Retro Aire R40C Instruction manual

e Right Fit for Comfort
™
ECR International Inc
2201 Dwyer Avenue
Utica, NY 13501
e-mail: [e-mail]
An ISO 9001-2008 Certified Company
P/N 240008639, Rev. B [8/16/2011]
R40C
Packaged Terminal Air Conditioner (PTAC)
Straight cooling nominal capacities
Btuh 9,000 12,000 15,000
kW (2.6) (3.5) (4.4)
Installation, Operation,
& Maintenance Manual
R40C
Replacement for:
Fedders Model CMEA
packaged terminal unit

Read This First
To the installer
Retain this manual and warranty for future reference.
Before leaving the premises, review this manual to be sure the unit
has been installed correctly and run the unit for one complete cycle
to make sure it functions properly.
To obtain technical service or warranty assistance during or aer the
installation of this unit, contact your local representative. Visit our web
site www.retroaire.com for a local representative listing. For further
assistance call 1-800-228-9364.
When calling for assistance, please have the following information ready:
Model Number___________________________________
Serial Number____________________________________
Date of installation_________________________________
NOTICE
e RetroAire™ replacement PTAC/PTHP is backed by EMI
and ECR International and is tested and rated in accordance
with:
AHRI Standards 310/380
UL-484
Due to ongoing product development, product designs and
specications may change without notice.
Please contact the factory for more information.
Contents
Read This First 2-3
To the installer . . . . . . . . . . . . . . . . . 2
Inspection . . . . . . . . . . . . . . . . . . . 3
General precautions . . . . . . . . . . . . . . . 3
General Product Information 4-6
Product description . . . . . . . . . . . . . . . 4
Standard controls and components . . . . . . . . . 4
Factory-installed options (consult the factory) . . . . . . 4
Field-installed options . . . . . . . . . . . . . . 4
R40C Chassis . . . . . . . . . . . . . . . . . 5-7
PTAC/PTHP Model Coding 8
Features 9-10
Optional wall-mounted thermostats . . . . . . . . .10
Preparing for the Installation of the PTAC/PTHP 11
Electrical power connection . . . . . . . . . . . .11
Remove the old chassis . . . . . . . . . . . . . .11
Installation Instructions — R40C 12
Sequence of Operation 13-14
Initial Power-Up or power restoration . . . . . . . .13
R_ _C / R_ _H: Cooling Operation . . . . . . . . . .13
R_ _C / R_ _H: Heating Operation . . . . . . . . . .14
R_ _H: Mechanical Heating "Heat Pump" . . . . . . .14
R_ _H: Auxiliary Heating "Electric" or "Hydronic" . . . .14
Final Inspection & Start-up 15-20
Before operating the unit . . . . . . . . . . . . .15
Setting the control board jumpers. . . . . . . . . .16
Start Up . . . . . . . . . . . . . . . . . . . . 17
Unit-mounted thermostat . . . . . . . . . . . . . 17
Remote-mounted thermostat . . . . . . . . . . .17
Straight cooling PTAC's . . . . . . . . . . . . 17-18
Heat Pump PTHP's . . . . . . . . . . . . . . 18-19
Start-up . . . . . . . . . . . . . . . . . . . .20
Maintenance & Troubleshooting 21-24
Monthly inspection and maintenance . . . . . . . .21
Seasonal start-up and maintenance . . . . . . . 21-22
Heat pump units — temporary emergency heating mode 22
Troubleshooting sensors . . . . . . . . . . . . .22
Troubleshooting . . . . . . . . . . . . . . . .23
Reseting Limit Switch . . . . . . . . . . . . . .24
Performance Data 25
Electrical Specications 26-27
Replacement Packaged Terminal Air-Conditioning / Heat Pump
• Installation, Operation, and Maintenance Manual •
The Right Fit for Comfort 2P/N 240008639, Rev. B [8/16/2011]

Read This First (continued)
General precautions
DANGER
Electrical Supply
Carefully read the rating plate located on the front panel.
e RetroAire replacement PTAC/PTHP must:
Be properly connected• to electrical supply with the
proper voltage as stated on the rating plate.
Be properly grounded• .
Use the properly-sized over-current protection•
device as stated on the rating plate. (time-delay fuse/
HACR Breaker)
Do not modify the RetroAire replacement PTAC/PTHP
Do not attempt to modify or change this unit in any way.
Tampering with the RetroAire replacement PTAC/PTHP is
dangerous and may result in serious injury or death. Tampering
voids all warranties.
Power Cord
The power cord supplied with the RetroAire replacement
PTAC/PTHP should be checked before every use. Follow the
instructions in the order listed on the device. Do not use the
product if the cord fails the test. A damaged power supply cord
must be replaced with a new cord from the manufacturer and not
repaired. e use of extension cords is prohibited.
Failure to follow these instructions can result in a re, explo-
sion or electrical shock causing property damage, personal
injury or death.
WARNING — Safety instructions
Save these instructions — this manual is intended as an
aid to qualied service personnel for proper installation,
operation, and maintenance of the RetroAire replacement
PTAC/PTHP.
Read all instructions thoroughly and carefully before at-
tempting installation or operation. Install or locate this unit
only in accordance with these instructions. Use this unit only
for its intended use as described in this manual.
Turn o the electrical supply before servicing the unit.
PTAC/PTHP chassis are heavy. To avoid injury, use assistance
when liing.
Do not use the unit if it has damaged wiring, is not working
properly, or has been damaged or dropped.
Failure to follow these instructions may result in improper installa-
tion, operation, service, or maintenance, possibly resulting in re,
electrical shock, property damage, personal injury, or death.
Recognize this symbol as an indication
of important safety information.
Inspection
Carefully check the shipment against the bill of lading.•
Make sure correct chassis has been received (• as well as any op-
tions).
Verify your equipment by using• “Model coding” on page 8.
Verify unit:
Unit size and type correct per submial sheet and job requirements?•
Voltage correct?•
Verify options (if any):
Capacity, electric heat if used?•
Hydronic coil included, if required? Piping located as required?•
All other factory installed options installed, if any?•
All eld installed options included, if any?•
Shipping damage MUST be reported to
the carrier IMMEDIATELY.
Examine the exterior.•
Remove cover and examine•
compressor and piping for signs
of damage.
Inspect each component for damage.•
Concealed damage must be reported to the carrier•
within 15 days of the receipt of the shipment.
e carrier must make proper notation on the delivery•
receipt of all damage identied and complete a carrier
inspection report.
e purchaser must notify ECR International’s Cus-•
tomer Service department of all damage and is respon-
sible for ling any necessary claims with the carrier.
Customer Service : [phone]
Replacement Packaged Terminal Air-Conditioning / Heat Pump
• Installation, Operation, and Maintenance Manual •
P/N 240008639, Rev. B [8/16/2011] 3Made in USA

General Product Information
Product description
RetroAire Replacement Packaged Terminal Air Condition/Heat
Pumps units are available in straight cooling (PTAC) or as heat pump
systems (PTHP). Both the PTAC and PTHP congurations t the
wall sleeves of the units listed on the front cover. Heat pumps (PTHP)
reduce energy costs and will operate in mechanical heat mode down
to an outdoor temperature of 40°F (4.4°C), Below 40°F (4.4°C)
heating is accomplished by an auxillary heat option.
e Retroaire PTAC/PTHP units:
Use R-410A refrigerant. is refrigerant is not aected by a phase out•
schedule.
Include high-eciency rotary compressors, protected by a 5-year war-•
ranty.
Include an enhanced, high-eciency heat exchangers.•
Oer two fan speeds.•
Incorporate positive condensate re-evaporation to improve eciency.•
Have an optional motorized fresh-air feature with a positive pressure•
seal.
RetroAire PTAC/PTHP ratings meet or exceed ASHE 90.1 Stan-
dards for energy eciency:
PTAC/PTHP units are available in nominal sizes of 9,000 Btuh, (2.6kW)•
12,000 Btuh (3.5kW) or 15,000 Btuh (4.4kW).
PTAC units (straight cooling only) are also available at 18,000 Btuh•
(5.3kW).
Energy Eciency Rating (EER) as high as 10.•
Coefficient of performance (COP) ratings as high as 2.90 for heat•
pumps.
Standard controls and components
Construction
20-gauge galvanized steel construction of chassis.•
Condenser bae options to accommodate extended wall sleeve applica-•
tions. (Consult the factory for special order items).
Powder-coated condenser and evaporator drain pan.•
Foam strip seal for supply air duct.•
Weather strip insulation.•
Air systems
Motors are thermally-protected PSC type.•
Air-stream surfaces are insulated with ¹∕₄" ber-glass or ¹∕₈" (3.2 mm)•
Volara™.
e indoor fan is a foward-curved type, directly mounted to the motor•
sha.
Unit mount controls include a eld selection switch to control indoor fan by•
either cycling with compressor operation or continuously with the unit.
Condensate removal
e outdoor fan incorporates condensate slinger ring — Condensate•
is thrown onto the coil, where it evaporates, improving system perfor-
mance.
ermostatic drain pan valve for condensate elimination when outdoor•
temperature drops below 60°F (15°C) (heat pump units only).
Controls
Unit-mounted operating controls include thermostat, fan speed control,•
heat/cool switch, fan cycle switch, fresh air switch (if equipped)
Ability to utilize 1-stage or 2-stage thermostat. 2 stage thermostat is capable•
of activating emergency heat if an auxiliary heat source is available.
Low ambient protection — see "Microprocessor control board" for•
details.
Ability to control a normally-open or normally-closed motor valve switch•
(on hydronic heat units only). Valve controls must be ordered for 24V
or line voltage.
All hydronic heat units include molex plugs for connection of hydronic•
valve motor.
Remote mount controls include fan speed control and fresh air switch (if•
equipped)
All units are equipped with manual reset high pressure switch which•
prevents abnormal high pressure operation, increasing compressor reli-
ability.
Microprocessor control board
e universal control board is used in straight cooling, electric resistance•
heat, hydronic heat, or cooling/heat pump applications.
Random start timer prevents multiple units from simultaneous startups•
aer power interruption or on initial power-up.
Fan purge — fan remains on for 60 seconds aer heat/cool is satised.•
Anti-short-cycle compressor protection prevents the compressor from•
rapid cycling, increases compressor reliability.
Freeze-protection prevents evaporator coil freeze up, improving compres-•
sor reliability.
Low ambient lockout prevents compressor operation in outdoor tem-•
peratures less than 40°F (4.4°C). (On PTHP units supplied with unit-
mounted control, the control causes automatic changeover to auxiliary
heat, if installed.)
Test operation — all timers are temporarily suppressed to allow ease of•
testing or troubleshooting.
Control board LED provides self-diagnostic troubleshooting codes, see•
"Sequence of operation."
Factory-installed options (consult the factory)
265/277V(12 and 15 only)•
115V (09 &12 Models Only)•
Corrosion-resistant coil option — used for seacoast and harsh-envi-•
ronment usage; coated aluminum n/copper tube condenser coil.
Motorized fresh-air damper•
Supplemental electric heat — see heat options on• “Model coding” on
page 8.
Hydronic heat controls•
Front air intake•
Field-installed accessories
Hydronic heat — the coil assembly is shipped loose for eld installation.•
Remote wall thermostat — digital 1-stage or 2-stage available.•
Wall sleeves, louvers, and cabinets•
Aquastat - delays fan start-up until coil reaches 100°F (38°C) to virtually•
eliminate "cold" blow condition.
Hydronic control valve , Water 2 way & 3 way•
Hydronic control valve, Steam 2 way•
Hydronic Isolation valve, 1/2 in Sweat Connection.•
The R41 does not have a standard ECR PTAC control board, Please use this section as a reference only.
Replacement Packaged Terminal Air-Conditioning / Heat Pump
• Installation, Operation, and Maintenance Manual •
The Right Fit for Comfort 4P/N 240008639, Rev. B [8/16/2011]

General Product Information (continued)
High Pressure
Switch (HPS)
reset
Optional
Knockouts
5 - POS
Terminal
Block
Optional
Knockouts
Thermostat
System
Switch
(SS)
Fan
Speed
Switch
(FSS)
Remote Mount
Unit Mount
R40C ChassisFigure 1
Replacement Packaged Terminal Air-Conditioning / Heat Pump
• Installation, Operation, and Maintenance Manual •
P/N 240008639, Rev. B [8/16/2011] 5Made in USA

R40C Chassis Electrical BoxFigure 2
General Product Information (continued)
Open/Close
Remove Screws
to Open Door
Rating
Plate
Electrical
Diagram
Replacement Packaged Terminal Air-Conditioning / Heat Pump
• Installation, Operation, and Maintenance Manual •
The Right Fit for Comfort 6P/N 240008639, Rev. B [8/16/2011]

General Product Information (continued)
R40C Dimensioned Front ViewFigure 3
R40C Dimensioned Rear ViewFigure 4
Replacement Packaged Terminal Air-Conditioning / Heat Pump
• Installation, Operation, and Maintenance Manual •
P/N 240008639, Rev. B [8/16/2011] 7Made in USA

PTAC/PTHP Model Coding
Product Series
[R_ _C - Stright Cool Unit -
40 ]
Design Revision
[A= revision level ]
Open Options
[A= standard ]
Open Options
[A= standard ]
[C= coated coil ]
Compressor Codes
[A= TECH ]
[L= LG ]
[T= TOSHIBA ]*
Standard/Special
[0= standard ]
[A-Z = special option ]
Air Options
[A= no fresh air damper ]
[B= with fresh air damper ]
[C= front air intake, no fresh air damper ]
[D= front air intake, with fresh air damper ]
Heat Options (230 Volts):
[0= no electric heat ]
[2 = 2 KW electric heat ]
[3 = 3 KW electric heat ]
[4 = 4 KW electric heat ]
[5 = 5 KW electric heat ]
Control Options
[ 0= (UM) unit-mount with elec. heat or no elec. heat ]
[1 = (RMT) remote tstat with elec. heat or no elec. heat ]
[2 = (UM) unit-mount hyd. heat N/O or N/C valve (line volt.) ]
[3 = (RMT) remote tstat hyd. heat N/O or N/C valve (line volt.) ]
[4 = (UM) unit-mount hyd. heat N/O or N/C valve (24 volt.) ]
[5 = (RMT) remote tstat hyd. heat N/O or N/C valve (24 volt.) ]
Voltage
[ A= 115 V / 1 / 60 ] (Models 9 & 12 BTU only)
[ D= 208/230 V / 1 / 60 ]
Chassis coding
[verify with rating plate]
Position number: 1 2 3 54 6 7 8 9 10 11 12 13 14 15
R
Cooling Capacity
[09 = 9,000 Btuh ]
[12 = 12,000 Btuh]
[15 = 15,000 Btuh]
Model codingFigure 5
Remote thermostat Sea Coast Coated Coils (Factory Installed, consult factory)
Hydronic Heat
Wall Sleeves. Louvers, & Cabinet (Consult Factory)
Field Installed Accessories [items to be selected during the ordering process]
Chassis Type
[ C= straight cooling ]
*Toshiba compressors subject to factory availability
Replacement Packaged Terminal Air-Conditioning / Heat Pump
• Installation, Operation, and Maintenance Manual •
The Right Fit for Comfort 8P/N 240008639, Rev. B [8/16/2011]

Features
Indoor coil freeze protection (standard)
is feature will prevent the indoor coil from freeze up in the cooling
mode.
Indoor coil freeze up can occur due to a dirty air lter, restricted•
or poor air ow, low refrigerant charge or low room or outdoor
temperatures.
is in turn can cause compressor damage.•
Should a freezecondition bedetected,thecompressorandoutdoor•
fan will be switched o for a minimum of three minutes until the
freeze condition is satised.
During this time the indoor fan will continue to run to aid in the•
defrost process.
Condensate removal (standard)
e RetroAire replacement unit (cooling operation) is designed to
eliminate condensate by slinging it onto the outdoor coil.
Condensate drains through the bulkhead to the area near the•
outdoor fan.
As part of its normal operation, the unit will produce condensate•
and collect it in the base pan of the unit. ere it is picked up by
the outdoor fan slinger ring and deposited onto the condenser coil.
During the cooling season, this improves the unit’s eciency by
maintaining reduced refrigeration system pressures.
Base pan has overow notches, if too much condensate is produced•
notches allow condensate to ow out of the basepan and into the
wallsleeve out of the building.
Thermostatic drain pan valve (standard on heat pump units)
On heat pump models (PTHP), condensate can accumulate in the
outdoor drain pan during the heat pump cycle.
PTHP units include a thermostatic drain valve that opens when•
outdoor temperatures fall below 60°F (15°C).
When the drain valve opens, condensate ows from the drain pan•
onto the boom of the wall sleeve, where it drains to the outside.
is keeps the base pan free of condensate water, which could•
otherwise freeze during colder outdoor temperatures.
Random start feature (standard)
e random start feature is initiated on initial power-up or aer a
power interruption.
e controller adds a random time delay (from 5–120 seconds) on•
start-up, preventing the compressor from starting.
is staggers the starting of multiple units in a single facility,•
preventing a large surge that might occur if all units started at the
same time.
Anti-short cycle timer (standard)
e microprocessor control uses this timing to prevent short-cycling
of the compressor.
When the compressor cycles o on a heating or cooling call, the•
controller starts a 180-second timer.
e compressor will not be allowed to start until this time has•
elapsed.
On initial power-up or aer a power failure, this timing occurs aer•
the random start timing.
Power cord with integral safety protection
(standard)
All PTAC/PTHP units rated 250v or less are equipped with a
power cord with integral safety protection as standard.
Providing personal shock protection as well as arcing and re•
prevention, the device is designed to sense any damage in the line
cord and disconnect power before a re can occur.
Tested in accordance with Underwriters Laboratories, the cord set•
also oers a unique “passive” operation, meaning the unit does not
require reseing if main power is interrupted.
Heat pump
Heat pump units are “Limited Range” and should be equipped with
back-up electric resistance or hydronic heat. Limited Range heat
pumps are designed to operate when outdoor temperatures are
between 75°F(24°C) and 40°F(4.4°C) and with a maximum indoor
temperature of 80°F(26.6°C). e unit is equipped with a reversing
valve that is energized for cooling and de-energized in heating mode.
Electric heating or hydronic heat will operate using the onboard con-
trol logic below the operating conditions of the heat pump.
Hydronic heating (optional)
An optional hydronic heat package may be selected in lieu of electric
heat. Heating operation is essentially the same as that of units with
electric heat.
Aquastat connection (optional)
All replacement PTAC/PTHP's with hydronic heat are supplied with
a standard line volt Aquastat connection. e eld installed Aquastat
delays the fan operation until the hydronic coil reaches a temperature
of 100°F (38°C).
Replacement Packaged Terminal Air-Conditioning / Heat Pump
• Installation, Operation, and Maintenance Manual •
P/N 240008639, Rev. B [8/16/2011] 9Made in USA

Motorized fresh air damper (optional)
e optional motorized fresh air damper allows fresh air into the space
to be conditioned. When the Fresh Air switch is in the "YES" posi-
tion the damper door is open and allows fresh air into the space. is
feature is only available when the indoor fan is on. When the damper
door switch is in the "NO" position, the damper door is closed and
does not allow air in the space.
Optional wall-mounted thermostats
Thermostats available from EMI
EMI oers a thermostat that is compatible with your PTAC/PTHP
unit.
Select EMI partnumber 240008208fromthelatestRetroAireprice•
list for this option. is is a single stage, cool/heat, thermostat
that can be used in all RetroAire cooling, heating or heat pump
applications.
The thermostat has an adjustable setpoint range of between•
45°F(7°C) and 90°F(32°C).
For heat pumps another option is EMI part number 240008209.•
is is a 2 stage heat/cool thermostat which allows for emergency
heat.
Selecting a thermostat (by others)
When selecting a thermostat other than one oered by EMI, choose
a single stage heat/cool, 24v thermostat.
Straight cooling with electric heat or hydronic heat (R10C
— PTAC's)
Select a thermostat that is compatible with a cooling/electric heat
system.
e thermostat should have “R”, “Y”, “W”, "C" and “G” terminals.
Heat pump with electric heat (R__H - PTHPs)
Select a thermostat that is compatible with a cooling/single-stage
heat/heat pump system.
e thermostat should have "R", "Y", "O" and "G" terminals. RetroAire-
units are single stage heating only.
e eleactric heat and heat pump will not operate simultaneously.
Features
Replacement Packaged Terminal Air-Conditioning / Heat Pump
• Installation, Operation, and Maintenance Manual •
The Right Fit for Comfort 10 P/N 240008639, Rev. B [8/16/2011]

Preparing for the Installation of the PTAC/PTHP
WARNING
Moving parts can cause personal injury. Avoid contact with
moving parts when testing or servicing the unit.
Verify existing wall sleeve/enclosure:
RetroAire replacement PTAC/PTHP's are to be used with
metal wall sleeves.
e existing front panels must be secured by screws that prevent
contact with all parts.
Minor dimensions of openings must not exceed ½ inch
(12.5mm).
eindoor airdischargegrill must havedimensionsnotlessthan
26” x 4”. e grill must separate the top surface of the chassis
from the top surface of the discharge grill by a minimum of 1
in (25.4mm).
For all models, the outdoor openings must prevent contact
of all moving parts by means of louvers or grills, with minor
dimension not exceeding 1 in (25.4mm).
Electrical supply
Each unit must have a separate branch circuit protected by a fuse
or breaker. Refer to the unit rating plate for the proper wire and
breaker or fuse size. Use of extension cords is prohibited.
DO NOT connect the RetroAire unit to a circuit with an
incorrectly-sized overcurrent-protection device.
All cord-connected 265-volt units must be plugged into recep-
tacles within the unit subbase or chassis.
Electrical shock hazard — Before opening the existing
unit:
Open the power supply disconnect switch. Secure it in an open
position during installation. Aach a sign stating, " DO NOT
TURN ON. "
On a plug and receptacle connection, unplug the existing unit at
the wall outlet. DO NOT plug in the new unit until installation is
complete and the start-up checklist has been completed.
Failure to comply with the above could result in severe personal
injury, death or substantial property damage.
NOTICE
All wiring should be in accordance with both the National
Electric Code (NEC) and the local building codes.
UNITS RATED 208/230V — the RetroAire unit is wired for
230v primary voltage from the factory. e transformer must
be rewired by the installer if the jobsite voltage is 208v. Change
the transformer tap from orange to red. See the wiring diagram
for details.
Electrical power connection
Check the RetroAire unit rating plate for circuit ampacity and1.
required breaker or fuse size.
Verify that the existing breaker or fuse is the correct size.2.
Replace the breaker or fuse if incorrectly-sized.a.
Breakers must be type HACR only.b.
Cord-connected units — verify that the wall outlet is the correct3.
rating. e outlet's blade conguration must match that of the
cord supplied with the RetroAire unit.
Hard-wired units — verify that the power wiring is correctly sized.4.
Inspect the existing wiring for any deciencies, such as cuts or
frayed wires. Replace such wiring if found.
Remove the old chassis
Disconnect power or unplug cord before proceeding.1.
See WARNING at le.
Remove the front of the existing room enclosure to expose the2.
old chassis.
Loosen any tie-down bolts or screws and remove the old chassis.3.
NOTICE
Dispose of the old chassis following existing state and federal
regulations.
Inspect the wall sleeve/cabinet for any rust, holes, or damage.4.
Clean the wall sleeve of any dirt.a.
Repair any damage.b.
Ensure proper drainage of condensate or rainwater to exteriorc.
of building.
Remove or repair the old weather seals and make note of the5.
location for the installation of any new seals.
Check the wall sleeve/cabinet to ensure all drain holes are open6.
and that:
e wall sleeve/enclosure is level le to righta.
e back is pitched to the outside by ½in (12.5mm) maxi-b.
mum.
Before installing the new chassis, inspect the outdoor louver for a7.
minimum free area of 70% and remove any obstructions. Obstruc-
tions will restrict air ow over the condenser coil and may cause
serious damage to the chassis. It will also void the warranty.
See the instructions for the specic RetroAire unit on the fol-8.
lowing pages.
DO NOT9. connect power to the unit or plug in the cord until all
instructions in this manual have been followed.
Replacement Packaged Terminal Air-Conditioning / Heat Pump
• Installation, Operation, and Maintenance Manual •
P/N 240008639, Rev. B [8/16/2011] 11 Made in USA

Installation Instructions — R40C
Installation
Verify the existing wall thickness1. — e distance from the
condenser coil to the outdoor louver varies with sleeve depth,
unit(s) ship standard with 2 "(51mm) baes. In addition, EMI
stocks an optional condenser-side air bae kit for chassis instal-
lation in deeper-than-standard wall sleeves. For fast, trouble-free
installation, know your wall sleeve depth when ordering.
Install the baes2. — Slide the unit back out of the wall sleeve.
Remove both sets of baes from the kit bag supplied with unit.
Install only one set of le and right side baes on the condenser
coil by completing steps below :
Choose the proper ing baes for your application by verifying•
selected baes come in contact with the outdoor louver.
Make sure the baes are directed inward toward the center of•
coil.
Secure baes tightly into the existing holes of the condenser coil•
using the screws provided.
NOTICE
e correct condenser air baes must be installed or performances
may be impaired.
Baes OptionsFigure 6
Standard Bae
Standard Bae
Standard Bae
Standard Bae
Replacement Packaged Terminal Air-Conditioning / Heat Pump
• Installation, Operation, and Maintenance Manual •
The Right Fit for Comfort 12 P/N 240008639, Rev. B [8/16/2011]

Sequence of Operation
The following Sequence of Operation
applies to PTAC/PTHP units.
e R_ _C units are straight cool, single stage air conditioners avail-
able with electric or hydronic heat.
e R_ _H units are limited range, single stage heat pump. Mechani-
cal compression heating (heat pump mode) is locked out at outdoor
temperatures of approximately 35 ºF (1.7 ºC) and below. Below
these ambient temperatures, the auxiliary electric or hydronic heat
will be used.
General
e unit is controlled by a microprocessor. ermostat and control
connections are made to the control board.
- Control BoardFigure 7
Two conguration jumpers are located on the board, see Figure
8. e Heat Pump Conguration Jumper is a 3 pin jumper.
Straight• Cool units R_ _C, the jumper should be located on the
outside two pins.
Heat• Pump units R_ _H, the jumper should be located on the
inside two pins.
A second conguration jumper “TEST” allows for the control’s inter-
nal timers to be by-passed for test purposes. Placing the jumper on
the two pins enables the test mode.
A status LED (Light Emiing Diode), LED1 is located on the center
of the board. A series of blinks communicates the status of the board.
Betweentheblink sequenceis aseparationof approximately2 seconds.
e Status Code is listed below.
Trouble
Code
(Blinks)
Status
1Normal Operation
2Anti-Short Cycle Timer Active
3Outdoor Coil Freeze Protection
4Indoor Coil Freeze Protection
5Simultaneous “Y” and “W” Call
Initial Power-Up or Power Restoration
When power is applied to the unit, either for the rst time or aer a
power failure, the board will initialize itself. During the initialization,
LED1 will be lit continuously for approximately 5 seconds. Following
the initialization, a random start timer is initiated. is timer adds
a randomly selected 5-120 seconds to the start-up sequence, reduc-
ing the possibility of multiple units starting at the same time. Once
the random start timer has expired, a 180 second Anti-Short Cycle
Timer is initiated and the Processor Board Trouble Code LED is set
to blink a 2 ash code. is timer prevents the compressor from rapid
cycling. AertheAnti-Short CycleTimerexpires,theProcessorBoard
Trouble Code LED is set to blink a 1 blink Trouble Code, indicating
normal operation.
R_ _C / R_ _H; Cooling Operation
( For unit mount controls)
With the System Switch [SS] set to “Cool”, and the Fan Cycle Switch
[FCS] set to “On” (Continuous Fan Operation), the indoor fan mo-
tor will start. If the Fan Cycle Switch [FCS] is set to “O ” (Cycling
Fan Operation), the indoor fan motor will start with a call for cool-
ing from the internal thermostat [T’stat]. If the unit is equipped
with a Motorized Fresh Air Damper, and is active with the Fresh
Air Switch [FAS], the damper will open with a call for the indoor
fan. If the room temperature is below the thermostat seing the fan
operation will continue as noted above. If the room temperature is
above the thermostat seing, the reversing valve will be energized,
the compressor and outdoor fan will start provided the Anti-Short
Cycle Timer has timed out from the initial power-up, power restora-
tion or a previous compressor on cycle. Operation will continue
until the room temperature satises the thermostat. Once the room
temperature falls below the set point by 3 ºF (2 ºC), the compressor,
outdoor fan motor and reversing valve will de-energize. If the FCS
is set to “O”, the indoor fan will continue to operate for 60 seconds
aer the compressor stops. If the FCS is set to “On”, the indoor fan
will continue to operate. As soon as the compressor is de-energized,
the Anti-Short Cycle Timer will be initialized and will prevent the
compressor from starting again for another 180 seconds. While the
Anti-Short Cycle Timer is active, the Processor Board Trouble Code
LED is set to blink a 2 ash code. Aer the Anti-Short Cycle Timer
expires, the Processor Board Trouble Code LED is set to blink a 1
blink Trouble Code, indicating normal operation.
LED
Indicator
Light
TEST
Cong.
Jumper
Heat
Pump
Cong.
Jumper
Replacement Packaged Terminal Air-Conditioning / Heat Pump
• Installation, Operation, and Maintenance Manual •
P/N 240008639, Rev. B [8/16/2011] 13 Made in USA

Sequence of Operation (continued)
NOTE:
Remote-Mount Cooling Operation depends on the features of•
the wall-mounted thermostat. By default the fan will cycle with a
call for cooling. For thermostats with an AUTO / ON fan switch,
the fan will run continuously if this is “ON” (Continuous Fan
Operation). e fan will cycle with a call for cooling if this is set
to “AUTO” (Cycling Fan Operation).
In cooling the units will not start is the indoor air temperature is•
60ºF (15.5 ºC) or below or if the outdoor temperature is below
40ºF (4.5ºC).
R_ _C / R_ _ H; Heating Operation
With the System Switch [SS] set to “Heat”, and the Fan Cycle Switch
[FCS] set to “On” (Continuous Fan Operation), the indoor fan mo-
tor will start. If the Fan Cycle Switch [FCS] is set to “O ” (Cycling
Fan Operation), the indoor fan motor will start with a call for heating
from the internal thermostat [T’stat]. If the unit is equipped with a
Motorized Fresh Air Damper, and is active with the Fresh Air Switch
[FAS], the damper will open with a call for the indoor fan. If the
room temperature is above the thermostat seing the fan operation
will continue as noted above. If the room temperature is below the
thermostat seing, the action of the unit will depend on the outdoor
temperature and the freeze sensor status.
NOTE: Remote-Mount Heating Operation depends on the features
of the wall-mounted thermostat. By default the fan will cycle with a
call for Heating. For thermostats with an AUTO / ON fan switch,
the fan will run continuously if this is “ON” (Continuous Fan Opera-
tion). e fan will cycle with a call for heating if this is set to “AUTO”
(Cycling Fan Operation).
R_ _H; Mechanical Heating “Heat Pump"•
”If the outdoor coil temperature remains above 25 ºF (-4 ºC), the
compressor and outdoor fan will start provided the Anti-Short
Cycle Timer has timed out from the initial power-up, power
restoration or a previous compressor on cycle. Operation will
continue until the room temperature satises the thermostat.
Once the room temperature rises above the set point by 3 ºF (2
ºC), the compressor and outdoor fan motor will de-energize. If
the FCS is set to “O”, the indoor fan will continue to operate
for 60 seconds aer the compressor stops. If the FCS is set to
“On”, the indoor fan will continue to operate. As soon as the
compressor is de-energized, the Anti-Short Cycle Timer will be
initializedandwill preventthecompressorfromstarting again for
another180seconds. WhiletheAnti-ShortCycle Timerisactive,
the Processor Board Trouble Code LED is set to blink a 2 ash
code. Aer the Anti-Short Cycle Timer expires, the Processor
Board Trouble Code LED is set to ash a 1 blink Trouble Code,
indicating normal operation.
R_ _H; Auxiliary Heating “Electric” or “Hydronic”•
If the outdoor coil temperature falls to 25 ºF (-4 ºC) or below
for 180 seconds at anytime during a heating call, the compressor
and outdoor fan motor will be de-energized and auxiliary heat
will be energized. e Anti-Short Cycle Timer will be initi-
ated, prohibiting compressor operation for 180 seconds. e
Processor Board Trouble Code LED will ash a 3 blink Trouble
Code, indicating auxiliary heat operation. Heating operation
with auxiliary heat will continue until the outdoor coil sensor
reaches 50 ºF (10 ºC).
“Electric Heat”
˚With the System Switch [SS] set to “Heat”, and the Fan Cycle
Switch [FCS] set to “On” (Continuous Fan Operation), the
indoor fan motor will start. If the Fan Cycle Switch [FCS] is
set to “O” (Cycling Fan Operation), the indoor fan motor
will start with a call for heating from the internal thermostat
[T’stat]. If the unit is equipped with a Motorized Fresh Air
Damper, and is activated with the Fresh Air Switch [FAS], the
damper will open with a call for the indoor fan. If the room
temperature is above the thermostat seing the fan operation
will continue as noted above. If the room temperature is below
the thermostat seing, the electric heater is energized until the
room temperature satises the thermostat. Once the room
temperature increases above the set point by 3 ºF (2 ºC), the
electric heaters will de-energize.
“Hydronic Heat”
˚If the FCS is set to “On” (Continuous Fan Operation) and
the unit has an AquaStat, the indoor fan and fresh air motor-
ized damper operation will be controlled by the Aquastat. If
the AquaStat senses a temperature of 80 ± 5 ºF (26 ± 3 ºC)
or below, the indoor fan will shut down and the motorized
damper will close fresh air door. With a call for heat, a signal
from the processor board will activate the water or steam valve.
If the unit is equipped with a eld installed AquaStat [AS], the
indoor fan start will be delayed until the hydronic coil reaches
100 ± 5 ºF (38 ± 3 ºC). e signal to the water or steam valve
will continue until the room temperature rises above the set
point by 3 ºF (2 ºC). If the FCS is set to “O”, the indoor fan
will continue to operate for 60 seconds or until the hydronic
coil temperature as sensed by the AquaStat reaches 80 ± 5 ºF
(26 ± 3 ºC), whichever occurs rst. If the FCS is set to “On”,
the indoor fan will de-energize if the AquaStat senses a tem-
perature of 80 ± 5 ºF (26 ± 3 ºC) or below.
“Remote Wall Thermostat Controls”
˚Coolingand Heating operatesidenticaltounitmountcontrols.
See remote controls manual for control details. Remote units
do not use a system switch, or FCS.
Replacement Packaged Terminal Air-Conditioning / Heat Pump
• Installation, Operation, and Maintenance Manual •
The Right Fit for Comfort 14 P/N 240008639, Rev. B [8/16/2011]

Final Inspection & Start-up
Before operating the unit
Read and understand the contents of this manual.☐
Install the unit per the instructions outlined in this manual and☐
all applicable local and national codes.
Ensure the electrical supply matches the electrical requirements☐
of the unit, and that the unit is properly grounded.
Examine control box. Ensure all wire connections are secure,☐
and that control board jumpers are in the proper positions. See
“” on page 16.
Verify that the chassis is properly ed to the wall sleeve and☐
securely mounted to the surrounding framing.
Make sure the chassis is level:☐
Pour water into the drain pan.•
Make certain it ows through the drain hoses to the condenser•
side of the unit.
Verify that indoor blower wheels and outdoor fan blades are☐
secured to their motor shas, and rotate freely.
Ensure all sheet metal panels are in place and secure.☐
Aach the front panel to the existing cabinet enclosure.☐
Verify that nothing will interfere with the room discharge air or☐
the return air of the units. Examples:
Check for curtains or drapes that obstruct the air ow.•
See• Figure 8 and Figure 9.
Check for plush carpeting that can obstruct the return air.•
Items like these can cause serious damage to the chassis.•
CAUTION
Any obstruction of supply air, including the use of deector
baes, may cause condensate to form on the louver or cabinet
(see Figure 8).
Proper air ow diagramFigure 8
To ensure optimum performance of your PTAC/PTHP, avoid
restricting the air ow. e position of curtains or drapes over
supply air grille may cause air to recirculate without cooling
the room. e unit will short cycle and may cause premature
compressor failure (see Figure 9).
Restricted air ow diagramFigure 9
Replacement Packaged Terminal Air-Conditioning / Heat Pump
• Installation, Operation, and Maintenance Manual •
P/N 240008639, Rev. B [8/16/2011] 15 Made in USA

NOTICE
All wiring should be in accordance with both the National
Electric Code (NEC) and the local building codes.
UNITS RATED 208/230V — the RetroAire unit is wired for
230v primary voltage from the factory. e transformer must
be rewired by the installer if the jobsite voltage is 208v. Change
the transformer tap from orange to red. See the wiring diagram
for details.
Setting the control board jumpers
e control board has two sets of factory installed jumper pins on the
control board, HP jumper and TEST jumper. ese pins have
HP jumper — to select heat pump or straight cooling
ese pins determine whether the unit operates as straight cooling or
as heat pump (see Figure 10 and Figure 12).
Jumper the right pin to the center pin for heat pump operation.•
Jumper the le pin to the center pin for straight cooling operation.•
HP JumperFigure 10 (selects heat pump or straight cooling)
TEST jumper — to select normal or test mode
is jumper is for use in testing only (see Figure 11 and
Figure 12).
When the JUMPER pins are jumpered together, all timers are elimi-
nated (example — anti-short cycle, purge, etc.). is is mainly used for
production line testing. But it may be used for eld testing as well.
e units are factory set with the jumper on only one pin (normal
operation position).
WARNING
Do not leave the unit operating with the TEST jumper in the
TEST position.
TEST jumperFigure 11 (selects normal or test mode)
Circuit boardFigure 12
TEST JUMPER
HEAT PUMP
JUMPER
Final Inspection & Start-up (continued)
HP
HP
HP
Heat Pump
Mode
(jumper center
& Btm. pins)
Straight
Cool Mode
Mode
(jumper center
& top pins)
TEST
Normal operation
(pins not jumpered)
Test mode
(pins jumpered)
Replacement Packaged Terminal Air-Conditioning / Heat Pump
• Installation, Operation, and Maintenance Manual •
The Right Fit for Comfort 16 P/N 240008639, Rev. B [8/16/2011]

Typical Representation of a Unit Mount ControlFigure 13
THERMOSTAT KNOB
CAUTION
DO NOT rotate the thermostat knob back and forth from
heating to cooling. is causes the compressor to cycle on and
o rapidly and will cause damage to the compressor. Allow
the compressor to remain o for at least three minutes prior to
restarting the unit.
Remote-mounted thermostat
Use the thermostat to place the PTAC/PTHP in either the1. COOL,
HEAT, or OFF position. Test operation in all positions.
If the thermostat is ed with a2. fan switch, set as desired places the
fan in either ON, OFF,or AUTO. Test operation in all positions.
Check thermostat calibration for both heating and cooling op-3.
eration .
Straight cooling PTAC's
Cooling cycle
Place the thermostat or system switch in the1. COOL position.
Adjust the thermostat to a cooler temperature until the indoor fan2.
starts running. e compressor and outdoor fan should then turn on
and cold air will begin to ow from the unit. Let the unit continue
operating to cool the room and remove humidity.
Aer the unit starts running and the space gets cooler, adjust the3.
thermostat to a warmer temperature until the compressor cycles
o.
If a colder room temperature is desired, adjust the thermostat to a4.
cooler temperature seing, turning the compressor and both fans
back on.
If a warmer room temperature is desired, adjust the thermostat to5.
a warmer temperature seing. e compressor and outdoor fan
will stop and the indoor fan will switch o aer the sixty-second
purge time has elapsed.
Place the thermostat or system switch in the6. OFF position.
All operation should stop.
Final Inspection & Start-up (continued)
Start Up
Ensure the unit is secure and level.1.
Heat pump units only2. — Verify that the thermostatic drain
pan valve is operating correctly. e valve should be closed if the
temperature is above 60°F and open if the temperature is below
60°F.
If equipped, test the fresh air damper by seing the damper door3.
switch to the "YES" position and verify the damper opens and
allows fresh air to be moved into the space. en, set the damper
door switch to the "NO" position, and verify the ow of air into
the space has stopped. Fresh air will only be available when the
indoor fan is running.
Verify that the4. HP jumper is set correctly for the unit type —
cooling only or heat pump unit (see Figure 10, page 16).
Set the5. TEST jumper to test mode if desired. is will disable
time delays, including anti-short-cycle and purge times (see
Figure 11, page 16).
Verify that the unit is wired according to instructions in this6.
manual, including requirements on page 15.
Connect Electric power to the unit .7.
Turn on the unit to check for proper operation. Check conden-8.
sate removal by pouring water into the base pan, puing the unit
in cooling mode, and with the condenser fan running, seeing
if water is picked up by the slinger ring and thrown onto the
outdoor coil.
NOTICE
e compressor will not start until the anti-short time period
has elapsed. On power-up, there will also be delays for control
board initialization and random-start timing. See “Sequence of
Operation” on page 13.
Unit-mounted thermostat
Use the system switch to place the PTAC/PTHP in either the1.
COOL,HEAT, or OFF position (see Figure 13). Test operation
in all positions.
Use the fan speed switch places the fan in either2. LOW or HIGH speed
(see Figure 13). Test operation in both positions for heating and
cooling.
Test operation of the Fan Cycle switch (this is a toggle switch3.
on side of control box), with switch set at ON (continuous fan
operation) or AUTO (cycling with thermostat) for both heating
and cooling. Set the switch in the desired position.
Rotate the thermostat knob to the le to increase setpoint temperature,4.
or to the right to decrease (see Figure 13). Turning the unit-mount-
ed thermostat knob to the far le will produce the warmest room
temperature, while turning it all the way to the right will produce
the coolest. e seing can be adjusted for personal comfort.
Replacement Packaged Terminal Air-Conditioning / Heat Pump
• Installation, Operation, and Maintenance Manual •
P/N 240008639, Rev. B [8/16/2011] 17 Made in USA

NOTICE
e room temperature must be above 65°F (18°C) for the
compressor to operate in cooling mode on PTAC's with unit-
mounted controllers .
CAUTION
When the unit is rst powered up, high humidity conditions
can cause condensation to form on the discharge grill. Keep
doors and windows closed to reduce humidity and condensa-
tion will evaporate.
Heating cycle — electric option
Place the thermostat or system switch in the1. HEAT position.
Adjust the thermostat for a warmer temperature until the indoor2.
fan starts running and the electric heater coil starts emiing
heat.
NOTICE
e outdoor fan does not run during the heating cycle.
Aer the unit starts running and the space gets warmer, adjust3.
the thermostat to a cooler temperature until the electric heater
turns o.
If a warmer room temperature is desired, adjust the thermostat to4.
a warmer temperature seing, which will turn the electric heater
back on.
If a cooler room temperature is desired,5. adjust the thermostat
to a cooler temperature seing until the electric heater turns o.
e indoor fan will switch o aer the sixty-second purge time
has elapsed.
Place the thermostat or system switch in the6. OFF position.
All operation should stop.
NOTICE
Room temperature must be below 85°F (29.4°C) to energize
the heater on PTAC's with unit-mounted controllers.
Heating cycle — hydronic option
NOTICE
Make sure the motor valve is rated for the correct voltage.
Most RetroAire units with unit mount controls will power a
hydronic valve that is the same voltage as the unit (ex: a unit
rated208/230v willpower a 208/230v). A switchisprovidedon
the control box to change from NO to NC. Be sure to check the
wiring diagram (located on the unit) and voltage application for
the specic unit. Other valve congurations and voltage options
are available. Consult Technical Service if the unit voltage does
not match your valve application.
Place the1. thermostat or system switch in the HEAT position.
Adjust the thermostat to a warmer temperature.2.
e following should then occur:
A signal from the processor board will activate the water or•
steam valve.
e motorized valve should open and allow hot water or steam•
to run through the coil.
e indoor fans will run, blowing air through the hydronic coil•
If the unit is equipped with an Aquastat, the indoor fan and the
motorized damper operation will be delayed until the hydronic
coil reaches 100 ± 5°F (38 ± 3°C).
esignaltothewaterorsteamvalve will continue untiltheroom•
temperature rises above the setpoint by 3°F (2°C).
Aer the unit starts running and the area gets warmer, adjust the ther-3. mostat to a cooler temperature, the hydronic valve will close and indoor
fan will switch o aer the sixty-second purge time has elapsed.
If a warmer room temperature is desired,4. adjust the thermostat to
a warmer temperature seing , which will open the hydronic valve
and turn on the indoor fan.
If a cooler room temperature is desired, a5. djust the thermostat to
a cooler temperature seing . e hydronic valve will again close
and indoor fan will switch o aer the sixty-second purge time
has elapsed.
Place the thermostat or system switch in the6. OFF position.
All operation should stop.
NOTICE
Room temperature must be below 85°F (29°C) for the hydronic
heater to operate on PTAC's with unit-mounted controllers.
e hydronic valve is a 24Vac normally open valve. Should power
be interrupted, the valve will default to the open position.
Completion of testing for cooling-only PTAC's
Operation testing is now complete. If TEST jumper was set to test
mode then make sure to set it back to normal operation (see
Figure 11, page 16).
WARNING
Do not leave the unit operating with the TEST jumper in the
TEST position. Prolonged operation with the unit on test mode
will cause damage to the internal components of the unit.
Heat Pump PTHP's
NOTICE
e unit is equipped with a reversing valve that is energized for
cooling and de-energized in heating mode.
Cooling cycle — heat pump units
Place the thermostat or system switch in the1. COOL position.
Adjust the thermostat to a cooler temperature until the indoor2. fan
Final Inspection & Start-up (continued)
Replacement Packaged Terminal Air-Conditioning / Heat Pump
• Installation, Operation, and Maintenance Manual •
The Right Fit for Comfort 18 P/N 240008639, Rev. B [8/16/2011]

Final Inspection & Start-up (continued)
starts running. e compressor and outdoor fan should then turn on
and cold air will begin to ow from the unit. Let the unit continue
operating to cool the room and remove humidity.
Aer the unit starts running and the space gets cooler, adjust the3.
thermostat to a warmer temperature until the compressor cycles
o.
If a colder room temperature is desired, adjust the thermostat to a4.
cooler temperature seing, turning the compressor and both fans
back on.
If a warmer room temperature seing is desired, adjust the thermo-5.
stat to a warmer temperature. e cooling mode will cease and the
compressor and outdoor fan will stop. e indoor fan will switch
o aer the sixty-second purge time has elapsed .
Place the thermostat or system switch in the6. OFF position.
All operation should stop.
NOTICE
e room temperature must be above 65°F (29°C) for the
compressor to operate in cooling mode on PTHP's with unit-
mounted controllers .
Place system switch in the7. OFF position. All operation should stop.
Heating operation — heat pump units — outdoor
temperature above 40°F (4°C)
Place1. the thermostat or system switch in the HEAT position.
Adjust the thermostat to a warmer temperature seing2. until the
indoor fan start running. e compressor and outdoor fan should
then turn on and warm air will begin to ow from the unit.
Aer the unit starts running and the space gets warmer, adjust the3.
thermostat to a cooler temperature until the compressor cycles o.
For a warmer room temperature,4. adjust the thermostat to a warmer
temperature seing turning the indoor and outdoor fans, and
compressor back on .
If a cooler room temperature is desired,5. adjust the thermostat to
a cooler temperature seing . e heating mode will cease and the
compressor and outdoor fan will stop. e indoor fan will switch
o aer the sixty-second purge time has elapsed .
NOTICE
Room temperature must be below 85°F (29°C) for the compres-
sor to operate in heating mode on PTHP's with unit-mounted
controllers . .
Place the thermostat or system switch in the6. OFF position.
All operation should stop.
NOTICE
Heat pump units are “Limited Range” equipped with back-
up electric resistance heat. Limited Range heat pumps are
designed to operate when outdoor temperatures are between
75°F(24°C)and 40°F (4°C) and with a maximum indoor tem-
perature of 85°F (29°C) . When the outdoor temperature falls
below approximately 40°F (4°C) the unit will switch from heat
pump to electric resistance heat, or hydronic heat if optionally
added. Electric heat or hydronic heat will then remain as the
heat source until the outdoor temperatures rise above 50°F
(10°C). RetroAire heat pumps (R_ _H) are single-stage heat-
ing units. e electric heat and heat pump will NOT operate
simultaneously.
Auxiliary heating operation — heat pump units —
outdoor temperature below 40°F (4C°) — electric
option
Place1. the thermostat or system switch in the HEAT position.
Adjust the thermostat to a warmer temperature until the indoor2.
fans start running and the electric coil starts emiing heat.
Aer the unit starts running and the space gets warmer, adjust3.
the thermostat to a cooler temperature until the electric heater
turns o.
If a warmer room temperature is desired, adjust the thermostat to4.
a warmer temperature seing, which will turn the electric heater
back on.
If a cooler room temperature is desired,5. adjust the thermostat
to a cooler temperature seing until the electric heater turns o.
e indoor fan will switch o aer the sixty-second purge time
has elapsed.
Place the thermostat or system switch in the6. OFF position.
All operation should stop.
Replacement Packaged Terminal Air-Conditioning / Heat Pump
• Installation, Operation, and Maintenance Manual •
P/N 240008639, Rev. B [8/16/2011] 19 Made in USA

Final Inspection & Start-up (continued)
NOTICE
Room temperature must be below 85°F(29°C) to energize the
heater on PTHP's with unit-mounted controllers .
5 kW heat models only — in the event the limit switch opens and de-
energizes the electric heat, the limit switch will need to be manually reset.
To reset switch:
Turn power o•
Remove the control box cover.•
Locate the limit switch.•
Push in the reset buon on the face of the switch (see• Figure 14).
Auxiliary heating operation — heat pump units —
outdoor temperature below 40°F (4°C) — hydronic
option
Place1. the thermostat or system switch in the HEAT position.
Adjust the thermostat to a warmer temperature.2.
e following should then occur:
A signal from the processor board will activate the water or•
steam valve.
e motorized valve should open and allow hot water or steam•
to run through the coil.
e indoor fans will run, blowing air through the hydronic coil•
If the unit is equipped with an Aquastat, the indoor fan and the
˚motorizeddamperoperationwill bedelayeduntilthehydronic
coil reaches 100 ± 5°F (38 ± 3°C).
esignaltothewaterorsteamvalve will continue untiltheroom•
temperature rises above the setpoint by 3°F (2°C).
Aer the unit starts running and the space gets warmer, the•
hydronic valve will close and indoor fan will switch o aer the
sixty-second purge time has elapsed.
Aer the unit starts running and the space gets warmer,3. adjust the
thermostat to a cooler temperature seing, the hydronic valve will
close and indoor fan will switch o aer the sixty-second purge
time has elapsed.
If a warmer room temperature is desired,4. adjust the thermostat to
a warmer temperature seing , which will open the hydronic valve
and turn on the indoor fan.
If a cooler room temperature is desired, adjust the thermostat to5.
a cooler temperature seing. e hydronic valve will again close
and indoor fan will switch o aer the sixty-second purge time
has elapsed.
Place the thermostat or system switch in the6. OFF position.
All operation should stop.
NOTICE
Room temperature must be below 85°F (29°C) for the hydronic
heater to operate on PTHP's with unit-mounted controllers.
e hydronic valve is a 24Vac normally open valve. Should power
be lost to the unit, the valve will default to the open position.
Completion of testing for heat pumps
Operation testing is now complete. If the TEST jumper was set to
test mode then make sure to set it back to normal operation
(see Figure 11, page 16).
Replacement Packaged Terminal Air-Conditioning / Heat Pump
• Installation, Operation, and Maintenance Manual •
The Right Fit for Comfort 20 P/N 240008639, Rev. B [8/16/2011]
