resideo Honeywell Home T6RWP User manual

The T6RWP smart thermostat is designed is for wall
mounted installations and works wirelessly with the
Receiver module (single or 2-channel version).
It provides automatic time and temperature control of
heating and optionally stored Hot water systems in homes
and apartments.
The T6RWP consist of a thermostat and in wall power
module, which fits in a standard wall box.
The thermostat has a high contrast PMVA display with
dynamic text line and touch screen buttons. The
thermostat has a simple programming philosophy to make
it easier to install and very user friendly.
The T6 is ideal for consumers who want to control their
comfort and hot water remotely and is based on a modern
design, which is simple to program and easy to use.
FEATURES & BENEFITS
•Attractive, ultra-modern styling makes it ideal for any location
in any type of home.
•Wall mounted thermostat to fit a new and replacement
installations were 230V is available.
•For control of central heating and optionally stored hot water
systems.
•Wi-Fi communication to connect to the Internet
- Smart Home and Apple HomeKit ready
•Honeywell Home mobile App for:
- Remote view and change of settings of heating and
hot water
- Schedule changes
- Smartphone Geolocation temperature control
•A dynamic text display on the LCD that gives enhanced
feedback to the user / installer.
•High LCD Contrast and backlighting for easier viewing in all
light conditions.
•Time out screen with selectable brightness
•Heating control:
- Factory programmed daily or 5+2 default schedule
- Schedule with up to 6 independent time and temperature
pairs to suit the comfort needs.
- “Hold until”temperature override of programmed schedule
temperature till the next switch point.
- Schedule off mode for manual operation.
- Setpoint and room temperature always displayed.
- OFF position has an integral frost protection setting at
minimum 5C so that pipes in the house will never freeze in
winter.
•Hot water control (optional):
- Factory programmed daily or 5+2 default schedule.
- Schedule with up to 3 ON periods per day to suit the
comfort needs.
- Hot water Boost function for temporary override
•Alert messages to assist in fault-finding.
•Works wirelessly with standard Receiver module and 2-
channel Receiver box.
•Requires to be bound with a Receiver box
•User menu allows extra functions to be set at the discretion of
the user:
- Language selection
- Wi-FI setup
- Optimisation
- Clock setting
- Resetting the heating program to factory default
- Brightness
- Temperature offset
- Lock function
•Advanced menu (Installer Set-Up) allows extra functions to be
set at the discretion of the installer to match the consumer’s
applications and needs:
- Language selection
- System type
- 5+2 or daily schedule option
- Upper / Lower Set point Limit Adjust
- Minimum ON time
- Cycle rate
- Factory Reset
- Binding (wireless version)

Reference to the icons:
Schedule period
2

T6RWP Thermostat
Control form
Adaptive Fuzzy Logic
Room
Temperature
display range
From 0 oC to 50 oC
Dimensions
(w x h x d)
T6RWP (wireless) 103 x 103 x 68 mm
Time display
24 hour or 12 hour AM/PM format
Time keeping
accuracy
Synchronized with Internet when
connected or typically better than 10
minutes per year
Program
Heating
5+2 or daily schedule with 6 daily time
and temperature level changes
Program Hot
water
5+2 or daily schedule with 3 ON periods
per day
Time setting
resolution
Program - 10 minute steps
Sensing
element
100K (@ 25 oC) NTC thermistor
Temperature
setting range
Program : 5 to 37oC in 0.5 oC steps
OFF : 5 oC
Power
5VDC
ACC900 In-wall power module
Power
230VAC
Output
5VDC
Max. 650mA
Wiring (230V)
Terminal block capable of accepting
wires up to 1.5 mm2
Wiring (5VDC)
10 cm cable with 2 wires.
Dimensions
49 x 52 x 27 mm (w x h x d)
IP class
30
RF communication
RF operation
band
ISM (868.0-868.6) MHz, 1% duty cycle
Max. power
25mW

Protocol
Encrypted
Comm. Range
30 m in a residential building
environment
Comm.
technology
short, high rate transmissions to
minimise air time and avoid collisions
Receiver class
R.E.D.
RX Cat 2 (ETSI EN300 220-1 version
1.3.1)
RF binding
method
Factory pre-bound

Wi-Fi
IEEE 802.11b/g/n –2.4GHz
Max. power
100mW
Environmental and standards
Operating
temperature range
0 to 40oC
Shipping and storage
temperature
-20 to 55oC
Humidity range
10 to 90% rh, non-condensing

Receiver Category 2
868.3MHz
Max RF Power
25 mW
Operating frequency
868–868.6MHz


Wi-Fi
2.4GHz
Max Power
100mW
Operating frequency
2.4–2.458GHz

ErP
Class V (+3%), (EU) 811/2013
Hereby, Pittway Sarl declares that that the radio
equipment type T6H700RW is in compliance with
Directive 2014/53/EU.
The full text of the EU declaration of conformity is
available at the following internet address:
https://hwllhome.co/DoC
3

To enter the Advanced menu (installer set-up):
Press the menu key for 5 seconds.
Menu item
Default
Options
Language
English
English, Francais, Espanol, Deutsch, Nederlands, Italiano
System type
Heat + H/W
Heat only, Heat + H/W
OpenTherm
-
OpenTherm boiler data when a vailable
Cycle rate
6
3,6,9 or 12
Min on time
1 minute
1, 2, 3, 4 or 5 minutes
Heat range
Min = 5.0
Max = 37.0
Min: 5.0°C to 21.0 °C, Max:21.0°C to 37.0 °C
Schedule options
Daily
1 = daily schedule, 2 = 5+2 days schedule
Optimisation
Opt.start on
Opt.stop off
Opt start: 0 = off, 1 = on, 2 = Delayed start
Opt stop: 0 = off, 1 = on
Clock
Format: 24h
Time: --:--
Date:
01/09/2016
Clock format: 1 = 12h, 2 = 24h
Setup time and date
Low Load Control
ON
0= Off, 1 = On
Temperature offset
0.0
-1.5°C to 1.5 °C
Bind
-
Bind, check RF and clear bind.
Adv Reset
-
Factory, schedule, Wi-Fi and Homekit reset
Failsafe
OFF
0= Off, 1 = On
Specific Applications
Setting
What do you need to change?
Cycle/
Hour
Minimum ON time
(in minutes)
Note :
a. To change Cycle/Hour,
b. To change Minimum ON Time,
Heating
Gas Boilers
(<30KW)
6
1
No action required
Oil Boiler
3
4
1. Set Minimum ON Time to 4 minutes.
2. Set Cycle/Hour to 3.
Thermal Actuator
12
1
Set Cycle/Hour to 12.
Zone valve
6
1
No action required.
Special Features
Description
System Type
When bound to a 2-channel receiver box the system type can be set: Heating only, Heating
+ Hot Water
OpenTherm
If the Receiver box is connected to an OpenTherm appliance various appliance specific data
can be viewed. The data displayed is depending on what the appliance is providing.
Heat Range
The normal lower temperature limit of 5 oC can be increased up to 21 oC to protect the
inhabitants from cold conditions. This is a useful feature aimed at supporting the elderly,
children and disabled inhabitants.
The normal upper temperature limit of 35 oC can be reduced down to 21 oC to save energy.
This feature is useful for leased homes and apartments.
Schedule options
The thermostat has 2 default schedules: daily (every day) and 5+2 (week + weekend days)
4

Special Features
Description
Optimisation (optimal
start, optimal stop and
delayed start)
Optimal Start: learns how long it takes your system to reach the programmed temperature.
It turns on the heating system earlier to make sure it’s comfortable at the scheduled time.
Optimal Stop: Saves energy and money by switching off a little bit earlier than the normal
programmed time. If the home is up to temperature, it will not notice the effect on the
temperature, but will show a difference in the fuel bill.
Delayed start: Saves energy by slightly delaying the start of heating depending on the
difference between the scheduled temperature and the actual room temperature
Clock setting
Change display format (default 24hr) and adjust time and date.
When connected to Internet time and date will be synchronized
Low Load Control
If the Receiver box is connected to an OpenTherm appliance this setting is used in the
demand control. When an appliance is no longer able to modulate lower the control
switches from modulating control to low/off control.
Temperature Offset
If the Thermostat is located in a hot/cold location and cannot be moved because of wiring
then the measured/ displayed temperature can be adjusted by +/- 1,5 oC. This feature is
useful if the homeowner wants the reading to match another appliance temperature
display.
Binding
Menu to bind the Thermostat and the Receiver box, test the RF signal strength of the radio
communication and to clear an existing binding.
Reset
Menu to reset the thermostat back to factory default settings, reset the schedule to default
settings, reset the Wi-Fi and Homekit settings.
Failsafe
When the radio communication between the Thermostat and Receiver box is lost for longer
than 1 hour the Receiver box will start to cycle the demand 20% on / 80% off.
Advanced menu item
Default
Data / Options
OpenTherm
Submenu
(read only)
-Low Load Control
-Control Setpoint →Requested supply temperature
-Supply Water Temperature →Actual supply water temperature
-Return Water Temperature →Actual return water temperature
-Max Supply Water Temperature
-Hot water Temperature →Actual hot water temperature
-Hot Water Setpoint
-Actual Power →Actual power of appliance
-Water Pressure
Hot Water Overnight
1
0= OFF, 1 = ON
Hot Water Setpoint
60
30 tot 75 °C (appliance depending)
Max Supply Water Setpoint
90
30 tot 90 °C (appliance depending) - future
Low Load Control
1
0= OFF, 1 = ON
5

T6RWP THERMOSTAT
PACKAGING
ACC900 IN-WALL POWER MODULE
6

A. Power off
First make sure the power is
turned off!
To ensure your safety, always make sure mains power is switched OFF before accessing wiring.
Before removing the old thermostat take a picture of the old thermostat’s wiring as a reference then proceed to installation.
The T6RWP thermostat should not be placed near draughts, in direct sunlight or near heat sources. It should be at least 1.2 -
1.5 meters from the floor.
Needed during installation:
•Wall box with minimum depth of 40 mm and with 230V cabling (neutral
and line)
•An installed Receiver Box (single or 2-channel version)
C. Wall plate
Using a screwdriver open wall plate
terminal cover to connect wires.
B. Power module
Connect the 230V power wires to the
power module.
D. Wiring wall plate
E. Place thermostat
F. Power on
Turn power back on
7

After power up of the T6RWP thermostat the SETUP screen is shown and the following steps need to be done to complete
the installation.
Select language.
Set clock format, time
and date.
Once setup is completed go to the advanced menu to change application specific changes.
Start setup, press arrow
Now bind.with the
Receiver box
Press the big button on the
Receiver Box for 3 seconds
Press to bind the
thermostat to the Receiver Box
When binding is successful:
- Thermostat will show SUCCESS
- First Receiver box status LED will show green
Press to continue the set up.
When bound to a 2-channel
Receiver box, the system type
can be selected.
Press to set up system
type.
Touch to finalise setup.
( to setup using the
Honeywell Home App is
currently unsupported)
Select the system type and
press
8

The T6RWP Smart Thermostat wireless thermostat comes unbound from the factory and binding is required during
installation (see previous page).
The binding operation described below is only required if:
•The T6RWP thermostat or Receiver box is replaced.
•The T6RWP thermostat or Receiver box has incorrect or no binding data stored.
- Thermostat will indicate the Alert message: NO RECEIVER BOX BINDING
- Receiver box status LED remains green blinking (no communication from thermostat)
- Receiver box status LED does not light up (not bound).
To rebind
3. Put the Receiver box into binding mode by pressing the Heat button for 3 sec.
- The first LED will flash amber
4. Enable binding on the thermostat:
- Enter the advanced menu by pressing the button for 5 sec.
- Navigate to BINDING
- Select BIND and the signal will be sent
5. When binding is successful:
- Thermostat will show SUCCESS
- First Receiver box status LED will show green
Note: When the Receiver box has been bound before first press with a small pin
the pinhole for approximately 3 seconds to reset the binding. All LED’s will
flash amber for a moment.
When binding is NOT successful:
- Thermostat will show FAILED
- Receiver box will exit binding after 3 min.
RF communication might be too far or is blocked due to wrong location of the
Thermostat or Receiver box. Try to move closer or re-locate and re-bind again.
System type setting (optional)
After binding with a 2-channel Receiver box the System type of the thermostat can optionally to be set to enable
heating and also hot water control.
1. In the Advanced menu navigate to System Type.
- Select Heat for only heating or 2 zone control
- Select Heat + H/W for heating and hot water control
2. Exit the Advanced menu and the binding and setup is complete
9

Description
Model
EAN code
Literature
Smart Thermostat wall powered
T6H700RW5001
5025121380027
http://hwllhome.co/eut-T6
Symptom (Fault message)
Possible Cause
Remedy
The Receiver box button LED is
green but the heat or hot water
does not switch on.
Heat or hot water wiring might be
incorrect or broken
Check the Receiver box wiring
The status LED on the Receiver
box is red (Communication
loss)
The Receiver box receives no
communication from the
thermostat: RF communication
might be too far or is blocked due to
Receiver box location.
Thermostat is no longer powered.
Try to move thermostat or Receiver box closer or
re-locate.
Check the power to the thermostat
Thermostat alert messages
WIFI RADIO ERROR
The Wi-Fi radio of thermostat is
faulty.
Replace thermostat
INTERNAL MEMORY ERROR
The internal memory of thermostat
is faulty.
Replace thermostat
INDOOR TEMPERATURE SENSOR
ERROR
(wired only) The external
temperature sensor is not
connected or the wiring is faulty.
Check external sensor wiring and sensor
NO COMMUNICATION
RECEIVER BOX
The thermostat receives no
communication from the
thermostat: RF signal is blocked due
to the location of the thermostat.
Receiver box is no longer powered.
RF communication might be too far or is
blocked due to the location of the Thermostat or
Receiver box.
Check the power to the Receiver box
RF SIGNAL OFRECEIVER
BOX LOW
There is a weak radio signal from the
Receiver box
Try to move thermostat or Receiver box closer or
re-locate.
NO RECEIVER BOX
The thermostat is not bound with
the Receiver box
Bind or re-bind the Receiver box
NO INTERNET
Thermostat has no longer Internet
connection.
End user needs to check their Internet
connection via router.
NO WIFI SIGNAL
Thermostat has no longer a Wi-Fi
connection.
End user needs to check their Wi-Fi network of
router.
REGISTER ONLINE
Thermostat is connected to Internet
but not yet registered to an account.
End user needs to download the App, create an
account and register the thermostat.
WIFI NOT CONFIGURED
Thermostat is not connected to
Wi-Fi network.
End user needs to download the App, create an
account, connect and register the thermostat.
BOILER FAILURE FAULT xx
The OpenTherm boiler reported a
failure number XX.
Check the boiler
BOILER LOW WATER PRESSURE
The boiler reported low water
pressure.
Fill up the hydronic system with water.
