INSTALLATION INSTRUCTIONS
ALL CONNECTIONS TO BE CARRIED OUT BY A QUALIFIED ELECTRICIAN
ALL CONNECTIONS TO BE CARRIED OUT BY A QUALIFIED ELECTRICIAN
1
2
PLEASE READ CAREFULLY BEFORE STARTING INSTALLATION.
PLEASE READ CAREFULLY BEFORE STARTING INSTALLATION.
Regent Lighting reserves the right to change specifications modify designs and discontinue items without
incurring obligation and whilst every effort is made to ensure that descriptions, specifications and other
information in this catalogue are correct, no warranty is given in respect thereof and the company shall not be
liable for any error therein.
WARNING: TO AVOID FIRE, SHOCK OR DEATH
TURN OFF POWER AT CIRCUIT BREAKER OR FUSE AND TEST THAT THE POWER IS OFF BEFORE WIRING
ALL LUMINAIRES SUPPLIED AND TO BE INSTALLED ABOVE AND BELOW 5 METERS ARE IN COMPLIANCE WITH SANS
60598 SECTION 3.5.6 ACCORDING TO THE MANUFACTURER GUARANTEE AND WARRANTY
Electrical products can cause death, injury, or damage to
property. Installation of this product must be carried out by a
qualified electrician, in compliance with SANS 10142 or
corresponding regulations of the country of installation. On
completion of installation, the Certificate of Compliance must
be updated.
32W Large Inground Mite
WARNING
Remote Electronic Control Device
Electronic Control Device
WARNING
3 - 13 MAIN REEF SERVICE ROAD, CORNER
SPRINGBOK AND MAIN REEF ROAD, INDUSTRIA,
JOHANNESBURG. SOUTH AFRICA.
TEL : [phone]
www.regentlight.co.za
RE GENT L I GHT ING A D IVIS ION
OF WA HL IND USTR IES.
Save These Instructions for Future Reference
DO NOT CONNECT THE LUMINAIRE LIVE
ELECTRIC SHOCK
HAZARD
This equipment is to be
serviced by trained
personnel only.
ELECTRIC SHOCK
HAZARD
This equipment is to be
serviced by trained
personnel only.
Requirements:
Be sure the electricity to the
system you are working on is
isolated.
Receive the complete fitting with
an electrical cable tail supplied.
Select the required position for the
luminaire.
32W Large Inground Mite
Create a cavity for fitting in the
ground/paving at the required
position.
*NB: GRAVEL FOR DRAINAGE - Lay
at least 150mm of gravel beneath
the well of the cavity and check
drainage efficiency.
Ensure there is a drain under the
gravel when installing the fitting
into paving or cement.
Drain/Gravel
DRAIN UNDER GRAVEL
GROUND
PAVING/
CEMENT
Drain/Gravel
Save These Instructions for Future Reference
June 2017

www.regentlight.co.za
www.regentlight.co.za
3
This product should be installed by a competent person i.e. Qualified electrician.
This product requires a constant stable electrical supply 220V - 240V VAC 50Hz - alternating current.
The product must be regularly maintained, including the replacement of lamps/LED timeously.
This product could be HAZARDOUS if not used correctly, it could cause electric shock, serious bodily harm or death.
This product is not a toy, please keep away from children.
This product may contain small parts that can be swallowed.
Use only the correct light bulbs/LED as stipulated on the carton for the product.
Any modifications of this product after supply will result in the guarantee being void.
Spare parts may become unavailable over time.Items can vary slightly from the picture on the carton
Coastal humidity can affect the longevity of the light fitting over time.
Be sure to follow the steps in the order given.
Read instructions carefully.
Important Safety Instructions
A: Loosen and remove the CSK
stainless steel screws from the
complete fitting.
B: Remove the inner fitting from the
outer casing.
4
A: Feed the electrical
cable from the inner fitting
through to the external cable
joint kit. Seal the gland
by fastening the gland
to the casing.
B: Place the outer casing
into the cavity. Adjust the
height to finished floor level.
When installing in cement or paving,
ensure there is a drain pipe under the
cavity, under the gravel.
DRAIN UNDER GRAVEL
A
A
B
B
5
GROUND
PAVING/
CEMENT
Insert the fitting into the outer casing.
Connect the electrical tail supplied
from the fitting to the cable joint kit.
Following the resin instructions on the
cable joint kit.
Connect the Switched Live (S/A),
Neutral (N) and Earth (E) cable(s) to
the terminal block.
SWITCHED LIVE – (Red or Brown) to
terminal marked L
NEUTRAL – (Black or Blue) to terminal
marked N
EARTH – (Green/Yellow) to terminal
marked E.
TOP VIEW OF ELECTRICAL INSTALLATION
Switch
Wire Red
Neutral loop
Black or Blue
Earth loop
Green/Yellow
Mains to
Luminaire
(L) Brown
(N) Blue
(E) Green/Yellow
4
Pot once junction
is connected, according
to the instructions for the
cable joint kit
GROUND
PAVING/CEMENT
Pot once junction
is connected,
according to the
instructions for the
cable joint kit
7
6
Align and fasten the fitting to the
outer casing with the CSK stainless
steel screws.
Ensure the gasket is securely in
place before fastening the fitting.
8
7
Switch on power supply.
Inner fitting
Outer casing
A
B
SURGE ARRESTOR
SURGE ARRESTOR
