77 11 193 528 Edition Anglaise
RENAULT 1997
AUTOMATIC TRANSMISSION
Cancels and replaces Workshop Manual M.R. T.A.M., Part Number : 77 11 088 275
and N.T. N°1275 - 1599 - 1769 - 1770 - 2061
Type Range
Renault 5
Extra
Renault 9/11
Renault 19
Clio
Twingo
Renault 5
Renault 9/11
Renault 19
Renault 18
Renault Fuego
Renault 18
Renault Fuego
Renault 20
Renault 21
Renault 25
Renault Trafic
MB1
MB3
MJ1
MJ3
ML1
Workshop repair manual

Contents
AUTOMATIC TRANSMISSION
Diagram 23-1
Using 23-3
Identification 23-4
Gear change thresholds 23-7
Gear ratios 23-11
Specifications 23-13
Parts to be replaced (after removal) 23-13
Consumables 23-13
Maintenance 23-14
Piston (Identification) 23-20
Number of discs 23-20
Transmission operation 23-21
Cross section and tightening torques
(in daN.m) 23-23
Strainer 23-27
Hydraulic distributor 23-32
Solenoid valves 23-37
Speedo shaft seal (MJ - ML) 23-38
Speedo drive (MB) 23-39
Speedo drive (J) 23-40
Differential seal (MB) 23-41
Differential seal (MJ) 23-42
Differential seal and nut (ML) 23-43
Converter 23-44
Drive plate 23-46
Stator shaft 23-48
Converter seal 23-49
Gear section casing 23-52
Final drive assembly (MB) 23-73
Final drive assembly (MJ) 23-86
Final drive assembly (ML) 23-98
Exploded view 23-107
Exploded view of mechanisms 23-109
Final drive exploded view (MJ) 23-110
Final drive exploded view (MB) 23-111
Computer and wiring 23-112
Kickdown 23-116
Computer 23-117
Multifunction switch 23-119
Speed sensor 23-122
Oil pressure 23-124
Vacuum capsule 23-126
Special tooling 23-127
37
Page Page
Fault finding- Introduction 23-132
Vehicles concerned 23-133
FF
FFII IICC CCHH HHEE EE NN NN
°1
General 23-137
XR25 fiche 23-140
Meaning of the bargraphs 23-141
Adjusting the load potentiometer 23-143
Fault finding using bargraph
illumination 23-144
Fault finding - Control unit-
B. Vi. 958 23-152
Fault finding- Checking connectors 23-167
FF
FFII IICC CCHH HHEE EE NN NN
°24
General 23-173
XR25 fiche 23-179
Meaning of the bargraphs 23-180
Additional checks 23-183
FF
FFII IICC CCHH HHEE EE NN NN
°26
General 23-189
Fiche XR25 23-195
Meaning of the bargraphs 23-196
Additional checks 23-200
FF
FFII IICC CCHH HHEE EESS SS NN NN
°24 and 26
Fault finding using bargraph
illumination 23-207
Fault finding aid 23-223

AUTOMATIC TRANSMISSION
Diagram
This diagram represents an automatic transmission
TT
TTyy yypp ppee ee MM MMBB BB
23
DI2325
23-1

AUTOMATIC TRANSMISSION
Diagram
This diagram represents an automatic transmission
TT
TTyy yypp ppee ee MM MMJJ JJ
23
DI2328
23-2

AUTOMATIC TRANSMISSION
Using 23
DD
DDRR RRII IIVV VVII IINN NNGG GG
As the automatic transmission is lubricated under
pressure, lubrication only occurs if the engine is
running.
Consequently, the following instructions must be
respected in order to avoid serious damage:
- Never move the vehicle with the ignition off
(when going down a slope for example), the
danger of such a measure cannot be
emphasised too greatly.
- Never have the vehicle pushed (for example in
order to reach the next service station), unless
precautions taken in the "Towing" are fol-
lowed).
In addition, the vehicle can only be driven if the
engine is running. It is therefore impossible to
start the engine on a vehicle with automatic trans-
mission by pushing the vehicle.
TT
TTOO OOWW WWII IINN NNGG GG
The front of the vehicle must be raised, however if
this is impossible towing can be carried out in ex-
ceptional cases with the wheels on the ground in
the following conditions:
1- Add an additional 2 litres of oil to the auto-
matic transmission ("Elf Renaultmatic D2" or
Mobil ATF 220).
2- When towing, do not exceed a speed of
25 mph (40 km/h) or a distance of 30 miles
(50 km) maximum (lever in N).
Remember to drain off the excess oil at the end of
the towing operation.
23-3

AUTOMATIC TRANSMISSION
Identification 23
The identification plate indicates:
- at A: the type of automatic transmission,
- at B: the type suffix,
- at C: the fabrication number,
- at D: the manufacturing factory.
DI2329
Vehicle Type of
A.T. Suffix Final drive ratio Step-down gear ratio Speedo
drive
ratio
Oil
pressure
in bar
±0.1 bar)
No. of
planet
wheels
Computer
number
B/C 403
B/C 40J MB1
600
601
602
603
17/56 29/24 21/20 4.4 3 21 221
135
B/C 408 MB3 001 16/57 29/24 21/19 4.4 3 134
L 423
B/C 373 MB1
000
001
007
013
017
021
025
16/57 25/23 21/19 4.4 3
05
24
224
228
125
B 373 MB1
002
008
014
018
16/57 25/23 Electric 4.4 3 05 24
224
L 423
B/C 373
Switzer-
land
MB1
003
011
015
019
16/57 25/23 21/19 4.4 3 11 25
125
90775
86304S 85710S
TYPE
XXX - XX
X 000000
D
A
C
BTYPE XXX XX
BP AUTO X
000000
B
DC
AB
0
X
0 0 0 0 0 0
X
X0
0
0
A
D
C
MB MM
MMBB BB -- -- MM MMJJ JJ
ML
23-4

AUTOMATIC TRANSMISSION
Identification 23
Vehicle Type of
A.T. Suffix Final drive ratio* Step-down gear ratio Speedo
drive
ratio
Oil
pressure
(in bar
±0.1 bar)
No. of
planet
wheels
Computer
number
L 423
B/C 373
DAI MB1
500
501
502
503
504
15/58 25/23 21/19 4.4 3
11
25
125
129
L 426
B 376 MB3 001 356 16/57 29/24 21/19 4.4 3 132 133
B
C 53B
LMB3 003
005 16/57 29/24 21/19 4.4 3 132 137
B
C 537/A
LMB1
023
027
031
300
15/58 29/24 21/19 4.4 3 138
140
1342
1352 MJ1 000 9/32 25/23 7/20 4.2 3 04
1342
1352 MJ1 001 9/32 25/23 7/20 4.4 3 04 104
1362 MJ1 100 9/32 26/25 6/18 4.2 3 04
1362 MJ1 101 9/32 26/25 6/18 4.4 3 04
104
1341
1351 MJ1 500 9/32 25/26 6/20 4.4 3 10 110
1363 MJ3 300 9/32 26/25 6/18 4.6 4 03
1343
1353
1363 MJ3 301
351
352 9/32 26/25 6/18 4.6 4 03
103
107
1344
1354 MJ3 200 9/32 25/22 7/19 4.2 3 08*
1344
1354 MJ3 201 9/32 25/22 7/19 4.2 3 14
1279 MJ3
000
001
002
102
9/32 26/25 6/18 4.8 4 02
102
1277 MJ3
002
100
101
102
9/32 26/25 6/18 4.6 4 02
102
1277 DAI MJ3 500 9/32 23/25 6/19 4.6 4 02
F40 MB1 031
038 15/58 29/24 21/19 4.15 3 141
X57 B/T
B 573
C573 MB1
021
026
029
030
16/57 29/24 21/20 4.4 3 139
DAI
* The instrument panel warning light must be disconnected.
23-5

AUTOMATIC TRANSMISSION
Identification 23
Vehicle Type of
A.T. Suffix Final drive ratio
Step-down gear ratio
Step down
mechanisms Differential step down
Speedo
drive
ratio
Oil
pressure
(in bar
±0.1 bar)
No. of
planet
wheels
Computer
number
B 297 MJ3 110
111 9/32 Elec. 4.5 4 13 113
B 297 MJ3 120
121 9/32 7/19 4.5 4 13 113
B297
B29B
with cruise
control
MJ3 012 116
112 9/37 Elec. 4.5 4 13
113
B29B
B297 MJ3 126 9/37 7/20 4.5 4 113
B29E MJ3 011
010 9/32 Elec. 4.7 4 13 113
B29E MJ3 016 9/37 Elec. 4.7 4 113
483
48K
489 MJ3 800 (1)
801 (2) 9/37 7/19 4.7 4 130 126
L 48A
K (USA) MJ3 760
761
762 9/37 7/19 4.7 4 126
Txx1 ML1
001
004
005
006
007
008
9/32 28/25 23/32 5/20
5/21 4.7 3 20 120
C06 MB1 033 15/58 21/20 4.15 ±
0.05 3 143
F40 MB1 031
038 15/58 21/19 4.15 3 141
X57 B/T
B573
C573 MB1
024
026
029
030
16/57 21/20 4.4 3 139
(1) Sump 6 mm deeper, felt gauze strainer with increased surface area, leaktight dipstick with reduced level.
(2) Sump 6 mm deeper, felt gauze strainer with increased surface area; leaktight dipstick with reduced level.
Unidirectional differential output seals (specific to right hand/left hand sides).
25/23
25/23
26/21
26/21
25/23
26/21
26/20
26/20
29/24
L
K
29/24
29/24
23-6

AUTOMATIC TRANSMISSION
Gear change thresholds 23
(The kickdown switch is integrated into the
computer).
B408 - C408
B403 - C403
Pedal
position
1223
No load 25* 15 35* 30
Full load 75 60 20 110
(The kickdown switch is integrated into the
computer).
L423 - B373 - C373
Pedal
position
1223
No load 23 15 33 26
Full load 68 54 108 98
L423 - B373 - C373 (DAI)
Pedal
position
1223
No load 25 15 45 25
Full load 70 55 110 95
Kickdown 66 55 109 95
(The kickdown switch is integrated into the
computer).
Pedal
position
1223
No load 20 15 35 25
Full load 60 55 100 90
(The kickdown switch is integrated into the
computer).
1342 - 1352 - 1343 - 1353 - 1277 - 1279
L423 - B373 - C373 (Switzerland)
Pedal
position
1223
No load 22* 15 38* 25
Full load 67 60 110 95
1362
Pedal
position
1223
No load 25* 15 50* 25
Full load 65 45 115 85
Kickdown 70 60 125 105
1363
Pedal
position
1223
No load 22* 12 44* 25
Full load 62 42 110 79
Kickdown 68 56 117 100
* These values are given as an example.
Pedal
position
1223
No load 22* 12 46* 25
Full load 65 44 113 81
Kickdown 70 58 121 103
23-7

AUTOMATIC TRANSMISSION
Gear change thresholds 23
(The kickdown switch is integrated into the
computer).
L42
L48K - L483 - L489 - L/K 48A
Pedal
position
1223
No load 26 17 43 30
Full load 75 66 122 107
(The kickdown switch is integrated into the
computer).
B297 - B29B - B29E
Pedal
position
1223
No load 22 14 37 25
Full load 67 58 109 94
Pedal
position
1223
No load 25* 15 35* 30
Full load 75 60 125 110
Pedal
position
1223
No load 20* 10 35* 20
Full load 45 30 70 53
Kickdown 50 40 80 70
B/C 373/573
Pedal
position
1223
No load 23 15 33 26
Full load 71 43 120 80
Kickdown 71 60 120 107
F40 (031)
Pedal
position
1223
No load 21 14 29 22
Full load 74 48 126 99
Kickdown 74 62 126 114
F40 (038)
Pedal
position
1223
No load 19 12 27 20
Full load 68 44 116 91
Kickdown 68 56 116 105
* These values are given as an example.
Pedal
position
1223
No load 21 16 37 27
Full load 72 47 123 94
Kickdown 72 60 123 114
(The kickdown switch is integrated into the
computer).
Txx1
XX
XX55 5577 77 BB BB// //TT TT
23-8

AUTOMATIC TRANSMISSION
Gear change thresholds 23
1343 - 1353 - 1363 (Argentina)
1343 - 1353 - 1363
Pedal
position
1223
No load 23 14 45 26
Full load 65 43 112 81
Kickdown 70 57 120 101
(The kickdown switch is integrated into the
computer).
1341 - 1351 (DAI)
Pedal
position
1223
No load 20 15 35 25
Full load 60 55 100 85
Pedal
position
1223
No load 20* 10 40* 25
Full load 60 40 100 75
Kickdown 65 50 110 90
Pedal
position
1223
No load 15* 10 40* 20
Full load 60 45 105 90
B53B - C53B - L53B
Pedal
position
1223
No load 24 15 40 27
Full load 72 63 118 102
Kickdown 72 63 118 102
XX
XX55 5533 33AA AA
Pedal
position
1223
No load 23 13 46 26
Full load 62 40 102 74
Kickdown 67 54 109 94
1277 (DAI)
Pedal
position
1223
No load 20 13 28 21
Full load 71 46 121 95
Kickdown 71 59 121 110
* These values are given as an example.
Pedal
position
1223
No load 20* 15 45* 25
Full load 60 40 110 80
Kickdown 65 55 115 95
1344 - 1354
B537 - C537 - L537
(The kickdown switch is integrated into the
computer).
23-9

AUTOMATIC TRANSMISSION
Gear change thresholds 23
C06
Pedal
position
1223
No load 19 15 41 29
Full load 65 45 111 92
Kickdown 67 57 113 106
(The kickdown switch is integrated into the
computer).
The figures in the tables indicate the theoretical
average gear change speeds (actual time speed).
These figures may vary depending on the ac-
cepted tolerance limits on the component units
and tyres fitted.
No load = Foot off accelerator pedal.
Full load = Kickdown switch disconnected,
full throttle.
Kickdown = Kickdown connected, full throttle.
23-10

AUTOMATIC TRANSMISSION
Gear ratios 23
For vehicles B53A - C53A - L53A - B537 - C537 - L537
Gear ratio 1st 2nd 3rd Reverse
Gear reduction 2.5 1.5 1 2
Gear reduction + stepdown 2.069 1.241 0.828 1.655
Overall reduction 7.999 4.799 3.199 6.399
Speed in km/h per 1000 rpm. * 12.937 21.562 32.343 16.171
For vehicles B53B - C53B - L53B
Gear ratio 1st 2nd 3rd Reverse
Gear reduction 2.5 1.5 1 2
Gear reduction + stepdown 2.069 1.241 0.828 1.655
Overall reduction 7.370 4.422 2.948 5.896
Speed in km/h per 1000 rpm. * 14.042 23.403 35.105 17.552
* For vehicles fitted with 165/70 R13 tyres.
For vehicles B 573 - C 573
Gear ratio 1st 2nd 3rd Reverse
Gear reduction 2.5 1.5 1 2
Gear reduction + stepdown 2.069 1.241 0.828 1.655
Overall reduction 7.370 4.422 2.948 5.896
Speed in km/h per 1000 rpm. * 13.431 22.385 33.578 16.789
* For vehicles fitted with 165/65 R13 tyres.
23-11

AUTOMATIC TRANSMISSION
Gear ratios 23
For vehicles C06
Gear ratio 1st 2nd 3rd Reverse
Gear reduction 2.5 1.5 1 2
Gear reduction + stepdown 2.069 1.241 0.827 1.655
Overall reduction 8 4.8 3.2 6.4
Speed in km/h per 1000 rpm. 12.52 20.87 31.31 15.656
For vehicles F40
Gear ratio 1st 2nd 3rd Reverse
Gear reduction 2.5 1.5 1 2
Gear reduction + stepdown 2.069 1.241 0.827 1.655
Overall reduction 8 4.8 3.2 6.4
Speed in km/h per 1000 rpm. 13.2 22 33 16.5
Tyres: 155 R 13.
Tyres: 155/70 R 13.
23-12

AUTOMATIC TRANSMISSION
Specifications 23
RR
RREE EEPP PPLL LLAA AACC CCEE EEMM MMEE EENN NNTT TT II IINN NNSS SSTT TTRR RRUU UUCC CCTT TTII IIOO OONN NNSS SS
• Damaged brakes or clutch:
1st possibility:
Repair the gear section and clean the final drive,
oil cooler, converter* and check the hydraulic dis-
tributor.
2nd possibility:
Change the gear section alone. (Adjust the end
float and the oil pressure setting). Or change the
entire automatic transmission (service exchange
or new transmission).
* The cleaning method is given in the "Torque
converter" section.
• Bearing(s) which is/are noisy but not broken:
Change the bearing(s) and the filter.
• Bearing(s) or other mechanical component
damaged:
If the damage is extensive, change the automatic
transmission (service exchange or new transmis-
sion).
For a service exchange:
Return the worn transmission with the packaging
in which the new part was delivered.
Parts to be replaced (after removal)
- roll pins,
- O and square section seals,
- lip seals,
- paper seals,
- bearings (if they have had to be removed),
- circlips,
- differential bank (MJ),
- speedometer drive shaft (MB),
- speedometer drive gears (if they have had to
be removed),
- the entire free wheel (if there is a problem),
- the quadrants with the drive hub (if they are
seized in the hub).
Consumables
Name Packaging To be used for:
LOCTITE FORMAJOINT 50 ml bottle Housing joint faces
LOCTITE FRENETANCH 24 ml bottle 1 drop on converter drive plate
bolt at crankshaft end.
LOCTITE SCELBLOC 24 ml bottle 1 drop on converter seal (MB).
Transmission oil
ELF RENAULTMATIC D2 or
MOBIL ATF 220
Immersion of all parts before
assembly (except those for ML
final drive).
Final drive oil
SAE 80 W or 75 W Immersion of final drive components (ML).
23-13

AUTOMATIC TRANSMISSION
Maintenance 23
MM
MMBB BB.. ..MM MMJJ JJ
automatic transmissions have a single oil level and a single oil grade for all sections (converter, final
drive, gear section). ML type automatic transmission has two different oil levels and grades .
1°) Oil for MB.MJ automatic transmission and for ML converter and gear section
Grade: EE
EELL LLFF FF RR RREE EENN NNAA AAUU UULL LLTT TTMM MMAA AATT TTII IICC CC DD DD22 22
otherwise use MOBIL ATF 220
Capacity in litres (approximately) :
AT MB MJ ML
Theoretical total 4.5 6 5
After oil change 2 2.5 2.5
2°) Oil for ML final drive section
AA
AAPP PPII II GG GGLL LL55 55
Oil grade or
MM
MMII IILL LL LL LL22 2211 1100 0055 55 BB BB oo oorr rr CC CC
SAE 80 W: Hot and temperate countries
Viscosity SAE 75 W: Cold countries
Capacity in litres: Final drive 0.8
23-14

AUTOMATIC TRANSMISSION
Maintenance 23
85546R1
DD
DDRR RRAA AAII IINN NN -- -- RR RREE EEFF FFII IILL LLLL LL
ML, MB and MJ gear sections
The oil must be drained when the engine is cold
and with dipstick and plugs (A) removed.
Allow the oil to drain out for as long as possible.
Refit the plugs with new seals.
DI2330
MJ
ML
88148R
MB
23-15

AUTOMATIC TRANSMISSION
Maintenance 23
87297R
The oil is refilled via the dipstick tube.
Use a funnel fitted with a 15/100 mesh filter to
trap any impurities in the oil.
When the oil has been drained, refill with the rec-
ommended oil.
Start the engine and let it idle, check the oil level
and top up if necessary.
EXAMPLE : MB
MJ
85935R1
Fit plug (C).
The oil is refilled through plug (B) and the oil
should be level with the bottom of the aperture
of plug (B).
CC
CCHH HHEE EECC CCKK KKII IINN NNGG GG TT TTHH HHEE EE LL LLEE EEVV VVEE EELL LL (( ((gg ggee eeaa aarr rr ss ssee eecc cctt ttii iioo oonn nn oo ooii iill ll)) ))
The vehicle must be unladen.
The oil is at ambient temperature (engine cold).
Place the vehicle on a flat, horizontal surface.
Place the selector lever in "Park" (P).
Start the engine and wait one or two minutes for
the converter and cooler to fill with oil
Remove the dipstick with the engine running.
The oil level must not be below the MIN COLD
mark (risk of damage) or above the MAX COLD
mark (risk of damage).
2) ML final drive
The oil must be drained with plugs (B) and (C) re-
moved.
84495R
AMin cold
BMax cold
AA
AATT TTTT TTEE EENN NNTT TTII IIOO OONN NN:: ::
Too much oil will lead to
- the oil overheating abnormally,
-leaks.
Too little oil will lead to:
- the gear section being damaged.
23-16

AUTOMATIC TRANSMISSION
Maintenance 23
CC
CCOO OONN NNFF FFOO OORR RRMM MMII IITT TTYY YY OO OOFF FF TT TTHH HHEE EE DD DDII IIPP PPSS SSTT TTII IICC CCKK KK
II
IIMM MMPP PPOO OORR RRTT TTAA AANN NNTT TT:: ::
in order to ensure that the oil level is correct, you must check the conformity of the dipstick .
1341 - 1342 - 1351 - 1352 - 1362
No PAS - no CA Grey (1) L = 225 mm MJ1 001
1341 - 1342 - 1351 - 1352 - 1362
with PAS and CA Yellow (1) L = 660 mm MJ1 500 501
1343 - 1353 - 1363 - 1277 - 1279
B29E - B297 - B29B Green (1) L = 243 mm MJ3 301 350
010
012
112
120
122
110
B29E - B29B - B297
L/K 483 - L/K 48K - L/K 489 Blue (2) L = 247 mm MJ3 015 016
115
116
125
126
800
801
B/C 403 - B/C 408 - B/C 40J
L423 - B/C 373 Green (2) L = 243 mm MB3 All types MB1 000 011 021
001 013 504
002 015 600
003 017 601
007 019 602
L423 - L426 Red (1)
L = 252 mm MB1 500 501
502
503
C40J - C403/B Red (2)
L = 243 mm MB1 500 501
502
503
C57/3/B Red (2)
L = 243
Orange (2)
L = 231 mm
MB1 024
026
MB1 029
F40 Violet (2)
L = 347 mm MB1 031 038
L423 - B/C 373 DAI
with air pre-filter White (1) L = 324 mm MB1 500 501
502
503
23-17

AUTOMATIC TRANSMISSION
Maintenance 23
1344 - 1354 Yellow (1)
L = 240 mm MJ3 200 201
L/K 48A
(deeper sump) Grey (2) L = 247 mm MJ3 761 762
B
C 53B
L
Red (2)
L = 243 mm MB3 003 005
B
C 537
L
Yellow (2)
L = 334 mm MB1 023 027
X06 Light grey (2)
L = 338 mm MB1 033
C373 Green (2)
L = 243 mm MB1 001 011 019 002 013 021
003 015 504
007 017
MB3
B373 (1)
L = 252 mm MB1 500 501
502
503
23-18
