REED R2100 User manual

reedinstruments
www com
Model R2100
Thermal Imager
Instruction
Manual
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
[e-mail] REED-Direct.com

reedinstruments
www com
2
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Table of Contents
Safety ............................................................................................ 3
Features ......................................................................................... 4
Specications .............................................................................4-5
Instrument Description ...............................................................6-7
Operating Instructions ..............................................................8-10
Main Menu ................................................................................... 11
Measurement Menu ...............................................................11-16
Image Menu ............................................................................16-22
Camera Menu .............................................................................. 23
Photo Browser ............................................................................. 24
Video Browser .............................................................................25
Settings Menu ........................................................................26-29
Factory Settings .......................................................................... 30
Battery Instructions ..................................................................... 31
For service on this or any other REED product or information on other
REED products, contact REED Instruments at [email protected]
[e-mail] REED-Direct.com

reedinstruments
www com
3
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Safety
• To prevent eye damage and personal injury, do not look into the laser
• Do not point laser directly at people or animals or indirectly off
reective surfaces
• Do not disassemble or do modications to the Thermal Imager
• Do not point the Thermal Imager (with or without the lens cover) at
intensive energy sources as this can damage the Thermal Imager
• Do not use the Thermal Imager in a temperature higher than 50°C
(122°F) or lower than -20°C (-4°F)
• Only use the correct equipment to charge the battery
• Do not disassemble or do a modication to the battery
• Do not put the battery in or near a re, or in direct sunlight, or other
high-temperature locations
• Always charge the battery between 0 to 50°C (32 to 122°F)
• Do not get water or salt water on the battery, or permit the battery to
get wet
• Clean the case with a damp cloth and a weak soap solution
• Do not use abrasives, isopropyl alcohol, or solvents to clean the case
or lens/screen
• Do not clean the infrared lens too vigorously, this can damage the
anti-reective coating
• Remove the battery from the Thermal Imager if not in use for an
extended period of time
• Store the Thermal Imager in cool and dry environment
[e-mail] REED-Direct.com

reedinstruments
www com
4
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Features
• 3.5" colour TFT LCD capacitive touch screen with sun visor
• High thermal sensitivity (NETD) of <80mK
• Built-in laser and white LED ashlight
• Built-in visible light digital camera
• Includes 7.5mm (29.8 x 22.6° FOV) lens
• 20X continuous zoom
• Infrared and visual images, picture-in-picture, as well as visual image
with infrared overlay
• Three spot, three area with min/max and average, two-line and
isothermal measurement analysis
• Automatic lens recognition identies the temperature calibration data
associated with each of the interchangeable lenses
• Automatic hot/cold spot indicator
• Choice of six colour palettes including custom
• Automatic image capture
• Save images with voice annotations
• Video recording with voice annotations
• Micro SD memory card extension possible
Specifications
IR Resolution: 160 x 120 pixels
Field of View: 29.8 x 22.6°
Detector Type: Uncooled microbolometer
Thermal Sensitivity (NETD): < 0.08°C @ 30°C (86°F)/80 mK
Image Capture Frequency: 50Hz
Focus: Manual
Temperature Range: -20 to 400°C (-4 to 752°F)
Accuracy: ±2°C (±3.6°F) or ±2% of reading
Storage Medium: 4GB micro SD card continued ...
[e-mail] REED-Direct.com

reedinstruments
www com
5
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Digital Camera Resolution: 640 x 480 pixels
Digital Lens Data: FOV 62.3°
Video Format: MPEG-4, 640x480 @ 30fps,
on memory card >60 minutes
Image Format: JPEG, on memory card >1000 pictures
Interface: USB-mini, audio, composite video
(PAL and NTSC), Micro SD slot
Drop Test: 2m
Encapsulation: IP65
Laser: < class 2
Operating Temperature: -20 to 50°C (-4 to 122°F)
Storage Temperature: -40 to 70°C (–40 to 158°F)
Operating/Storage Humidity: 10 to 90%RH
Power Supply: 7.4V lithium polymer rechargeable
battery
Battery Life: 4.5 hours
Dimensions: 243 x 103 x 160mm (9.57 x 4.05 x 6.29")
Weight: 920g (32.45oz) (including battery)
Includes: 7.5mm lens, lens cap, micro SD memory
card, video output cable, headset, USB
cable, hood, tripod stand, shoulder
strap, two batteries, charger, AC
adapter, software CD(Multiple language)
and hard carrying case
Optional Accessories: 20.6° 11mm Replacement Lens (RL-11)
10.4° 22mm Replacement Lens (RL-22)
6.9° 33mm Replacement Lens (RL-33)
Spare Battery (R2100-7.4V)
REED Instruments offers certied thermography training. Contact REED
Instruments at [e-mail] for complete information, dates
and locations.
[e-mail] REED-Direct.com

reedinstruments
www com
6
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Instrument Description
1. Infrared Camera Lens
2. Trigger
3. LCD Display
4. Button Panel
5. Battery Compartment
6. LED Light
7. Visual Camera
8. Laser Pointer
9. Infrared Camera Lens Lock
10. Infrared Camera Lens
11. Hood
12. Thermal Imager
13. Tripod Base
14. Lens Cap
continued ...
[e-mail] REED-Direct.com

reedinstruments
www com
7
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Button Panel Description
Display Description
15. Video Output
16. USB Cable Connection
17. Audio/Microphone
18. AC Adapter/
Charger Input Terminal
19. MicroSD Slot
[e-mail] REED-Direct.com

reedinstruments
www com
8
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Operating Instructions
Before you use the Thermal Imager for the rst time, charge the battery
for a minimum of 1.5 hours. To charge the battery, refer to the "Battery
Instructions" section of this manual.
To turn the Thermal Imager on or off,
press and hold the Power Button for three
seconds. You can also turn the Thermal
Imager off by pressing the Power Button,
and sliding the arrow icon to the right.
Focus
Correct focus is important in all imaging applications. Without the correct
focus, the image can be blurry and the radiometric data will be inaccurate.
Out-of-focus infrared images are frequently unusable or of little value. This
Thermal Imager has focus-free in manual mode. To adjust the focus rotate
the IR lens.
Shutter
A shutter is pivoted into the ray path in order to make a temperature
reference available for image correction. The self calibration shutter in this
Thermal Imager can be set to Manual or Auto. To manually activate the
shutter, press the Shutter Button. To activate or adjust the shutter Auto
Mode please refer to the Settings Menu section of this manual.
Optical Lens
Rotate the Lens Lock counter-clockwise to remove the optical lens.
The optical lens that is supplied with the Thermal imager has the
following specications:
Focal Length: 7.5mm Horizontal FOV: 29.8°
IFOV: 3.33mrad Vertical FOV: 22.6°
[e-mail] REED-Direct.com

reedinstruments
www com
9
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Emissivity
This Thermal Imager measures infrared energy from the surface of the
object and uses this data to calculate an estimated temperature value.
Surfaces that are good at radiating energy (high emissivity), the
emissivity factor is ≥0.90. Shiny surfaces or unpainted metals are not
good at radiating energy (low emissivity) have an emissivity of <0.6.
To more accurately measure materials with a low emissivity, an emissivity
correction is necessary. Emissivity is set directly as a value or from a list
of emissivity values for some common materials. The global emissivity
displays on the LCD Screen as "E=x.xx".
The following table gives typical emissivity of some materials:
Material Emissivity
Asphalt 0.95
Concrete 0.95
Hard plaster 0.90
Wood (natural) 0.93
Lime Stone 0.98
Ballast chipping 0.95
Paper (every color) 0.95
Plastics non lm 0.95
Tissue (fabric) 0.95
Sand 0.90
Glass wool 0.90
Melted asphalt 0.93
Screed/pavement 0.93
Foamed polystyrene 0.94
Material Emissivity
Drywall 0.95
Render 0.94
Smoothing cement 0.90
Lacquer 0.92
Latex paint 0.97
Wallpaper 0.93
Tilling 0.93
Parquet oor 0.90
Laminate 0.90
PVC-Floor 0.92
Brick 0.93
Cliff 0.97
Roong cardboard 0.93
Stucco 0.91
[e-mail] REED-Direct.com

reedinstruments
www com
10
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Reflected Temperature
Using the offset factor, the reection is calculated out due to the low
emissivity and the accuracy of the temperature measurement is improved.
In most cases, the reected temperature is identical to the ambient air
temperature. Only when objects with strong emissions of a higher
temperature are in the proximity of the object being measured should
be determined and used. The reected temperature has only little effect
on objects with high emissivity. The reected temperature can be set
individually.
Follow these steps to get the right value for the reected temperature:
1. Set the emissivity to "1.0"
2. Adjust the optical lens to near focus
3. Looking in the opposite direction away from the object, take a
measurement and save the image
4. Determine the average value of the image and use that value for
your input of reected temperature
Thermal Imager Reporter Software
Reporter Software is supplied with this Thermal Imager. This software
contains features to analyze images, organize data and information, and
make professional reports. The Thermal Imager Reporter Software allows
audio annotations and commentary to be reviewed on a PC.
[e-mail] REED-Direct.com

reedinstruments
www com
11
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Main Menu
Press the Home Button, or tap the screen to enter the Main Menu.
The following menus are available:
Measure: Set the calculation and display of radiometric
temperature measurement data related to the
thermal images
Image: Adjust the display on the LCD
Camera: Contains the snapshot, video, text and audio
annotation functions
Photo: Review, delete, zoom, and rotate images saved
on the SD Memory Card
Play: Review, delete, and play video les saved on the SD
Memory Card
Settings: Set user preferences such as language, unit of
temperature measurement, unit of distance, date,
time, and more
Measurement Menu
In the Main Menu, press the icon
to access the Measurement Menu.
The Measurement Menu contains
Point Measurement, Line Measurement,
Area Measurement, and Measurement
Settings.
[e-mail] REED-Direct.com

reedinstruments
www com
12
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Point Measurement
In the Measurement Menu, press the icon to access the Point
Measurement Menu. There are 3 points to measure, and each point has
three modes: manual mode, maximum temperature capture, and minimum
temperature capture. Each point can use global parameter settings or
custom parameters to set the measuring parameters.
Press on Spot 1, 2, or 3 to activate the
corresponding point of the temperature
measurement. Press the icon to
enter the Point Submenu. Press on
"Manual" to select the point manually.
The current point’s icon will turn to .
Press on "Max" to select maximum
temperature capture mode. The current
point’s icon will turn to . Press on
"Min" to select minimum temperature
capture mode. The current point’s
icon will turn to .
While in the Point Submenu, press the
icon to set the point parameters.
Press on "use global para" to check or
un-check the use of global parameters
for measuring. When global parameters
is selected, "Emiss", "Distain", and
"Offset" are disabled. Click on the left
or right arrows to adjust the parameters.
Emiss: Object emissivity, value range is 0.01 to 1.00
Distain: Object distance, the value range is 0 to 5000
Offset: Object offset, the value range is -100 to 100°C
[e-mail] REED-Direct.com

reedinstruments
www com
13
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Line Measurement
In the Measurement Menu, press the
icon to access the Line Measurement
Menu. There are 2 lines to measure.
Each line can use global parameter
settings or custom parameters to set
the measuring parameters. Press
"Hor Line" and "Ver Line" to check
and un-check them.
Press the icon to set the amount
of rows and columns. "Row" sets the
amount of rows, with a range of 1 to 240.
"Column" sets the amount of columns,
with a range of 1 to 320.
Press the icon while in the Line
Measurement Menu to set the Line
Parameters. Press "use global para"
to check or un-check global parameters
for measuring. When global parameters
is selected, "Emiss", "Distain", and
"Offset" are disabled. Click on the left
or right arrows to adjust the parameters.
Emiss: Object emissivity, value range is 0.01 to 1.00
Distain: Object distance, the value range is 0 to 5000m
Offset: Object offset, the value range is -100 to 100°C
[e-mail] REED-Direct.com

reedinstruments
www com
14
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Area Measurement
In the Measurement Menu, press the
icon to enter the Area Measurement
Menu. There are 3 areas to measure and
each area has the measurement of
maximum temperature, minimum
temperature and average temperature.
Each area can also use global parameter
settings or custom parameters to set the
measuring parameters.
Press on Area 1, 2, or 3 to activate the
temperature measurement of the
corresponding area. Press the icon
to set the area mode. Press on "Max"
to select maximum temperature capture
mode. The icon shows the maximum
temperature of the area. Press on "Min"
to select minimum temperature capture
mode. The icon shows the minimum
temperature of the area. Press "Averg" to
display average temperature of the area.
Press the icon while in the Area
Measurement Menu to adjust the Area
Parameters. Press "use global para"
to check or un-check global parameters
for measuring. When global parameters
is selected, "Emiss", "Distain", and
"Offset" are disabled. Click on the left
or right arrows to adjust the parameters
Emiss: Object emissivity, value range is 0.01 to 1.00
Distain: Object distance, the value range is 0 to 5000m
Offset: Object offset, the value range is -100 to 100°C
[e-mail] REED-Direct.com

reedinstruments
www com
15
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Measurement Settings
In the Measurement Menu, press the
icon to enter the Measurement Settings
Menu. This menu contains Global
Parameters Setting, Measure Parameters
Setting and Alarm Settings.
Global Parameters Setting
Press "Global Para" to adjust the global
parameters settings. Press "Reset Para"
to reset all measurement parameters to
the factory deates. Press "Yes" to reset
global parameters, press "No" to cancel.
Factory default parameters are:
Emissivity: 0.95
Distance: 5m
Ambient temperature: 25°C
Humidity: 60%
Reflection temperature: 25°C
Offset: 0.0°C
Measurement Settings
In the Measurement Settings Menu,
press on "Measure Setting" to display
the current infrared optical lens, and also
adjust the temperature measurement
range, ambient temperature, humidity,
and reection temperature. The standard
lens is 7.5mm. The temperature
measurement ranges are "-20 to 150°C"
and "0 to 400°C". The overlap temperature
of the two ranges is more accurate to choose "-20 to 150°C".
continued ...
[e-mail] REED-Direct.com

reedinstruments
www com
16
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
The ambient temperature, humidity and reection temperature are
important for radiometric temperature measurement. This Thermal Imager
has temperature compensation for these values. To get more accurate
temperature measurement you need to accurately set the ambient
temperature, humidity, and reection temperature. In most cases, the
reected temperature is identical to the ambient temperature. Only when
objects with strong emissions with much higher temperature are in the
proximity of the object being measured, the reected temperature is
different of the ambient temperature and must set the temperature of
environment. Press the left or right arrows to adjust the measurement
settings.
Alarm
In the Measurement Settings Menu, press
on "Alarm" to check the Alarm on or off.
Press the icon to adjust the Alarm
settings. There are 3 kinds of alarm modes:
Above, where the alarm will sound if
temperature goes above a set point; Below,
where the alarm will sound if temperature
goes below a set point; and Equal, where
the alarm will sound if temperature equals
a set point. Press the left and right arrows
to adjust the following parameters:
Target: Sets the target of temperature alarm, there are 3 kinds
of choices: Spot 1, Spot 2, and Spot 3
Mode: Sets the alarm mode to "Above", "Below", or "Equal"
Temp: Sets alarm temperature value
Image Menu
In the Main Menu, press the icon to access the Image Menu. The
Image Menu contains Image Mode, Image Palette, Image Adjust, and
Image Setting.
[e-mail] REED-Direct.com

reedinstruments
www com
17
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Image Mode
In Image Menu, press the icon to enter the Image Mode Menu. Press
the left and right arrows to change the image mode. This Thermal Imager
has 6 kinds of image modes for display.
IR: Displays only infrared image
Visible: Displays only visible image
IR_PIPE_VIS: IR display with small visible picture
VIS_PIPE_IR: Visible display with small IR picture
IR_Mix_VIS: IR display with visible picture overlay
VIS_Mix_IR: Visible display with IR picture overlay
In IR_PIPE_VIS and VIS_PIPE_IR
mode, there are four options for
image pipe position: top left (TL),
bottom left (BL), bottom right (BR),
and top right (TR). In "Position: XX",
press the left and right arrows to
change picture-in-picture position.
In IR_Mix_VIS and VIS_Mix_IR mode,
in "Size: XX", press the left and right
arrows to change image mix size.
There are two options: Half or Full.
In "Blend: XX%", press left arrow or
right arrows to change image mix
percentage. The range is 0 to 100%.
[e-mail] REED-Direct.com

reedinstruments
www com
18
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Image Palette
In the Image Menu, press the icon
to enter the Image Palette Menu.
The Image Palette lets you change
the false-colour presentation of the
infrared images on display or
captured. A variety of palettes are
available for specic applications.
This Thermal Imager has standard
and custom palettes. The standard
palettes offer an equal, linear presentation of colors that allow for best
presentation of detail. The custom palettes allow user to customize
personal palettes. The * icon represents the current image palette in the
corresponding group.
Standard Palette
Press the Standard icon to access the
Standard Palette Menu. It shows eight
kinds of palettes: IRON, Rainbow,
Grey, GreyInverted, Sepia, Blue_Red,
Hot_Cold, and Humidity. Press "OK"
to select a palette, and "Cancel"
to keep the present palette.
Custom Palette
Press the Custom icon to access the
Custom Palette Menu. Ten Custom
Palettes can be saved at a time. Press
"OK" to select a palette, and "Cancel"
to keep the present palette. To add,
remove and rename custom palettes
press and hold the Custom Palette
Menu.
continued ...
[e-mail] REED-Direct.com

reedinstruments
www com
19
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Press the icon to adjust a Custom
Palette. The colour bar to the right displays
the current palette. Every colour value is
based on liner gradient. "0.0" is the
minimum value, "50.0" is the maximum
value. There are 3 scales which the value
is based on: position, minimum value and
maximum value. Press and move
the scale to change the position.
Press "0.0" or "50.0" to adjust the
minimum or maximum parameter settings.
Click the colour bar to choose a colour,
"Current Colour" shows the selected
colour. "Red", "Green", and "Blue" shows
the RGB value of selected colour. Press
the left or right arrows to change the value.
Press "OK" to save and "Cancel" button to
cancel parameter settings.
Press a scale to change the parameter
settings. Press "Enable" to switch on
(checked) or off (unchecked). Click the
colour bar to choose a colour.
"Current Colour" shows the selected
colour. "Red", "Green", and "Blue" shows
the RGB value of the selected colour.
Press the left or right arrows to change the
corresponding value. Press "OK" to save
the parameter settings and "Cancel" to
cancel parameter settings.
If "Enable" is checked the linear gradient
in this scale is switched on. The icon
will appear on the top of scale. If "Enable"
is unchecked, linear gradient in this scale
is disabled and the icon will disappear.
[e-mail] REED-Direct.com

reedinstruments
www com
20
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
Image Adjustment
In the Image Menu, press the icon to access the Image Adjustment
Menu. There are 3 kinds of modes for thermal image adjustment:
All Auto: Level and span are set by the thermal image of
minimum and maximum temperature
Histogram: Level and span are set by the histogram of
thermal image temperature
Manual: Level and span are set by values set by the user
Press the left and right arrows to
change the image adjustment.
In Manual mode, press "Adjust"
to adjust the level and span.
Press left or right arrows to change
value. Press "Level" to jump to
"Span" and vice-versa.
[e-mail] REED-Direct.com
