REL Profusion XW UV-4700 User manual

THIS UV LIGHT EMITS A VERY LARGE AMOUNT OF UV-A RADIATION THAT CAN DAMAGE UNPROTECTED EYES AND
SKIN. PLEASE USE CAUTION WHEN PERFORMING INSPECTIONS WITH THIS LAMP.
ALWAYS WEAR POLYCARBONATE SAFETY GLASSES AND NEVER LOOK DIRECTLY INTO THE LAMP.
WEAR GLOVES AND PROTECTIVE CLOTHING TO AVOID DIRECT EXPOSURE TO SKIN.
DO NOT PLACE THE LAMP FACE DOWN WHILE THE UV LAMP IS ON, AS THIS WILL LEAD TO HEAT
BUILDUP AND DAMAGE THE LED AS WELL AS THE SURFACE IN WHICH IT IS SET UPON.
1. AFFIX MOUNT RAM-202U TO A WELL SUPPORTED SURFACE.
2. AFFIX POWER SUPPLY (UV-2031) TO A FLAT SURFACE AND PLUG INTO A SWITCHED AC SOURCE.
(100-240V 50/60Hz 1.5A, 12 UNITS MAX ON 16A TYPE C CIRCUIT BREAKER AT 120V)

3. USE CONNECTING ARM RAM-201U-B TO JOIN THE TWO 1.5” BALLS (ONE ON LAMP, ONE SECURELY
MOUNTED TO A FLAT SURFACE AS DIRECTED IN STEP 1) AND ANGLE LAMP TOWARD TARGET WHILE
TURNING HANDLE CLOCKWISE TO LOCK THE LAMP ORIENTATION.
4. JOIN THE MALE BARREL JACK FROM POWER SUPPLY (UV-2031) TO THE LAMP AND TURN THE
LOCKING COLLAR CLOCKWISE UNTIL IT IS TIGHT. IF AN EXTENSION IS REQUIRED, USE UV-2007 10’
DC EXTENSION WIRE BETWEEN THE POWER SUPPLY AND THE LAMP.
5. THE LAMPS ARE NOW READY FOR SERVICE AND WILL OPERATE WHEN THE AC SOURCE IS SWITCHED
ON. PLEASE NOTE THE MAX NUMBER OF UNITS PER 16 AMP TYPE C CIRCUIT BREAKER IS 6 AT 240V
AND 12 AT 120V.

NOTE: THIS UNIT IS THERMALLY PROTECTED AND WILL SHUT DOWN IF HIGH TEMPERATURES ARE SENSED. IF
YOUR LAMP IS NOT PERFORMING AS EXPECTED, EXECUTE THESE STEPS BEFORE CONTACTING YOUR
DISTRIBUTOR:
CHECK ALL CORDS FOR ABRASIONS OR DAMAGE AND REPLACE AS NECESSARY.
CLEAN FINS AND FAN AREA OF DUST AND DEBRIS.
MAKE SURE THAT THE UV LENS IS CLEAN AND FREE OF CRACKS OR SCRATCHES.
ENSURE THAT THE POWER SUPPLY IS SUPPLYING DC POWER.
CHECK THE SPLIT CENTER PIN ON FEMALE DC BARREL JACK CONNECTOR. ENSURE THERE IS A 2mm
GAP BETWEEN THE TWO PIN HALFS.
RECERTIFICATION SERVICES FOR ALL LAMPS ARE AVAILABLE UPON REQUEST. PLEASE CONTACT OUR SALES
DEPARTMENT FOR MORE DETAILS REGARDING FACTORY RECERTIFICATION.
REL, INC. WILL REPAIR, WITHOUT CHARGE, ANY DEFECTS DUE TO FAULTY MATERIALS OR WORKMANSHIP FOR
ONE YEAR FROM THE DATE OF PURCHASE. THIS WARRANTY DOES NOT COVER PART FAILURE DUE TO WEAR OR
TOOL ABUSE. FOR FURTHER DETAIL REGARDING WARRANTY COVERAGE AND/OR WARRANTY REPAIR
INFORMATION, PLEASE CALL 1-906-337-3018. THIS WARRANTY DOES NOT APPLY TO ACCESSORIES OR DAMAGE
CAUSED WHERE REPAIRS HAVE BEEN MADE OR ATTEMPTED BY OTHERS.
