RetroPie PITENDO User manual

NEED HELP WITH INSTALLATION,
MAINTENANCE, OR SERVICE?
hps://retropie.org.uk/forum
PRINTED IN USA
INSTRUCTION BOOKLET
RT(R)-PIE-USA-4.2

WARNING: PLEASE CAREFULLY READ THE CONSUMER INFORMATION AND
PRECAUTIONS BOOKLET INCLUDED WITH THIS PRODUCT BEFORE USING
YOUR RETROPIE® HARDWARE SYSTEM, ROMS, OR ACCESSORY.
TABLE OF CONTENTS
Secon 1
All Retropie products are unlicensed for sale and
should only be used at the risk of the consumer.
RETROPIE INSTRUCTION MANUAL
RETROPIE COMPONENTS
CONNECTION & INSTALLATION
Secon 2 RETROPIE OPERATION
EXITING GAMES
RETURNING TO REGULAR TV
CONFIGURING WIFI
CONFIGURING NEW CONTROLLERS
ADDING ROMS
SCRAPING ROMS

MEMO
Secon 1
RETROPIE INSTRUCTION MANUAL
Thank you for supporng the RetroPie, the Internet’s most advanced
video entertainment system, featuring old school sound and nostalgic
graphics! The RetroPie Entertainment System includes a Control Deck,
2 high-tech controllers, and an AC adapter.
NEED HELP WITH INSTALLATION
MAINTENANCE OR SERVICE?
Access the RetroPie forum
On the World Wide Web
hps://retropie.org.uk/forum
Please read the setup instrucons and the Consumer Informaon and
Precauons Booklet before aempng to connect the RetroPie Con-
trol Deck to your TV set. If aer reading all setup instrucons, you are
sll unable to hook up your system, please consult the RetroPie forum
at the url listed above.

RETROPIE COMPONENTS
Power Input
Audio Out
HDMI
CONTROL DECK
SNES CONTROLLER
AC ADAPTER
KEYBOARD & MOUSE
(oponal)
Ethernet
4x USB
MEMO

ADDING ROMS
(1) Ensure that your USB is formaed to FAT32.
(2) Create a folder called retropie on your USB drive.
(3) Plug the USB into the Control Deck and wait for it to nish
blinking.
(4) Pull the USB drive out and plug it into a computer.
(5) Add the roms to their respecve folders (in the retropie/
roms folder).
(6) Plug it back into the Control Deck.
(7) Wait for it to nish blinking.
(8) Refresh emulaonstaon by choosing quit from the start
menu and selecng Restart Emulaon Staon.
SCRAPING ROMS
(1) Press the Start buon on your controller.
(2) Choose Scraper from the menu.
(3) Select Scrape now.
(4) Choose your desired lter, systems, and conict resoluon.
(5) Select Start.
NOTE: The amount of me scraping takes will depend on choices
made and number of ROMs being scraped. An internet connecon
is required for this process.
CONNECTION & INSTALLATION
Connect the HDMI cable to the HDMI port on your Control Deck
and to the HDMI port on your TV Set.
Connect the SNES USB cable to a USB port on the Control Deck.
Connect the AC plug to the power input jack on the Control
Deck, plug the AC adapter into a standard (110/120 volt AC)
wall outlet.
Oponal:
Connect an Ethernet cable to the Ethernet port on the Control
Deck, plug the Ethernet cable into your router.
Connect a Keyboard and/or Mouse to the Control Deck.
CONFIGURING WIFI
(1) A keyboard will be needed for this operaon.
(2) Select Retropie from the console menu.
(3) Navigate to Wi using the D-Pad and select with the A
buon.
(4) Select Connect to Wi Network with the keyboard.
(5) Choose the SSID you want to connect to.
(6) Enter wi password using the keyboard and select ok.
(7) Select cancel with the keyboard to exit back to the Retropie
console menu.

RETROPIE OPERATION
Secon 2
(1) Turn your television on.
(2) Set your TV to the HDMI source.
(3) Plug in AC adapter to Control Deck and wall outlet.
Make sure the red power indicator light and the green ac-
vity light on the front of the Control Deck are on (check
the AC adaptor and plug if not).
(4) Use the D-pad on controller #1 to nd the console you
want, then press the A buon to select it .
(5) Use the D-pad on controller #1 to navigate the game list
and the A buon to select a game you want to play. Use
the B buon to return to the console list.
EXITING GAMES
(1) Save your game before exing.
(2) Press the Select buon and the Start buon simultaneously
on controller #1.
—OR—
Press the Escape key on an aached keyboard.
CONFIGURING NEW CONTROLLERS
RETURNING TO REGULAR TV
Aer you have nished playing, press the start buon on the
console or game list menu. Navigate to Quit and select Shut-
down System. Select Yes when asked if you really want to shut-
down. Wait for the system to shutdown and conrm by check-
ing to make sure the green acvity light on the front of the
Control Deck is o. Remove the AC adapter from the power in-
put on the Control Deck. Turn your TV selector to the desired
channel to view regular TV programs.
NOTE: This process is necessary to keep the operang system
from being corrupted due to sudden power loss.
(1) Insert the new controller’s USB into an empty port
on the Control Deck.
(2) Hit the Start buon on an already congured con-
troller and select Congure input in the menu.
(3) Follow the prompts on the new controller. If you do
not have a buon to correlate, hold down any
buon unl it dismisses the current prompt.
(4) Hit OK.
