Renault KlGER User manual


Vehicle user manual
 
  111 11
         
@RENAULT
  
I
0K

0.1
The descriptions of the models given in this manual are based on the technical specifications at the time of writing. This manual
covers all items of equipment (both standard and optional) available for these models, but whether or not these are fitted
to the vehicle depends on the version, options selected and the country where the vehicle is sold.
This manual may also contain information about items of equipment to be introduced later in the model year.
The diagrams in the user manual are provided as examples.
Welcome aboard your vehicle
This vehicle user manual contains the information necessary:
– for you to familiarise yourself with your vehicle, to use it to its best advantage and to benefit fully from the all the functions and
the technical developments it incorporates.
– to ensure that it always gives the best performance by following the simple, but comprehensive advice concerning regular main-
tenance.
– to enable you to deal quickly with minor faults not requiring specialist attention.
It is well worth taking a few minutes to read this manual to familiarise yourself with the information and guidelines it contains about
the vehicle and its functions and new features.If certain points are still unclear, our authorised dealers will be pleased to provide
you with any additional information.
The following symbol will help you when reading this manual.
 and  These appear in the vehicle and indicate that you should consult the manual for detailed information and/orlimits
on operations with respect to your vehicle’s equipment.
➥ anywhere in the manual indicates a transfer to a page.
Translated from English. Copying or translation, in part or in full, is forbidden unless prior written permission has been obtained from the vehicle manufac-
turer.
To indicate a hazard, danger or safety recommendation.
Enjoy driving your new vehicle.

0.2
EXTERIOR
Electric windows ➥ 3.11
Windscreen wipers ➥ 1.61
Demisting ➥ 1.62, ➥ 3.6 and ➥ 3.8
Lights: operation ➥ 1.58
Lights: replacement ➥ 5.10 Tyres ➥ 5.7
Bodywork maintenance ➥ 4.10
Locking/unlocking the doors
➥ 1.10
Key/Remote control ➥ 1.2
Rear view mirrors ➥ 1.39

0.3
PASSENGER COMPARTMENT
Passenger compartment storage/fit-
tings ➥ 3.16 Adjusting your driving position ➥ 1.19
Front headrest ➥ 1.17
Front seats ➥ 1.18
Child safety ➥ 1.29
Rear headrest ➥ 3.19
Rear seat ➥ 3.20

0.4
DRIVER’S POSITION
Instrument panel ➥ 1.43
Multimedia screen ➥ 3.24
Heating/Air conditioning
system ➥ 3.5
Engine start/stop button ➥ 2.5
Exterior lighting ➥ 1.58
Hand brake ➥ 2.8
Gear lever ➥ 2.8
Steering wheel adjustment ➥ 1.42
Key ignition switch ➥ 2.2

0.5
DRIVING AIDS
ABS (anti-lock braking system)
ESC (electronic stability control)
Braking assistance
➥ 2.10
Parking distance control ➥ 2.25
Reversing camera ➥ 2.27

0.6
SAFETY ON BOARD
Front airbags ➥ 1.22
Seat belts ➥ 1.19
Side Airbags ➥ 1.28

0.7
IDENTIFYING A VEHICLE - LABELS
Review of a vehicle identification number ➥ 6.2
Tyre pressure labels ➥ 4.9
Engine identification plate ➥ 6.3

0.8
THE ENGINE COMPARTMENT (routine maintenance)
Opening the bonnet ➥ 4.2
Coolant level ➥ 4.7
Windscreen washer fluid ➥ 4.6
Battery ➥ 4.8
Brake fluid ➥ 4.6
Engine oil ➥ 4.3

0.9
BREAKDOWN RECOVERY
Replacing front windscreen wiper
blade(s) ➥ 5.23
Puncture ➥ 5.2
Tools ➥ 5.4
Emergency spare wheel ➥ 5.2
Changing a wheel ➥ 5.5
Front towing point ➥ 5.24
Fuses ➥ 5.13
Replacement of the rear lights ➥ 5.12
Replacing windscreen wiper
blade(s) ➥ 5.23
Replacing headlight
bulbs ➥ 5.10

0.10

0.11
Getting to know your vehicle ...............................
Driving ...................................................................
Your comfort .........................................................
Maintenance .........................................................
Practical advice ....................................................
Technical specifications ......................................
Alphabetical index ...............................................
Sections
1
CONTENTS
2
3
4
5
6
7

0.12

1.1
Section 1: Getting to know your vehicle
Keys, radio frequency remote control: general information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2
Radio frequency remote control:use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.3
Hands free card:general information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.4
Hands free card:use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.6
Locking and unlocking the doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.10
Automatic locking of doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.13
Opening and closing the doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.14
Engine Immobiliser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.16
Front headrests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.17
Front seats. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.18
Seat belts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.19
Methods of restraint in addition to the front seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.22
Side protection devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.28
Child safety : general information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.29
Child safety : choosing a child seat mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.31
Child safety : fitting a child seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.34
Child seats : attachment by the seat belt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.35
Child seats : attachment using the ISOFIX system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.37
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.39
Driving Position - Right Hand Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.40
Steering wheel/Power assisted steering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.42
Warning lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.43
Displays and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.47
On-board computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.52
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.57
Exterior lighting and signals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.58
Headlight height adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.59
Audible and visual signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.60
Screen washer/wiper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.61
Fuel tank (filling with fuel) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.63

1.2
KEYS, RADIO FREQUENCY REMOTE CONTROL: general information
Radio frequency remote
control key B
Depending on vehicle,
2 Locks all doors.
3 Unlocks all doors.
4 Coded key for ignition switch.
Key A
Depending on vehicle,
1 Coded key for ignition switch.
A
1 2
3
4
B
The remote control unit
operating range
This varies according to the environ-
ment. It is therefore important when
handling the remote control to ensure
that you do not lock or unlock the ve-
hicle by inadvertently pressing the but-
tons.
Interference
The presence of certain objects (metal
objects, mobile telephones, or an area
with strong electromagnetic radiation,
etc.) close to the key may create inter-
ference and affect the operation of the
system.
Replacement and additional keys or
remote controls
If you lose your remote control key or
require another, you can obtain one
from an approved dealer.
If a remote control or key is replaced,
it will be necessary to take the vehicle
and all of its remote control keys to
an authorised dealer to reset them.
You may use up to four remote control
keys per vehicle.
Driver’s responsibility when parking or stopping the vehicle
Never leave an animal, child or adult who is not self-sufficient alone in
your vehicle, even for a short time.
They may pose a risk to themselves or to others by starting the engine, activating
equipment such as the electric windows or locking the doors, for example.
Also, in hot and/or sunny weather, please remember that the temperature inside
the passenger compartment increases very quickly.
RISK OF DEATH OR SERIOUS INJURY

1.3
Unlocking the doors
Press unlocking button 2.
The hazard warning lights and side in-
dicator lights flash once to indicate that
the doors have unlocked.
Driver’s responsibility
when parking or stopping
the vehicle
Never leave an animal,
child or adult who is not self-suffi-
cient alone in your vehicle, even for
a short time.
They may pose a risk to themselves
or to others by starting the engine,
activating equipment such as the
electric windows or locking the
doors, for example.
Also, in hot and/or sunny weather,
please remember that the tempera-
ture inside the passenger compart-
ment increases very quickly.
RISK OF DEATH OR SERIOUS
INJURY
Advice : Avoid leaving the
remote control in hot, cold or
humid areas.
Locking the doors
Press locking button 1.
The hazard warning lights and side in-
dicator lights flash twice to indicate
that the doors have locked.
If a door or the tailgate is open or not
properly shut, the doors and tailgate
lock then quickly unlock and the hazard
warning lights and side indicator lights
do not flash.
The key must not be used for any
function other than those described
in the handbook (removing the cap
from a bottle, etc.).
If the vehicle has been unlocked but
neither the doors nor tailgate are
open, it locks again automatically
after two minutes.
RADIO FREQUENCY REMOTE CONTROL: use
2
1

1.4
The card is used for:
– locking/unlocking the opening ele-
ments (doors, tailgate);
– switching on the vehicle interior light-
ing (refer to the following pages);
– starting the engine (refer to the in-
formation on “Starting the
engine -Vehicle with card” in
Section 2).
Battery life
Make sure that the correct battery type
is being used, and that the battery is
in good condition and inserted cor-
rectly. Its service life is approximately
two years: replace it when the mes-
sage “Keycard Battery Low” appears
on the instrument panel (refer to sec-
tion “Card: battery” in Section 5).
1 Unlocking the doors and tailgate.
2 Locking all doors and tailgate.
3 Unlocking/locking the tailgate.
4 Switching on the interior lighting re-
motely.
CARD: general information (1/2)
When the battery is flat, you can
still lock/unlock and start your ve-
hicle. Refer to the information on
“Locking/unlocking the doors” in
Section 1 and “Starting the engine”
in Section 2.
Card operating range
This varies according to the environ-
ment: take care not to accidentally lock
or unlock the vehicle by inadvertently
pressing the buttons on the card.
Note: if a door or the tailgate is open or
not closed properly, the doors and tail-
gate lock then unlock quickly.
Interference
Interference by factors in the immediate
vicinity (external installations or the use
of equipment operating on the same
frequency as the card) may disrupt its
operation.
1
2
3
4

1.5
CARD: general information (2/2)
Distance lighting function
Pressing button 4 switches ON the in-
terior lighting for approximately
20 seconds. This can be used,
for example, to identify your vehicle
from a distance when parked in a car
park.
Note: Pressing button 4 again switches
off the lighting.
Driver’s responsibility
when parking or stopping
the vehicle
Never leave an animal,
child or adult who is not self-suffi-
cient alone in your vehicle, even for
a short time.
They may pose a risk to themselves
or to others by starting the engine,
activating equipment such as the
electric windows or locking the
doors, for example.
Also, in hot and/or sunny weather,
please remember that the tempera-
ture inside the passenger compart-
ment increases very quickly.
RISK OF DEATH OR SERIOUS
INJURY
Advice
Avoid leaving the card in hot, cold or
humid areas.
Do not keep the card in a place
where it could be bent or dam-
aged accidentally, such as in a back
pocket of a garment.
Replacement: need for an
additional card
If you lose your card or require an-
other, you can obtain one from an
authorised dealer.
If a card is replaced, it will be nec-
essary to take the vehicle and all
its cards to an approved Dealer to
re-set the system.
You may use up to four cards per
vehicle.
4

1.6
“HANDS-FREE” CARD: use (1/4)
There are two ways to unlock/lock the
vehicle:
– the card in “hands-free” mode;
– the card in remote control mode.
Do not store the card anywhere it
may come into contact with other
electronic equipment (computer,
phone etc.) as this could hinder its
operation.
Driver’s responsibility
when parking or stopping
the vehicle
Never leave an animal,
child or adult who is not self-suffi-
cient alone in your vehicle, even for
a short time.
They may pose a risk to themselves
or to others by starting the engine,
activating equipment such as the
electric windows or locking the
doors, for example.
Also, in hot and/or sunny weather,
please remember that the tempera-
ture inside the passenger compart-
ment increases very quickly.
RISK OF DEATH OR SERIOUS
INJURY
Using the card in “hands-
free” mode
In “hands-free” mode, it is possible to
lock/unlock the vehicle without using
any of the card buttons, as long as the
card is within the access zone 1.
Note: if the vehicle has not been used
for more than 8 days, the hands-free
system switches to standby. To reacti-
vate it, press the unlocking button on
the card.
1
1 1
