Retina RET1023 User manual

RET1023
Retina Weather Proof IR Camera
with SONY High Resolution CCD Sensor & On-Screen Adjustability
USER MANUAL
INTRODUCTION
The RET1023 IR color camera employs the latest SONY technology optical components.
This day/night, indoor/outdoor model features a water – resistant housing. It will provide
rich color, high definition pictures. Easy to install and convenient to use. It will adapt to
most CCTV systems. Please read this instruction manual carefully to ensure proper use
of the product.
IN THE BOX
(1) RET1023 Vandal Proof IR Dome Camera
(1) User Manual
PRODUCT OVERVIEW
Sensor (CCD)
SONY 1/3” High Resolution CCD Sensor
Auto Gain Control (AGC)
Built-in auto gain control (AGC) circuit. The color camera can provide high definition
picture in low light conditions.
Auto-Electronic Shutter (AES)
Built-in auto electronic shutter function. The color camera’s AES speed can reach
1/1000,000.
Gama Characteristic
Camera Gama characteristic is 0.45.
Scanning Mode
NTSC or PAL mode.
Night-time Vision
0 Lux with IR Red ON.
CONNECTIONS
To prevent fire or shock hazard, do not expose the unit to prolonged
contact with water.
This symbol is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature
accompanying the application.
This symbol is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitude a risk of electrical shock to persons.
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK DO NOT REMOVE COVER
OR BACK. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION: TO PREVENT ELECTRICAL SHOCK AND RISK OF FIRE HAZARDS, DO NOT
USE OTHER THAN SPECIFIED POWER SOURCE.
CAUTION: PLEASE NOTE THE CAMERA’S OPERATING TEMPERATURE AND ENVIRON-
MENT REQUIREMENTS. AVOID USING THE CAMERA AT EXTREME TEMPERATURES.
CAUTION: NEVER POSITION THE CAMERA TO FACE THE SUN OR A BRIGHT OBJECT.
THIS MIGHT DAMAGE THE CCD.
CAUTION: DO NOT MOUNT THE CAMERA NEAR A HEAT SOURCE.
CAUTION: USE ONLY THE RECOMMENDED POWER SUPPLY.
CAUTION: WHEN USING THE CAMERA IN LIGHTNING CONDITIONS, BE SURE TO
INSTALL A SURGE – PROTECTION DEVICE, OR DISCONNECT POWER SUPPLY PLUG
AND CABLE.
CAUTION: IN ORDER TO CAPTURE HIGH QUALITY PICTURES, THE POWER SUPPLY’S
CABLE AND VIDEO OUTPUT CABLE SHOULD NOT BE TOO LONG.
WARNINGS
CAUTION
Risk of Electrical Shock DO NOT OPEN
CAUTION
Risk of Damaging Camera
Link wire rule：
Power
Video
Moniter
DC 12V Power Supply
*sold separately
Video 12V DC
RET1023

RET1023
Retina Weather Proof IR Camera
with SONY High Resolution CCD Sensor & On-Screen Adjustability
USER MANUAL
SPECIFICATIONS
Model RET1023
Pick Up Element SONY 1/3¨ CCD
Effective Picture Elements (H*V) NTSC: 976x582 PAL: 976x484
Horizontal Resolution 700 TV Lines
S/N Ratio >65dB
Clock Frequency (MHz) NTSC: 19.0699 PAL: 18.9375
Scanning System 2:1 Interface
Minimum Illumination 0 Lux (with IR LED ON)
Synchronous System Internal, Negative sync.
Auto Electronic Shutter NTSC: 1/60~1/100,000 PAL: 1/50~1/100,000
Gama Characteristic 0.45
IR Distance 40m (with 42 Unit Infrared LED)
IR Status <10 Lux by CDS
IR Power On CDS Auto Control
Video Output 1 Vpp, 75 Ohm
Auto Gain Control Auto
Power/Current 12V DC (±10%) / 600mA
Lens 4-9mm (optional)
Water Resistance IP66
Dimensions 200(W) x 171(H) x 83(D) mm
Weight 2.86 lbs
Storage Temperature -30~+60˚C RH 95% Max
Operating Temperature -10~+50˚C RH 95% Max
ON-SCREEN SETTINGS
TROUBLESHOOTING
1. No picture after providing power.
Possible power supply voltage abnormality. Check for proper power supply voltage and
polarity. Ensure that all the connecting cables and monitors are hooked up properly.
2. Interference (hum bars) are moving through the picture.
Check the monitor and peripheral equipment used.
3. The picture background changes color continuously.
The fluorescent light’s electromagnetic field can cause color roll. This is a normal
phenomenon. Reduce the number of fluorescent lights, or increase the distance
between the camera and the fluorescent lights.
4. The picture quality is poor or “fuzzy”
This is usually due to poor quality cables or poor connections. Ensure that all the
connecting cables and monitors are hooked up properly, or switch to higher quality
connecting cables.
LIMITED WARRANTY
This warranty remains in effect for one year from the date of purchase. Except as specified be-
low, this warranty covers all defects in material and workmanship. The following are not covered:
Damaged caused by accident, misuse, abuse, product modification or neglect, damage occurring
during shipment, damage from failure to follow instructions contained in the owner’s instruction
booklet, damage resulting from the performance of repairs by someone not authorized by Retina
Security Equipment, or any claims based on misrepresentations by the seller. This warranty does
not cover incidental or consequential damages. It does not cover the cost of removing or reinstall-
ing the unit. This warranty is void if the serial number has been removed or defaced.
This warranty gives you specific legal rights. You may also have other rights which vary from
state to state. Some states do not allow the exclusion or limitations of incidental or consequential
damages or limitation on how long an implied warranty lasts so the above may not apply to you.
HOW TO OBTAIN SERVICE
Please call us at [phone] Monday – Friday 8am – 5pm. Central Standard Time.
We may direct you to an authorized dealer/technician or request that you return the prod-
uct for repair. You must present the original bill of sale to establish the date of purchase.
Please do not ship your product to us for repair without prior authorization. You are
responsible for transportation of your product and payment of any shipping charges. If
the repairs are covered under warranty, we will pay the return shipping charges.
NOTE: Do not attempt to disassemble the camera. Doing so may void your warranty.
No user-serviceable parts inside.
LENSM ANUAL/DC/VIDEO
AUTO,FLK,1/50,1/250,1/500,1/2000,1/4000,1/5000,1/10000,1/100000
0-255
OFF
BURST(OFF/ON),IR SMART(OFF/ON:IR GAIN/HEIGHT/WIDTH/LEFT/RIGHT/TOP/BOTTOM),IR LEVEL(HIGH/LOW)
OFF
LENS SHAD: OFF/ON
2DNR: OFF/ON
MIRROR: OFF/ON
CAM ID: 0-255
BAUD RATE:2400/4800/9600/19200/38400/57600
PROTOCOL:PELCO-D/PELCO-P/NEXTCHIP
DISPLAY ID: ON/OFF
ID POS
ENGLISH/CHINESE
FACTORY RESET
FONT COLOR: FONT(0-15)/ID & TITLE(0-15)
COTRAST: 0-255, SHARPNESS: 0-31, NEG. IMAGE: OFF/ON
DISPLAY: CRT(PED LEVEL:0-63/COLOR GAIN:0-255)
LCD(GAMMA:0-1/PED LEVE:0-63/COLOR:0-255)
USER(GAMMA:0-1/PED LEVEL:0-63/COLOR:0-255)
AREA SEL: AREA 1-8
AREA STATE: ON/OFF
HEIGHT/WIDTH/LEFT/RIGHT/TOP/BOTTOM/COLOR
ON/OFF
OFF/ON(LT/LB/RT/RB/F/N/T)
AREA SEL: AREA 1-4
AREA STATE: ON/OFF
HEIGHT/WIDTH/LEFT/RIGHT/TOP/BOTTOM/DEGREE/VIEW
BLC:AREA SEL/AREA STATE/GAIN/HEIGHT/LEFT/RIGHT/TOP/BOTTOM
HLC:LEVEL(0-255)/MODE(ALL DAY/NIGHT ONLY)
COVER THE LENS THEN PRESS ENTER KEY
ATW1,ATW2,AWC-SET,MANUAL:(INDOOR/OUTDOOR/MANUAL)
LOW/MIDDLE/HIGH/OFF
OFF/ON(LEVEL:0-63)
EXPOSURE
SHUTTER
BRIGHTNESS
AGC
COLOR
CAM TITLE
MOTION
OFF/ON
PRIVACY
OFF/ON
B/W
AUTO
PARK LINE
IMAGE ADJ
COMM ADJ
LANGUAGE
D-WDR
RETURN
WHITE BAL
BACK LIGHT
DPC
DAY/NIGHT
SPECIAL
RESET
EXIT
