The Rened Feline Rened Lier Box Assembly Instrucons 2
WHAT’S IN THE BOX?
Hardware
Parts
H
B
E
J
A
G
F
C
N
O
M
K
L
D
I
Screwdriver
1
Wood
Dowel
Ø8x30mm
12 pieces
2
Machine
Screw
M6x30mm
4 pieces
3
Cam Lock
Ø15x12mm
8 pieces
4
Cam
Screw
M6x40mm
8 pieces
5
Wood
Screw
3.5x12mm
8 pieces
67
Door Knob
2 pieces
Machine
Screw
M4x28mm
2 pieces
8
Wood
Screw
M4*35mm
8 pieces
9
Feet
Leveler
M6*15mm
4 pieces
10
Wood
Screw
M7*15mm
10 pieces
11
Foam
Pad
Ø22*2mm
2 pieces
12

The Rened Feline Rened Lier Box Assembly Instrucons 3
1
2
4 pieces
4 pieces
3
10
A
10
Note: If oponal feet purchased,
disregard levelers and install feet.
Install feet levelers (#10).
Adjust levelers so base is stable on oor.
3
3
Entryway can face either le or
right by switching placement of
parts E & F.
Install part H on le wall and part
G on right wall with screws (#3).
Wheel on H and G
should face hinges
E
H
G
F

The Rened Feline Rened Lier Box Assembly Instrucons 4
3
4
4 pieces
6 pieces 5
2
52
E
F
A
A
F
Install cam screws (#5) and dowels (#2) into part A.
Place parts E & F over cam screws and dowels.
With arrow facing downward,
insert cam locks (#4) into boom
of parts E & F then turn to lock.
Note: Do not force! If cam lock
does not turn, remove wall, turn
cam screw counter clockwise so
screw is higher.
See assembly video for addional
assistance.
5
2
1
4
F
4 pieces
4
Note: Groove on back of part A should face rear,
away from hinges on parts E & F.

The Rened Feline Rened Lier Box Assembly Instrucons 5
5
6
2
5
4 pieces
6 pieces
5
2
4
1
4 pieces
4
Install cam screws (#5) and dowels
(#2) into part I.
Place part I on top of walls E & F.
Note: Groove on back of part I
should face rear, away from hinges.
With arrow facing upward, insert
cam locks (#4) into top of parts E &
F then turn to lock.
Note: Do not force! If cam lock does not turn, remove wall, turn cam screw counter
clockwise so screw is higher. See assembly video for addional assistance.
I

The Rened Feline Rened Lier Box Assembly Instrucons 6
7
8
Carefully lay on its side. Place part D into
grooves and secure with screws (#11)
Aach doors B & C using screws (#6). Notch
on back indicates boom of the door.
Insert all screws rst before ghng.
A slight bend in part D is normal.
Note: Doors unaligned? See page 11 for ps.
11
10 pieces
11
8 piece
6
Repeat on other side
B
C
D
Note: Carbon odor lters available at
TheRenedFeline.com

The Rened Feline Rened Lier Box Assembly Instrucons 7
9
2 pieces
2 pieces
2 pieces
12
7
8
Aach foam pad (#12) to
top corner of each door
Install door knob (#7) with
screw (#8) to each door
Repeat step for door B
Note: Standard panels can be removed and
replaced with alternave panel designs.
Visit TheRenedFeline.com to view
panel design opons.
12
8
7

The Rened Feline Rened Lier Box Assembly Instrucons 8
10
11
2 pieces
9
Note: Make sure grooves line up and wheel on
rail faces away from part K.
Note: Make sure grooves line up and wheel on
rail faces away from part K.
Aach part L to part K with screws (#9).
Aach part M to part K with screws (#9).
M
K
9
2 pieces
99
L
K
M

The Rened Feline Rened Lier Box Assembly Instrucons 9
12
13
O
N
4 pieces
9
9
Slide part O into grooves
Aach part N using screws (#9)

The Rened Feline Rened Lier Box Assembly Instrucons 10
14
Slide drawer over wheels on rails
inside lier box.
Assembly Complete. Enjoy!
Fold tabs of short side of lier liner inward, then aach to velcro strip of
long side. Repeat for each corner, then slide inside cabinet.
J
15
Note: Lier liner not
meant to replace lier pan

The Rened Feline Rened Lier Box Assembly Instrucons 11
Door Alignment Tips
1) Make sure lier box is level.
Turn levelers on boom to adjust.
2) If doors fails to close ush, turn screw
on rear of hinge to loosen. Adjust doors and
reghten screw.
3) If doors are askew, turn middle screw on
each hinge as needed unl doors align.
Your Rened Lier Box can be customized to your the style of
your home’s decor. Choose from various panel and feet opons.
Visit TheRenedFeline.com to review these opons and more.
Customize your Rened Lier Box
Coage Style with Tapered Feet Shaker Style with Square Feet Farmhouse Style with
Mid-Century Modern Feet
See assembly video for addional assistance.
