Reload RSI305755G Installation instructions

SKU# 035-0156-8 (RSI305755G)
4.3” MONITOR WITH
SUCTION CUP MOUNT
Installaon and Owner’s Manual
Care!
Please read this manual carefully before using and keep it
for future reference.
BACKUP CAMERA
Installation Video
4.3"

Congratulaons on purchasing your new 4.3” backup camera kit. This
product uses the latest technology to ensure performance, reliability
and durability.
The compact design and quick connectors make the system simple to
install and ideal for DIY installaon.
Please read all of the installaon instrucons carefully before
installing
this system. Improper installaon will void manufacturer's
warranty.
These installaon instrucons do not apply to all types of vehicles, and
are only guidelines to assist in installing the system.
BEFORE using this reversing system, please read the safety informaon
provided in this user manual.
ALWAYS use the product as outlined in this user manual.
1
1 877 466 8191
Welcome

This kit is designed for 12V & 24V DC automove system.
This kit is designed for passenger vehicles, SUVs, Mini Vans,
Vans and some Van Trucks.
Great for
Please insure this product is applicable to your vehicle
before installaon. Otherwise, please return it to the
stores with complete packaging.
Any queson, please call 1 877 466 8191
for help.
12V
24V
2
1 877 466 8191
Applicable Car Models & Help

Safety Informaon 4
Package Contents
6
Product Specificaon
Installaon
Tesng & Adjustment
Trouble Shoong
Maintenance
Warranty
20
7
8
18
21
22
31 877 466 81911 877 466 8191
Contents of the Manual

A failure to read, understand and follow these warnings and
instrucons may result in a serious accident, including damaged
property or a serious injury, including loss of life.
WARNING
• This Reversing Camera system is designed as an aid to the driver in detecng large
staonary objects to help avoid damaging the vehicle or property. However, the
driver must use it safely and properly. Use of this system is not a substute for safe,
proper and legal driving.
• Adhere to all applicable traffic laws and motor vehicle regulaons applicable to the
device and consult local laws and regulaons for any restricons on installaon or
use.
• Never allow children to play with the device. Small parts may be a choking hazard.
• ALWAYS engage Parking/Emergency/Hand Brakes of the vehicle when tesng the
system.
• The area displayed by the reversing camera system is limited. The system cannot
display objects that are close to or below the bumper, underneath the vehicle, or
objects out of the camera's field of view. The area displayed on the screen may vary
according to vehicle orientaon or road condions.
• The colors of objects on the rear view monitor may differ somewhat from those of
the actual object.
• Be sure to check the camera's posion and mounng angle before each use.
• If the back of the vehicle is hit, the posion and mounng angle of the Digital
Backup Camera may change, and need to be readjusted.
• When washing the vehicle with high pressure water, be sure not to spray it around
the camera. Otherwise, water may enter the camera unit causing water
condensaon on the lens, malfuncon or fire.
• Do not strike the camera. It is a precision instrument. Otherwise, it may malfuncon
or cause damage.
• This product will only provide images of items that are within the field of view of the
camera. Thus, it is imperave that the camera should be kept clean and
unobstructed, and should be mounted so that its field of view includes the enre
area behind your vehicle.
• There is a plasc cover over the camera. Do not scratch the cover when cleaning dirt,
dust or snow from the cover.
• Do not use alcohol, petrol or thinner to clean the camera. This will cause
discoloraon. To clean the camera, wipe with a clean cloth dampened with mild
cleaner diluted with water and then wipe with a dry cloth.
• The camera has a water resistant construcon. Do not detach, disassemble or
modify it. This may cause incorrect operaon. Camera is waterproof.
4
1 877 466 8191
Safety Informaon

• Using a Backup Camera is not enough to completely overcome a vehicle's blind spot.
Many preventable injuries and deaths occur in driveways or parking lots when
drivers do not see children, pets, or others near their vehicles. Here are a few safety
ps that will help you to avoid a back-over accident.
• Walk completely around your vehicle before geng in. Check for kids, toys, and pets
before entering the vehicle and starng the engine.
• Know where children are. Have children stand in a place where they are in full view.
• Be aware of young children. Young children are small and hard to see.
• Parents, caregivers and all adults need to be vigilant in supervising children,
especially when children are in the yard, driveway or parking lot playing near parked
cars.
• Roll down your window so you will be able to hear what is happening outside your
vehicle.
• Owners of SUVs, trucks, and vans need to take extra care to avoid hing or running
over a child.
• Teach children to move away from a vehicle whenever it is started.
• Do not submerge camera in water, which can cause internal damage to the camera.
• Never back up while looking only at the screen. You should always check behind and
around the vehicle when reversing. Always make sure your intended path is clear. If
you back up while looking only at the monitor, you may hit a vehicle, pedestrian,
child, pet, or other object resulng in damage, injury or death. Always reverse
slowly.
• Never depend on the reversing system enrely when reversing up. Objects viewed in
the rear view monitor differ from actual distance because the wide-angle lens is
used. Use the inside mirror or glance over your shoulder to properly judge distances
to other objects.
• Make sure the trunk, hatch, or backdoor is completely and securely closed when
reversing.
• If the temperature changes rapidly, such as when hot water is poured on the vehicle
in cold weather, the system may not operate normally. The Digital Camera can
withstand the effects of rain, snow, and inclement weather.
• When strong light directly enters the camera or screen, objects may not be
displayed clearly.
• The screen may flicker under fluorescent light.
Safety Around and Behind Other Vehicles
51 877 466 8191
Safety Informaon

Please check all the components listed below are in the kit
Part A
1 x 4.3" monitor
1 x camera with mounng
bracket and 3m (9.84 feet)
cable
Part B
1 x 8 meter (26.24 feet)
main cable with quick
connectors
Part C
2 x pairs of quick
connectors
Part D
1 x sucon cup mount
Part E
6
1 877 466 8191
Package Contents

4.3-inch Color TFT LCD Monitor
Operaon Voltage
480(RGB)x272
DC9
~
15V
Resoluon
Operang Temperature
Power Consumpon
Camera
Extension Power Cable
High Definion Color CMOS
Total 10m (32.8 feet) reach
TV System
Operang Temperature
Lens Angle
(Approx. )
Resoluon
Power Supply
Waterproof
< 2.5W
-20
~
+70°C
420TV Lines
NTSC
170° (Diagonal Angle )
110° (Horizontal Anglel)
12V DC & 24V DC
-20
~
+70°C
IP68
71 877 466 8191
Product Specificaon

Both the camera and the monitor are powered by reverse light. You don't need a 12V
socket or to wire the monitor into the fuse box.
Quick connectors are used for easy connecon.
When you reverse your car, the reverse light is on and will provide power to the
camera and monitor, and the back view image will appear automacally.
1. During installaon you may be required to remove interior panels to run the
camera cable from outside to inside the trunk. Panels and the retaining methods
vary from vehicle to vehicle, and are too varied to be covered in this document.
However, most panels are either secured with screws or spring loaded retaining
clips and can be unscrewed or carefully removed by levering. Care should be
taken in removing panels to make sure the panel won't distort or break.
2. A set of pliers, a flat screwdriver and a screwdriver or spanner, to remove the
license plate are required during the installaon.
3. A power drill might be required for drilling a small hole for roung the camera
cable.
This is how this product works
8
1 877 466 8191
Installaon

There are four steps to install the backup camera
Connecon with reverse light. Install camera (B).
Install monitor (A). Running main cable (C) from the
monitor (A) to the camera (B).
2
3
1
4
AAB
C
B
91 877 466 8191
Installaon

1.2
Locate your reverse light by shiing the gear
to reverse posion while turning the car
ignion switch to "ON" posion.
Remove the tail-light cover to access the
reverse light. Locate the wiring behind the
reverse light.
You may wish to remove the reverse light bulb
holder by carefully twisng while pulling, then
check that the removed bulb glows. Now
locate the posive and negave wires to this
bulb, a test light or voltmeter may be used.
If you are not sure of the power wires,
please contact your vehicle
manufacturer or reference a wiring
diagram in your vehicle manual.
1.1
Connecon with
reverse light
Step
1
11.2
1.3 1.5 1.4
C
D
D
10
1 877 466 8191
Installaon

1.4
Aach the wire quick connectors (D) to the
reverse light posive wire and negave wire
separately. Ensure the wire sits well in the
metal slot of the connector. Snap the cap of
the connector over and use a clamp to
squeeze the cap to ensure solid connecon.
Aach the quick connectors (female
end) of the main cable (C) with the
quick connectors (D) on the reverse
light wire. Ensure posive wire
connect with posive wire and
negave wire with negave wire.
1.5
C
D
D
Shi the gear to “P” posion and turn the car
ignion switch to “Lock” posion.
Before you start the next step, we suggest you simply connect the camera (B) and the
monitor (A) with the main cable (C) and then test whether the backup camera system
works well. Please refer to the following illustraon. When you turn the ignion
switch to “ON” and shi the gear to “R” , the monitor should show the backup image
clearly. Then you can connue the next step. Otherwise, please go back to Step 1 and
check the connecons between the reverse light and the main cable (C).
11 1 877 466 8191
Installaon

Please consult your car manufacturer
or professional if you don't know
how to remove it.
Remove your license plate and check
whether there is a hole that allows the
camera cable to go through. Please see
the above two posions that possibly
exist in many cars.
2.1 2.2
Remove part of the interior panel of the
trunk to ensure the hole you find (in the
last step) allows the camera wire to go
through from outside to inside of the
trunk.
Most panels are either secured with
screws or spring loaded retaining
clips.
1
2
Install camera (B)
Step
2.3 2.4 2.5
2.1 2.2
B
B
12
1 877 466 8191
Installaon

If you can't find a hole for the camera
cable, you need to drill a hole behind or
around the license plate.
Run the camera (B) cable inside the
trunk through the hole drilled or found
in previous steps. Then posion the
license plate back onto the trunk.
2.5
Mount the camera (B) on the license
plate. We suggest mounng the camera
on the top-middle of the license plate.
Before drilling a hole, please
ensure there is no obstacle behind
the posion you decide and the
camera cable can go through
without geng blocked.
2.3 2.4
Please clean your license plate
before mounng the camera
with the double sided tape.
B
B
13 1 877 466 8191
Installaon

Make sure the mounng area is
clean and grease free.
1
3
Install monitor (A)
Step
A
A
Please ensure it does not impede the
vision of the driver while driving, but
can be clearly seen when reversing.
Aach the sucon cup mount (E) with
the monitor (A) and ensure the
connecon is secure.
3.1 3.2
Find your preferred posion to mount the
monitor (A) on the windshield of the
vehicle with provided sucon cup mount.
3.1 3.2
A
E
A
E
14
1 877 466 8191
Installaon

See wiring diagram below for an overview
OR
4
Running wire from the monitor (A) to the camera (B).
Step
4.1 4.2
4.44.3
III
AB
A
A
A
C
C
BC
C
15 1 877 466 8191
Installaon

OR
Please note that the monitor cable
plug has a locater and must be in-line
with the locater on the main cable (C).
Locate the “For monitor” (colored red)
end of the main cable (C) and connect
with the monitor (A) cable plug. Please
ensure the connecon is firm.
4.1
4.2
Run the main cable (C) from the monitor (A) backward to the trunk of the car.
You can route your cables under the vehicle floor covering or route in the
following two ways.
Route I - Conceal the cable behind the rubber seal of the doors of your vehicle
unl you reach the rear seat.
Route II - Conceal the cable under the edge of the plasc strip that holds the
floor covering in place unl you reach the rear seat.
I II
A
A
A
C
C
C
16
1 877 466 8191
Installaon

Now all the wire connecons are
complete and you are ready to
test your backup camera.
Run the main cable (C) to the trunk of
your car. For many cars, the rear seat can
be folded and the cable can go through
easily. For other cars, you can push the
cable around the boom corner of the
rear seat. Then push it over the edge of
the panel and get it into the trunk.
4.3 4.4
Locate the “For camera” end (colored
black) of the main cable (C) and plug the
camera (B) cable into this socket. Please
ensure the connecon is firm.
C
CB
Please note that the plug has a
locater and must be in-line with
the locater on the main cable (C).
17 1 877 466 8191
Installaon

You don't have to bend the
bracket much to see a big change
on the monitor (A).
Have your car ignion switch to "ON"
posion, then shi the gear to reverse
posion, the monitor and the camera
will be powered by the reverse light and
the back-view image will appear on the
monitor automacally unl the gear is
changed.
Please make sure you have the best view
you desire. You can bend the camera (B)
bracket gently to achieve that.
5.2
18
1 877 466 8191
Tesng & Adjustment

Congratulaons on the successful
installaon of your backup camera!
Organize your wires and dy up
When tesng is done and the
camera system is funconing
correctly, please put all the
interior and trunk panels back
into posion, and conceal any
surplus cables.
The camera can be adjusted for brightness,
color, contrast and RESET. You can press
“M” to select the funcon you want and
press “+” or “-” to adjust the image effect
you prefer. These 3 buons are located at
the back of the monitor (A).
5.3 5.4
A
19 1 877 466 8191
Tesng & Adjustment
