Renesas QB-MINI2 User manual

To our customers,
Old Company Name in Catalogs and Other Documents
On April 1st, 2010, NEC Electronics Corporation merged with Renesas Technology
Corporation, and Renesas Electronics Corporation took over all the business of both
companies. Therefore, although the old company name remains in this document, it is a valid
Renesas Electronics document. We appreciate your understanding.
Renesas Electronics website: http://www.renesas.com
April 1st, 2010
Renesas Electronics Corporation
Issued by: Renesas Electronics Corporation (http://www.renesas.com)
Send any inquiries to http://www.renesas.com/inquiry.
Note that the following URLs in this document are not available:
http://www.necel.com/
http://www2.renesas.com/
Please refer to the following instead:
Development Tools | http://www.renesas.com/tools
Download | http://www.renesas.com/tool_download
For any inquiries or feedback, please contact your region.
http://www.renesas.com/inquiry

Notice
1. All information included in this document is current as of the date this document is issued. Such information, however, is
subject to change without any prior notice. Before purchasing or using any Renesas Electronics products listed herein, please
confirm the latest product information with a Renesas Electronics sales office. Also, please pay regular and careful attention to
additional and different information to be disclosed by Renesas Electronics such as that disclosed through our website.
2. Renesas Electronics does not assume any liability for infringement of patents, copyrights, or other intellectual property rights
of third parties by or arising from the use of Renesas Electronics products or technical information described in this document.
No license, express, implied or otherwise, is granted hereby under any patents, copyrights or other intellectual property rights
of Renesas Electronics or others.
3. You should not alter, modify, copy, or otherwise misappropriate any Renesas Electronics product, whether in whole or in part.
4. Descriptions of circuits, software and other related information in this document are provided only to illustrate the operation of
semiconductor products and application examples. You are fully responsible for the incorporation of these circuits, software,
and information in the design of your equipment. Renesas Electronics assumes no responsibility for any losses incurred by
you or third parties arising from the use of these circuits, software, or information.
5. When exporting the products or technology described in this document, you should comply with the applicable export control
laws and regulations and follow the procedures required by such laws and regulations. You should not use Renesas
Electronics products or the technology described in this document for any purpose relating to military applications or use by
the military, including but not limited to the development of weapons of mass destruction. Renesas Electronics products and
technology may not be used for or incorporated into any products or systems whose manufacture, use, or sale is prohibited
under any applicable domestic or foreign laws or regulations.
6. Renesas Electronics has used reasonable care in preparing the information included in this document, but Renesas Electronics
does not warrant that such information is error free. Renesas Electronics assumes no liability whatsoever for any damages
incurred by you resulting from errors in or omissions from the information included herein.
7. Renesas Electronics products are classified according to the following three quality grades: “Standard”, “High Quality”, and
“Specific”. The recommended applications for each Renesas Electronics product depends on the product’s quality grade, as
indicated below. You must check the quality grade of each Renesas Electronics product before using it in a particular
application. You may not use any Renesas Electronics product for any application categorized as “Specific” without the prior
written consent of Renesas Electronics. Further, you may not use any Renesas Electronics product for any application for
which it is not intended without the prior written consent of Renesas Electronics. Renesas Electronics shall not be in any way
liable for any damages or losses incurred by you or third parties arising from the use of any Renesas Electronics product for an
application categorized as “Specific” or for which the product is not intended where you have failed to obtain the prior written
consent of Renesas Electronics. The quality grade of each Renesas Electronics product is “Standard” unless otherwise
expressly specified in a Renesas Electronics data sheets or data books, etc.
“Standard”: Computers; office equipment; communications equipment; test and measurement equipment; audio and visual
equipment; home electronic appliances; machine tools; personal electronic equipment; and industrial robots.
“High Quality”: Transportation equipment (automobiles, trains, ships, etc.); traffic control systems; anti-disaster systems; anti-
crime systems; safety equipment; and medical equipment not specifically designed for life support.
“Specific”: Aircraft; aerospace equipment; submersible repeaters; nuclear reactor control systems; medical equipment or
systems for life support (e.g. artificial life support devices or systems), surgical implantations, or healthcare
intervention (e.g. excision, etc.), and any other applications or purposes that pose a direct threat to human life.
8. You should use the Renesas Electronics products described in this document within the range specified by Renesas Electronics,
especially with respect to the maximum rating, operating supply voltage range, movement power voltage range, heat radiation
characteristics, installation and other product characteristics. Renesas Electronics shall have no liability for malfunctions or
damages arising out of the use of Renesas Electronics products beyond such specified ranges.
9. Although Renesas Electronics endeavors to improve the quality and reliability of its products, semiconductor products have
specific characteristics such as the occurrence of failure at a certain rate and malfunctions under certain use conditions. Further,
Renesas Electronics products are not subject to radiation resistance design. Please be sure to implement safety measures to
guard them against the possibility of physical injury, and injury or damage caused by fire in the event of the failure of a
Renesas Electronics product, such as safety design for hardware and software including but not limited to redundancy, fire
control and malfunction prevention, appropriate treatment for aging degradation or any other appropriate measures. Because
the evaluation of microcomputer software alone is very difficult, please evaluate the safety of the final products or system
manufactured by you.
10. Please contact a Renesas Electronics sales office for details as to environmental matters such as the environmental
compatibility of each Renesas Electronics product. Please use Renesas Electronics products in compliance with all applicable
laws and regulations that regulate the inclusion or use of controlled substances, including without limitation, the EU RoHS
Directive. Renesas Electronics assumes no liability for damages or losses occurring as a result of your noncompliance with
applicable laws and regulations.
11. This document may not be reproduced or duplicated, in any form, in whole or in part, without prior written consent of Renesas
Electronics.
12. Please contact a Renesas Electronics sales office if you have any questions regarding the information contained in this
document or Renesas Electronics products, or if you have any other inquiries.
(Note 1) “Renesas Electronics” as used in this document means Renesas Electronics Corporation and also includes its majority-
owned subsidiaries.
(Note 2) “Renesas Electronics product(s)” means any product developed or manufactured by or for Renesas Electronics.

MINICUBE
®
OCD Checker
MINICUBE Utility
Printed in Japan
Document No. U18591EJ2V0UM00 (2nd edition)
Date Published October 2008 NS
User’s Manual
Target Devlopment Tool
QB-MINI2
QB-78K0MINI
QB-78K0SKX1MINI
2007

User’s Manual U18591EJ2V0UM
2
[MEMO]

User’s Manual U18591EJ2V0UM 3
MINICUBE is a registered trademark of NEC Electronics Corporation in Japan and Germany.
Windows is either a registered trademark or a trademark of Microsoft Corporation in the United States and/or
other countries.
The names of other companies and products are the registered trademarks or trademarks of their companies.
The information in this document is current as of October, 2008. The information is subject to
change without notice. For actual design-in, refer to the latest publications of NEC Electronics data
sheets or data books, etc., for the most up-to-date specifications of NEC Electronics products. Not
all products and/or types are available in every country. Please check with an NEC Electronics sales
representative for availability and additional information.
No part of this document may be copied or reproduced in any form or by any means without the prior
written consent of NEC Electronics. NEC Electronics assumes no responsibility for any errors that may
appear in this document.
NEC Electronics does not assume any liability for infringement of patents, copyrights or other intellectual
property rights of third parties by or arising from the use of NEC Electronics products listed in this document
or any other liability arising from the use of such products. No license, express, implied or otherwise, is
granted under any patents, copyrights or other intellectual property rights of NEC Electronics or others.
Descriptions of circuits, software and other related information in this document are provided for illustrative
purposes in semiconductor product operation and application examples. The incorporation of these
circuits, software and information in the design of a customer's equipment shall be done under the full
responsibility of the customer. NEC Electronics assumes no responsibility for any losses incurred by
customers or third parties arising from the use of these circuits, software and information.
While NEC Electronics endeavors to enhance the quality, reliability and safety of NEC Electronics products,
customers agree and acknowledge that the possibility of defects thereof cannot be eliminated entirely. To
minimize risks of damage to property or injury (including death) to persons arising from defects in NEC
Electronics products, customers must incorporate sufficient safety measures in their design, such as
redundancy, fire-containment and anti-failure features.
NEC Electronics products are classified into the following three quality grades: "Standard", "Special" and
"Specific".
The "Specific" quality grade applies only to NEC Electronics products developed based on a customer-
designated "quality assurance program" for a specific application. The recommended applications of an NEC
Electronics product depend on its quality grade, as indicated below. Customers must check the quality grade of
each NEC Electronics product before using it in a particular application.
The quality grade of NEC Electronics products is "Standard" unless otherwise expressly specified in NEC
Electronics data sheets or data books, etc. If customers wish to use NEC Electronics products in applications
not intended by NEC Electronics, they must contact an NEC Electronics sales representative in advance to
determine NEC Electronics' willingness to support a given application.
(Note)
•
•
•
•
•
•
M8E 02. 11-1
(1)
(2)
"NEC Electronics" as used in this statement means NEC Electronics Corporation and also includes its
majority-owned subsidiaries.
"NEC Electronics products" means any product developed or manufactured by or for NEC Electronics (as
defined above).
Computers, office equipment, communications equipment, test and measurement equipment, audio
and visual equipment, home electronic appliances, machine tools, personal electronic equipment
and industrial robots.
Transportation equipment (automobiles, trains, ships, etc.), traffic control systems, anti-disaster
systems, anti-crime systems, safety equipment and medical equipment (not specifically designed
for life support).
Aircraft, aerospace equipment, submersible repeaters, nuclear reactor control systems, life
support systems and medical equipment for life support, etc.
"Standard":
"Special":
"Specific":

User’s Manual U18591EJ2V0UM
4
INTRODUCTION
Target Readers This manual is intended for users who use the MINICUBE OCD Checker when designing
and developing a system using an NEC Electronics on-chip flash memory microcontroller.
Purpose This manual is intended to give users an understanding of the basic specifications and
correct use of the MINICUBE OCD Checker.
Organization This manual includes the following sections.
•Overview
•Installation and startup
•OCD check for MINICUBE2 and 78K0 microcontroller
•OCD check for MINICUBE2 and V850 microcontroller
•OCD check for MINICUBE2 and 78K0S microcontroller
•OCD check for MINICUBE2 and 78K0R microcontroller
•OCD check for 78K0 MINICUBE
•OCD check for 78K0S MINICUBE+
•OCD checker version indication
•Uninstallation
How to Read This Manual It is assumed that the readers of this manual have general knowledge of electricity, logic
circuits, and microcontrollers. In the explanations of the operation of the applications, it is
also assumed that the readers have sufficient knowledge of WindowsTM. For the usage
and terminology of Windows 98, Windows Me, Windows 2000, and Windows XP, refer to
each Windows manual.
The mark <R> shows major revised points.
The revised points can be easily searched by copying an "<R>" in the PDF file and
specifying it in the "Find what:" field.
To understand the overall operation of the MINICUBE OCD Checker
→Read this manual according to the CONTENTS.
Conventions Note: Footnote for item marked with Note in the text
Caution: Information requiring particular attention
Remark: Supplementary information
Numeric representation: Binary ... xxxx or xxxxB
Decimal ... xxxx
Hexadecimal ... xxxxH
“ ”: Indicates an arbitrary message or item on the screen.
[ ]: indicates the name of a button, command, dailog box, or
area.

User’s Manual U18591EJ2V0UM 5
Terminology The meanings of the terms used in this manual are as follows.
Term Meaning
Emulator General name that means MINICUBE2, 78K0 MINICUBE and
78K0S MINICUBE+
MINICUBE2 Indicates QB-MINI2, an on-chip debug emulator with programming
function.
78K0 MINICUBE Indicates 78K0 on-chip debug emulator QB-78K0MINI.
78K0S MINICUBE+ Indicates 78K0S/Kx1+ in-circuit emulator QB-78K0SKX1MINI.
Debugger Indicates NEC Electronics integrated debugger ID78K0-QB,
ID78K0S-QB, ID78K0R-QB, or ID850QB.
QBP Indicates the QB-Programmer, GUI software used for flash
programming.
Device file Binary file that contains device-dependent information. It is prepared
for each target device or group of devices in the same lineup.
Related Documents Please use the following documents in combination with this manual.
The related documents listed below may include preliminary versions. However,
preliminary versions are not marked as such.
{Documents Related to Development Tools (User’s Manuals)
Document Name Document Number
MINICUBE OCD Checker This manual
QB-MINI2 On-Chip Debug Emulator with Programming Function U18371E
QB-78K0MINI On-Chip Debug Emulator U17029E
ID78K0-QB Ver. 2.90 Integrated Debugger Operation U17437E
QB-78K0SKX1MINI In-Circuit Emulator U17272E
ID78K0S-QB Ver. 2.90 Integrated Debugger Operation U18247E
ID78K0R-QB Ver. 3.20 Integrated Debugger Operation U17839E
ID850QB Ver. 3.20 Integrated Debugger Operation U17435E
QB-Programmer Programming GUI Operation U18527E
MINICUBE2 Diagnostic Tool U18588E
Caution The related documents listed above are subject to change without notice.
Be sure to use the latest version of each document for designing, etc.

User’s Manual U18591EJ2V0UM
6
CONTENTS
CHAPTER 1 OVERVIEW............................................................................................................................8
1.1 MINICUBE OCD Checker ............................................................................................................. 8
1.2 Target Emulators and Items to Be Checked.............................................................................. 8
1.3 Notes Before Using OCD Checker..............................................................................................9
CHAPTER 2 INSTALLATION AND STARTUP........................................................................................10
2.1 When NEC Electronics Tool Is Used........................................................................................ 10
2.1.1 Installation...................................................................................................................................... 10
2.1.2 Startup ........................................................................................................................................... 10
2.2 When Tools Manufactured by Partner Companies (GHS and IAR) are Used....................... 11
2.2.1 Installation...................................................................................................................................... 11
2.2.2 Startup ........................................................................................................................................... 11
2.3 Explanation of Each Area.......................................................................................................... 12
CHAPTER 3 OCD CHECK FOR MINICUBE2 AND 78K0 MICROCONTROLLER .................................14
3.1 Execution of OCD Check........................................................................................................... 14
3.2 Format of Log File ...................................................................................................................... 16
3.3 Error Output................................................................................................................................ 17
3.4 Action for Error........................................................................................................................... 18
CHAPTER 4 OCD CHECK FOR MINICUBE2 AND V850 MICROCONTROLLER .................................20
4.1 Execution of OCD Check........................................................................................................... 20
4.2 Format of Log File ...................................................................................................................... 22
4.3 Error Output................................................................................................................................ 23
4.4 Action for Error........................................................................................................................... 24
CHAPTER 5 OCD CHECK FOR MINICUBE2 AND 78K0S MICROCONTROLLER...............................26
5.1 Execution of OCD Check........................................................................................................... 26
5.2 Format of Log File ...................................................................................................................... 28
5.3 Error Output................................................................................................................................ 29
5.4 Action for Error........................................................................................................................... 30
CHAPTER 6 OCD CHECK FOR MINICUBE2 AND 78K0R MICROCONTROLLER...............................32
6.1 Execution of OCD Check........................................................................................................... 32
6.2 Format of Log File ...................................................................................................................... 34
6.3 Error Output................................................................................................................................ 35
6.4 Action for Error........................................................................................................................... 36
CHAPTER 7 OCD CHECK FOR 78K0 MINICUBE ..................................................................................38
7.1 Execution of OCD Check........................................................................................................... 38
7.2 Format of Log File ...................................................................................................................... 40
7.3 Error Output................................................................................................................................ 41
7.4 Action for Error........................................................................................................................... 43

User’s Manual U18591EJ2V0UM 7
CHAPTER 8 OCD CHECK FOR 78K0S MINICUBE+ .............................................................................44
8.1 Execution of OCD Check........................................................................................................... 44
8.2 Format of Log File...................................................................................................................... 46
8.3 Error Output................................................................................................................................ 47
8.4 Action for Error .......................................................................................................................... 48
CHAPTER 9 OCD CHECKER VERSION INDICATION...........................................................................50
CHAPTER 10 UNINSTALLATION ...........................................................................................................51
APPENDIX A REVISION HISTORY ..........................................................................................................52
A.1 Major Revisions in This Edition................................................................................................ 52

User’s Manual U18591EJ2V0UM
8
CHAPTER 1 OVERVIEW
1.1 MINICUBE OCD Checker
MINICUBE OCD Checker (hereinafter referred to as OCD Checker) is a self-check tool for simply detecting
problems that may occur when an on-chip debug emulator and target system are connected.
1.2 Target Emulators and Items to Be Checked
The following table lists the items that can be checked with the OCD Checker.
MINICUBE2
Check Items
78K0 V850 78K0S 78K0R
78K0
MINICUBE
78K0S
MINICUBE+
Status of main clock √√√
Status of target power supply √√√√√
Status of RESET pin √√√√√√
Hardware version indication √√√√√√
ID verification √√√√
Download of flash memory data √√√√√
Program execution and stop operation √√√√√
Erasure of flash memory data √√√√
Remark 1. √: Available blank : Unavailable
2. For the 78K0S MINICUBE+, the system clock status, target power supply status, RESET pin
status and hardware version indication are checked, based on connection check of the QB-
78K0SMINI and QB-78K0SKX1-DA, both are components of the 78K0S MINICUBE+.
Target system Host machine
MINICUBE2
Target device
USB
communication
Serial communication
Communication circuits
must be mounted on
the target system.
The OCD Checker checks i
f
the communication circuits
operate normally.
Target system Host machine
Target device
USB
communication
Serial communication
Communication circuits
must be mounted on
the target system.
The OCD Checker checks i
f
the communication circuits
operate normally.

CHAPTER 1 OVERVIEW
User’s Manual U18591EJ2V0UM 9
1.3 Notes Before Using OCD Checker
Chapters 1 and 2 present an overview and basic specifications of the OCD Checker, and the following sections
provide separate description for the target device and the emulator to be used. To utilize this manual effectively, refer
to the following table and see the relevant section for your target device and purpose of use.
Target Device Emulator Refer to:
78K0 CHAPTER 3 OCD CHECK FOR MINICUBE2 AND 78K0 MICROCONTROLLER
V850 CHAPTER 4 OCD CHECK FOR MINICUBE2 AND V850 MICROCONTROLLER
78K0S CHAPTER 5 OCD CHECK FOR MINICUBE2 AND 78K0S MICROCONTROLLER
78K0R
MINICUBE2
CHAPTER 6 OCD CHECK FOR MINICUBE2 AND 78K0R MICROCONTROLLER
78K0 78K0 MINICUBE CHAPTER 7 OCD CHECK FOR 78K0 MINICUBE
78K0S 78K0S MINICUBE+ CHAPTER 8 OCD CHECK FOR 78K0S MINICUBE+

User’s Manual U18591EJ2V0UM
10
CHAPTER 2 INSTALLATION AND STARTUP
This section explains how to install and start the OCD Checker.
2.1 When NEC Electronics Tool Is Used
2.1.1 Installation
•Select the “Emulator Utilities” check box when installing CubeSuite V1.00 or later. The MINICUBE OCD
Checker is then installed automatically.
•Select the “MINICUBE Utilities Vx.xx” check box when installing ID78K0-QB V2.93 or later. The OCD Checker
is then installed automatically.
•Select the “MINICUBE Utilities Vx.xx” check box when installing ID850QB V3.20 or later. The OCD Checker is
then installed automatically.
•Select the “MINICUBE Utilities Vx.xx” check box when installing QBP V1.00 or later. The OCD Checker is then
installed automatically.
•Select the “MINICUBE Utilities Vx.xx” check box when installing ID78K0S-QB V2.82 or later. The OCD Checker
is then installed automatically.
•Select the “MINICUBE Utilities Vx.xx” check box when installing ID78K0R-QB V3.20 or later. The OCD
Checker is then installed automatically.
Caution If multiple debuggers are installed, “MINICUBE Utilities Vx.xx MINICUBE OCD Checker” in the
[Latest Version] folder is overwritten. When an ID78K0-QB or ID78K0S-QB earlier than V3.00
is installed, the OCD Checker in the [NEC Tools32] folder is overwritten.
Remark The MINICUBE2 diagnostic tool is installed when the OCD Checker is installed.
2.1.2 Startup
Start the OCD Checker using either of the following procedure.
•When using CubeSuite
Click the Start menu of Windows, point to “Programs”, “NEC Electronics CubeSuite”, “Emulator Utilities”,
“<Target Device>”and then click “OCD Checker”.
•When using the ID850QB, ID78K0-QB, ID78K0S-QB, ID78K0R-QB, or QB-Programmer
Start OCD Checker by using either of the following methods.
•Click the Start menu of Windows, point to “Programs”, “NEC Electronics Tools”, “Latest Version”, and then
click “MINICUBE Utilities Vx.xx OCD Checker”.
•Click the Start menu of Windows, point to “Programs”, “NEC Tools32”, and then click “OCD Checker”. (For
an ID78K0-QB or ID78K0S-QB earlier than V3.00)
<R>
<R>

CHAPTER 2 INSTALLATION AND STARTUP
User’s Manual U18591EJ2V0UM 11
Caution If the debugger, QBP, or MINICUBE2 diagnostic tool is running, terminate it before starting the
OCD Checker.
Remark When an ID78K0-QB or ID78K0S-QB earlier than V3.00, a link file for startup is created in the [NEC
Tools32] and [NEC Electronics Utilities] folders.
2.2 When Tools Manufactured by Partner Companies (GHS and IAR) are Used
2.2.1 Installation
•Download MINICUBE Utilities (MINICUBE_Utilities_Vxxx.lzh) from one of the following websites.
http://www.necel.com/micro/ghs/jpn/exec/execindex.html (Japanese version)
http://www.necel.com/micro/ghs/eng/exec/ (English version)
<1> Download MINICUBE_Utilities_Vxxx.lzh into an arbitrary folder from the website.
<2> Execute MINICUBE_Utilities_Vxxx.lzh in the arbitrary folder.
<3> The following folders and files will be created in the arbitrary folder.
MINICUBE_Utilities_Vxxx MINICUBE_Utilities_Vxxx
MINICUBE_Utilities_Document_Vxxx
readme_j.txt
readme_e.txt
<4> Install MINICUBE_Utilities_Vxxx main unit as follows.
•If the OS is Japanese Windows, execute setup.exe in the MINICUBE_Utilities_Vxxx\Japanese\DISK1
folder and install the software according to the installer instructions.
•If the OS is not Japanese Windows, execute setup.exe in the MINICUBE_Utilities_Vxxx\English\DISK1
folder and install the software according to the installer instructions.
Caution Specify C:\Program Files\NEC Electronics Tools as an installation destination folder.
Remarks 1. The MINICUBE OCD Checker and MINICUBE2 diagnostic tool can be installed by installing
MINICUBE Utilities Vxxx.
2. GHS: Green Hills Software, Inc
IAR: IAR Systems AB
2.2.2 Startup
•Click the Start menu of Windows, point to “Programs”, “NEC Electronics Tools”, “Latest Version”, and then click
“MINICUBE Utilities Vx.xx OCD Checker”.
Caution If the debugger, QBP, or MINICUBE2 diagnostic tool is running, terminate it before starting
the OCD Checker.

CHAPTER 2 INSTALLATION AND STARTUP
User’s Manual U18591EJ2V0UM
12
2.3 Explanation of Each Area
When the OCD Checker is started, the following window appears.
(1) Emulator mode select area
Select from the drop-down list the emulator mode for which target connection check is to be performed.
(2) Target Device Connection area
If “MINICUBE2 V850”, “MINICUBE2 78K0S” or “MINICUBE2 78K0R” is selected for the emulator mode,
specify from the drop-down list the device file for the target device and the mode for connection with the target
system. This menu is unavailable if an item other than “MINICUBE2 V850”, “MINICUBE2 78K0S” or
“MINICUBE2 78K0R” is selected.
•Device: Select from the drop-down list the target device to be connected.
If the target device (device file) is not displayed in the list, specify the folder where the device file is
saved, using the (3) [Device file folder] button in the above window.
•Port: Select the mode for connection with MINICUBE2 and target system from the drop-down list
(available only when “MINICUBE2 V850” or “MINICUBE2 78K0R” is selected)
(3) [Device file folder] button
This button is used for searching the folder where the device file is saved to define the device file to be
connected when “MINICUBE2 V850”, “MINICUBE2 78K0S”, or “MINICUBE2 78K0R” is selected. When the
device file has been installed using the device file installer (DFINDT), the saved folder is automatically
specified.
(1)
(7)
(2)
(6)
(4) (10)(5)
(9)
(8)
(11) (3)

CHAPTER 2 INSTALLATION AND STARTUP
User’s Manual U18591EJ2V0UM 13
(4) Clock select area
Select with the radio button the clock supplied to the emulator.
•internal: When a clock mounted in the emulator is used.
•socket: When a clock mounted in the CLK1 socket of the MINICUBE2 78K0-OCD board and a
clock mounted in the CLK1 socket of the 78K0 MINICUBE or 78K0S MINICUBE+ are used.
•Main OSC(MHz): Input the target system clock frequency when “MINICUBE2 V850” is selected.
(5) Internal ROM Security setting area
To set the ID code, select the “ID Code” check box; otherwise, the ID code is handled as 0xFF.
If “MINICUBE2 V850” is selected, this area is available only when a debug monitor program has been written
to the target device.
This area is unavailable if “MINICUBE2 78K0S” or “78K0S MINICUBE+” is selected for the emulator mode.
(6) [Log file] button
Specifies the file to which the check log will be output (log file).
The location for saving the log file can be changed by clicking the [Log file] button. The log file is created as
“IEOCDUTL.log” in a temporary folder by default. Normally, the temporary folder is specified in the tmp or
temp environmental variable.
(7) [Test] button
Starts checking. The checked items and their result are output to the log file.
(8) Log view window
Displays the check result. The contents displayed in this area are also output to the log file that is specified
using the (6) [Log file] button.
(9) [Clear] button
Clears the log view window. The contents output to the log file are not cleared.
(10) [Exit] button
Terminates the OCD Checker.
(11) System menu
Version can be checked by clicking “About OCD Checker...” on the System menu.
Remark Settings for the OCD Checker are maintained when the OCD Checker is started the next time,
except for the setting in the Internal ROM Security setting area.

User’s Manual U18591EJ2V0UM
14
CHAPTER 3 OCD CHECK FOR MINICUBE2 AND 78K0 MICROCONTROLLER
This section describes the method to check the connection between MINICUBE2 and the target system, which
uses a 78K0 microcontroller as the target device, using the OCD Checker.
3.1 Execution of OCD Check
Be sure to terminate the debugger, QBP and MINICUBE2 diagnostic tool before executing the OCD Checker.
Perform the connection check according to the following steps (1) to (6).
(1) MINICUBE2 setup
•Power select switch: Set the switch corresponding to the target system.
•Mode select switch: Set to “M2”.
•78K0-OCD board: Connect the board in accordance with MINICUBE2 User’s Manual (U18371E).
•Target cable: Connect the cable having a pin count corresponding to the target system (16- pin or
10-pin).
(2) Connection and power application
Connect MINICUBE2 to the target system in accordance with MINICUBE2 User’s Manual (U18371E), and the
turn on power to the target system.
(3) Setting the OCD Checker
Refer to 2.3 Explanation of Each Area.
•Emulator mode select area: Select “MINICUBE2 78K0”.
•Clock select area: Select “internal” or “socket”.
•Internal ROM Security setting area: Input the ID code.
•[Log file] button: Specify the log file name and the location for saving the log file.
(4) Click the [Test] button. If an error occurs during checking, refer to 3.3 Error Output and 3.4 Action for
Error.
(4)
(3)

CHAPTER 3 OCD CHECK FOR MINICUBE2 AND 78K0 MICROCONTROLLER
User’s Manual U18591EJ2V0UM 15
(5) When all of the tests are complete, the result dialog box is displayed as shown below. The contents displayed
in the log view window are saved in the log file. If an NG is displayed, refer to 3.3 Error Output and 3.4
Action for Error. Click the [OK] button.
(6) Click the [Exit] button.
(6)
(5)

CHAPTER 3 OCD CHECK FOR MINICUBE2 AND 78K0 MICROCONTROLLER
User’s Manual U18591EJ2V0UM
16
3.2 Format of Log File
The following shows an example of the log file when the check results show “OK” statuses.
tt:mm:ss
Target Clock: 20.00MHz [OK]
Target Power: 5.1V [OK]
Target Reset: HIGH
OCD Control Code Vx.xx
MINICUBE2 4100 x xx.xx
Program Download: OK
Run Test: OK
Flash Erase: OK
ALL OK
Emulator Test End
Execution time
Clock status
VDD status
Reset status
Hardware version
Check result
tt:mm:ss
Target Clock: 20.00MHz [OK]
Target Power: 5.1V [OK]
Target Reset: HIGH
OCD Control Code Vx.xx
MINICUBE2 4100 x xx.xx
Program Download: OK
Run Test: OK
Flash Erase: OK
ALL OK
Emulator Test End
Execution time
Clock status
VDD status
Reset status
Hardware version
Check result
•Execution time: The time when checking was started by clicking the [Test] button
•Clock status: Frequency of the selected clock
•VDD status: VDD value that is applied to the target device
•Reset status: RESET pin status
[HIGH] Reset signal input from the target system is HIGH
[LOW] Reset signal input from the target system is LOW
•Hardware version: Version of each hardware.
•Check result: [Program Download] ID verification, result of downloading to flash memory in the target
device
[Run Test] Result of executing and stopping the program
[Flash Erase] Erasure result of flash memory in the target device
Remark The version of MINICUBE2 can also be checked with the MINICUBE2 diagnostic tool, debugger and
QBP. The latest version of MINICUBE2 firmware can be checked on the following NEC Electronics
websites.
Japanese version:
http://www.necel.com/micro/ods/jpn/index.html
English version:
http://www.necel.com/micro/ods/eng/index.html
See Version-up service →MINICUBE2_Software.

CHAPTER 3 OCD CHECK FOR MINICUBE2 AND 78K0 MICROCONTROLLER
User’s Manual U18591EJ2V0UM 17
3.3 Error Output
The following describes the operation and display example when an NG is displayed as a result of 3.1 Execution
of OCD Check. The message just indicates “NG”, but there are various causes.
(1) The result is displayed in the dialog box. Click the [OK] button.
(1)(1)
(2) The contents displayed in the log view window are saved in the log file.
[Log view window]
[Log file]
tt:mm:ss
Target Clock: 20.00MHz [OK]
Monitor Command(3FH) Error
Communication Error
MINICUBE2 4100 x xx.xx
Emulator Test End
Execution time
Clock status = OK
Error indication
Hardware version
tt:mm:ss
Target Clock: 20.00MHz [OK]
Monitor Command(3FH) Error
Communication Error
MINICUBE2 4100 x xx.xx
Emulator Test End
Execution time
Clock status = OK
Error indication
Hardware version
In this NG example, the monitor command (3FH) error and communication error are output.
The communication failure between the target device and MINICUBE2 is detected. The cause is an error in
the target cable connection between the target system and MINICUBE2.

CHAPTER 3 OCD CHECK FOR MINICUBE2 AND 78K0 MICROCONTROLLER
User’s Manual U18591EJ2V0UM
18
3.4 Action for Error
The errors that may occur during self-testing (such as setting error) and relevant actions for coping with the errors
are listed below.
If an error other than below is displayed, the cause may be a defect in MINICUBE2. If the same error is displayed
even after the relevant action is implemented, the cause may be a defect in MINICUBE2. In such a case, consult an
NEC Electronics sales representative or distributor.
(1/2)
No. Error message and action
Communication error1
There is no response from the target device.
→Address 0x84 (on-chip debug emulator use enable flag) is set to 0x00 (disable use) or the target system and
MINICUBE2 are not connected correctly.
Confirm the file of the program written to the target device and connection between the target system and
MINICUBE2.
Target Power : 0.0V [NG]2
The power supply to the target system cannot be detected.
→Confirm that the power for the target system is on.
→Check the connection between the target system and MINICUBE2
78K0 OCD board is not connected3
The 78K0-OCD board is not connected.
→Confirm that the 78K0-OCD board is connected.
Target Clock: 0.00MHz [NG]4
The clock mounted in the CLK1 socket may not be operating.
→Confirm the clock oscillation, or remove the clock mounted in the CLK1 socket in the 78K0-OCD board and
use the internal clock.
Select Socket Clock5
The clock mounted in the CLK1 socket is not selected.
→Select “socket” for the clock setting, or remove the clock mounted in the CLK1 socket and select “internal”.
Driver open error6
(1) There is no response from MINICUBE2.
→Check the connections between the host machine and the USB cable, and the USB cable and the
MINICUBE2.
→Turn all the power supplies off according to the procedures described in the user’s manual. (MINICUBE2 is
turned off by disconnecting the USB cable.)
Turn all the power supplies on, and then click the [Test] button.
If an error message is displayed even after taking these measures, restart Windows on the host machine
before turning all the power supplies on.
(2) The debugger has been started.
→The debugger and the OCD Checker cannot be started simultaneously, so terminate the debugger.
(3) The USB driver may not be operating normally.
→Confirm the cable connection and the USB driver setup. Re-install the USB driver as necessary.
(4) The debugger may not be installed normally.
→Re-install the debugger.
