Reform Steel Drawer User manual

PRODUCT MANUAL
STEEL DRAWER
EUBDDBX99DOC001

PAGE 1  17PRODUCT MANUAL: STEEL DRAWER
Important information.
Read carefully. Follow each step of the instruction carefully.
Keep this information for further reference.
WARNING
Serious or fatal crushing injuries can occur from furniture tip-over.
To prevent this furniture from tipping over it must be permanently
fixed to the wall with the included wall attachment devices.
Fastening devices for the wall are not included since dierent wall materials
require dierent types of fastening devices. Use fastening devices suitable
for the walls in your home. For advice on suitable fastening devices, contact
your local specialized dealer.
Safety recommendation:
- Place heaviest items in the lowest drawers.
- Prevent children from climbing or hanging on the drawers, doors or shelves.
Vigtige oplysninger Læs omhyggeligt Følg de enkelte trin i anvisningerne
omhyggeligt Gem disse oplysninger til senere brug.
ADVARSEL!
Der kan opstå alvorlig eller livsfarlig tilskadekomst, hvis møblet vælter.
For at undgå, at møblet vælter, skal det fastgøres permanent til væggen
med de medfølgende vægbeslag.
Forskellige vægmaterialer kræver forskellige skruer og rawplugs. Medfølger
ikke. Brug skruer og rawlplugs, der passer til væggene i dit hjem. Hvis du
er i tvivl om, hvilken type skruer/rawlplugs du skal bruge, skal du kontakte
et byggemarked.
Wichtige information.
Sorgfältig lesen. Jeden Schritt der Anleitung sorgfältig befolgen.
Diese Information aufbewahren.
ACHTUNG
Wenn Möbelstücke umkippen, können ernste oder lebensgefährliche
Verletzungen durch Einklemmen die Folge sein. Um zu verhindern, dass
dieses Möbelstück umkippt, muss es mit der beigepackten Vorrichtung
zur Wandbefestigung fest an der Wand verankert werden.
Beschläge für die Wandbefestigung sind nicht beigepackt, da sie von der
Beschaenheit der Wand und des Untergrundmaterials abhängig sind.
Befestigungsbeschläge benutzen, die für die heimischen Wände geeignet
sind. Bei diesbezüglichen Fragen den.
Information importante.
Lire attentivement. Suivre soigneusement chacune des étapes de ces instru-
ctions. Conserver ces instructions pour une utilisation ultérieure.
ATTENTION
Risque de blessure grave ou mortelle en cas de basculement du meuble.
Pour éviter que le meuble ne bascule, il faut le fixer au mur de façon per-
manente à l’aide des pièces pour fixation incluses.
Les vis ne sont pas incluses car leur choix dépend du matériau du mur
sur lequel est fixé le meuble. Utilisez des vis adaptées au matériau du mur.
Pour obtenir des conseils sur les vis à utiliser, adressez-vous à un vendeur
spécialisé.
English
Dansk
Deutsch
Français
!
LAST UPDATE MADE IN JUNE 2020

PAGE 2  17PRODUCT MANUAL: STEEL DRAWER
3 INTRODUCTION
5 DRAWER SLIDES
9TIPON  BLUMOTION
10 INSTALLATION OF DRAWER BOX
17 INSTALLATION OF INNER DRAWER BOX
18 FINAL ADJUSTMENTS
INDEX

PAGE 3  17PRODUCT MANUAL: STEEL DRAWER
INTRODUCTION In the following pages, you’ll find easy-to-follow instructions with images
that show you how to assemble your Reform steel drawers. The box is the
same for the regular drawer box and the inner drawer box. The dierence
lies in the mounting of the fronts. The guide is divided into four sections:
Our equipment for steel drawers comes in 2-3 boxes:
1) Drawer box (3 sizes: low, medium, high)
2) Drawer slides (3 lengths: 300 mm, 400 mm, 500 mm)
3) (ADD-ON) push-system/TIP-ON BLUMOTION technology
4) (OPTIONAL*) interior front for inner drawer box
*This only applies to the inner drawer
If you’d like more in-depth information on your steel drawers, we recommend
visiting the Legrabox drawer manufacturer, Blum: https://www.blum.com/eu/
en/products/boxsystems/legrabox/overview/
EQUIPMENT
TOOLS YOU MIGHT NEED
DRAWER
HIGH = C  MEDIUM = M  LOW = N
INTERIOR FRONT FOR
INNER DRAWER BOX
DRAWER SLIDES
LENGTH 300 MM  400 MM  500 MM
PUSH FUNCTION
TIPON BLUMOTION
SCREWDRIVER PH SCREWDRIVER TORX T20

PAGE 4  17PRODUCT MANUAL: STEEL DRAWER
COUNTING ROWS
17
15
13
11
9
7
5
4
3
2
1
This illustration shows how to count rows on the inside of the side of the cabinet.

PAGE 5  17PRODUCT MANUAL: STEEL DRAWER
Below, you’ll find the five most common combinations.
15
14
10
6
2
16
14
10
7
10
2
7
13
10
2
DRAWER SLIDES PLACEMENT 1.
DRAWER SLIDES PLACEMENT 3.
DRAWER SLIDES PLACEMENT 2.
DRAWER SLIDES PLACEMENT 4.
DRAWER SLIDES PLACEMENT 5.
DRAWER SLIDES PLACEMENTS 1
2

PAGE 6  17PRODUCT MANUAL: STEEL DRAWER
Below, you’ll find the five most common combinations.
14
12
9
4
DRAWER SLIDES PLACEMENTS 2
14
14 14
10
4
10 9
4 4
11
4
DRAWER SLIDES PLACEMENT 1.
DRAWER SLIDES PLACEMENT 3.
DRAWER SLIDES PLACEMENT 2.
DRAWER SLIDES PLACEMENT 4.
DRAWER SLIDES PLACEMENT 5.

PAGE 7  17PRODUCT MANUAL: STEEL DRAWER
Make sure that you use the right drawer slide hole when you mount the
slide on the cabinet. Note that drawer slides for inner drawers are mounted
dierently.
FOR THE CABINET WITH A DEPTH OF 60 CM
MOUNTING DRAWER SLIDES
Drawer box with
front attachment
Inner drawer box without
front attachment
16
13
10
7
2
PLEASE NOTE THAT YOU HAVE TWO KINDS OF SCREWS.
EACH SCREW IS COMPATIBLE WITH A PARTICULAR HOLE.

PAGE 8  17PRODUCT MANUAL: STEEL DRAWER
Make sure that you use the right drawer slide hole when you mount the
slide on the cabinet. Note that drawer slides for inner drawers are mounted
dierently.
FOR THE CABINET WITH A DEPTH OF 37 CM
MOUNTING DRAWER SLIDES
PLEASE NOTE THAT YOU HAVE TWO KINDS OF SCREWS.
EACH SCREW IS COMPATIBLE WITH A PARTICULAR HOLE.
Inner drawer box without
front attachment
Drawer box with
front attachment
14
10
6
2

PAGE 9  17PRODUCT MANUAL: STEEL DRAWER
If you’ve acquired push-function for your drawers, follow the instructions
outlined below.
If you’d like more in-depth information on TIP-ON BLUMOTION technology,
we recommend visiting the Legrabox drawer manufacturer, Blum:
https://www.blum.com/su/en/products/motion-technologies/tip-on-blumotion/
legrabox/assembly/
TIPON  BLUMOTION
STEP 1  LATCH STEP 2  UNIT
STEP 3  SYNCHRONIZATION ROD
Viewed from below
Click
1
2
1
2

PAGE 10  17PRODUCT MANUAL: STEEL DRAWER
In the following pages, you’ll find instructions for mounting these
combinations:
1) Low drawer box + 10 cm / 15 cm / 20 cm front
2) Medium drawer box + 20 cm / 40 cm front
3) High drawer box + 40 cm / 60 cm front
Please note that the fronts should be mounted according to the specific dra-
wer location in the cabinet.
Please note that some fronts don’t go with all drawers. We’ve made a table
that shows you the dierent combinations.
INSTALLATION OF DRAWER BOX
HIGH
Low Page 11 Page 12 Page 12
Page 13 Page 14
Page 15 Page 15
– –
––
–– –
–Medium
High
10 cm 15 cm 20 cm 40 cm 60 / 80 cm
Front
size
Drawer
box
LOW MEDIUM
OVERVIEW

PAGE 11  17PRODUCT MANUAL: STEEL DRAWER
Please note that the fronts should be mounted according to the specific dra-
wer location in the cabinet. This is to ensure that the fronts will fit perfectly.
If you’d like more in-depth information on fronts mounting, we recommend
visiting the Legrabox drawer manufacturer Blum: https://www.blum.com/fi/en/
products/boxsystems/legrabox/assembly/
For mounting of inner drawers, see page 16.
MOUNTING DRAWER FRONTS
GENERAL INTRODUCTION
STEP 1
START BY FASTENING THE BRACKET TO THE FRONT USING YOUR SCREWS.
SEE WHAT HOLES TO USE ON THE FOLLOWING PAGES.
STEP 2
THEN CLICK THE FRONT ONTO THE DRAWER.
HOLES AND DOTS
Click

PAGE 12  17PRODUCT MANUAL: STEEL DRAWER
MOUNTING DRAWER FRONTS
LOW DRAWER + 10 CM FRONT
DRAWER FRONT POSITIONED IN THE TOP: 1ST HOLE AND 2ND DOT FROM THE BOTTOM.
DRAWER FRONT POSITIONED IN THE MIDDLE: 1ST DOT AND 2ND HOLE FROM THE BOTTOM.
Low x x x – –
10 cm 15 cm 20 cm 40 cm 60 / 80 cm
Front
size
Drawer
box
Bottom drawer not available
The drawers can be positioned
in the darker area
Bottom drawer not available
The drawer can be positioned
in the darker area

PAGE 13  17PRODUCT MANUAL: STEEL DRAWER
MOUNTING DRAWER FRONTS
LOW DRAWER + 15 CM FRONT
The drawer can be positioned
in the darker area
The drawer can be positioned
in the darker area
The drawer can be positioned
in the darker area
The drawers can be positioned
in the darker area
DRAWER FRONT POSITIONED IN THE MIDDLE AND TOP:
1ST AND 4TH HOLE COUNTING FROM THE BOTTOM.
DRAWER FRONT POSITIONED IN THE BOTTOM:
3RD AND 5TH HOLE COUNTING FROM THE BOTTOM.
DRAWER FRONT POSITIONED IN THE BOTTOM:
1ST DOT AND 2ND HOLE COUNTING FROM THE BOTTOM.
DRAWER FRONT POSITIONED IN THE MIDDLE:
1ST HOLE AND 2ND DOT COUNTING FROM THE BOTTOM.
MOUNTING DRAWER FRONTS
LOW DRAWER + 20 CM FRONT

PAGE 14  17PRODUCT MANUAL: STEEL DRAWER
MOUNTING DRAWER FRONTS
MEDIUM DRAWER + 20 CM FRONT
DRAWER FRONT POSITIONED IN THE MIDDLE AND TOP: 2ND AND 6TH HOLE COUNTING FROM THE BOTTOM.
DRAWER FRONT POSITIONED IN THE BOTTOM: 4TH AND 7TH HOLE COUNTING FROM THE BOTTOM.
Medium – – x x –
10 cm 15 cm 20 cm 40 cm 60 / 80 cm
Front
size
Drawer
box
The drawer can be positioned
in the darker area
The drawers can be positioned
in the darker area

PAGE 15  17PRODUCT MANUAL: STEEL DRAWER
MOUNTING DRAWER FRONTS
MEDIUM DRAWER + 40 CM FRONT
DRAWER FRONT POSITIONED IN THE TOP: 1ST AND 3RD HOLE COUNTING FROM THE BOTTOM.
DRAWER FRONT POSITIONED IN THE BOTTOM: 2ND AND 4TH HOLE COUNTING FROM THE BOTTOM.
The drawer can be positioned
in the darker area
The drawer can be positioned
in the darker area

PAGE 16  17PRODUCT MANUAL: STEEL DRAWER
High – – – x x
10 cm 15 cm 20 cm 40 cm 60 / 80 cm
Front
size
Drawer
box
MOUNTING DRAWER FRONTS
HIGH DRAWER + 40 CM FRONT
MOUNTING DRAWER FRONTS
HIGH DRAWER + 60  80 CM FRONT
DRAWER FRONT POSITIONED IN THE TOP:
1ST, 3RD, 5TH, 7TH HOLE COUNTING FROM THE BOTTOM.
DRAWER FRONT POSITIONED IN THE BOTTOM:
2ND, 4TH, 6TH, 8TH HOLE COUNTING FROM THE BOTTOM.
The drawer can be positioned
in the darker area The drawer can be positioned
in the darker area
DRAWER FRONT POSITIONED IN THE BOTTOM: 2ND, 4TH, 6TH, 8TH HOLE COUNTING FROM THE BOTTOM.
The drawer can be positioned
in the darker area

PAGE 17  17PRODUCT MANUAL: STEEL DRAWER
LOW
HIGH
MEDIUM
INSTALLATION OF INNER
DRAWER BOX
Inner drawer fronts come in one size.
MOUNTING OF INNER
DRAWER FRONTS
NOTE THAT THE BRACKETS ARE ALREADY MOUNTED TO THE FRONT BEFORE YOU MOUNT THE INNER DRAWER FRONTS.
YOU JUST NEED TO CLICK THE PARTS TOGETHER.
Click
OVERVIEW

PAGE 18  17PRODUCT MANUAL: STEEL DRAWER
FINAL ADJUSTMENTS
MOUNTING  UNMOUNTING
If you’d like more in-depth information on adjustments, we recommend
visiting the Legrabox drawer manufacturer, Blum: https://www.blum.com/fi/
en/products/boxsystems/legrabox/assembly/
IT’S TIME TO MOUNT YOUR DRAWER ONTO THE RUNNER. FOLLOW THE INSTRUCTIONS ABOVE.
IN CASE YOU NEED TO UNMOUNT THE DRAWER:
WITH THE DRAWER FULLY EXTENDED, REACH UNDER THE DRAWER AND SQUEEZE THE RELEASE LEVELERS FOR THE LOCKING DEVICES. THEN PULL THE DRAWER OUT.
Press

PAGE 19  17PRODUCT MANUAL: STEEL DRAWER
FINAL ADJUSTMENTS
DRAWER ADJUSTMENT 
TIPON BLUMOTION
In case you need to make adjustments to your drawer position, follow the
instructions below.
If you’d like more in-depth information on adjustments, we recommend
visiting the Legrabox drawer manufacturer Blum: https://www.blum.com/fi/en/
products/boxsystems/legrabox/assembly/
MAKING ADJUSTMENTS WITH TIPON  BLUMOTION:
TIPON  BLUMOTION ADJUSTMENT FROM THE UNIT  DEPTH ADJUSTMENT TOWARDS THE FRONT: +2, 1 MM.
MAKING ADJUSTMENTS INSIDE THE DRAWER.
Drawer front release, height adjustment,
side-to-side adjustment – counting from the top
R
L
Tilt the front, so that it’s vertically aligned
Tilt
