Safety of Information Technology
Equipment. For installations in the United States, the entire equipment installation
must be in accordance with Article 810 of the United States National Electrical
Code.
Les appareils RDL-3000 de Redline doivent être installés par un personnel
professionnel. Le personnel responsable doit s’assurer que l’installation est bien
achevée, et qu’elle répond aux exigences de tous les codes de sécurité.
Une installation faite au Canada doit observer les normes 22.2, numéro 60950 du CSA,
Sécurité des matériels de traitement de l'information. Une installation faite aux États-
Unis doit être faite selon les stipulations de l’Article 810 du United States National
Electrical Code.
Safety Precautions
Installation and service must be done by personnel having technical training and
experience necessary to be aware of hazards during installation and/or service of
outdoors RF equipment. The installation and/or service must be done using procedures
designed to minimize any danger to technical personnel or any other person.
Use safety devices when working on or around the mast. Be aware of the risk of falling
objects. Use provided safety catches when hoisting antennas and radios.
Do not use any components (screws, nuts, etc.) other than those delivered together with
the Redline microwave radio equipment or those recommended by Redline.
Lightning Protection / Protection Contre la Foudre
When installed, this equipment is to be connected to a Lightning/Surge Protection
Device that meets all applicable national safety requirements. Before Ethernet cables
enter buildings, voltages shall be clamped down to SELV by approved type primary
protectors.
WARNING: The information provide in this user manual consists of general
recommendations for installation the system equipment. The wireless equipment must
be installed by a qualified professional installer who is knowledgeable of the
requirements of installing outdoor radio equipment and follows local and national codes
for electrical grounding and safety. Failure to meet safety requirements and/or use of
non-standard practices and procedures may result in personal injury and/or damage to
equipment.

RDL-3000 FAMILY USER MANUAL
70-00158-01-08 Proprietary Redline Communications © 2011 Page 13 of 150 December 7, 2011
The system must be properly grounded to protect against power surges and
accumulated static electricity. It is the user’s responsibility to install this device in
accordance with the local electrical codes: correct installation procedures for grounding
the unit, mast, lead-in wire and discharge unit, location of discharge unit, size of
grounding conductors and connection requirements for grounding electrodes.
All outdoor wireless equipment is susceptible to surge damage from a direct hit or
current induced from a near strike. A direct lightning strike may cause serious damage
even if recommended guidelines are followed. Installing surge protection and following
grounding practices detailed in local and national electrical codes can minimize
equipment damage, service outages, and chance of serious injury.
The major reasons for surge damage can be summarized as:
- Poorly grounded antenna sites
- Improperly installed surge protection equipment
A lighting protection system provides a means by which the energy may enter earth
without passing through and causing damage to parts of a structure. A good grounding
system disperses most of the surge energy from a lightning strike away from the building
and equipment. Improperly grounded connections are a source of noise that can cause
malfunctions in sensitive equipment. The remaining energy on the Ethernet cable shield
and conductors can be directed safely to ground by installing a surge arrestor in series
with the cable. A surge protection system does not prevent lightning strikes, but protects
equipment by providing a low resistance path for the discharge of energy safely to
ground. If you have determined that surge protection is required for your system, the
following general industry practices are provided as a guideline only:
1. The AC wall outlet ground for the indoor POE adapter should be connected to the
building grounding system.
2. Install a surge arrestor in series with the Ethernet cable at the point of entry to the
building. The grounding wire should be connected to the same termination point
used for the tower or mast.
3. Provide direct grounding connections from the RDL-3000, the mounting bracket, and
the antenna to the common building ground bus. Use the grounding screws provided
for terminating the ground wires.
L’installation exige aussi que l’appareil soit branché à un parafoudre qui répond à
toutes les normes nationales de sécurité.
Electrocution Hazard / Risque D’électrocution
Warning to Service Personnel:48 VDC
This product is intended to be connected to a –36 to -57 VDC power source, which
must be electrically isolated from any ac sources and reliably connected to Earth
ground. Do not install Redline products near any type of power line. Should your
antenna or related hardware come in contact with power lines, severe bodily harm or
death could result!
Attention au personnel du service: 48V CD
Cet appareil est raccordée à une source de tension de –36 a -57 VCD, qui doit être
isolée de toute autre source de tension et raccordée à une mise à terre isolée. Les
produits de Redline ne doivent pas être installés près de ligne à haute tension. Des
dommages corporels sévères et même la mort peuvent survenir si l’antenne ou toute
autre pièce viennent en contact avec des lignes de haute tension Dommage corporel.

RDL-3000 FAMILY USER MANUAL
70-00158-01-08 Proprietary Redline Communications © 2011 Page 14 of 150 December 7, 2011
Radio Frequency Safety / Sécurité des Fréquences Radio
The installer of this radio equipment must ensure that the antenna is located or pointed
such that it does not emit RF fields in excess of the general population limits as defined
by FCC CFR 47, Part 2.1091, Radiofrequency radiation exposure evaluation for fixed
devices & Health Canada limits for the general population; consult Safety Code 6,
obtainable from Health Canada’s website:
http://www.hc-sc.gc.ca/ewh-semt/pubs/radiation/radio_guide-lignes_direct-eng.php .
Le programme d'installation de cet équipement radio doit s'assurer que l'antenne est
située ou orientée de façon à ne pas émettre des champs RF au-delà de la population
en général des limites telles que définies par la FCC CFR 47, partie 2,1091, l'évaluation
par radiofréquence exposition aux rayonnements pour les appareils fixes et de Santé
Canada limites pour la population en général, consulter le Code de sécurité 6, disponible
sur site Web de Santé Canada:
http://www.hc-sc.gc.ca/ewh-semt/pubs/radiation/radio_guide-lignes_direct-fra.php .
Electrical Safety
The equipment meets the requirements for class I EN 60950 (protection against electric
shock).
All external circuits are TNV-1 (as defined in EN 60950).
All equipment must be grounded before the power cable is connected.
For electrical safety the DC power supply shall have reinforced insulation to the mains
supply.
Electrical Safety Compliance / Conformité à la Sécurité Electrique
The RDL-3000 hardware has been tested for compliance to the electrical safety
specifications listed in the following table:
Table 1: Notice - Electrical safety specifications
Class I
EN 60950
All External Circuits
TNV-1 as defined in EN 60950
All equipment must be grounded
Le RDL-3000 du matériel a été testé pour la conformité aux normes de sécurité
électriques indiquées dans le tableau suivant:
Table 2: Avis - Spécifications de sécurité électrique
Classe I
EN 60950
Tous les circuits externes
TRT-1 tel que défini dans la norme EN
60950
Tous les équipements doivent être mis à la terre
UL Information
1. The suitability of the supplied Ethernet cable is subject to the approval of Authority
Having Jurisdiction and must comply with the local electrical code.
2. The equipment must be properly grounded according with NEC and other local
safety code and building code requirements
3. To meet the over-voltage safety requirements on the telecommunications cables, a
minimum 26 AWG telecommunication line cord must be used.

RDL-3000 FAMILY USER MANUAL
70-00158-01-08 Proprietary Redline Communications © 2011 Page 15 of 150 December 7, 2011
Pour être en conformance avec les exigences finies de sûreté de sur-tension sur les
câbles de télécommunications un fil de télécommunication ayant un calibre minimum
de 26 AWG doit être utilisé.
4. Reminder to all the BWA system installers: Attention to Section 820-40 of the NEC
which provides guidelines for proper grounding and, in particular, specifies that the
cable ground shall be connected to the grounding system of the building, as close to
the point of cable entry as is practical.
5. RDL-3000 must be installed in compliance with relevant articles in National Electrical
Code-NEC (and equivalent Canadian Code-CEC) including referenced articles 725,
800 and 810 in NEC.
6. RF coaxial cable connecting an antenna to the RDL-3000 must comply with the local
electrical code.
1.3 Regulatory Notices
FCC & IC Notices: Deployment in USA and Canada / Avis de la FCC et IC:
Déploiement aux Etats-Unis et le Canada
Read the following notices about deployment in the USA and Canada:
1. The Model RDL-3000 and its antenna must be professionally installed.
2. WARNING -- FCC & IC RF Exposure Warnings
To satisfy FCC and IC RF exposure requirements for RF transmitting devices, the
following distances should be maintained between the antenna of this device and
persons during device operation:
Table 3:Notice - FCC/IC RF Recommended Safe Separation Distances
Frequency (GHz)
Deployment
Separation Distance
4.9 - 5.3
PTP or PMP
270 cm (107 in) or more
5.8
PMP
20 cm (8 in) or more
PTP
270 cm (107 in) or more
To ensure compliance, operation at closer than these distances is not
recommended. The antenna used for this transmitter must not be collocated in
conjunction with any other antenna or transmitter.
3. FCC Information to Users @ FCC 15.105:
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.

RDL-3000 FAMILY USER MANUAL
70-00158-01-08 Proprietary Redline Communications © 2011 Page 16 of 150 December 7, 2011
- Consult the dealer or an experienced radio/TV technician for help.
Where DFS is required by regional regulations, this function is permanently enabled
at the factory and can not be disabled by the installer or end-user.
4. FCC Information to Users @ FCC 15.21:
Warning: Changes or modifications not expressly approved by Redline
Communications could void the user’s authority to operate the equipment.
Lisez les mentions suivantes sur le déploiement aux Etats-Unis et le Canada:
1. Le modèle RDL-3000 et son antenne doivent être installés par un professionnel.
2. AVERTISSEMENT - FCC et IC avertissements d'exposition RF
Pour satisfaire les exigences d’IC et du FCC en ce qui a trait aux expositions aux
RF pour RF dispositifs de transmission, les distances suivantes doit être maintenue
entre l'antenne de ce dispositif et des personnes pendant le fonctionnement du
dispositif:
Table 4:Avis - FCC/IC RF Distances de séparation sécuritaire
recommandées
Fréquence (GHz)
Déploiement
Distance de Séparation
4.9 - 5.3
PTP ou PMP
270 cm (107 in) ou plus
5.8
PMP
20 cm (8 in) ou plus
PTP
270 cm (107 in) ou plus
Pour assurer la conformité , l’operation à une distance moindre que celles-ci n'est
pas recommandé. L'antenne utilisée pour ce transmetteur ne doit pas être co-
localisé avec une autre antenne ou transmetteur.
3. Informations de la FCC aux utilisateurs @ FCC 15.105:
NOTE: Cet équipement a été testé et démontré conforme aux exigences pour un
dispositif numérique de classe B, conformément à la partie 15 des règles FCC. Ces
exigences sont conçues pour fournir une protection raisonnable contre les
interférences nuisibles dans une installation résidentielle.
Cet équipement génère, utilise et peut émettre des fréquences radio et, s'il n'est pas
installé et utilisé conformément aux instructions, peut causer des interférences
nuisibles aux communications radio. Toutefois, il n'existe aucune garantie que des
interférences ne se produiront pas dans une installation particulière. Si cet
équipement provoque des interférences nuisibles à la réception radio ou télévision,
ce qui peut être déterminé en mettant l'équipement hors tension, l'utilisateur est
encouragé à essayer de corriger l'interférence par un ou plusieurs des mesures
suivantes:
- Réorienter ou déplacer l'antenne de réception.
- Augmenter la distance entre l'équipement et le récepteur.
- Alimenter l'équipement par un circuit différent de celui du récepteur.
- Consulter le revendeur ou un technicien radio / TV pour assistance.
Lorsque DFS est requis par les règlements régionaux, cette fonction est activée en
permanence à l'usine et ne peut pas être désactivé par l'installateur ou l'utilisateur
final.
4. Informations de la FCC aux utilisateurs @ FCC 15.21:

RDL-3000 FAMILY USER MANUAL
70-00158-01-08 Proprietary Redline Communications © 2011 Page 17 of 150 December 7, 2011
Avertissement: Les changements ou modifications non expressément approuvées
par Redline Communications peut annuler l'autorisation de l'utilisateur à utiliser cet
équipement.
WEEE Product Return Process
In accordance with the WEEE (Waste from Electrical and Electronic Equipment)
directive, 2002/96/EC, Redline Communications equipment is marked with the logo
shown above. The WEEE directive seeks to increase recycling and re-use of electrical
and electronic equipment. This symbol indicates that this product should not be disposed
of as part of the local municipal waste program. Contact your local sales representative
for additional information.
Fig. 1: Notice - WEEE Logo
1.4 Service & Warranty Information
1. Refer all repairs to qualified Service personnel. Removing the cover panel or
modifying any part of this device will void the factory warranty.
2. Locate the serial numbers and record these for future reference. Use the space
below to affix serial number stickers. Also, record the MAC address identified on the
unit product label.
3. Redline does not endorse or support the use of outdoor cable assemblies: i) not
supplied by Redline, ii) third-party products that do not meet Redline's cable and
connector assembly specifications, or iii) cables not installed and weatherproofed as
specified in the RDL-3000 Installation Guidelines manual. Refer to the Redline
Limited Standard Warranty and RedCare Service agreements.

RDL-3000 FAMILY USER MANUAL
70-00158-01-08 Proprietary Redline Communications © 2011 Page 18 of 150 December 7, 2011
2 Functional Description
2.1 Overview
The RDL-3000 operates on a common software base controlled by options keys. Each
key enables modes of operation (PTP/PMP), modulation, RF frequency, available
channel sizes, etc. The operator must obtain and enter a permanent options key for
each unit before deploying units in a production network. The RDL-3000 can operate in
PPM mode (following chapters) or PTP mode.
2.2 PMP Mode
This section describes the parameters required to configure PMP support and an
overview of supported VLAN functions.
Operation in PMP mode is controlled by the options keys. Separate options keys are
required for the sector controller and each subscriber. Enter the options keys before
deploying and configuring the RDL-3000 units.
2.2.1Overview
Features
The RDL-3000 PMP firmware provides the following main features:
IEEE 802.1Q/1p standards compliance
Multiple Virtual Local Area Network (VLAN) services per subscriber
VLAN trunking with tag insert/delete/re-map
Multiple Transparent LAN Services (TLS) transport based on VLAN ID
classification
VLAN Service Groups (broadcast/multicast) span subscribers
VLAN tagged management traffic
Individual Committed Information Rate (CIR) and Peak Information Rate (PIR)
setting per service
Fig. 2: Function - Distributed L2 VLAN-Aware Wireless Switch
Chapter 3

RDL-3000 FAMILY USER MANUAL
70-00158-01-08 Proprietary Redline Communications © 2011 Page 19 of 150 December 7, 2011
Classification
The RDL-3000 can operate as a point-to-multipoint (PMP) VLAN-aware wireless L2
switch. Traffic is classified and processed by creating Service and Service Group profiles
to be applied to all packets received and being transmitted on the Ethernet port of each
RDL-3000. The sector controller and subscriber are configured separately for use with
VLAN tagged traffic, untagged traffic, or a combination these two types. Multiple VLAN
IDs can be configured for each port.
Each ingress and egress Ethernet packet is examined and classified according to the
VLAN ID. The matching profile and data direction determines if a VID should be added
or removed, if the packet should be forwarded unmodified (pass through mode), or if the
packet is discarded. Additional traffic controls include CIR/PIR settings to guarantee
required bandwidth.
Links and Services
Ethernet data traffic can not be transmitted over the wireless interface until at least one
Link, Service, and Service Group have been provisioned. All provisioning is performed
on the sector controller:
Link: Define the wireless connection between the sector controller and subscriber
and set the uplink and downlink uncoded burst rates (UBR).
Service: Define how packets are classified and processed at the subscriber Ethernet
port. Set traffic parameters for subscriber (unicast) traffic.
Service Group: Define how packets are classified and processed at the sector
controller Ethernet port. Set traffic parameters for broadcast/multicast groups.
2.2.2Wireless Links
A Link defines a wireless connection between the sector controller and subscriber Each
link is uniquely identified with either a name and the subscriber MAC address, or with a
link template (STID). The Link definition sets the uplink and downlink rates (UBR).
Fig. 3: Function - Wireless Subscriber Links

RDL-3000 FAMILY USER MANUAL
70-00158-01-08 Proprietary Redline Communications © 2011 Page 20 of 150 December 7, 2011
2.2.3Services and Service Groups
Overview
The RDL-3000 operates as a VLAN-aware wireless L2 switch, classifying and forwarding
traffic based on the packet VID. Ethernet ingress packets containing a VLAN (802.1Q)
field are first compared to the tagged-type Services or Service Groups defined for that
Ethernet port.
When a VID is matched to a classifier, the packet is processed according to the settings
for that Service or Service Group. Packets with a unicast address are forwarded based
on destination address. Packets with a multicast/broadcast address, and unicast
addresses with unknown destinations, are forwarded to all Service Group members.
A Service or Service Group set to 'Pass through' mode forwards (unmodified) packets
that are not matched to the classifier for any tagged Service or Service Group (e.g.,
unclassified VID or packet without 802.1Q tag). If no pass through classifier is defined,
non VLAN packets are discarded.
Table 5: Web - Operation - Traffic Classification
Type
Function
Settings
Service
Classify and forward ingress and
egress traffic at the subscriber Ethernet
port.
Tagging Mode (VLAN ID/Pass through)
VLAN ID (tag)
Default Priority
Service
Group
Classify and forward ingress and
egress traffic at the sector controller
Ethernet port.
Tagging Mode (VLAN ID/Pass through)
VLAN ID (tag)
Default Priority
Fig. 4: Function - Services and Service Groups
