repabad Vision Series User manual

OPERATING INSTRUCTIONS
for whirlpools – electronic Vision series
0022771-01_BEDWHPV.1 © 12/2021 FA repaBAD GmbH
Please be sure to read the operating instructions carefully before using the whirlpool!
Make sure that you observe the care instructions!
Repabad cannot be held liable for damages caused by inappropriate use.

20022771-01_BEDWHPV.1 12/2021 • repaBAD GmbH • We reserve the right to make technical changes. All dimensions in cm.
CONGRATULATIONS!
You have chosen an innovative, premium product from Repabad.
Our products combine impressive technology with ease of use.
Please read these operating instructions carefully, so that you can best use the whirlpool to improve
your well-being and enjoy the product for many years to come.
Gunther Stolz
Managing Director, Repabad GmbH
Introduction

3
0022771-01_BEDWHPV.1 12/2021 • repaBAD GmbH • We reserve the right to make technical changes. All dimensions in cm.
01 SAFETY INFORMATION 4
02 WELLNESS TIPS 5
03 WHIRLPOOL DESIGNS 5
04 OPERATION WITH THE CONTROL PANEL 6
Vision 500 6
Vision 700 6
Vision 1000 6
“Night design” control panel illumination 6
05 BEFORE USE 7
06 DURING USE 7
Operation with Vision 500 control panel 7
Operation with Vision 700 control panel 9
Operation with Vision 1000 control panel 11
Whirlpool programmes (Vision 1000 only) 15
Safety shutdown 15
Loudspeaker safety shutdown 15
07 AFTER USE 16
Automatic fresh water rinsing and blow-out 15
08 DISINFECTION 16
09 CARE INSTRUCTIONS 19
10 SERVICING 20
11 NOZZLE FUNCTION AND STRUCTURE 21
12 CLEANING THE DRAIN FILTER, ADJUSTING THE DRAIN PLUG 22
13 TECHNICAL DATA 23
14 HOW TO ENJOY THE WHIRLPOOL 24
The rules 24
Effect on the body and wellness 24
Aromatherapy 25
Rules for aromatherapy 25
Aromatherapeutic bath additives 25
Effects of the bath additives 26
WARRANTY CARD 28
Table of contents

40022771-01_BEDWHPV.1 12/2021 • repaBAD GmbH • We reserve the right to make technical changes. All dimensions in cm.
01 SAFETY INFORMATION
General
Danger to life! Danger of electric shock!
Ensure that no electrical devices are operating within the whirlpool or
in close proximity while using it. If there is contact between an electri-
cal device which is plugged in and water or when bathing, fatal electric shocks
may occur.
With appropriate supervision, this product can be used by children from age 8
and persons with reduced physical, sensory or metal capacity, as well as those
without knowledge and experience of the product. Do not allow children to
play with the product. Do not allow children to clean and perform maintenance
on the product without supervision.
Anybody with a healthy cardiovascular system can use the whirlpool.
If you are uncertain or if you have questions, please consult your doctor.
Avoid using the whirlpool after consuming alcohol or directly after eating. This
could stress the cardiovascular system.
Do not use the whirlpool if you have a cold, infectious diseases, open wounds or
inammations. We recommend waiting until you have fully healed before using
it.
Only use Repabad whirlpool bath additives. Using other bath additives risks
damaging the whirlpool.
Depending on the frequency of use, you should disinfect the whirlpool roughly
every 4 weeks. Only use Repabad disinfectant (art. no. 0002511). If other bath
agents are used, you run the risk of damaging the whirlpool.

5
0022771-01_BEDWHPV.1 12/2021 • repaBAD GmbH • We reserve the right to make technical changes. All dimensions in cm.
03 WHIRLPOOL DESIGNS
Repabad whirlpools can be equipped with four different whirlpool systems:
Air system (Vision 500)
The whirlpool with an air system is equipped with a xed fan
installed under the bathtub. Preheated air is blown from the fan into the bathtub via air nozzles.
Use the control elements to control the fan. For a description of the nozzles, please refer to page 21.
Jet system (Vision 700)
The whirlpool with a jet system is equipped with a xed jet pump
installed under the bathtub. The jet pump draws in the bath water and directs it into the bathtub via
jet nozzles or micro jet nozzles. The jet pump is controlled via the control panel. The aeration
is switched on and off using a key. For a description of the nozzles, please refer to page 22.
Air and jet system (Vision 1000)
The whirlpool with a combined air and jet system is equipped with a xed fan and a jet pump installed
under the bathtub. Preheated air is conveyed from the fan into the bathtub via air nozzles. The jet
pump draws the bath water in and directs it into the bathtub via jet nozzles and micro jet nozzles. The
aeration is switched on and off via a control panel. For a description of the nozzles, please refer to
page 21/22.
Champagne system (Vision 1000)
The Champagne system whirlpool is equipped with a xed fan installed under the bathtub and a jet
pump. The Champagne system whirlpool has combined air and water nozzles in the bathtub base
area: the Champagne nozzles. As for the air system, they are used to convey preheated air to the
bathtub when the fan is switched on. However, if the jet pump is switched on, the rising air bubbles are
split by the nest of water jets, forming millions of ne beads – the “Champagne-effect” sets in. At the
same time, the intake water is conveyed to the bathtub via the jet nozzles and micro nozzles. For a
description of the nozzles, please refer to page 21/22.
The human body nds a water temperature between
35 and 36°C to be most pleasant.
At a water temperature of 36°C, the bath duration should not
exceed 20 minutes. At a water temperature of 38°C, you should
bathe for no more than 10 minutes.
In order to become accustomed to the invigorating massage ef-
fect, keep the massage time short initially.
The massage duration can be increased over time to suit your preference. After use,
you should rest for at least as long as the time spent bathing.
02 WELLNESS TIPS
General

60022771-01_BEDWHPV.1 12/2021 • repaBAD GmbH • We reserve the right to make technical changes. All dimensions in cm.
04 OPERATION WITH THE CONTROL PANEL
Three different control elements and electronic controllers are available for the whirlpool systems.
Vision 500
The whirlpool is operated using the Vision 500 control panel. The control panel is used
to switch the fan on and off. It is innitely adjustable.
If whirlpool lighting (a special accessory) is tted, you can switch it on or off.
The “fresh water rinse” function (a special accessory) is controlled via the control panel.
You can also use the control panel to select from two different whirlpool massage programmes.
Vision 700
The whirlpool is operated using the Vision 700 control panel. Use the control panel to
switch the jet pump on and off. It is innitely adjustable.
If whirlpool lighting (a special accessory) is tted, you can switch it on or off.
The aeration is switched on via key.
If supplementary heating (a special accessory) is tted, it is activated automatically when the jet
pump is switched on.
The “Automatic disinfection” and “Fresh water rinsing” functions (both special accessories) are con-
trolled via key.
You can also use the control panel to select from two different whirlpool massage
programmes.
Vision 1000
The whirlpool is operated using the Vision 1000 control panel. You can switch the fan and jet pump on
and off using the control panel. The massage intensity can be precisely regulated with both systems.
If whirlpool lighting (a special accessory) is tted, you can switch it on or off.
The aeration is switched on via key.
The supplementary heating (a special accessory) is automatically activated when the jet pump is
switched on. The target temperature can be set and the current water temperature is shown on the
display.
The “Automatic disinfection” and “Fresh water rinsing” functions (both special accessories) are con-
trolled via key.
You can also use the control panel to select from six different whirlpool massage programmes.
“Night design” control panel illumination
All three control panel types have individual keys which remain subtly illuminated for some 60 minutes
after the last input. Power consumption for this is extremely low (LED technology).
Operation

7
0022771-01_BEDWHPV.1 12/2021 • repaBAD GmbH • We reserve the right to make technical changes. All dimensions in cm.
Operation
05 BEFORE USE
06 DURING USE
Operation with the Vision 500 control panel
- Rinse out the whirlpool with cold water.
- Close the bathtub drain.
- Fill the whirlpool with hot water.
Important: Since the piping system must be partially lled with water before the bathtub can be
lled, it takes some time for the water to visibly collect in the tub.
To enable the use of all functions, ll the whirlpool up to around the overow with the user(s)
inside.
The keylock is activated when the key ashes, irrespective of which key is pressed.
All functions are blocked (please refer to the following page).
You can select a function by pressing the corresponding key.
The key is illuminated for as long as the function is active.
The corresponding keys are also illuminated for functions which are
selected by the massage programme.
If a key ashes quickly after being pressed, it is not possible to carry out the function selected. This
is because one of the conditions necessary for the function has not been met, such as not enough
water in the whirlpool.
Turns the air massage on or off when output is set to medium (even when the tub is
empty). A few minutes after the bath, when the bath water has drained off, the key
ashes until the blow-out and fresh water rinsing (special accessories) automatic pro-
grammes are completed.

80022771-01_BEDWHPV.1 12/2021 • repaBAD GmbH • We reserve the right to make technical changes. All dimensions in cm.
Increases the intensity of the air massage (if the air massage is on).
The key illuminates if pressed and ashes when the maximum value is reached.
Reduces the intensity of the air massage (if the air massage is on). The key illuminates if
pressed and ashes when the minimum value is reached.
Press once to turn on the LED whirlpool lighting (optional).
Press again to set the next colour.
After pressing for a sixth time, the colours begin to change automatically, starting with
magenta. Press again while the colours are alternating to choose the colour. The key
ashes slowly.
Press again to restart the colour change process.
Press and hold to turn off the LED whirlpool lighting.
Switches the air massage interval function on (only if there is water in the bathtub). If
the air massage is off, it is turned on when the interval function is activated.
If the interval function is activated, the key is illuminated as intensity increases and
the key as it decreases.
Switches the whirlpool programme P1 Soft or. P2 Power on (only if there is water in the
bathtub); programme duration approx. 15 minutes.
Any active massage or programme is switched off rst. Start the programme again by
pressing or again. The or key is illuminated when the programme is running.
Functions activated by the programme are indicated by the ,and keys, which
are lit up accordingly. The current programme can be stopped at any time by pressing
or .
Switches fresh water rinsing (a special accessory) off manually if the bathtub is empty.
Please also refer to page 18.
The key is illuminated if automatic fresh water rinsing (a special accessory) is activated
several minutes after emptying the bathtub. Automatic fresh water rinsing cannot be
interrupted.
The keylock is activated when the key ashes, irrespective of which key is
pressed. All functions are blocked.
Keylock
The keylock can be activated to prevent accidental or unauthorised activation of whirlpool func-
tions (e.g. by children).
Activating the keylock: Press and hold the key until the key ashes.
Deactivating the keylock: Press and hold the key until the key no longer ashes.
The current keylock status is maintained even if the device is disconnected from the electrical
power supply.
Operation

9
0022771-01_BEDWHPV.1 12/2021 • repaBAD GmbH • We reserve the right to make technical changes. All dimensions in cm.
The keylock is activated when the key ashes, irrespective of which key is pressed.
All functions are blocked (please refer to the following page).
If a function is selected by pressing a key, this key is illuminated as long as the function is active.
The corresponding keys are also illuminated for functions that are selected by the massage pro-
gramme.
If a key ashes quickly after being pressed, it is not possible to carry out the function selected. This
is because one of the conditions necessary for the function has not been met, such as not enough
water in the whirlpool.
Turns the jet massage on and off (only when the tub is full).
Press the key again to switch the interval function (increasing and decreasing massage
intensity) on. Press the key a third time to switch the jet massage off again.
If the interval function is activated, the key is illuminated as intensity increases and
the key as it decreases.
Increases the jet massage intensity (if the jet massage is on).
The key illuminates if pressed and ashes when the maximum value is reached.
Decreases the jet massage intensity (if the jet massage is on). The key illuminates if
pressed and ashes when the minimum value is reached.
Press once to turn on the LED whirlpool lighting (optional).
Press again to set the next colour.
After pressing for a sixth time, the colours begin to change automatically,
starting with magenta.
Press again while the colours are alternating to choose the colour.
The key ashes slowly.
Press again to restart the colour change process.
Press and hold to turn off the LED whirlpool lighting.
Operation
Operation with the Vision 700 control panel

10 0022771-01_BEDWHPV.1 12/2021 • repaBAD GmbH • We reserve the right to make technical changes. All dimensions in cm.
Turns the aeration on or off.
Adding air increases the intensity of the massage.
If the jet massage is off, activating the aeration also turns on the jet massage (only
when the tub is full).
Switches whirlpool programme P1 Soft or P2 Power on (only if the bathtub is full); pro-
gramme duration approx. 15 minutes.
Any active massage or programme is switched off rst. Start the programme again by
pressing or again. The or key is illuminated when the programme is running.
Functions activated by the programme are indicated by the key ,and , which
illuminate accordingly. The current programme can be stopped at any time by press-
ing or .
Switches fresh water rinsing (special accessory) on and off when the tub is empty
(please refer to page 18).
Switches the disinfection system (special accessory) on and off when the tub is full
(press and hold the key for at least 5 seconds, please refer to pages 16/17).
The key is illuminated when the (special accessory) fresh water rinsing or the disinfec-
tion system is activated.
The keylock is activated when the key ashes, irrespective of which key is
pressed. All functions are blocked.
Keylock
The keylock can be activated to prevent accidental or unauthorised activation of whirlpool func-
tions (e.g. by children).
Activating the keylock: Press the key until the key ashes.
Deactivating the keylock: Press and hold the key until the key no longer ashes.
The current keylock status is maintained even if the device is disconnected from the electrical
power supply.
Set the direction of the massage jet by swivelling the jet nozzles or micro jet nozzles.
The supplementary heating (special accessory) is automatically switched on or off with the jet
massage. The supplementary heating keeps the bath water hot.
Operation

11
0022771-01_BEDWHPV.1 12/2021 • repaBAD GmbH • We reserve the right to make technical changes. All dimensions in cm.
The keylock is activated when the display shows
--
, irrespective of which key is pressed. All func-
tions are blocked (please refer to page 13).
You can select a function by pressing the corresponding key.
The key is illuminated for as long as the function is active.
The corresponding keys are also illuminated for functions which are
selected by the massage programme.
If a key ashes quickly after being pressed, it is not possible to carry out the function selected. This
is because one of the conditions necessary for the function has not been met, such as not enough
water in the whirlpool.
Jet massage
Turns the jet massage on and off (only when the tub is full).
Press and hold to activate the and keys for setting the temperature.
Increases the jet massage intensity (if the jet massage is on).
The key illuminates if pressed and ashes when the maximum value is reached.
Decreases the jet massage intensity (if the jet massage is on). The key illuminates if
pressed and ashes when the minimum value is reached.
Turns the aeration on or off. Adding air increases the intensity of the massage. If the jet
massage is off, activating the aeration also turns on the jet massage (only when the
tub is full).
Switches the jet massage interval function (increasing and decreasing massage intensi-
ty) on when the bathtub is full. If the jet massage is deactivated, it is activated with the
interval function.
If the interval function is activated, the key is illuminated as intensity increases and
the key as it decreases.
The direction of the massage jet is set by swivelling the jet nozzles or micro jet nozzles.
Jet massage Air massageDisplay
Temperature setting
Whirlpool light-
ing
Fresh water rinsing/
disinfection
Programme
selection
Operation
Operation with the Vision 1000 control panel

12 0022771-01_BEDWHPV.1 12/2021 • repaBAD GmbH • We reserve the right to make technical changes. All dimensions in cm.
Air massage
Turns the air massage on or off when output is set to medium (even when the tub is
empty). A few minutes after the bath, when the bath water has drained off, the key
ashes until the blow-out and fresh water rinsing (special accessories) automatic pro-
grammes are completed.
Increases the intensity of the air massage (if the air massage is on).
The key illuminates if pressed and ashes when the maximum value is reached.
Reduces the intensity of the air massage (if the air massage is on). The key illuminates if
pressed and ashes when the minimum value is reached.
Activates the interval function for the air massage (only when the tub is full).
If the air massage is off, it is turned on when the interval function
is activated.
If the interval function is activated, the key is illuminated as intensity increases and
the key as it decreases.
Temperature setting (only with supplementary heating special accessory)
Use the and keys beneath the display to set the temperature.
Activate the keys by pressing and holding the key.
Press once to increase target temperature by 1°C (setting range 10-42°C)
Press once to reduce target temperature by 1°C (setting range 10-42°C)
The bath water temperature is shown on the display during normal operation. The desired temper-
ature is displayed and can be adjusted when the and keys are activated. Approximately 4
seconds after the last target temperature change, the display switches back to the actual tem-
perature. If the bath water temperature is lower than the target temperature when the heating
is on, this is shown by a dot after the temperature display. When the jet massage is switched on,
the supplementary heating (a special accessory) is also switched on and the water heated to the
desired temperature.
Operation

13
0022771-01_BEDWHPV.1 12/2021 • repaBAD GmbH • We reserve the right to make technical changes. All dimensions in cm.
Further functions
Opens the massage programs. When rst pressed, the P1 Vital programme.
Keep pressing to cycle through the programmes (P2, P3, P4, etc.). The programme
selected is started automatically if you do not press again for approx. 3 seconds.
The respective programme number is shown on the display. The programme takes
approx. 15 minutes.
Any active massage or programme is switched off rst. Select the programme again by
pressing again. The key is illuminated while the programme is running. Functions
activated by the programme are indicated by the ,and keys, which are lit up
accordingly. The current programme can be terminated at any time by pressing .
Press once to turn on the LED whirlpool lighting (optional).
Press again to set the next colour.
After pressing for a sixth time, the colours begin to change automatically, starting with
magenta. Press again while the colours are alternating to choose the colour. The key
ashes slowly. Press again to restart the colour change process. Press and hold again to
switch off the LED coloured light.
Press and hold to turn off the LED whirlpool lighting.
Switches fresh water rinsing (special accessory) on and off when the tub is empty
(please refer to page 18).
Switches the disinfection system (special accessory) on and off when the tub is full
(press and hold the key for at least 5 seconds, please refer to pages 16/17).
The key is illuminated when the (special accessory) fresh water rinsing or the disinfec-
tion system is activated.
The keylock is activated when the key ashes, irrespective of which key is pressed.
All functions are blocked.
Keylock
The keylock can be activated to prevent accidental or unauthorised activation of whirlpool func-
tions (e.g. by children).
Activating the keylock:
Press the air massage key until
--
is shown on the display ( is illuminated).
Deactivating the keylock:
Press the air massage key until a temperature is shown on the display ( is illuminated).
The current keylock status is maintained even if it is disconnected from the electrical power supply.
Operation

14 0022771-01_BEDWHPV.1 12/2021 • repaBAD GmbH • We reserve the right to make technical changes. All dimensions in cm.
Automatic lling (Vision 1000 only)
If the bathtub is empty, start automatic lling by pressing the key.
- Keep the key pressed for at least 2 seconds. Automatic lling starts and the key is illuminated.
- Press the key again to stop automatic lling.
During lling, the following appears in the display:
Automatic lling running
Level control reached
Filling switches off, display switches to show temperature
After automatic lling switches off, you can continue to ll the bathtub by pressing and holding the
key. This runs for as long as the key remains pressed.
Supplementary heating (a special accessory)
The supplementary heating (optional), if installed, is automatically switched on or off with the jet sys-
tem. The supplementary heating is not appropriate for heating cold water (e.g. from 20°C to 38°C).
The supplementary heating keeps the bath water at the target temperature set (setting range 10-
42°C). The latest set target temperature also remains set after disconnection from the electrical power
supply.
Screen display
38
The current water temperature
(with a full bathtub) is shown as standard. 38°C in this case.
...
There is not enough water in the whirlpool to use a function such as the jet
massage. Fill the whirlpool.
...
There is not enough water in the whirlpool to use a function such as fresh wa-
ter rinsing. Draining off water.
2...1 Display during automatic blow-out
--
Unavailable function selected (e.g. whirlpool lighting or supplementary heat-
ing) or keylock active
5 P Fresh water rinsing manually activated.
After emptying the bathtub, automatic blow-out and automatic fresh water rinsing (a special ac-
cessory) is activated. This programme cannot be interrupted. 2...1. is shown on the display (with a
ashing dot). Please also refer to pages 16 and 18, fresh water rinsing.
Operation

15
0022771-01_BEDWHPV.1 12/2021 • repaBAD GmbH • We reserve the right to make technical changes. All dimensions in cm.
Whirlpool programmes (Vision 1000 only)
All programmes have a running time of 15 minutes. After this, the whirlpool switches off automatically.
The remaining running time is shown on the display in minutes.
Use the key to interrupt the course of the programme at any time.
You can choose from six programmes:
P1 Vital
Medium-intensity jet massage which transitions to an air massage.
P2 Power
Powerful air and jet massage using both systems.
P3 Soft
A soft air and jet massage with increasing and decreasing intensity.
P4 Relax
Medium-intensity air massage intensity which transitions to a jet massage.
P5 Dream
Variations of a soft and medium air and jet massage, letting you dream.
P6 Sport
Very powerful air and jet massage with a revitalising effect.
Safety shutdown
All the whirlpool functions are automatically de-activated 30 minutes after the whirlpool is switched
on. The whirlpool remains in standby mode and can be reactivated at any time.
Loudspeaker safety shutdown
Whirlpool loudspeakers (a special accessory) are equipped with overload protection.
If the volume of the connected music system is set too high, overload protection is activated. This
results in the loudspeakers becoming considerably quieter or even being switched off. In this case, the
volume of the music system must be reduced immediately. After a short period the loudspeakers will
work normally again.
Operation

16 0022771-01_BEDWHPV.1 12/2021 • repaBAD GmbH • We reserve the right to make technical changes. All dimensions in cm.
07 AFTER USE
08 DISINFECTION
First steps
- Turn off all the whirlpool functions.
- Open the bathtub drain and drain the water out completely.
- Rinse out the whirlpool with hot water.
Automatic fresh water rinsing and blow-out
Irrespective of how the bathtub has been used - whether for a shower a bath or the whirlpool, the
fresh water rinsing programme (a special accessory for Vision 500, 700 and 1000) and blow-out (Vision
500 and 1000 only) is started automatically. The automatic fresh water rinsing and blow-out cannot be
interrupted.
- The key ashes during automatic blow-out for the Vision 500 and Vision 1000
control panels.
- In addition, 2...1 is shown on the Vision 1000 control panel display during blow-out.
- The key is illuminated on all three control panels (Vision 500, 700 and 1000) during the fresh water
rinse programme.
If the fresh water rinsing system is present, the jet massage is rinsed rst, followed by the air massage.
The remaining water is not automatically blown out of the air piping until this process is complete. If
automatic disinfection (special accessory) was selected while the bathtub was still full, no fresh water
rinsing takes place. Otherwise the disinfectant would be rinsed out.
Afterwards
Dry the air nozzles and bathtub using a soft, non-abrasive
and lint-free cloth. Leave the bathtub drain open.
Disinfectants cause skin irritation!
Ensure that you observe the safety instructions on the label of the disinfectant!
Keep disinfectants out of reach of children!
You must not bathe in the whirlpool whilst it is being disinfected!
Depending on the frequency of use, you should disinfect the whirlpool roughly
every 4 weeks. Only use Repabad disinfectant (art. no. 0002511). If other bath
agents are used, you run the risk of damaging the whirlpool.
Usage / Disinfection

17
0022771-01_BEDWHPV.1 12/2021 • repaBAD GmbH • We reserve the right to make technical changes. All dimensions in cm.
Manual disinfection
(Vision 700 or Vision 1000 control panel without an automatic disinfection system and Vision 500)
Make sure the bath is lled up to at least 5 cm above the jet or micro jet nozzles before disinfection!
- Add the disinfectant to the water after bathing:
Use approx. 80 - 500 ml, depending on the bathtub size (concentration 100 ml to 100 l of water).
- Let the disinfectant solution react for approx. 30 minutes.
- During this period, run all the available whirlpool systems (air and jet) 3 times for 1 to 2 minutes.
- Switch off the whirlpool, open the bathtub drain and let the disinfectant solution drain out.
Automatic blow-out starts once the bathtub has fully emptied (Vision 500 and Vision 1000).
The fan is automatically de-activated after the end of the blow out time.
After approx. 5 minutes, dry the air nozzles and bathtub with a soft, non-abrasive and lint-free cloth.
- Leave the bathtub drain open.
Automatic disinfection
(a special accessory, only for Vision 700 and Vision 1000)
Make sure the bath is lled up to at least 5 cm above the top nozzles before disinfection!
Start the disinfection process after bathing and with a full bathtub:
Using the Vision 700 control panel
- Press and hold the key until the pump switches on (approx. 5 seconds)
and the key slowly ashes.
If the key ashes quickly, the disinfectant tank must be topped up (please refer to “Servicing”
on page 20).
- Automatic disinfection is started.
- The running time for the automatic disinfection is approx. 30 minutes.
- After automatic disinfection, the key illumination goes out.
- Press the key again to stop automatic disinfection at any time.
- Once the disinfection process is complete, open the bathtub drain and let the
disinfection liquid drain out.
- After approx. 5 minutes, dry the air nozzles and bathtub with a soft, non-abrasive and lint-free cloth.
- Leave the bathtub drain open.
Usage / Disinfection

18 0022771-01_BEDWHPV.1 12/2021 • repaBAD GmbH • We reserve the right to make technical changes. All dimensions in cm.
Using the Vision 1000 control panel
- Press and hold the key (approx. 5 seconds) until d. (with ashing dot) appears on the display.
- The key is illuminated at the same time.
- After 5 seconds, the display switches to d. together with the running time of the
disinfection process.
If the key ashes quickly, the disinfectant tank must be topped up (please refer to “Servicing”
on page 20).
- Automatic disinfection is started.
- The display shows the remaining disinfection time in minutes.
- Press the key again to stop automatic disinfection
at any time.
- Once the disinfection process is complete, open the bathtub drain and let the
disinfection solution drain out.
- The remaining water is blown off automatically once the bathtub has fully emptied.
- The fan is automatically switched off after the end of the blow-out time.
- After approx. 5 minutes, dry the air nozzles and bathtub with a soft,
non-abrasive and lint-free cloth.
- Leave the bathtub drain open.
Fresh water rinsing(special accessory)
Fresh water rinsing starts automatically a few minutes after the whirlpool is completely drained and
cannot be cancelled. The jet system is rinsed rst, followed by the air system. After this, the remaining
water is blown out of the air pipes automatically (only for Vision 500 and Vision 1000).
Dry the air nozzles and bathtub with a soft, non-abrasive and lint-free cloth.
- Leave the bathtub drain open.
You can also start fresh water rinsing manually:
Using the Vision 500 control panel
- Press the key when the bathtub is empty.
- Fresh water rinsing is started. The key is illuminated until the end of the rinsing programme.
- Press the key again to interrupt fresh water rinsing at any time.
- The fresh water rinsing ends when the rinsing time has elapsed.
- The remaining water is blown off automatically once the bathtub has fully emptied.
- The fan is automatically switched off after the end of the blow-out time.
Dry the air nozzles and bathtub with a soft, non-abrasive and lint-free cloth.
- Leave the bathtub drain open.
Disinfection

19
0022771-01_BEDWHPV.1 12/2021 • repaBAD GmbH • We reserve the right to make technical changes. All dimensions in cm.
Using the Vision 700 control panel
- Press the key when the bathtub is empty.
- Fresh water rinsing is started, the key is illuminated until the end of the rinsing programme
- Press the key again to interrupt fresh water rinsing at any time.
- The fresh water rinsing ends when the rinsing time has elapsed.
- After approx. 5 minutes, dry the jet nozzles and bathtub with a soft, non-abrasive and lint-free cloth.
- Leave the bathtub drain open.
Using the Vision 1000 control panel
- Press the key when the bathtub is empty.
Fresh water rinsing is started,the key is illuminated.
- The display shows 5 P. (with ashing dot).
- Press the key again to interrupt fresh water rinsing at any time.
- The fresh water rinsing ends when the rinsing time has elapsed.
- The automatic blow-out is activated once the bathtub is drained.
This programme cannot be cancelled.
- The key ashes and the remaining time until the end of the programme
is shown on the display in seconds.
- After approx. 5 minutes, dry the air and jet nozzles and bathtub with a soft,
non-abrasive and lint-free cloth.
- Leave the bathtub drain open.
09 CARE INSTRUCTIONS
Do not use cleaning agents which contain solvents, are aggressive or abrasive! They damage
the bathtub surface. Only use soft, non-abrasive and lint-free cloths for cleaning!
The bathtub surface must be freed of abrasive dust etc. before cleaning, e.g. by rinsing it with
clear water. Chemical drain cleaners may not be used.
After bathing, clean the bathtub with a household cleaning agent. Clean the acrylic parts at regular
intervals with anti-static Repabad “Special cleaner” acrylic and plexiglass cleaner (art. no. 0010276).
To deal with minor scratches, use Repabad’s “Acrylic care set” (art. no. 0007135).
Disinfection / care instructions

20 0022771-01_BEDWHPV.1 12/2021 • repaBAD GmbH • We reserve the right to make technical changes. All dimensions in cm.
10 SERVICING
Topping up the disinfection tank
(only if you have the disinfection system as a special accessory)
If the key ashes quickly when the disinfection system is started (please refer to page 17),
the disinfection tank must be topped up.
Disinfectants cause skin irritation!
Ensure that you observe the safety instructions on the label of the disinfectant!
Keep disinfectants out of reach of children!
You must not bathe in the whirlpool whilst it is being disinfected!
Depending on the frequency of use, you should disinfect the whirlpool roughly
every 4 weeks. Only use Repabad disinfectant (art. no. 0002511). If other bath
agents are used, you run the risk of damaging the whirlpool.
- Unscrew the cover on the lling opening on the rim of the bathtub.
- Pour in one bottle (1 litre) of Repabad disinfectant (art. no. 0002511) using a funnel.
- Close the lling opening cover again tightly.
Cleaning the nozzles
As required, remove the lime scale deposits on the whirlpool nozzles using Repabad “Special cleaner”
(art.no. 0010276). Please refer to page 21 for instructions on how to remove and install the nozzles.
Servicing
