Resolution Opus 21 User manual

Opus 21
Compact Disc Player
Owner's Manual
resolution

From all of us at Resolution Audio, thank you for choosing the Opus 21 CD player. We went to great lengths to
design and produce a compact disc player that offers musical pleasure and superior performance.
Unpacking
After unpacking your Opus 21 CD player, inspect it for any shipping damage and contact us immediately
if any is found. Do not plug the power supply into any outlet if you find any shipping damage.
Please keep all packing materials for future transport of your player. Shipping the Opus 21 in anything
other than its original crate may result in damage that is not covered by warranty. If you require
a replacement crate or packing materials, please contact Resolution Audio.
Should you need to repack the player, be certain to place the power centre on the bottom, the player
in the middle, and the accessory box on top, with foam sheets beneath each piece.
The accessory box contains the following items:
AC power cord
Remote control
(2) AAA batteries
OpusLink interconnect cable
To install the batteries in the remote control, open the cover on the back of the remote. Insert the batteries in
the orientation shown in the compartment, and replace the cover.
Installation
Locate the Opus 21 CD player and Power Centre on your shelf.
While the cd player can be stacked directly above or below the power centre, we recommend that separate
shelves be used for optimum performance. Alternatively, the components may be placed side-by-side on a
single shelf.
Turn off any associated components prior to connecting the Opus 21.
This minimizes the chance of momentary electrical surges disturbing your system.
Connect the OpusLink interconnect to both the CD player and Power Centre.
Note that the cable can only be installed in one direction. Be sure to secure the connectors by hand-tightening
the integral screws.

With the power switch in the OFF position, attach the power cord and connect it to your outlet.
The OFF position is selected when the O symbol on the switch is depressed.
Connect the analog outputs of the Opus 21 to your preamplifier or amplifier.
This Opus 21 is designed to connect to any preamplifier or amplifier directly using RCA or XLR interconnects.
The DIN output is for connection to certain European preamplifiers only.
Turn on the main power switch.
The ON position is selected when the | symbol on the switch is depressed. The Opus 21 will take a few seconds
to initialize and read the disc if present. The Opus 21 initially sets the volume to a low level (50).
Turn on the rest of your system.
It is a good habit to turn the amplifier on last, and off first, to prevent surges and transients from reaching
your loudspeakers. While the Opus 21 does produce an audible "thump" when turned off, it will not cause
harm to your speakers even at high volume levels.
Insert a disc and press PLAY, or select the external input via the remote.
Adjust the volume. If you are using a preamplifier, we recommend setting the level at or near maximum (99).
The volume setting can also be used to match the level of the Opus 21 to other source components, in
order to minimize the difference when switching sources.
The Opus 21 is designed to remain powered continuously. In standby mode, the display is turned off and
the output is muted, but all of the circuitry remains powered. This keeps the player sounding its best.
If you do not intend to use the player for an extended period of time, the power may be removed via the
power switch in the rear. When power is reapplied, the Opus 21 will warm up and sound its best in about 1 hour.
Using the digital input
The Opus 21 provides an external digital input, which allows it to be used as an outboard d/a converter.
If you are using a DVD player, we strongly recommend connecting the digital output to the Opus 21. This
allows you to play movies and high-resolution DVD music through the Opus 21's superior circuitry. Be sure
to configure your DVD player for PCM output only, as the Opus 21 will not decode AC-3 or DTS multichannel
audio streams.

Safety Precautions
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK,
DO NOT REMOVE COVER.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
The lightning flash with an arrowhead symbol, within
an equilateral triangle, is inteneded to alert the user to
the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the product.
Check that the operating voltage of your unit
is identical to that of your local power supply.
Replace fuses only with identically rated
fuses.
To reduce risk of electrical shock, keep the
unit dry and grounded. Do not operate the
unit near water.
If the unit causes RF interference with another
product, move one unit or both until the
interference is eliminated. If the interference
cannot be sufficiently reduced, cease
operation and consult Resolution Audio.
Clean the chassis, faceplate, and controls with a soft
cloth lightly moistened with mild detergent solution. Do
not use any type of abrasive pad, scouring powder, or
solvent such as alcohol or benzine.
Do not discard the original box and packing materials.
When shipping the unit to another location or for repair
work, repack in original material.
Do not attempt to service this product. All servicing
should be referred to qualified service personnel.
Do not install the unit in a location near heat sources
such as radiators or heat ducts, or in a place subject
to mechanical vibration or shock.

Warranty
Resolution Audio warrants all products against faulty workmanship or defective materials for a period of
three (3) years from date of shipment, with the exception of transport mechanisms. Transport mechanisms
are covered for one (1) year. If a defect occurs within this period, Resolution Audio will repair, replace, or issue
a credit for the product at our discretion. Prior to return, authorization is required. All merchandise must be
returned in the original packing material with all accessories. If a product is recalled and it is not returned
within 90 days, the warranty is void. This warranty is not transferrable. Resolution Audio assumes no
responsibility for defects resulting from misuse, neglect, improper installation, unauthorized repair, alteration,
inadequate packing, or accident. No other obligations expressed or implied shall be assumed by
Resolution Audio.
Warranty Registration
SAVE YOUR SALES SLIP AND REGISTER AT WWW.RESOLUTIONAUDIO.COM
You must be able to show evidence of purchase
date to obtain warranty parts and service
Model: Opus 21 CD Player
Serial Number:
Model: Opus 21 Power Centre
Serial Number:
Purchase Date:
Purchased From:
Warranty registration of your unit ensures that you
will be contacted immediately if there should be a
safety inspection, modification, or other product
recall under applicable laws or regulations or
otherwise. If you did not purchase directly from
Resolution Audio, please visit
www.resolutionaudio.com to register your player.

Front Panel and Controls
1 2 3 4
7 8 9
65

1
STOP / DRAWER
Pressing this button once in play mode will stop playback.
In stop mode, this button opens and closes the cd drawer.
2
PLAY / PAUSE
Pressing this button initiates playback.
In play mode, this button will toggle between play and pause.
3
TRACK BACKWARD
Pressing this button successively backs up one track with each press.
Holding this button will rapidly back through tracks.
5DISPLAY
Indicates status, track, and time. Volume level is displayed in the two rightmost digits.
6INFRARED REMOTE CONTROL SENSOR
Maintain a clear path to ensure reliable remote control operation.
7STANDBY
This button toggles the player between normal operation and standby. In standby mode,
the display is turned off and the output is muted. Volume control settings are retained.
8
VOLUME DOWN
Pressing this button momentarily reduces the volume level by one step.
Holding this button will rapidly reduce the volume setting.
4
TRACK FORWARD
Pressing this button successively advances one track with each press.
Holding this button will rapidly advance through tracks.
9
VOLUME UP
Pressing this button momentarily increases the volume level by one step.
Holding this button will rapidly raise the volume setting.

Rear Panel and Connections
opus 21 cd
compact disc player
serial number:
opus 21 ps
power centre
serial number:
din
resolution audio
san francisco, california usa
CLASS 1 LASER PRODUCT
CERTIFICATION
THIS PRODUCT COMPLIES WITH DHHS
RULES 21 CFR SUBCHAPTER J
APPLICABLE AT DATE OF MANUFACTURE.
digital
input
96 kHz max
connect only
to opus 21 ps
analog
outputs
leftright
connect only
to opus 21 series
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK,
DO NOT REMOVE COVER.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
VAC 35 W
resolution audio
san francisco, california usa
50-60 Hz
1 3 4
109
5
2
6 7 8

1
Balanced Analog Output, variable - XLR connector
5.5Vrms maximum, 100 Ohm impedance
Connect to preamplifier or directly to amplifier
2
Single-ended Analog Output, variable - RCA connector
2.5Vrms maximum, 100 Ohm impedance
Connect to preamplifier or directly to amplifier
3
Single-ended Analog Output, fixed - DIN connector
2.5Vrms maximum, 100 Ohm impedance
Connect to specially equipped European preamplifier
4OpusLink connection - DB25 male
Connect only to Opus 21 Power Centre using supplied cable
5
S/PDIF Digital Input - RCA coaxial 75 Ohms
32 - 96 kHz / 16 - 24 bit
Connect to DVD player or other digital source
6Main Power Switch
When off, power is completely disconnected from the player
7
Fuse - Replace only with time-lag fuse, IEC 60127 Type 3
Rating: 100-120 VAC use 1.6 A
200-240 VAC use 800 mA
8Mains power
Connect to mains using IEC power cord
9
Voltage Indication - Be certain the Opus 21 has been configured for your
local line voltage. Attempting to operate the Opus 21 at any other voltage
may cause damage not covered by warranty.
10 OpusLink connection - DB25 female
Connect only to Opus 21 Compact Disc Player using supplied cable

Remote Control
The Opus 21 remote control contains buttons for all of the controls on the front panels, plus the following:
Display
Mute
Repeat
Scan
Input
Pressing and holding these buttons will perform a fast forward or
backward scan during playback. The program will be audible at
a reduced level in play mode, and silent in pause mode.
Pressing this button once enters disc repeat mode. A second press
enters track repeat mode. A third press, or ejecting the disc, exits
repeat mode. Repeat is indicated on the display by the following
symbols: Disc repeat
Pressing this button selects the external digital input. The display
will indicate the lock status. To return to the cd mode, either press
this button again or press play with a disc loaded.
Pressing this button engages the muting function without affecting
the transport or volume setting. A second press restores the
output to its current volume setting. When mute is on, the volume
level indication flashes.
This button controls the intensity of the display. Upon
power-up, the display begins in its brightest state. Subsequent
presses of this button cycle through four levels:
Bright, Medium, Dim, and Off
In the Off mode, pressing any key will "wake-up" the display
momentarily at medium intensity. If the disc is playing, pressing
play on the remote will wake the display without affecting playback.
0, 1, .. 9
These buttons are used to directly access a cd track. For example,
to go directly to track 25, press 2 followed by 5. For track 2, either
press 0 followed by 2, or press 2 and wait a moment.
resolution
Display
Input
Mute Volume
1 2 3
4 5 6
7 8 9
0
Track repeat

Setup Mode
The Opus 21 offers customization features accessible in the SETUP mode. For example, if the Opus 21
will always be used with a pre-amplifier, the initial volume setting can be set to 99. To access this mode,
place the Opus 21 in standby (via remote control or front panel) and then press the REPEAT button on
the remote. Successive presses of the PLAY button will display the setup options as well as displaying the
firmware revisions present in each product. The custom settings selected in setup will be remembered when
power is disconnected. To exit setup mode, press the REPEAT button. The Opus 21 will re-enter standby mode.
Specifications
Dimensions 24 x 25 x 7.5 cm / 9.5 x 9.8 x 3" W x D x H (each component)
Weight 12.3 kgs / 27 lbs. shipping
Power requirements Preconfigured at factory
100-120 / 200-240 VAC, 50-60 Hz
Power consumption 35 Watts maximum
Input (1) Digital S/DPIF input, coaxial via RCA, 75 Ohm, 96 kHz / 24-bit
Outputs (1 pair) Analog balanced via XLR, variable
(1 pair) Analog single-ended via RCA, variable
(1) Analog single-ended via DIN, fixed
Output voltage 5.0 Vrms balanced, 2.5 Vrms single-ended
Output impedance 100 Ohms
Analog attenuation 0.5 dB steps from -30 dB to full scale
1.0 dB steps from -69 dB to -31dB
Resolution Audio · [phone] Ph · [phone] Fax · www.resolutionaudio.com
